Ornithopoda The duck-billed dinosaurs Evolution Space and Time - - PowerPoint PPT Presentation

▶
ornithopoda the duck billed dinosaurs
SMART_READER_LITE
LIVE PREVIEW

Ornithopoda The duck-billed dinosaurs Evolution Space and Time - - PowerPoint PPT Presentation

Sep 10, 2023 178 likes •654 views

Ornithopoda The duck-billed dinosaurs Evolution Space and Time Basal Ornithopods Diet Brains Movement Behavior Genosauria Cerapoda Marginocephalia Pachycephalosauria Ceatopsia Ornithopoda: bird feet Iguanodon

slide-1
SLIDE 1
slide-2
SLIDE 2

Ornithopoda The ‘duck-billed’ dinosaurs

Evolution Space and Time Basal Ornithopods Diet Brains Movement Behavior

slide-3
SLIDE 3

Genosauria Cerapoda Marginocephalia Pachycephalosauria Ceatopsia Ornithopoda: ‘bird feet’

Edmontosaurus

Primitive Characteristics: basal Ornithopods are ‘typical’ Ornithischians

Opisthopubic condition No fenestra in mandible

Iguanodon

slide-4
SLIDE 4

Derived Characteristics:

Ventrally offset premaxillae Very low jaw joint

slide-5
SLIDE 5

Early Ornithopods & Euornithopods Small, bipedal Heterodontosaurids may have been basal Ornithopods (or basal Ornithischians, depending on who you ask)

Small, bipedal Derived: Larger, mainly quadrupedal Euornithopoda

slide-6
SLIDE 6

A quick revisit of Heterodontosaurids

(also covered during the introduction of Ornithischian dinos)

Heterodontosaurids: Not Primitive... unique chewing. Three kinds of teeth Anterior: Snipping/Cropping Posterior: Chewing Tusks/Caniforms: Potentially display/courtship

slide-7
SLIDE 7

Heterodontosaurids: Kinetic LOWER JAW Efficient mastication Bipedal Short forelimbs Increased number of teeth Long tail Short femur Long tibia/fibula Likely fast, agile

slide-8
SLIDE 8

vs. Heterodontosaurus: Short femur; Long tibia/fibula = fast Scelidosaurus (basal Thyreophoran): Long femur; Short tibia/fibula = slow

slide-9
SLIDE 9

We will explore this concept more with Theropod dinosaurs

slide-10
SLIDE 10

Heterodontosaurid time range Basal euornithopod time range

Triassic Jurassic Cretaceous

slide-11
SLIDE 11
slide-12
SLIDE 12

Iguanodontia: the most diverse clade Toothless premaxilla Smooth, rounded predentary Generally larger Derived forms (Ankylopollexia): Expanded dental batteries & spiked thumb Tenontosaurus

slide-13
SLIDE 13

broad predentary many teeth in dental battery

slide-14
SLIDE 14

Thumb spike Reduced digit 4

Defense? Competition? Dietary needs?

slide-15
SLIDE 15

Thumb spike placement

slide-16
SLIDE 16

Facultative quadrupeds

Big, with appropriate modifications. Iguanodon

slide-17
SLIDE 17
slide-18
SLIDE 18

Obligate Bipedal Facultative Bipedal

Tenontosaurus

slide-19
SLIDE 19

Scales: Ornithopods, great and small

Camptosaurus Iguanodon Shantungosaurus Dryosaurus (small) Corythosaurus Heterodontosaurus (sm) Tenontosaurus

Dryosaurus: one of the smallest; 2.4 - 4.3 m long; 200 lbs Shantungosaurus: one of the largest; skull 1.6 m (5 ft); length: 15 m (50 ft); 16 tonnes = 35,274 lbs

slide-20
SLIDE 20
slide-21
SLIDE 21

Hadrosaurid time range Non-hadrosaurid iguanodontian time range

Triassic Jurassic Cretaceous

slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24

Hadrosaurids Well developed dental battery Modifications to skull and mandible to enhance chewing efficiency

3+ teeth per position (up to 1200 in mouth) Very big, 7-17 m Thick, bumpy skin Large sacrum Large coronoid process No thumb, mitten- like hand ~ support weight

slide-25
SLIDE 25

Hadrosaur front foot Anatotitan

slide-26
SLIDE 26
slide-27
SLIDE 27

Meet the Hadrosaurines (wide snouts)

Anatosaurus

slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

Meet the Lambeosaurines

slide-32
SLIDE 32
slide-33
SLIDE 33

Parasaurolophus

slide-34
SLIDE 34
slide-35
SLIDE 35

Parasaurolophus Corythosaurus Lambeosaurus

slide-36
SLIDE 36

Hadrosaur skin

slide-37
SLIDE 37

Scales: the largest Hadrosaurids

slide-38
SLIDE 38

Lambeosaurus

Major Evolutionary Trends

  • 1. Efficient, robust dental battery
  • 2. Larger body size

Bipedality => Facultative Quadrupedality => Facultative Bipedality

slide-39
SLIDE 39

Lycorhinus (Heterodontosaurid) Hypsilophodon Iguanodon Lambeosaurus

TRENDS

  • 1. Efficient, robust dental battery
  • 2. Larger body size

Gastroliths Large, robust coronoid process Deep, inset tooth row

slide-40
SLIDE 40

Brachylophosaurus

slide-41
SLIDE 41

A new type of chewing (Euornithopoda) Pleurokinesis Lateral mobility of UPPER jaws

http://www.youtube.com/watch?v=6Sr5is7-wdk

slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44

So what did they eat? Twigs, fruits, berries Ground cover Lower level foliage from conifers Newly evolving Angiosperms Limited to 1-2 meters off the ground; larger animals, up to 4 meters (13 ft)

slide-45
SLIDE 45
slide-46
SLIDE 46

Hadrosaur Basal Ornithopod Closely related non-Hadrosaur Iguanodontians
