Power Systems Capabilities By Horizon Electronics Challenge us with your Environment! 1 About Us and Our DNA Since 1970, Horizon Electronics has been a leading designer and manufacturer of power supply systems, converters and inverters,

slide-1
SLIDE 1

Challenge us with your Environment!

1

Power Systems Capabilities

By Horizon Electronics

slide-2
SLIDE 2

About Us and Our DNA

  • 45 years of developing and manufacturing of power supply systems
  • Hundreds of thousands power supply units delivered
  • Hundreds of man-years of Power supply expertise and knowledge
  • Leading customer base in diverse vertical markets
  • State of the art Technologies industry-leading performance
  • Innovation driven
  • Platforms optimized with experience and know-how gained over multiple

platform generations

  • Complete cost-effective power supply systems and components
  • Flexibility and fast customization to customer’s specific requirements
  • Strong Technical support
  • Global international partners

Experience Performance Value

2

Since 1970, Horizon Electronics has been a leading designer and manufacturer of power supply systems, converters and inverters, specialized in harsh environmental, industrial, civil and defense. Horizon offers both standard and custom solutions, ranging from light customization up to fully customized products. The company brings to its customers high-quality, innovative products, and cost effective solutions.

slide-3
SLIDE 3

The Titan 4G Power System series, with its ruggedized constructions, is best suited for use in harsh environments. Its water resistant (IP 65) housing, high performance, and superb reliability, make the Titan 4G the ideal DC power source for use in

  • utdoor, vehicular, naval and field applications.

The Titan 4G Series

DC Harsh Environment Power Supply:

Powerful Performance, One Size Fits All, Simple Integration for harsh environment

3

Features

  • Output Power: 1Kw or 2Kw
  • Single output: 28V or 36V or 48V
  • Adjustable output voltage:
  • Ultra-high efficiency
  • Small Shape
  • Optional Communications
  • OR-ing Function
  • IP 65
  • MIL-STD 810E, MIL-STD 461E
  • IEC / EN STD
  • Applying For UL
  • Universal Input Voltage 120-230VAC / 47-440Hz

120-380VDC Set Point Adjust Range (V) Output Voltage Model 19-28 28 26-40 36 36-58 48

  • 3 Year Warranty
slide-4
SLIDE 4

The Titan 4G Series:

4

slide-5
SLIDE 5

The Inverter 4G (I4G) Power System series, with its ruggedized constructions, is best suited for use in harsh environments. Its water resistant (IP 65) housing, high performance, and superb reliability, make the Inverter 4G the ideal AC power source for use in outdoor, vehicular, naval and field applications.

Inverter 4G Series

For Harsh Environment:

Powerful Performance, One Size Fits All, Simple Integration for harsh environment

5

Features

  • Output 230VAC
  • Input voltage: 18-72VDC
  • High efficiency
  • Small Shape
  • IP 65
  • MIL-STD 810E, MIL-STD 461E

Output Voltage Models 115 VAC 60Hz 230 VAC 50Hz

slide-6
SLIDE 6

The Titan 3G Power System series, with its ruggedized constructions, is best suited for use in harsh environments / defense / homeland security. Its waterproof (IP 65/68) housing, high performance, and superb reliability, make the Titan 3G the ideal DC power source for use in outdoor, vehicular, avionic, naval and field applications. The standard Titan 3G products can be tailored to meet specific projects requirements.

Titan 3G Power Supply Series

DC Harsh Environment Power Supply

Powerful Performance, Effortless Flexibility Simple Integration for harsh environment

6

3rd Generation of standard products with 500 standard options

slide-7
SLIDE 7

Nautilus

7

Its waterproof (IP 68) for Harsh Naval Applications – 2Kw Output

slide-8
SLIDE 8

HRD - 2.4kw DC-DC Converter

8

slide-9
SLIDE 9

HRD - 2.4kw DC-DC Converter

9

  • Safety – Low Voltage Alimentation
  • Inputs: 24VDC
  • Outputs: 48 VDC / 2.4 Kw (Total)
  • Full Redundancy for Inputs and Outputs
  • Includes Particular built-in Redundancy for each output
  • Fully MIL Standards Approved
  • MIL STD. 810E, MIL STD. 461E, MIL STD. 1275B
slide-10
SLIDE 10

Solutions for AC-DC and DC-DC

AC-DC 60w-5,000w

10

  • High power density
  • Low profile design with blade solder pins; terminal blocks (optional)
  • r mounting on DIN-rail (optional)
  • Case operating temperature ranges: -40°С…+85°С, -50°С…+85°С
  • Output current up to 185 А, output power 5,000 W; one, two or three output channels
  • Output nominal Voltages: 15 VDC, 24 VDC, 27 VDC, 48 VDC
  • Input voltage ranges: 80…140 VAC, 100…242 VAC, 176…242 VAC, 3 ph.
  • Galvanically isolated output channels
  • Over current, short circuit, overvoltage and thermal protection
  • Metal case

60W……………………………………………………………………………………..……..……………….…….5Kw

MIL-STD-810F MIL-STD-461F

1.2 Kw

slide-11
SLIDE 11

HI-REL Power Supplies for Aerospace, avionics & MIL COTS

11

Application Include:

  • Radar equipment
  • Marine equipment
  • Test and Measurement
  • Industrial equipment
  • Telecommunications

Features and Benefits:

  • 1000W in a 1U x 264 x 127mm package
  • 55/-40°C to 70°C operation
  • MIL-STD 810G
  • MIL-461F
  • Conformal coated
slide-12
SLIDE 12

Solutions for DC-DC on board

DC-DC 20 W - 1,200 W

12

  • High power density
  • High efficiency ≥ 92%
  • Low profile 13 mm design
  • Standard from 1/16 up to full brick size
  • Case operating temperature range: –40°С…+110°С,

for special request up to -60°С…+130°С

  • Output current up to 40 А
  • Output power up to 1,200 W
  • Output nominal Voltages: 15 VDC, 24 VDC, 27 VDC, 48 VDC
  • Input voltage ranges: 10,5…18 VDC, 18…36 VDC
  • Parallel operation
  • Feedback from load
  • Output voltage adjustment, remote on/off
  • Metal case, with mounting holes
slide-13
SLIDE 13

Industrial Harsh Environment: 19” Cassettes

13

  • Q

4TE, 100W/150W – DCDC – 1, 2 outputs

  • P

4TE, 195W – DCDC – 1, 2, 3, 4 outputs

  • M

8TE, 50W – AC+ DCDC – 1, 2, 3 outputs

  • S

12TE, 100W – AC + DCDC - 1, 2 outputs

  • K

16TE, 150W – AC + DCDC – 1, 2 outputs

  • HR 288w – 10:1 DCDC
  • 1, 2 Outputs
  • HP 192w - 10:1 DCDC
  • 1,2,3,4 Outputs
slide-14
SLIDE 14

HP Cassette

14

slide-15
SLIDE 15

LKP Cassette – AC/DC 280W.

15

slide-16
SLIDE 16

Solutions for DC-DC

16 Cincon Series Output Size Features VICOR Series CQB150W-110S 150W Quarter Brick Input Voltage 43-160VDC MICRO Family - V72C & V110C CQB150-300S 150W Quarter Brick Input Voltage 180-425VDC MICRO Family – V300C & V375C CHB300-110S 300W Half Brick Input Voltage 43-160VDC MINI Family – V72B & V110B CHB300-300S 300W Half Brick Input Voltage 180-425VDC MINI Family – V300B & V375B CQB100-110S 100W Quarter Brick Input Voltage 66-160VDC MICRO Family – V110C CHB150-110S 150W Half Brick Input Voltage 66-160VDC MINI Family – V110B CHB100-110S 100W Half Brick Input Voltage 66-160VDC, same pinout with Vicor First Generation – VE-J00 CFB200-110S 200W Full Brick Input Voltage 66-160VDC, same pinout with Vicor First Generation – VE-200 CFB600-110S 600W Full Brick Input Voltage 43-160VDC MAXI Family – V72A & V110A CFB750-300S 750W Full Brick Input Voltage 200-425VDC MAXI Family - V300A & V375A

slide-17
SLIDE 17

17

ATE Power Supplies

  • Single unit operation and capability to connect

units in parallel and serial

  • Rack Mount

19 ( " 1 U- 9U(

  • Voltage Ranges / unit: 0-1200 V.d.c
  • Current Ranges / unit: 0-700 Amp.
  • Digital LCD displays for Voltage, Current and Power
  • Over Voltage, Over Current, Over Power, Over

Temperature Protection

  • Enable / disable Output(s(
  • Preset Parameters
  • Manual, Built-in USB, RS-

232 SR &

  • 485

LAN, GPIB & Isolated Analog Programming Interfaces option

  • Constant Current or Voltage Modes

\ \ \ \ \

slide-18
SLIDE 18
  • Design to meet customer’s requirements (Form, Fit, Function, Cost(
  • Field-proven building blocks approach
  • Customer’s competitive advantages:
  • Limited risk
  • Space & cost savings
  • Short time to market

Full Customization, Custom is our standard

18

Custom Products

Power supply solutions for EXTREME conditions

IP68 Multi Inputs Drop Unit Customer Embedded Base Plate Cooling Calmark Cooling Defined Surface Conduction Intelligent Power Distribution Unit

Custom solutions:

slide-19
SLIDE 19

19

New Logo – Inspiration and Vision

slide-20
SLIDE 20

www.horizon-pss.com
