Precipitation & Runoff modeling of Savinja catchment Ljubljana, 01.12.2016 Email: andrej.vidmar@fgg.uni-lj.si 1 The drainage basin hydrological cycle The drainage basin hydrological system Source:

slide-1
SLIDE 1

Precipitation & Runoff modeling

  • f Savinja catchment

Ljubljana, 01.12.2016 Email: andrej.vidmar@fgg.uni-lj.si

1

slide-2
SLIDE 2

The drainage basin hydrological cycle

Source: http://www.alevelgeography.com/drainage-basin-hydrological-system

The drainage basin hydrological system

2

slide-3
SLIDE 3

Drainage Basin Flow Chart

Source: http://www.alevelgeography.com

Lakes/ Reservoars

3

slide-4
SLIDE 4

The basic principle

4

slide-5
SLIDE 5

Which hydrological model?

  • various ongoing researches are there on topics like which model will give

more compatible results compared to P-R relations

  • HSPF, TOPMODEL, HBV, MIKE-SHE, SWAT,…

HBV-light & PEST

HBV-light: http://www.geo.uzh.ch/en/units/h2k/services/hbv-model/ PEST: http://www.pesthomepage.org/

5

slide-6
SLIDE 6

HBV - Hydrologiska Byråns Vattenbalansavdelning (Hydrological Agency Water Balance Department)

  • The HBV model (Bergström, 1976, 1992) is a rainfall-runoff model, which includes conceptual

numerical descriptions of hydrological processes at the catchment scale. The general water balance can be described as Where P = precipitation E = evapotranspiration Q = runoff SP = snow pack SM = soil moisture TZ = storage in soil top zone (introduced in HBV-light) UZ = upper groundwater zone storage LZ = lower groundwater zone storage lakes = lake volume

 

lakes LZ UZ TZ SM SP dt d

Q E P

     

 

6

Source: http://www.smhi.se/forskning/forskningsomraden/hydrologi/hbv-1.1566

slide-7
SLIDE 7

Semi-distribution

7

Subdivides a large problem into smaller, simpler parts with unique characteristic

  • Elevation zones
  • Vegetation zones
slide-8
SLIDE 8

HBV overview

8

  • The HBV model is a

simple multi-tank- type model for simulating runoff.

  • Rainfall and air temperature

data as well as estimated potential evaporation data based on the American Society of Civil Engineers Penman–Monteith method are inputs to the model, which consists of four commonly used routines: snow; soil moisture; response; and routing. Picture: Help HBV-light – An Overview of the HBV Model

slide-9
SLIDE 9

Model of Computed Runoff

9

Source: Help HBV-light – Three GW Box (Distributed STZ and SUZ) Model

slide-10
SLIDE 10

Equations Overview

Source: Help HBV-light – An Overview of the HBV Model

slide-11
SLIDE 11

Catchment Parameters

Three GW Box (Distributed STZ and SUZ) Model

slide-12
SLIDE 12

Vegetation Zone Parameters

12

Source: Help HBV-light – Parameter Overview

slide-13
SLIDE 13

Effect of TT

13

Picture: Help HBV-light

slide-14
SLIDE 14

Savinja Catchment

14

  • Enclosed Area of 1852.3 sq km
  • min_Elev_m=190.1 m
  • max_Elev_m=2429.0 m
  • avg_Elev_m=604.5 m
  • avg_Aspect=SE (127°)
  • Older_Celje_elev=~238.0 m
slide-15
SLIDE 15

Flood 1954 Savinja-Celje

15

slide-16
SLIDE 16

Jo Josephinische Landesaufnahme (1 (1763-1787)

16

slide-17
SLIDE 17

Flood 1990 Savinja-Laško

17

slide-18
SLIDE 18

Relational Hydro and Meteo Data

18

Data source: MOP -ARSO, 2015

slide-19
SLIDE 19

HIGRIS –Hydrologic Graphical IS

  • basically designed with Global Mapper and has more than 130 layers and

a lot of external links

  • GIS (Global Mapper [LiDAR], Map Window, SAGA, ILWIS, Google Earth Pro)
  • CAD (AutoCAD MAP 3D, QuickSurf, Surfer)
  • Graphic design (PhotoLine, PaintShop)
  • DB (ASCII, MS Access, PostGIS)
  • Statistic (MS Excell, Origin, Scilab)
  • Programming (SQL, PowerBasic, Python with NumPy)
  • P-R model (HBV-light_CLI, HBV-light-GUI)
  • Calibration Tools (PEST, GAP and Monte Carlo are included in HBV-light)
  • File navigation and data preview (Total Commander, IrfanView, Acrobat)

19

slide-20
SLIDE 20

Savinja 21 sub-catchments; I. model

20

slide-21
SLIDE 21

Savinja 77 sub-catchments; II. model

21

slide-22
SLIDE 22

Geology [Alluvi-Karst]

22

slide-23
SLIDE 23

Vegetation zones

23

  • 3 vegetation zones
slide-24
SLIDE 24

Elevation zones

24

  • 16 elevation zones
slide-25
SLIDE 25

Precipitation RRhour

25

  • 33 precipitation stations
slide-26
SLIDE 26

What is PEST?

26

slide-27
SLIDE 27

BeoPEST is an tool for model calibration

27

slide-28
SLIDE 28

Model Calibration

28

Source: Help HBV-light – Model Calibration

slide-29
SLIDE 29

[PTQ screen]

29

slide-30
SLIDE 30

Flood Wave Celje 18.-20.09.1007

30

slide-31
SLIDE 31

Goodnes of f Fit for calibration period - year 2007

31

Average model efficiency of Savinja River to Gračnica inflow for whole calibration period 2007 0.952 Average model efficiency for flood wave 18.-22.09.2007 0.988

slide-32
SLIDE 32

Savinja - vp Nazarje

32

0.00 100.00 200.00 300.00 400.00 500.00 600.00 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

3+4i vp Savinja - Nazarje

Series1 Series2

slide-33
SLIDE 33

Savinja - vp Letuš 1

33

100 200 300 400 500 600 700 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

5 vp Savinja -Letuš I

Series1 Series2

slide-34
SLIDE 34

Savinja – vp Medlog

34

100 200 300 400 500 600 700 800 900 1000 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

11 vp Savinja - Medlog

Series1 Series2

slide-35
SLIDE 35

Savinja – vp Celje II _ brv

35

200 400 600 800 1000 1200 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

13 vp Savinja - Celje II - brv

Series1 Series2

slide-36
SLIDE 36

Savinja – vp Laško

36

200 400 600 800 1000 1200 1400 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

19 vp Savinja - Laško

Series1 Series2

slide-37
SLIDE 37

Dreta – vp Kraše

37

0.00 50.00 100.00 150.00 200.00 250.00 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

4 vp Dreta - Kraše

Series1 Series2

slide-38
SLIDE 38

Bolska – vp Dolenja vas

38

20 40 60 80 100 120 140 160 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

10 vp Bolska - Dolenja vas

Series1 Series2

slide-39
SLIDE 39

Ložnica – vp Levec I

39

20 40 60 80 100 120 140 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

12 vp Ložnica - Levec I

Series1 Series2

slide-40
SLIDE 40

Gračnica – vp Vodiško I

40

2 4 6 8 10 12 14 17.09.2007 12:00 18.09.2007 00:00 18.09.2007 12:00 19.09.2007 00:00 19.09.2007 12:00 20.09.2007 00:00 20.09.2007 12:00

20 vp Gračnica - Vodiško I

Series1 Series2

slide-41
SLIDE 41

Goodnes of f Fit for validation period - year 1990

41

WS2 WS2_Name NS (1.10-14.11.1990) 1 Savinja do VP Solčava I 0.85 8 Dreta do VP Kraše 0.90 38 Ložnica do VP Levec I 0.94 45 Savinja do VP Celje II - brv 0.97 53 Hudinja do VP Škofja Vas 0.8 62 Voglajna do VP Celje II 0.8 67 Savinja do VP Laško 0.97 76 Savinja do VP Veliko Širje I 0.84

slide-42
SLIDE 42

Flood Wave vp Laško 26.10.-05.11.1990

42

slide-43
SLIDE 43

Savinja – vp Celje II _ brv

43

200 400 600 800 1000 1200 1400 26.10.1990 00:00:00 28.10.1990 00:00:00 30.10.1990 00:00:00 01.11.1990 00:00:00 03.11.1990 00:00:00 05.11.1990 00:00:00 07.11.1990 00:00:00 09.11.1990 00:00:00 11.11.1990 00:00:00

Savinja-Celje II - brv

Series2 Series3

slide-44
SLIDE 44

Savinja – vp Laško

44

200 400 600 800 1000 1200 1400 1600 26.10.1990 00:00:00 28.10.1990 00:00:00 30.10.1990 00:00:00 01.11.1990 00:00:00 03.11.1990 00:00:00 05.11.1990 00:00:00 07.11.1990 00:00:00 09.11.1990 00:00:00 11.11.1990 00:00:00

Savinja-Laško I

Series1 Series2

slide-45
SLIDE 45

Ložnica – vp Levec I

45

10 20 30 40 50 60 70 80 90 26.10.1990 00:00 28.10.1990 00:00 30.10.1990 00:00 1.11.1990 00:00 3.11.1990 00:00 5.11.1990 00:00 7.11.1990 00:00 9.11.1990 00:00 11.11.1990 00:00

Ložnica-Levec I

Series1 Series2

slide-46
SLIDE 46

Dreta – vp Kraše

46

50 100 150 200 250 300 26.10.1990 00:00:00 28.10.1990 00:00:00 30.10.1990 00:00:00 01.11.1990 00:00:00 03.11.1990 00:00:00 05.11.1990 00:00:00 07.11.1990 00:00:00 09.11.1990 00:00:00 11.11.1990 00:00:00

Dreta-Kraše

Series1 Series2

slide-47
SLIDE 47

Voglajna – vp Celje II

47

10 20 30 40 50 60 70 26.10.1990 00:00 28.10.1990 00:00 30.10.1990 00:00 1.11.1990 00:00 3.11.1990 00:00 5.11.1990 00:00 7.11.1990 00:00 9.11.1990 00:00 11.11.1990 00:00

Voglajna-Celje II

Series1 Series2

slide-48
SLIDE 48
  • 1. Why use a P-R modeling?
  • for education
  • for decision support
  • for data quality control
  • for water balance studies
  • for drought runoff forecasting (irrigation)
  • for fire risk warning
  • for runoff forecasting/prediction (flood warning and reservoir
  • peration)
  • for what happens if’ questions

48

slide-49
SLIDE 49
  • 2. Why use a P-R modeling?
  • to compute design floods for flood risk detection
  • to extend runoff data series (or filling gaps)
  • to compute design floods for dam safety
  • to compute energy production
  • to investigate the effects of land-use changes within the catchment
  • to simulate discharge from ungauged catchments
  • to simulate climate change effects

49

slide-50
SLIDE 50

Designed Flood Predictions

  • based on flood event 2007 (50 year return period)

24 hour Precipitation Event for Q10, Q20, Q50, Q100, Q200 and Q500

  • based on flood event 1990 and 1998 (100 year return period)

48 hour Precipitation Event for Q10, Q20, Q50, Q100, Q200 and Q500

50
