Optical Links for the ATLAS SCT and Pixel Detector Ingrid-Maria Gregor (University Wuppertal) for the ATLAS June 6th, 2000 collaboration International Workshop on Semiconductor Pixel Detectors for Particles and X-Rays Genova, Italy June


slide-1
SLIDE 1

Ingrid-Maria Gregor (University Wuppertal) for the ATLAS collaboration June 6th, 2000

Optical Links for the ATLAS SCT and Pixel Detector

International Workshop on Semiconductor Pixel Detectors for Particles and X-Rays Genova, Italy June 2000

slide-2
SLIDE 2

2

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Overview ➤ ATLAS Inner Detector ➤ Optical Link Architecture ➤ System Tests ➤ Conclusion

slide-3
SLIDE 3

3

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

ATLAS Inner Detector

Forward SCT Barrel SCT TRT Pixel Detectors

slide-4
SLIDE 4

4

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Data Transfer

➤ Control and clock information must be transferred from

acquisition system to the silicon detectors

➤ Hit data must be transferred from the modules to a remote

acquisition system

➤ use of copper links unfeasible

large amount of dead material which would be introduced

problems from cross-talk and ground loops

➤ it is proposed to use custom optical links to transfer data to

and from the detector modules (SCT and Pixel Detector)

slide-5
SLIDE 5

5

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Special Requirements (1)

➤ radiation hardness

ionizing radiation : 100kGy (SCT) to 550kGy (Pixel detector)

1 billion lung x-rays

neutron radiation : ➣

Si-devices: 1*1015 n(1MeV)/cm2

GaAs-devices: up to 6.4*1015 n(1MeV)/cm2

expected over the 10 year lifetime of ATLAS (1st layer)

slide-6
SLIDE 6

6

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Special Requirements (2)

➤ non-magnetic to avoid perturbing the inner detector

magnetic field

➤ low mass

additional interactions in non-instrumented regions of the detector would compromise the quality of momentum measurements

particle conversion

➤ reasonably low cost

slide-7
SLIDE 7

7

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Read-Out Link Architecture

Vertical Cavity Surface Emitting Laser

slide-8
SLIDE 8

8

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Timing Triggering and Control (TTC link)

➤ VCSEL Driver BiPhase Mark Encoder ➤ driver chip for VCSEL on acquisition side (12 way) ➤ 40MHz-Clock and Commands on one link

slide-9
SLIDE 9

9

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

TTC Link

➤ Digital Optical Receiver IC ➤ decodes the signals received by the PIN ➤ recovers commands and 40MHz-clock ➤ LVDS output ➤ 2 versions: bipolar (SCT) and CMOS (Pixel) ➤ SCT redundancy system: TTC data can be

taken from redundancy link from a neighbouring data

slide-10
SLIDE 10

10

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Data Link

➤ VCSEL Driver Chip ➤ LVDS input ➤ 40Mbit/s (SCT), 80Mbit/s (Pixel 1st and 2nd

layer) or 160Mbit/s (B-layer)

➤ NRZ (20MHz = 40Mbit/s) ➤ 2 versions: bipolar (SCT) and CMOS (Pixel) ➤ SCT: in the event of failure, the data can be

rerouted through the second link

➤ Pixel: one link for outer layers, two for B-layer

(160MBit/sec)

slide-11
SLIDE 11

11

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Opto-Package Specs

➤ Custom package made of material with low Z, non-magnetic,

with 2 VCSELs and 1 PIN

➤ Fibres attached without standard connector ➤ not larger than 5.5 mm x 5.5 mm x 1.6 mm ➤ package and including devices have to stand radiation levels ➤ operation temperature during testing: -25oC to 40oC ➤ operation temperature during ATLAS: -25oC to 15oC ➤ three different designs under survey

slide-12
SLIDE 12

12

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Taiwan Opto-Package

slide-13
SLIDE 13

13

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Taiwan Opto-Package

5.5 mm

slide-14
SLIDE 14

14

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Taiwan Opto-Package

slide-15
SLIDE 15

15

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Opto-Elbow (Pixel)

Module Pigtail Opto Elbow

Bending Zone Solder Connection Single Side

Glue Attachment & Wire Bonding

DORIC VDC Opto-Package

slide-16
SLIDE 16

16

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Opto Package Support (SCT)

VDC (VCSEL Driver Chip) DORIC (Receiver Chip) VCSEL/PIN Package ZIF Connector Kapton Cable Opto Hybrid Module Connector

slide-17
SLIDE 17

17

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

System Tests ➤ Characteristics of opto-link for this system

under test:

➢ Radiation and Annealing studies ➢ Lifetime studies ➢ Bit Error Rate ➢ Single Event Upsets

slide-18
SLIDE 18

18

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Annealing Studies of VCSEL

00:00 24:00 48:00 72:00 96:00 0,0 0,2 0,4 0,6 0,8 1,0

Average Relative Light Output (RLO) Annealing time [h]

RLO of VCSEL (group A) annealed at 10mA RLO of VCSEL (group A) annealed at 20mA RLO of VCSEL (group B) annealed at 10mA RLO of VCSEL (group B) annealed at 20mA

Light Output before Irradiation Light Output after Irradiation RLO =

Radiation levels:

2 14 2 14

10 * 5 B 10 * 8 A

cm n cm n

= =

slide-19
SLIDE 19

19

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

VCSEL tests

➤ VCSELs were not powered during irradiation ➤ radiation induced damages can be annealed up to 90%

  • ver a period of days/weeks

➤ results suggest brief 20 mA current annealing sessions ➤ following aging tests showed an expected lifetime of a few

hundred years (irradiated)

➤ further irradiation and lifetime tests are under way (up to

Pixel level of 6.4*1015 n(1MeV)/cm2)

slide-20
SLIDE 20

20

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Bit Error Rate (BER)

BER vs lightinput

1 .E-1 1 1 .E-1 0 1 .E-0 9 1 .E-0 8 1 .E-0 7 1 .E-0 6 1 .E-0 5 1 .E-0 4 1 .E-0 3 1 .E-0 2 1 .E-0 1 1 .E+ 0 0 1 .E+ 0 1 8 0 1 0 0 1 2 0 1 4 0 1 6 0 1 8 0 2 0 0 2 2 0 2 4 0

Lightinput ( m W )

BER

PIN-BIAS = 5V PIN-BIAS = 0V

➤ BER: good parameter to evaluate

the performance of the optolink

9

10 BER

< =

bits error

N N

➤ Good results with SCT link ➤ Pixel test under way

slide-21
SLIDE 21

21

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Single Event Upsets

➤ Single Event Upsets caused by a very high energy

deposition in a small volume of electronics chips

➤ most sensitive region: reverse-biased p/n junction

where high electric field is very effective in collecting the charge by drift

➤ PIN = reverse biased p/n junction ➤ 100µm x 50µm x 50µm ! ➤ First SEU appearance : NPL neutron beam ➤ test with pions at PSI

slide-22
SLIDE 22

22

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

SEU at PSI

➤ Sensitive power

around 100µW

➤ for P>350µW, BER

<10-10s-1

➤ discrepancy

between counter and Al foil

➤ repeat next week

slide-23
SLIDE 23

23

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Conclusion

➤ data transfer using optical links ➤ custom packaging developments for the 40 Mb/s optical

link show good physical results

➤ design of complete Pixel opto-link under way ➤ radiation induced damages can be annealed up to 90%

  • ver a period of days

➤ results suggest brief 20 mA current annealing sessions ➤ SEU problems can be fixed by sending more light

slide-24
SLIDE 24

24

Pixel2000 Genova, Italy

Ingrid-Maria Gregor University of Wuppertal

Conclusion

➤http://www.atlas.uni-wuppertal.de/

Optolink/Pix_Optolink.html
