SLIDE 1
Innovation
1
Achieving California's Renewable Energy Goals
RESEARCH, DEVELOPMENT, & DEMONSTRATION
SoCalGas RD&D
2
POWER-TO-GAS Innovation SoCalGas RD&D RESEARCH, DEVELOPMENT, - - PDF document
POWER-TO-GAS Innovation SoCalGas RD&D RESEARCH, DEVELOPMENT, - - PDF document
Achieving California's Renewable Energy Goals 1 POWER-TO-GAS Innovation SoCalGas RD&D RESEARCH, DEVELOPMENT, & DEMONSTRATION 2 Low Carbon Resources RD&D 3 Power-to-Gas ACHIEVING CALIFORNIAS RENEWABLE ENERGY GOALS 4 Renew
SLIDE 2
SLIDE 3
Low Carbon Resources RD&D
3
SLIDE 4
4
ACHIEVING CALIFORNIA’S RENEWABLE ENERGY GOALS
Power-to-Gas
SLIDE 5
Renew able Energy Goals
5
33% by 2020 50% by 2030 100% by 2050?
California is a Solar State:
- 32% of California’s renewable
power came from solar
- 460 of the 490MW of pending
renewable projects are solar
Source: California Energy Commission – Tracking Progress, 2016
SLIDE 6
Supply / Demand Mismatch
6
The Famous California “Duck Curve” Over-generation can lead to grid congestion or “curtailment”
SLIDE 7
Curtailment of Renew able Pow er is Here Today
7
Source: California Independent System Operator (CAISO)
SLIDE 8
CA Needs Energy Storage
SLIDE 9
What is Pow er-to-Gas (P2G)
excess renewable energy goes through electrolysis which splits water molecules to produce hydrogen hydrogen & carbon combine through methanation methane can be stored
- r transported on the
pipeline
hydrogen can also be stored directly in the pipeline
» P2G is the process of converting excess renewable energy to a gaseous fuel (hydrogen or methane). » P2G allows for storing large amounts of energy for long durations. » P2G can help California reach its Renewable Energy goals.
SLIDE 10
P2G Provides Seasonal Storage
SLIDE 11
P2G Creates Flexibility
11
SLIDE 12
GERMANY’S RENEWABLE ENERGY STORAGE
Potential for electrolysis is estimated at up to
170GW
which could power
114 million
homes.
A vision of what’s possible
GERMANY
Source: Commercialisation of Energy Storage in Europe, 2014
SLIDE 13
13
OUR WORK ON P2G
SoCalGas RD&D
SLIDE 14
14
» Simulation shows dramatic increase in solar utilization
Today: 3.5%
Renewable Energy Integration
With P2G: 35.31%
Renewable Energy Integration
UC Irvine P2G Simulation
SLIDE 15
15
» 60kW Proton OnSite Electrolyzer » On-campus Pipeline Blending » NGCC Power Production
UC Irvine P2G Demo
SLIDE 16
Biomethanation
16
Archaea
Water Electrolysis Renewable Hydrogen
CO2 CH4
Renewable Methane Carbon Dioxide
SLIDE 17
Co-electrolysis Cell
17
CH4
SLIDE 18
Innovation
18
Matt Gregori
mgregori@semprautilities.com
