[PPT] - 2018 Season 2018 Season Release Release 1 Summary I. Company PowerPoint Presentation

SLIDE 1

1

2018 2018 Season Season Release Release

SLIDE 2

I. Company Situation

 2017 season data  New Sherco factory  Racing Program

II. 2018 Product Evolutions

 Enduro  Cross Country  Trial

Summary

2

SLIDE 3

I. Company situation

3

SLIDE 4

Racing Program

 World Enduro Championship: Matthew Phillips / Lorenzo Santolino

I. Company situation

6

Sherco World Champion Enduro Gp/E2 2016

Benefit: Brand Image, Products credibility, Federate around the brand

SLIDE 5

Racing Program

 Enduro : Extreme & Indoor : Wade Young

> Winner X-Wiesel + Winner King of the Hill + Winner XL Lagares, Podium Alestrem

I. Company situation

7

Strong media coverage / Great international feedback

SLIDE 6

Racing Program

 Enduro : Extreme & Indoor : Mario Roman

> Winner Avanda Rocks, podium Alestrem

I. Company situation

8

Strong media coverage / Great international feedback

SLIDE 7

Racing Program

 Classic Enduro: Jeremy Tarroux

> Winner all classics 2017 and current leader French championship Val de Lorraine / Grappe de Cyrano / Trèfle Lozérien

I. Company situation

9

SLIDE 8

Racing Program

 Rally Raid

 Joan Pedrero  Adrien Metge  Aravind KP

I. Company situation

10

Worldwide promotion out of the pure offroad market

SLIDE 9

I. Company situation

11

Racing Program

 Trial

 Albert Cabestany  Miquel Gelabert  Alexandre Ferrer  Emma Bristow

SLIDE 10

I. Company situation

12

Racing Program

 Trial

 Albert Cabestany: The current generation

SLIDE 11

I. Company situation

13

Racing Program

 Trial

 Miquel Gelabert : The next generation

SLIDE 12

II. 2018 Enduro Evolutions

14

ENDURO

SLIDE 13

Welcome to SHERCO SE-R 125 !

100% new project to complete the range

II. 2018 Enduro Evolutions

15

125 2T

SLIDE 14

Context : The Engine to complete the range

 The 125 market is large in Europe, especially among young riders.  Motorcycle developed 100% for enduro but tested in MX and sand.  Tested in racing (French championships)  Euro 4 homologation  Attract young riders to Sherco brand

Product philosophy: making a high performance motorcycle

 Light weight and ease of handling that is a characteristic of Sherco motorcycles  Be part of the reference 125 category (in competition and leisure)

II. 2018 Enduro Evolutions

16

125 2T

SLIDE 15

ENGINE  Compact  Powerful  Cool running engine

II. 2018 Enduro Evolutions

17

125 2T

SLIDE 16

ENGINE

 Starting system: Only electric starter located under the engine (Sherco 2T experience)  More than 10,000 start-up cycles

II. 2018 Enduro Evolutions

18

125 2T

SLIDE 17

ENGINE

 Rotative drum valve that permit progressive delivery of the power  Electronic exhaust valve system: 2-piece drum including exhaust valve and boosters

 Exit exhaust slider system from 250/300 2T  Drum valve

Optimum sealing with the piston when the valve is closed
Mechanically simple
Easy to maintain and adjust
Strong and reliable
II. 2018 Enduro Evolutions

19

125 2T

SLIDE 18

20

II. 2018 Enduro Evolutions

125 2T

ENGINE

 Precise control of valve opening according to the RPM  Composed of 2 parts  Light aluminum material  Special shape to avoid sticking  Significant differentiation between Sherco and the competition

SLIDE 19

ENGINE

 2 maps (Soft/Hard) standard with switch button 3HP difference

II. 2018 Enduro Evolutions

21

125 2T

SLIDE 20

ENGINE

 Stability of combustion chamber with Water on all faces of the cylinder  Water chamber under the valve system

II. 2018 Enduro Evolutions

22

125 2T

SLIDE 21

ENGINE

 Monobloc cylinder head  Head bracket design has vertical C shape

 Reduces stresses at the frame interface

II. 2018 Enduro Evolutions

23

125 2T

SLIDE 22

ENGINE

 Keihin PWK 36 carburetor: A reference  Viton intake pipe material : ease of assembly, improved reliability

 Number of parts reduced  Carburetor fixed by only one clamp

 Vforce 4R reedcase :

 Low and midrange power gain 1 Hp  Stoppers for an optimal life.  Rubber on the reeds case to maintain sealing

II. 2018 Enduro Evolutions

24

125 2T

SLIDE 23

ENGINE

 Powerful ignition: 220W

 Great for additional light connection  Same power as 300 4T

 Double segment piston

 Increased sealing  Longevity improved

 Viton exhaust gasket

 High temperature resistant.

 Optimized water pump

 DLC treatment shaft and specific high-pressure seals  Standard turbine and gaskets  Plastic pinions glass fiber raw material PA66 for weight reduction

II. 2018 Enduro Evolutions

125 2T

SLIDE 24

ENGINE

 Crankshaft:

 Inertia studied for enduro: Provides excellent low end power with a smooth transition  Composite flywheels: PA66 glass fiber filler) secured with spacers to ensure

ptimum tightening

 FCC clutch discs: proved on our 4T models

II. 2018 Enduro Evolutions

125 2T

SLIDE 25

II. 2018 Enduro Evolutions

27

125 2T

CYCLE PART :

Sherco's experience adapted to the small engines

Specific 125 geometry

 Specification:

Common base 250 / 300cc
15mm shorter wheelbase
Steering angle reduced by 0.9 degrees

 Standardization: Whole cycle and body part common to other Sherco models. (Wheels, swingarm, plastics, brakes, handlebars, tires, air box, saddle ...) Specific shock and fork settings. WP Xplor fork used on factory models.

SLIDE 26

Other Enduro models

II. 2018 Enduro Evolutions

SLIDE 27

CYCLE PART :

 NEW WP 46 SHOCK

 Modified settings for better absorption  Bottom and compression  Eliminates link axle bending  All models except 450

29

ALL SE

II. 2018 Enduro Evolutions

SLIDE 28

CYCLE PART :

 NEW RADIATOR CAP  Easier to access and open

II. 2018 Enduro Evolutions

30

ALL SE

SLIDE 29

CYCLE PART :

 New Seat Material Luna Sella De La Valle

Improved grip in wet conditions

 Inmolded Graphic Kit for 2018

UV resistance fluorescent yellow

 PLASTICS MATERIAL

20 % more flexible
Handguards have rubber built in
Rear mudguard reinforced on rear number plate

fixation

II. 2018 Enduro Evolutions

31

ALL SE

SLIDE 30

CYCLE PART :

 Water resistance computer

 New membrane system

 Front light

 Reinforced mount  New front light bulb for resistance to shocks and vibrations  Protection rubber redesigned behind light

II. 2018 Enduro Evolutions

32

ALL SE

SLIDE 31

CYCLE PART :  Rear wheel axle

 New assembly process with Loctite and stronger tightening torque

 New gripster aluminium overmolded

 Better contact assembly

II. 2018 Enduro Evolutions

33

ALL SE

SLIDE 32

CYCLE PART :

 MODIFIED SELECTION DRUM

 New shifter fork rollers on the 250/300 2T and 450 4T  Selector drum profile modified for smoother gear changes

 Improved precision  GEAR SELECTOR SPRING  Stronger with longer service life  Tested and proven in the Dakar Rally

II. 2018 Enduro Evolutions

34

ALL SE

SLIDE 33

250 / 300 SE-R 2T 2018:

II. 2018 Enduro Evolutions

35

250 300 2T

SLIDE 34

250 / 300 SE-R 2T 2018 common evolutions

 Riders who promote this Engine design > Wade Young > Mario Roman

36

II. 2018 Enduro Evolutions

250 300 2T

SLIDE 35

250 / 300 SE-R 2T 2018 :

ENGINE :

 BENDIX TORQUE LIMITOR

 Resistance system improvement  The double pinion becomes torque limiter

II. 2018 Enduro Evolutions

37

2T 250 300 2T

SLIDE 36

250 / 300 SE-R 2T 2018:

ENGINE :

 SPROCKET DESIGN > PRIMARY TRANSMISSION DRIVE AND WATER PUMP MODIFIED  Friction reduced  Improved performance  Less noise

II. 2018 Enduro Evolutions

38

2T 250 300 2T

SLIDE 37

250 / 300 SE-R 2T 2018:

ENGINE :

 CLUTCH ASSEMBLY REINFORCED  Increased reliability  Clutch hub with different machining washer spacer location  NEW WATER PUMP SEALING  Output  Longer life  Seal ring adapted from 4T range  NEW CYLINDER GASKET  Longer life

II. 2018 Enduro Evolutions

39

2T 250 300 2T

SLIDE 38

250 / 300 SEF-R 4T 2018:

II. 2018 Enduro Evolutions

40

250 300 4T

SLIDE 39

250 / 300 SEF-R 4T 2018 common evolutions

 Riders who promote this Engine design  Matthew Phillips World Champion GP E2  Lorenzo Santolino Leader in Spanish Championship  Jeremy Tarroux Winner of all classic races this season

41

II. 2018 Enduro Evolutions

250 300 4T

SLIDE 40

250 / 300 SEF-R 4T 2018 common evolutions  New Exhaust Pipe Collector

 Better response at low RPM  The new shape provides heat protection for the riders boot  Esthetic  No heat protection plate necessary

42

II. 2018 Enduro Evolutions

250 300 4T

SLIDE 41

250 / 300 SEF-R 4T 2018 common evolutions CYCLE PARTS :

 NEW SICLENCER  More power  Weight reduction: - 300 g  Six Days design  Stronger aluminium tube  Improved impact resistance  INJECTION MAPPING CALIBRATION  Improved performance  Better throttle response

43

II. 2018 Enduro Evolutions

250 300 4T

SLIDE 42

250 / 300 SEF-R 4T 2018 common evolutions CYCLE PARTS

 ALUMINIUM T COOLING SYSTEM  Improved life in extreme conditions  Ideal during extreme riding  Maintains a more even engine temperature  FUEL PUMP EVOLUTIONS  Internal fuel circuit to avoid vapor lock effect  Pressure regulation optimized (new regulator mount)

44

II. 2018 Enduro Evolutions

250 300 4T

SLIDE 43

300 SEF-R 4T (SPECIFIC) ENGINE

 NEW PISTON

 Longer life  Compression increased  More Performance

 NEW CRANKSHAFT WITH V CONNECTING ROD PROFILE

 Adapted to new piston  The connecting rod has a viper shaped head 45

II. 2018 Enduro Evolutions

300 4T

SLIDE 44

II. 2018 Enduro Evolutions

46

450 4T

SLIDE 45

450 SEF-R 4T 2018:

CYCLE PARTS :

 NEW SILENCER

 More power  Weight reduction: - 500 g  Six days design  Aluminum  Improved impact resistance

II. 2018 Enduro Evolutions

47

450 4T

SLIDE 46

450 SEF-R 4T 2018:

ENGINE :

 OIL CIRCUIT SYSTEM MODIFIED

 Better heat control  More performance  Dakar tested

II. 2018 Enduro Evolutions

48

450 4T

SLIDE 47

450 SEF-R 4T 2018:

 CLUTCH EVOLUTIONS:

 Clutch plate oil jet mount reinforced  Neutral easier to select  Reduced slippage

 CYLINDER HEAD EVOLUTIONS:

 Redesigned distribution chain tensioner adjuster (material / geometry) Dakar type

 Plastic Bush with different material

 Valve guides and seats modified due to new technology of machining  Performance and longer life  Reinforced cylinder head fasteners

II. 2018 Enduro Evolutions

49

450 4T

SLIDE 48

Available in all engine versions:

II. 2018 Cross Country Range

50

SC

SLIDE 49

Benefits from all enduro evolutions:

 125 SC-R:

 Blue Rims  XPLOR Front fork  Aluminium silencer with carbon tip  Rear MX tire

II. 2018 Cross Country Range

51

SC

SLIDE 50

Benefits from all enduro evolutions:

 250/300 SC-R:

 Mx Fork double cartridge with spring  Fmf silencer  Rear MX tire

II. 2018 Cross Country Range

52

SC

SLIDE 51

Benefits from all enduro evolutions:

 250/300 SCF-R:

 Mx Fork double cartridge with spring  Ackrapovic full exhaust system  Rear MX tire

II. 2018 Cross Country Range

53

SC

SLIDE 52

II. 2018 Trial Evolutions

54

SLIDE 53

ST 125 / 250 / 300 Common evolutions

II. 2018 Trial Evolutions

55

ALL ST

SLIDE 54

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 SUSPENSION EVOLUTIONS

 ALUMINIUM FORK TECH  Lower weight: – 850 g  Comfort  Steering optimized  REIGER NEW SHOCK ABSORBER  Absorption  Traction  Precision  Repeatability

II. 2018 Trial Evolutions

56

ALL ST

SLIDE 55

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 AIR FILTER MOUNT

 Easier to disassemble

II. 2018 Trial Evolutions

57

ALL ST

SLIDE 56

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 MODIFIED RADIATOR

 Easy water level control  Improved access

II. 2018 Trial Evolutions

58

ALL ST

SLIDE 57

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 CLUTCH EVOLUTIONS

 Low volume AJP master cylinder  Better control feeling  Clutch receptor sealing optimized  Profile of the hose has been modified  Precision  Reliability

II. 2018 Trial Evolutions

59

ALL ST

SLIDE 58

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 Frame reinforced for the exhaust mounts  New Position Dual Map Switch  Foot pegs Position Optimized

II. 2018 Trial Evolutions

60

ALL ST

SLIDE 59

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 Fuel tank vent hose relocated

II. 2018 Trial Evolutions

61

ALL ST

SLIDE 60

ST 125 / 250 / 300 Common evolutions

CYCLE PARTS :

 Rear Sprocket Protection

 More security

 Black Swing arm

II. 2018 Trial Evolutions

62

ALL ST

SLIDE 61

ST 125 / 250 / 300 Common evolutions

ENGINE :

 Re map CDI:

 More performance at lower RPM and smoother transition

II. 2018 Trial Evolutions

63

ALL ST

SLIDE 62

ST 125 / 250 / 300 Common evolutions

ENGINE :

 New Dark Grey Crankcase color  Evolution of diameter bigger blue  Progressive exhaust 125 green  Better cooling of the clutch by oil retention

II. 2018 Trial Evolutions

64

ALL ST

SLIDE 63

ST 125 Specific Evolutions

ENGINE :

 New primary transmission ratio:  Allows 9 / 44 secondary (same 250 / 300 ST)  Sprocket diameter reduction  Chain effect reduced

 Better shock absorption

II. 2018 Trial Evolutions

65
