October 22, 2009 October 22, 2009 Regional Structure - Global Centers Boart Longyear Europe (BLE) Burghaun Salt Lake City Boart Longyear Americas (BLA) Boart Longyear Far East Sandton (BLFE) Peru Adelaide Boart Longyear South Africa

slide-1
SLIDE 1

October 22, 2009 October 22, 2009

slide-2
SLIDE 2

Regional Structure - Global Centers

Boart Longyear Americas (BLA) Salt Lake City Boart Longyear South Africa (BLSA) Sandton Boart Longyear Europe (BLE) Burghaun Boart Longyear Far East (BLFE) Adelaide Peru

slide-3
SLIDE 3

Flint

U.S. Locations - E & I

Salt Lake Salt Lake

Phoenix R e n

  • Atlanta

Huntsville Boston Indianapolis Little Falls/St. Cloud Wausau We service Canada & operate Internationally Seattle Portland Ocala Ocala Pensacola Ft.

  • Ft. Lauderdale

Lauderdale San Antonio Santa Fe Springs Memphis Marietta Windsor New Ellenton Yuba City Yuba City

slide-4
SLIDE 4

Boart Longyear Company

Diamond Coring & Percussive Surface Underground Drilling Products Rotary Air / Mud Reverse Circulation

Environmental & Infrastructure

slide-5
SLIDE 5

Environmental & Infrastructure Drilling Services

Speciality Contractor & Innovative Drilling Solutions 115 Years Experience Serving Environmental and Infrastructure Drilling Markets Drilling is our Business !

Drilling is our Business !

slide-6
SLIDE 6

Drilling Equipment

  • DPT (Geoprobes truck/tracked)
  • Hollow Stem Augers (truck/tracked)
  • Air/Mud Rotary (including Dual Rotary)
  • Cable Tool
  • Coring
  • Sonic (Truck/Tracked/Mini)
slide-7
SLIDE 7

Sonic Drilling Technologies Sonic Drilling Technologies

slide-8
SLIDE 8

SONIC DRILLING SONIC DRILLING

slide-9
SLIDE 9

Basic Principle of Sonic Drilling

VIBRATORY FORCE ROTARY FORCE AXIAL FORCE OR ‘FEED’ FORCE

  • E

Energy @ face of bit nergy @ face of bit achieves achieves localized d localized displacement isplacement to shear to shear and penetrate and penetrate

  • slow

slow rotation rotation to enhance to enhance vibratory effects & penetration vibratory effects & penetration

  • f hard layers
  • f hard layers
  • steady

steady down pressure down pressure to aid to aid advancement advancement

slide-10
SLIDE 10

Principles of Sonic Drilling

  • High-speed eccentric counter-rotating rollers
  • High-frequency low-amplitude mechanical vibration with

rotation & down-pressure.

  • Resonance occurs - vibrations coincide with the natural

resonate frequency of the drill string - resonant energy is delivered to and focused at the bit face.

  • Borehole advancement a result of shearing & displacement.
slide-11
SLIDE 11

Basic Principle of Sonic Drilling

slide-12
SLIDE 12

How Does Sonic Deliver Your Subsurface Information?

slide-13
SLIDE 13

Core Barrel Advancement - Sonic

slide-14
SLIDE 14

Sonic Core Barrel Advancement

slide-15
SLIDE 15

Casing Over Drilling Process

slide-16
SLIDE 16

Sonic Sample Extraction

slide-17
SLIDE 17
  • Speed

 2-4 times faster than conventional drilling

  • Superior Information (continuous core sample)

 Lithology/geochemistry/hydrogeology

  • Waste Minimization

 ~ 70% less IDW than conventional drilling methods due to cased hole  Ability to ”dry ” drill

  • Better Well Construction

 Less development time/better yield

  • Safer and Cleaner

 No flights – just smooth drill tooling  Elevated platform

  • No refusal

 Drills through cobbles, boulders, & hard layers/lenses  Great for heaving sands

  • Reduced Risk for Mistakes

 Better info to make decisions

 Angle wells/multi-cased wells w/o leaving casing in ground

Why Use Sonic?

slide-18
SLIDE 18

Sonic Benefit - Fast

  • 2- 4 times faster than HSAs when sampling
  • Advances at rates up to 1’/ second drilling

friendly formations

  • Automated rod make up and break out –

enhances speed & safety

  • Reduces Site Time - lowers project cost for

your client (compressed time line), lower management cost, lower per diem cost, reduced down time of an operational site

slide-19
SLIDE 19

Sonic Benefit – Sample Quality

  • Clearly displays lithology in

delicate, hard-to-recover material – Sample quality is basis of your remedial strategies

  • Samples virtually any
  • verburden formation or
  • bstruction
slide-20
SLIDE 20

Sonic Benefit - Remarkable Sampling & Recovery

  • Overburden
  • Cement Rebar (reinforced)
  • Rip-Rap
  • Sands
  • Gravels
  • Cobbles
  • Boulders
  • Bricks
  • Wood
  • Tires
  • Compacted Garbage
  • Slag Piles
  • Bedrock
  • Steel - Train Rails
  • Delicate Formations
slide-21
SLIDE 21

Sonic Samples

slide-22
SLIDE 22

Samples Delicate Soils & Hard-rock Interfaces

slide-23
SLIDE 23

Sonic Samples

Till 6” Granite

slide-24
SLIDE 24

Modeling Applications

slide-25
SLIDE 25

Sonic Samples - Aggregates

slide-26
SLIDE 26

Gas Station Sample - Drilled dry

slide-27
SLIDE 27

Sonic Sample - Hard Clay

slide-28
SLIDE 28

Penetrates Reinforced Concrete

slide-29
SLIDE 29

Sonic Sample - Steel Train Rail

slide-30
SLIDE 30

Sonically Cored Conglomerate

slide-31
SLIDE 31

Hard Rock Sample Diamond Cored using Speed increaser on Sonic Drill

slide-32
SLIDE 32

Acrylic Liners – Carolina Coastal Studies

slide-33
SLIDE 33

Split Barrel Sample -

slide-34
SLIDE 34

Telescoping Capability

  • Sample Sizes – 3,4,5,6,7 and 8 inch
  • Casing Sizes - 5,6,7,8,9,10, and 12 inch
slide-35
SLIDE 35

Sonic Drilling Platforms

slide-36
SLIDE 36

Sonic Truck Drills

slide-37
SLIDE 37

Full-Size Sonic Drills

slide-38
SLIDE 38

Off Road – Full size All Terrain Vehicle (ATV)

slide-39
SLIDE 39

Off Road – ATV to access most sites

slide-40
SLIDE 40

“Pre-collaring Pre-collaring” ” Diamond Diamond Core Core Holes Holes

  • Drill Through Difficult

Overburden Materials (glaciated tills, high permeability formations, flowing sands, etc)

  • Low Water Use

Required

  • Angle Drilling

Installations

  • Extremely straight

hole drilled due to “guided” system of Coring / Casing

slide-41
SLIDE 41

Inside Building – Small Footprint

slide-42
SLIDE 42

Inside Building - Compact footprint & ability to sample soil and rock

with same drill

slide-43
SLIDE 43

Maneuverable in tight spots

slide-44
SLIDE 44

Barge Work – lagoons, lake, river & ocean bottoms

slide-45
SLIDE 45

Sonic Benefit - Clean Site

slide-46
SLIDE 46

Multiple Programs – One Rig

Demonstrating a wide variety of our capabilities with Sonic

Shelby Tube Sampling

Deeper, larger diameter, targeting ʻfeaturesʼ, sleeve ports, barrier bags

Split Spoon Sampling Grout Borings

slide-47
SLIDE 47

How Will Sonic Benefit Your Project?

slide-48
SLIDE 48

Sonic Benefit – Minimizes IDW

  • Cuttings are expensive to dispose of

and require time & dollars to characterize them

  • Sonic drilling reduces the amount of

Investigative Derived Waste (IDW) by 70 – 80% compared with Hollow Stem Auger or Rotary Drilling operations.

slide-49
SLIDE 49

Sonic – Minimizes Bridging

slide-50
SLIDE 50

Water Sampling – Vertical Profile Aquifer

slide-51
SLIDE 51

Vertical Water Profiling

slide-52
SLIDE 52

Sonic Applications

  • Contaminated Soil and Groundwater Investigations
  • Plume Delineation – Vertical Aquifer Profiling
  • Monitor Well/Recover Well Installation
  • Air Sparge Installations
  • Remedial Injections
  • Deep Earth Dam and Levee Investigative Sampling
  • Karst Formation Exploration
  • Landfill Investigations/Expansion
  • MGP site characterizations
slide-53
SLIDE 53

Sonic Applications

  • Mine Tailings – Coal Bing Investigations
  • Freeze Hole Boring – Earth Stabilization
  • Quantification of Aggregate Resources
  • Micro-Pile Installation
  • Earth Anchors Installation
  • Grout Verification Sampling
  • Sampling of Soil Mixing Applications
  • Grouting -- Grout Curtain Installation
slide-54
SLIDE 54

Additional - Sonic Benefits

  • Angle Borings (Up to 22 Degrees from Horizontal)
  • Standard penetration test (Automatic Hammer)
  • Shelby Tubes
  • Dennison Samples
  • Piston Samplers
  • Pressure Meter Testing
  • Geophysical Logging
  • CMT Wells
  • FLUTe Liners
  • Multiple Casing installations
  • Excellent for Nested Well installations
slide-55
SLIDE 55

Angle Boring

slide-56
SLIDE 56

Multi-cased Wells - Sonic

slide-57
SLIDE 57

Sonic Value – Superior Information

  • Complete accurate geological information – Enables precise site

investigations

  • Visibility of delicate formations – Recovers delicate sand seams

and other easily altered geology

  • Penetrates Faster – Compresses time line – reduces overhead and

management cost

  • Drills Deep – To define lower contamination boundaries – such as

Chlorinated Solvents

  • Drills & Samples toughest geology without refusal
  • Drills Dry - Avoiding sample bias & cross contamination
slide-58
SLIDE 58
  • Speed

 2-4 times faster than conventional drilling

  • Superior Information (continuous core sample)

 Lithology/geochemistry/hydrogeology

  • Waste Minimization

 ~ 70% less IDW than conventional drilling methods due to cased hole  Ability to ”dry ” drill

  • Better Well Construction

 Less development time/better yield

  • Safer and Cleaner

 No flights – just smooth drill tooling  Elevated platform

  • No refusal

 Drills through cobbles, boulders, & hard layers/lenses  Great for heaving sands

  • Reduced Risk for Mistakes

 Better info to make decisions

 Angle wells/multi-cased wells w/o leaving casing in ground

Why Use Sonic?

slide-59
SLIDE 59

Safety and Training

SAFETY AND TRAINING _ We are an ISO 14001 company which means we are trained to lower environmental risks

  • n each project we undertake. Boart Longyear has attained ISO 14001 and ISO 18001 certification.

Boart Longyear is committed to safety; it’s our number one priority, as we have determined that efficiency and production go hand in hand. Comprehensive, ongoing training and surveillance program that is second to none. We employ safety officers focused

  • n our Behavior Based Safety (BBS) system to ensure regular reviews of all crews with a continuous circle of

modification and improvement.
