Port of San Francisco

Pier 29 Utility Upgrade & Beltline Building Sewer Re-Routing Project Contract No. 2797

May 31, 2018

1

AGENDA

• 1. Welcome, Introductions, & General Information – Tim Leung
• 2. Project Overview – David Hu
• 3. CMD – Finbarr Jewell
• 4. OLSE– Anna Liu
• 5. OEWD – Ian Fernando
• 6. ENVIRONMENTAL – Soko Made
• 7. Bid Documents – Tim Leung
• 8. Questions

• Refer to Section 00 73 16 for details.
• Worker’s Compensation, Commercial General Liability, Commercial

Automobile Liability

• U.S. Longshore and Harborworkers’ Act Insurance; Jones Act; Workers’

Compensation

• Watercraft Liability Insurance
• Water Pollution Insurance
• Builder’s Risk Insurance (Section 1.3A-1)

PIER 29 BELTLINE BLDG AREA OF WORK LOCATION MAP

• Extend Water Supply piping
• Extend Natural Gas Service piping
• Install new Sewer Riser and Bring Gravity Sewer above deck cross over

bulkhead

• Extend Electrical Service connection
• Provide Backup Generator connection
• Provide new Lighting

• Cut & Cap existing under-pier sewer currently connected to Pier 29
• Re-route new gravity sewer to the City sewer in street and eliminates Port-
• wned pump station
• Bring under pier electrical power to the Beltline Building above deck

• Award of Contract

July 2018

• NTP, Construction Start

September 2018

• Construction Term

270 Consecutive Calendar Days

• Substantial Completion

June 2019

• Final Completion

July 2019

• U.S. Longshore and Harborworkers’ Act Insurance (Section 00 73 16)
• Section 01 57 20 – Construction in Water Bodies or Near San Francisco Bay

Environmental Requirements

• BCDC Permit No. M1977.017 and all relevant amendments
• RWQCB Order R2-2016-0039 Waste Discharge Requirements & Water Quality Certification

for Port of San Francisco Maintenance Program, San Francisco, CA, dated September 16, 2016.

• NOAA/NMFS Concurrence & Response for Port of SF Maintenance Program
• Submittals
• Spill Prevention and Control Plan
• Environmental Health and Safety Plan
• Best Management Practices (BMPs). See drawings and Section 01 57 13.

• Project Coordination (Section 01 31 13)
• Pier 29 will be active construction site occupied by other Port contractors
• Contractor shall not commence work or complete construction activities onsite along the

Promenade when a cruise ship is berthed at Pier 27.

• Cruise Ship Schedule - http://sfport.com/cruise
• Lane closures are prohibited the day before, during, and after a Cruise Ship is berthed at

Pier 27.

• Construction along the Promenade and Embarcadero including lane closures are prohibited

during the following days due to Special Events at the Pier 27 Cruise Terminal:

• August 2, 2018
• August 3, 2018
• October 10, 2018
• October 25, 2018 through November 3, 2018
• Traffic Control (Section 01 55 26)
• Contractor to apply for Special Traffic Permit (STP) through SFMTA
• Contractor to maintain a minimum 8 feet of clear sidewalk for pedestrians at all times.

Presented By: Finbarr Jewell finbarr.jewell@sfgov.org

• Local Business Enterprise (LBE)

Subcontracting Goal = 24% 7.5% MBE 4.1% WBE 12.4% OBE

• Good Faith Efforts Exception, LBE = 32.4%
• Refer to Section 00 22 11 for details.

19

Presented By: Anna Liu anna.liu@sfgov.org

Employers need to match or exceed the City’s Ordinances for the following:

• Prevailing Wages
• Sick Leave
• Health Care
• Worker Compensation

23

24

Presented By: Ian Fernando ian.fernando@sfgov.org

• Required per San Francisco Administrative Code Section 6.22(g) and Chapter 82
• See Section 00 73 30 for details
• Applies to both Prime Contractor and ALL Subcontractors
• Local Hire Requirement 30% by trade
• At least 50% of Apprentice project work hours within each trade shall be

performed by local residents.

Presented By: Soko Made rusununguko.made@sfgov.org Construction & Demolition (C&D) Debris Management Requirements

• See Section 01 74 50 for details
• Minimum Diversion Rate of 75% Required
• Source‐separated C&D debris material must be taken to a facility that reuses

and/or recycles that material

• MIXED C&D debris material must be taken to a REGISTERED FACILITY by a

REGISTERED TRANSPORTER

• Diversion Reporting – Use Form C for initial, monthly, and final reports
• Weight Tags are required for monthly reporting
• Contractor MUST include materials from ALL Subcontractors in reports
• City Representative is responsible for reviewing, signing, and approving all

reports submitted by the Contractor.

QBD  Addendum

ENSUING SITE VISIT AT PIER 29

Questions?
