On Designing and Thwarting Worms using Co-ordination

Jayanthkumar Kannan Karthik Lakshminarayanan

{kjk, karthik}@cs.berkeley.edu

Impact of P2P Technology

• Widespread deployment of P2P networks

– Large user base: half a million nodes at any time – Significantly different traffic patterns

• DHT technology

– Efficient distributed lookup systems – Share information efficiently – Achieve load-balancing – Achieve locality properties

Brief outline of the talk

• Part I: How malicious can a worm get?

– Stealth – avoid alarms at intrusion detection systems – Efficiency – quicker scanning – Use p2p systems for hit-list generation – Understanding how bad a worm can get is essential in designing defenses

• Part II: Is there any hope against such worms?

DHTs enable sharing of information across nodes

State-of-the-art

• Worm attacks

– Pre-collected IP address hit-lists – Divide and conquer (permutation scanning) – Random probing of IP addresses – …

• Defense Techniques

– Unusual high number of rejected packets – Might do well if ISPs deploy it

Using a deployed P2P network

• Hit-list generation

– How fast can one get IP addresses from crawling a p2p network like Gnutella? – How stale is this information after a period of time?

• Passive probing

– Exploit security loopholes in P2P application – Use existing communication patterns of p2p networks

Coordinated worm attacks

• Avoid detection

– Policies followed by worms to avoid triggering alarms – For e.g., restrict number of probes to an address prefix, probe internal IP address, bound number of unique probes from source

• Reduce failed probes

– Uneven IP address allocation: random probing not ideal – Some IDS count number of unsuccessful attempts – Large number of “missed” probes

• Reduce network utilization

– Some worms caused congestion in the backbone – Local probes to reduce number of peering links crossed

• Faster propagation

Assumptions

• Bandwidth-limited worm (such as Slammer)

– Not affected by parameters such as number of

• utstanding TCP connections

– Issue if it is a TCP worm and uses kernel TCP implementation

I: Uneven IP address allocation

• Goal: Probe prefixes at a rate proportional to the

probability of finding a vulnerable host

• For each prefix maintain:

– Fraction of vulnerable hosts – Extent of IP address that has been scanned

• Let P be the total probes performed to a prefix, V be

the total number of vulnerable hosts, I be the number

• f infected hosts, S is size of the prefix

– P(finding a vulnerable host), pi = (S * V/P – I)/S

I: Uneven IP address allocation

• Use a DHT for maintaining P,V,I,S:

– Infected nodes probe DHT and get a prefix that is likely to have vulnerable hosts – Probe k-prefixes, and sample according to the vulnerability metric

• Desired characteristics of DHT:

– Performs admission control – Allow high query/update rate – High degree of churn – Target size of DHT not large (~5000 nodes) – We chose “Kelips” as our DHT

A brief overview of Kelips

• Combination of DHT and unstructured

network with O(sqrt(n)) memory usage

• Basic Idea: Gossiping used to maintain

consistency

• Information propagates to group in

O(log(n)) time

0 1 2

1 N −

Affinity Groups: peer membership thru consistent hash Affinity Group pointers Cross-group “contacts” Kelips Slide borrowed from authors

0 1 2

1 N −

Affinity Groups: peer membership by consistent hash filename, location hash filename replicate filetuple “filetuple” File Replica inserted Somewhere (DHT or DOLR) Kelips Slide borrowed from authors

Our Modifications

• Longest Prefix Match among home pointers

– Allows flexibility in relocating sub-prefixes – Eg: Node A has information about 10.1.0.0/16, Node B has information about 10.1.2.0/24.

• Inconsistency Resolution

– Application-level resolution – If two home pointers (id,A1), and (id,A2), then merge data in A1 and A2, and choose one randomly

• Choose number of groups such that number of

nodes in one group is small

– Simulations: Consistency attained within 10 secs.

• II. Evading intrusion detection

systems

• By following specific policies
• By minimizing number of AS-level hops

– Assuming ISPs do monitoring

• Can be achieved by having the home

pointer allocate prefixes to infecting nodes

– Home pointer can maintain number of nodes probing such addresses – Can be used to implement powerful policies

• III. Exploiting locality to reduce

network utilization

• Kelips can be made location-aware
• Adaptive improvement through gossiping: Pick

closest RTT ones

• Assumption:

– If A is close to B, and B is close to C, A is close to C.

• Gives two advantages:

– Each low-bandwidth host can find a nearest kelips ‘proxy’ – When inserting new item, inserter asks k random nodes to measure latencies to prefix, chooses best – Conflict resolution: Resolve in favor of closer node

Using DHTs for worm defenses

• Some initial high-level thoughts on this
• Our model of defense
• Some firewalls around Internet coordinate

with one another

– Need to cut off traffic from infected networks – Need to maintain models of normal traffic from every network, and shut – Models that offer hope: New IP addresses probed, New Prefixes probed etc

Using DHTs for worm defenses

• Expensive for every firewall to maintain and even
• bserve required state

– DHT can be used to share such traffic model information – Allocates responsibility in a secure fashion (replication) – Means traffic models can be verified from multiple views – Information across firewalls coordinated using a DHT

• Use redundant routing in DHTs to exchange

information in the presence of network congestion due to worms

Simulation methodology

• Strawman:

– Random probing (today, worms operate this way)

• Issues in simulation:

– Scalability with size of topology, number of nodes – Lack of data on distributions of typical AS-level and last-hop bandwidths – Address space occupancy information unavailable

Simulation methodology

• What we used:

– Discrete-time simulator – Scaled down AS-level Internet graph (from Subramanian et al, Infocom 2002) – Assigned IP prefixes as in SSFNet – Access bandwidth from Gummadi et al, MMCN – Kelips parameters: contacted Kelips’ authors

• Parameters:

– 100,000 vulnerable nodes (CodeRed had 400,000) – Living in 5000 Ases (/16 prefixes)

Quantifying hit-list generation

• Gnutella crawlers on PlanetLab (thanks to Boon!)
• Harvest a huge number of IP addresses within 1 hour!

– Further growth possibly due to the degree of churn

n=1 n=10 n=5 n=20 n=15 n=25 n = number of crawlers

Quantifying hit-list generation

• Diminishing returns
• 57% of the hosts can be contacted after 1 week

Coordinated worm: Infection rate

• Vanilla implementation of coordinated worm
• 1.5x faster than random probing
• Useful during initial phases of worm propagation (~2x faster)

Random probe Coordinated

Number of failed probes

• Once our algorithm “learns” the distribution,

it out-performs random probing worm

Random probe Coordinated

Effect of imbalance in address distribution

• Summary:

– Relative performance of coordinated worm increases with increases with increase in imbalance – … number of IP addresses seen – … number of failed probes

Implementation

• Oops…

Conclusion

• Have shown how DHT technology has a

bearing on the worm vs. defense tug of war

• Possible to have much stealthier and faster

worms using DHTs.

• Have also shown that if worm is aware of

security policies, can circumvent

– Security through obscurity is no good
