OpenWalnut – An Open-Source Visualization System

Sebastian Eichelbaum1 Alexander Wiebel3 Mario Hlawitschka2 Gerik Scheuermann1

1

Abteilung für Bild- und Signalverarbeitung, Institut für Informatik, Universität Leipzig, Germany

2

Institute for Data Analysis and Visualization (IDAV), and Department of Com- puter Science, University of California, Davis, USA

3

Max-Planck-Institut für Kognitions- und Neurowissenschaften, Leipzig, Ger- many

slide-2
SLIDE 2

Outline

1

Yet Another Visualization Tool?

2

What is OpenWalnut

3

Software Design

4

Results and Future Work

Sebastian Eichelbaum OpenWalnut

slide-3
SLIDE 3

Outline

1

Yet Another Visualization Tool?

2

What is OpenWalnut

3

Software Design

4

Results and Future Work

Sebastian Eichelbaum OpenWalnut

slide-4
SLIDE 4

Available Tools

  • MeVisLab (✇✇✇✳♠❡✈✐s❧❛❜✳❞❡)
  • Amira (✇✇✇✳❛♠✐r❛✳❝♦♠)
  • ParaView (✇✇✇✳♣❛r❛✈✐❡✇✳♦r❣)
  • VISH (✈✐s❤✳♦r✐❣♦✳❡t❤③✳❝❤)
  • MedINRIA

(✇✇✇✲s♦♣✳✐♥r✐❛✳❢r✴❛s❝❧❡♣✐♦s✴s♦❢t✇❛r❡✴▼❡❞■◆❘■❆)

  • Mayavi (♠❛②❛✈✐✳s♦✉r❝❡❢♦r❣❡✳♥❡t)
  • SCIRun (✇✇✇✳s❝✐r✉♥✳♦r❣)
  • Teem (t❡❡♠✳s♦✉r❝❡❢♦r❣❡✳♥❡t)

Sebastian Eichelbaum OpenWalnut

slide-5
SLIDE 5

Context

  • Collaboration: Neuroscientists & Visualization

Researchers

  • two different requirements to a visualization tool
  • Neuroscientist = End-User
  • Visualization Researcher = Developer

Sebastian Eichelbaum OpenWalnut

slide-6
SLIDE 6

Requirements

  • Open Source and free
  • MeVisLab
  • Amira
  • ParaView
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-7
SLIDE 7

Requirements

  • Open Source and free
  • General Purpose (w.r.t.

medical visualization)

  • MeVisLab
  • Amira
  • ParaView
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-8
SLIDE 8

Requirements

  • Open Source and free
  • General Purpose (w.r.t.

medical visualization)

  • All-In-One: Usable tool

and powerful framework

  • MeVisLab
  • Amira
  • ParaView
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-9
SLIDE 9

Requirements

  • Open Source and free
  • General Purpose (w.r.t.

medical visualization)

  • All-In-One: Usable tool

and powerful framework

  • Easily extensible

(flexibility)

  • MeVisLab
  • Amira
  • ParaView
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-10
SLIDE 10

Requirements

  • Open Source and free
  • General Purpose (w.r.t.

medical visualization)

  • All-In-One: Usable tool

and powerful framework

  • Easily extensible

(flexibility)

  • Easy to use (graphical

user interface)

  • MeVisLab
  • Amira
  • ParaView?
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-11
SLIDE 11

Requirements

  • Open Source and free
  • General Purpose (w.r.t.

medical visualization)

  • All-In-One: Usable tool

and powerful framework

  • Easily extensible

(flexibility)

  • Easy to use (graphical

user interface)

  • Portable (Linux, Windows

and MacOS X)

  • MeVisLab
  • Amira
  • ParaView
  • VISH
  • MedINRIA
  • Mayavi
  • SCIRun
  • Teem

Sebastian Eichelbaum OpenWalnut

slide-12
SLIDE 12

Outline

1

Yet Another Visualization Tool?

2

What is OpenWalnut

3

Software Design

4

Results and Future Work

Sebastian Eichelbaum OpenWalnut

slide-13
SLIDE 13

What is OpenWalnut today

  • Multi-modal visualization tool
  • Powerful framework
  • Fast growing amount of algorithms and methods
  • Actively developed
  • Heavily used by:
  • Max Planck Institute for Cognitive- and Brain Sciences
  • Max Planck Institute for Neurology
  • Our group for all kinds of medical visualization research
  • Other international groups began developing for/with

OpenWalnut

Sebastian Eichelbaum OpenWalnut

slide-14
SLIDE 14

How it looks

Sebastian Eichelbaum OpenWalnut

slide-15
SLIDE 15

How it looks

Sebastian Eichelbaum OpenWalnut

slide-16
SLIDE 16

How it looks

Sebastian Eichelbaum OpenWalnut

slide-17
SLIDE 17

How it looks

Sebastian Eichelbaum OpenWalnut

slide-18
SLIDE 18

How it looks

Sebastian Eichelbaum OpenWalnut

slide-19
SLIDE 19

Developer Details

  • Written in C++, extensively using Boost
  • GUI with QT
  • Graphics engine uses OpenSceneGraph
  • Programmed with long code life-time and readability in

mind

  • Extensive documentation with Doxygen
  • Unit-testing (cxxtest)
  • Strict Code-Style rules with automatic checking (cpplint)

Sebastian Eichelbaum OpenWalnut

slide-20
SLIDE 20

External Lib Integration

  • CUDA integration
  • Teem
  • ITK
  • Ossim
  • FSL
  • ...

Sebastian Eichelbaum OpenWalnut

slide-21
SLIDE 21

Outline

1

Yet Another Visualization Tool?

2

What is OpenWalnut

3

Software Design

4

Results and Future Work

Sebastian Eichelbaum OpenWalnut

slide-22
SLIDE 22

Design Goals

  • Easy-to-use GUI
  • Responsiveness
  • Interactivity
  • Flexibility
  • Extensibility
  • Only portable external libraries

Sebastian Eichelbaum OpenWalnut

slide-23
SLIDE 23

Overview

Sebastian Eichelbaum OpenWalnut

slide-24
SLIDE 24

The Module

  • Own Thread
  • Data In- and Output only

through connectors

  • Communication with User/GUI

by properties

  • Graphics Output using

scenegraph

  • No knowledge about other

modules, GUI or loaded data

  • Can be a container for other

modules

  • Push mechanism

Sebastian Eichelbaum OpenWalnut

slide-25
SLIDE 25

Connectors

  • Strictly typed by the kind of data transferred
  • Automatic connection management
  • GUI can provide list of compatible modules for an given

connector to user

  • Module get informed, or woke up if new data arrives on

connector

  • Automatic change propagation along module graph
  • Abstract implementation allows many kinds of connectors

(streaming, bidirectional, ...)

Sebastian Eichelbaum OpenWalnut

slide-26
SLIDE 26

Properties

  • Strictly typed (Bool, Floating Point Values, Integers,

Strings, Filenames, Vectors, Matrices, ...)

  • Possible to define value-constraints
  • Ensures always valid values
  • Grouping of properties
  • GUI implements widgets for handling them
  • According to type
  • Constraints
  • Grouping
  • Propagation of changes

Sebastian Eichelbaum OpenWalnut

slide-27
SLIDE 27

Container

  • Modules can be module container
  • Forwarding of properties and connectors from or to the

internal module graph

  • Allows hiding complexity
  • One module even for complex use cases
  • Easy to re-use existing functionality

Sebastian Eichelbaum OpenWalnut

slide-28
SLIDE 28

Overview II

Sebastian Eichelbaum OpenWalnut

slide-29
SLIDE 29

Outline

1

Yet Another Visualization Tool?

2

What is OpenWalnut

3

Software Design

4

Results and Future Work

Sebastian Eichelbaum OpenWalnut

slide-30
SLIDE 30

Results

  • Combines best out of two worlds
  • Flexible and extensible framework
  • Easy-to-use and interactive tool
  • Strict separation of GUI and framework
  • Exchangeable GUI and adaptable GUI
  • Interactive and Responsible
  • Portable

Sebastian Eichelbaum OpenWalnut

slide-31
SLIDE 31

Future Work

  • Integration of scripting features (arbitrary language via

SWIG)

  • Integration of OpenCL
  • More features from Teem
  • Several GUI’s for several purpose or one flexible GUI
  • More file types support

Sebastian Eichelbaum OpenWalnut

slide-32
SLIDE 32

Interested?

  • Website: ✇✇✇✳♦♣❡♥✇❛❧♥✉t✳♦r❣
  • Videos: ✇✇✇✳②♦✉t✉❜❡✳❝♦♠✴✉s❡r✴❖♣❡♥❲❛❧♥✉t❖r❣

Sebastian Eichelbaum OpenWalnut

slide-33
SLIDE 33

Demo

  • Demo

Sebastian Eichelbaum OpenWalnut

slide-34
SLIDE 34

Thank You for Listening

Questions?

Sebastian Eichelbaum OpenWalnut
