30 Years of High-Energy Neutrino Astronomy: What have we achieved? A brief Review of the Past and some Thoughts for the Future. Peter K. F. Grieder University of Bern Switzerland Vulcano Workshop 2010 May 24-29

slide-1
SLIDE 1

1

Peter K. F. Grieder

University of Bern Switzerland

Vulcano Workshop 2010 May 24-29 Frontier Objects in Astrophysics and Particle Physics

30 Years of High-Energy Neutrino Astronomy:

What have we achieved?

A brief Review of the Past and some Thoughts for the Future.

slide-2
SLIDE 2

2

Overview

  • Motivation
  • Link between Cosmic Ray and Neutrino Physics
  • Summary of Historic Events, Relevant Years
  • Neutrino Detection: Methods and Telescopes
  • Present Results: Predictions and Measurements
  • Experimental Aspects, Sites, Problems of Past

and Present in View of KM3

  • Comments on Supplementary Auxiliary Detector

Systems, Fall-back Projects

slide-3
SLIDE 3

3

Why Neutrino Astronomy

Find the Sources of UHE Cosmic Rays Astrophysical, Cosmological, Particle Physics Aspects Today’s astronomy is based on EM radiation: Optical Radio Infrared X-Rays Gamma Rays

It yields a rich but single-sided picture of the Universe

Much remains obscure, invisible. New alternative approaches, techniques are required. Neutrino astronomy is such an approach. It opens a new non-EM window into the Universe.

slide-4
SLIDE 4

4

A Specific Problem Presents the UHE Primary Cosmic Radiation

(Spectral uncertainties at UHE, GZK cutoff?)

Compressed Double-Logarithmic Spectrum

slide-5
SLIDE 5

5

Primary Cosmic Ray Spectrum

(Akeno, AGASA, EAS-TOP and Yakutsk data excluded)

slide-6
SLIDE 6

6

Questions concerning UHE CR

  • Where ends the primary spectrum *
  • Nature and composition of primaries *
  • Is there a GZK cutoff *
  • Where are the sources
  • What is the nature of the sources, mechanisms
  • Classical accelerators, cutoffs
  • Top-down hypothesis, mechanisms

* Answers are in sight

slide-7
SLIDE 7

7

How to Locate UHE CR Sources: Methods and Techniques

  • Anisotropy studies of arrival direction of

UHE CR air showers

Hadron astronomy (magnetic fields, GZK cutoff)

Gamma-ray astronomy (CMBR)

  • Search for, locate Cosmic Powerhouses

Gamma-ray astronomy

Neutrino astronomy

slide-8
SLIDE 8

8

Likely / Suspected Sources of UHE-CR, Neutrinos

  • Point Sources:
  • Supernova Remnants (E ≤ 10**16 eV)
  • AGNs
  • Blazars
  • Gamma Ray Bursters
  • Diffuse Sources:
  • GZK Neutrinos
  • Topological Defects, Supermassive Particles
  • Z-Bursts
slide-9
SLIDE 9

9

Important Developments, Landmarks

(Back to the Roots: How it all Began)

  • The energy crisis of the late 1920s (energy conservation in beta

decay) prompted Pauli’s neutrino hypothesis as solution (1930).

  • Reines & Cowan’s experiment verified existence of neutrino (1956),

(Reines, Nobel Price 1995).

  • Discovery of >10**18 eV showers by Clark et al. (1957) raises

questions concerning nature and origin of primaries (extragalactic?).

  • Frank, Tamm and Cherenkov (1937/1938) get Nobel Price (1958),

triggers development of Cherenkov detectors (Ginzburg, 1941/2003)

  • Cocconi (ICRC Moscow, 1959) proposed search for UHE gamma

ray showers to locate CR sources (CMBR was not yet established).

  • Markov (Rochester Conf., 1960). proposed UHE neutrino detection

in ocean, using Cherenkov light to locate CR sources.

slide-10
SLIDE 10

10

Developments, Landmarks (cont.)

  • Askaryan developed acoustic shock (1957) and Cherenkov radio

theory (1961).

  • Lederman et al. (1962) prove existence of electron and muon

neutrino (Nobel Price 1988).

  • Penzias and Wilson (1964) discover CMBR (Nobel Prive 1978).
  • Greisen, Zatsepin and Kuzmin (1966) predict GZK Cutoff.
  • Perl et al. (1975) discover tau lepton (Nobel Price 1995), tau

neutrino awaits discovery.

  • Neutrino oscillations (Theory: Pontecorvo et al., 1957, 1967;
  • bservations ~1993, ratio of ratios) (Koshiba, Nobel Price 2002).
slide-11
SLIDE 11

11

Comment

The evolution of Neutrino Physics has strongly affected neutrino astronomy in general, and in particular the scientific goals, but also the experimental concepts and techniques (electron-, muon- and tau neutrinos, and neutrino oscillations).

slide-12
SLIDE 12

12

Neutrino Detection

Via Neutrino Reactions only

Characteristics of neutrino reactions and reaction products are neutrino flavor specific.

slide-13
SLIDE 13

13

Effects of Neutrino Reactions in Target

Acoustic Shock, Optical and Radio Cherenkov Emission

slide-14
SLIDE 14

14

Detector Requirements

Small neutrino cross sections require large target mass / volume, large detector surface / volume Suitable target / detector media are large bodies of water, ice, salt, air or rock, the Moon

slide-15
SLIDE 15

15

Astrophysical Neutrino Telescopes

Concepts, Detection Principles

(Site and Energy Range Specific) Type Medium Detection

Deep-water water optical Cherenkov, acoustic shock Deep-ice ice optical, radio Cherenkov, acoustic

Surface air, rock EAS particles, fluorescence, radio Balloon ice radio Cherenkov emission Satellite air, ice, fluorescence, radio Cherenkov, rock reflected optical Cherenkov light

Typical Design Concepts

slide-16
SLIDE 16

16

3-D DUMAND Type Water / Ice Optical Cherenkov and Acoustic Detector Arrays

AMANDA, ANTARES, Baikal, IceCube, NEMO, NESTOR, KM3

Hawaii

slide-17
SLIDE 17

17

Surface based Particle, Fluorescence and Radio Detectors: Auger, GLUE, LOFAR (Tokyo INS)

Young, Inclined (Horizontal) Air Shower

slide-18
SLIDE 18

18

Balloon based Radio Detectors

ANITA (Antarctic Impulsive Transient Antenna)

Antarctica

slide-19
SLIDE 19

19

Satellite based Cherenkov Radio Detectors

LORD Project (Lunar Orbiting Detector)

Horn Antennas

slide-20
SLIDE 20

20

Satellite based Fluorescence Detectors

JEM-EUSO Project

Observes CR and Neutrino Induced Showers

Sakaki et al., 2008

slide-21
SLIDE 21

21

Site, Medium and Concept Specific Problems, Advantages

Ocean: instrumentation, long-range deployment from ship, platform, (ice), remote operations, background. Detector is serviceable.

ANTARES, (Baikal), NEMO, NESTOR, KM3

Ice sheet: access, drilling (melting) of holes to site, detector is irreparable, homogeneity, background. Comparatively easy deployment.

AMANDA, IceCube

Surface: background, event identification. Easy instrumentation, access.

Auger, GLUE, LOFAR (Tokyo INS)

slide-22
SLIDE 22

22

Site, Medium and Concept Specific Problems, Advantages

(cont.)

Balloon: launch, radio background, short run time, difficult analysis and interpretation. Large target area, volume; high threshold energy.

ANITA

Satellite: launch, optical, radio background. Very high threshold energy, huge target volume, area.

FORTE, JEM-EUSO, LORD

slide-23
SLIDE 23

23

Relevant Target / Detector Medium Specific Properties, Parameters

Composition (water, ice, air, salt, rock) Density, Homogeneity (Temperature) Optical properties, parameters (scattering, attenuation, refraction) Acoustic properties (sound propagation) Electromagnetic properties, parameters (radio propagation) (dielectric constant, conductivity)

slide-24
SLIDE 24

24

Neutrino Fluxes: Model Predictions

slide-25
SLIDE 25

25

Sensitivities of different Detectors:

Anticipated and Determined Sensitivities of Different Experiments

Saltzberg (2005)

slide-26
SLIDE 26

26

Measured Neutrino Flux Limits:

Results from Different Experiments

Gorham et al. 2004 Barwick et al., 2006

slide-27
SLIDE 27

27

Deep-Water Cherenkov Arrays:

Site Relevant Properties

Geographic location Depth Sky exposure Water properties Environment Background

slide-28
SLIDE 28

28

Muons Neutrinos

Detector Site

Relevant Parameters, Properties Geographic Location

Sky Visibility, Background

DUMAND

Near Equator

slide-29
SLIDE 29

29

Depth (Altitude):

Sky Visibility, Background: an Example

slide-30
SLIDE 30

30

Skymap of Detected Neutrinos by AMANDA II at South Pole

(can only observe northern hemisphere)

slide-31
SLIDE 31

31

Sea / Ocean Parameters

NESTOR Site DUMAND Site

slide-32
SLIDE 32

32

Sea / Ocean Parameters (cont.)

NESTOR Site DUMAND Site

slide-33
SLIDE 33

33

Background, Environmental Considerations:

(Site Specific)

  • ptical

cosmic rays bioluminescence, chemo-luminescence natural radioactivity, 40K acoustic noise (radio noise) bio-fowling (stops at > 800 m b.s.l.) sedimentation (e.g., Sahara sand, Rivers) sea, ocean currents lightning storms

slide-34
SLIDE 34

34

Muon Depth-Intensity Relation

In Standard Rock In Water

slide-35
SLIDE 35

35

Muon Depth-Intensity Relation (cont.)

Sea water NESTOR site

4108 m 3697 m Depth 3338 m ANTARES NESTOR NEMO, KM3

slide-36
SLIDE 36

36

Bioluminescence, Hawaii Site

Depth 3000 m (tethered)

Calibration Pulses

slide-37
SLIDE 37

37

Bioluminescence (cont.)

Ocean currents and turbulence can cause stimulated bioluminescence

  • f bacteria.

Effect is geographic location and depth dependent. Fish, animals are irrelevant sources

  • f bioluminescence.

Nearby rivers, cities increase effect.

C dark noise, 3°C F bottom tethered (100 m a.g.) 1500 m 2500 m 3500 m 4500 m

Channel Number 1 M 100 cps 100

slide-38
SLIDE 38

38

Bioluminescence, Hawaii Site (cont.)

4300 m 3000 m

4300 m at start ascent

slide-39
SLIDE 39

39

DUMAND Site

Optical Background v/s Depth in Pacific near Hawaii

Descent, Ascent ~40 – 80 cm/s (facing down)

slide-40
SLIDE 40

40

Deep-Water Cherenkov Arrays:

Important Elements, Topics

  • Optical (Acoustic) Sensor Modules, Clusters.
  • Array Design, Structure, Layout (mechanical).
  • Data Acquisition, Transmission and Processing Strategy, associated

Electronics.

  • Event Reconstruction and Analysis.
  • System and Event Simulation.
  • Array and Environmental Monitoring System, Housekeeping.
  • Deployment and Installation.
  • Support and Maintenance.
  • Auxiliary Systems, (Shallow Muon Array etc.)
  • Fall-Back Projects.
slide-41
SLIDE 41

41

Optical Sensor Modules

Benthos glass pressure housing (17”) for optical detector module.

slide-42
SLIDE 42

42

DUMAND Optical Detector Module

DUMAND optical detector module showing 17 “ Benthos glass pressure housing, 15” Hamamatsu PMT with magnetic shield (grid) and electronics (HVPS, control, monitoring, data and command handling system, 3-way communication).

slide-43
SLIDE 43

43

Optical Module Options for KM3

Pressure housing holds many small PMT’s (left) or two mid-size (right). OM Cluster below.

Module orientation is relevant

Module Cluster Twins

slide-44
SLIDE 44

44

Proposed Array Structures

! Must be Deployed !

KM3NeT NESTOR

slide-45
SLIDE 45

45

120 m 4000 m

NESTOR Tower

Folded

Tower Separation Tower Height 500 m

slide-46
SLIDE 46

46

Ocean Deployment Techniques

From Standard Ship (De Steiger) in Pacific, no Fun

slide-47
SLIDE 47

47

SSP Kaimalino (USN) at Sea Semi-Submersible Platform with DPS

slide-48
SLIDE 48

48

SPS Deployment from Kaimalino

Optical, Calibration Modules String Controller

slide-49
SLIDE 49

49

Work on Deck of the Kaimalino

  • P. Grieder and G. Wilkins (1987)
slide-50
SLIDE 50

50

String Deployment/Recovery from SSP Kaimalino (Diver’s View, ~30 m, Video)

slide-51
SLIDE 51

51

SSP Kaimalino (Front View)

at Snug Harbor, Honolulu, Hawaii

slide-52
SLIDE 52

52

SSP Kaimalino

in Drydock at Kaneohe, Hawaii

slide-53
SLIDE 53

53

SSC Kaio (Japan)

Semi-Submersible Catamaran

slide-54
SLIDE 54

54

slide-55
SLIDE 55

55

Oceanographic Research Vessel

Thomas G. Thompson (D.P.S.)

Helicopter picture by P. Grieder during string deployment

slide-56
SLIDE 56

56

Future Deployment Platform

Stable, Floating, Semi-Submersible (D.P.S.)

slide-57
SLIDE 57

57

Submarines and Robots

Sea Cliff (Pilot, Navigator, Observer, >5000m b.s.l. )

slide-58
SLIDE 58

58

Submarines and Robots (cont.)

Remotely Operated Vehicle (ROV)

slide-59
SLIDE 59

59

Detector Modules and Deployment Schemes

Old Ideas from the History Book Revisited Simple configurations simplify deployment

slide-60
SLIDE 60

60

Phase Shifting Light Collector-OM Combinations (from History Book)

Phase Shifting Light Collector Fan Sea Urchin Design Pressure Envelope 3 m Spines WS Sensor Tube

slide-61
SLIDE 61

61

Deployment Schemes, String Packing

slide-62
SLIDE 62

62

On-Shore Fly’s Eye

Partial Fly’s Eye

  • n Puu Hualalai,

Big Island ,Hawaii 2700 m a.s.l.

slide-63
SLIDE 63

63

Shallow, Anchored Muon Array

10 GeV Muon Array

slide-64
SLIDE 64

64

Thank you for your attention

Article on junction box, 400 m string & 30 km cable deployment on WEB: http://www.itp.unibe.ch/astrocosmo
