NRG Energy Indian River Power NRG Energy Indian River Power Plant Plant Center for the Inland Bays Citizen Advisory Center for the Inland Bays Citizen Advisory Committee Meeting January 17, 2019 Committee Meeting January 17, 2019

SLIDE 1

NRG Energy – Indian River Power Plant

Center for the Inland Bays Citizen Advisory Committee Meeting January 17, 2019

NRG Energy – Indian River Power Plant

Center for the Inland Bays Citizen Advisory Committee Meeting January 17, 2019

Alison Kiliszek, Engineer Delaware Department of Natural Resources and Environmental Control Solid and Hazardous Waste Management Section Alison Kiliszek, Engineer Delaware Department of Natural Resources and Environmental Control Solid and Hazardous Waste Management Section

SLIDE 2

SLIDE 3

Phase I (~38 acres) Active 1981 - 2014 Phase II (~26 acres) Active 2010 - present Leachate Accumulation Tanks Southwest Stormwater Basin Northern Stormwater Basin

SLIDE 4

Phase I (~38 acres) Active 1981 - 2014 Phase II (~26 acres) Active 2010 - present Geosynthetic Liner System Leachate Collection System Geosynthetic Cap to be installed upon closure Waste fully encapsulated upon final closure Unlined No Leachate Collection System Geosynthetic Cap Installed Top of waste encapsulated

SLIDE 5

Federal Coal Combustion Residual (CCR) Rule Federal Coal Combustion Residual (CCR) Rule

 Published in April 2015  Required CCR Landfills/Surface Impoundments to adhere to regulations similar to Municipal Solid Waste Landfills  Required a determination of background and/or statistically significant increases in a number of constituents in groundwater  Published in April 2015  Required CCR Landfills/Surface Impoundments to adhere to regulations similar to Municipal Solid Waste Landfills  Required a determination of background and/or statistically significant increases in a number of constituents in groundwater

SLIDE 6

Periodic Monitoring Frequency Periodic Monitoring Frequency

 Groundwater: Semi-Annual in April and October

Quarterly 2015-2017 for Federal CCR Rule

 Surface Water: Semi-Annual in April and October  Stormwater: Twice per year and at least four (4) months apart  Groundwater: Semi-Annual in April and October

Quarterly 2015-2017 for Federal CCR Rule

 Surface Water: Semi-Annual in April and October  Stormwater: Twice per year and at least four (4) months apart

SLIDE 7

3 3 1 4 1 1 1 3 1 3 3 1 1 1 1

Surface Water Locations Groundwater Locations

Stormwater Locations

SLIDE 8

Monitoring Result Influences Monitoring Result Influences

 Seasonal influences  Tidal influences  Surface Water and Groundwater Interface influences  Seasonal influences  Tidal influences  Surface Water and Groundwater Interface influences

SLIDE 9

Monitored Parameters Monitored Parameters

Alkalinity Antimony Arsenic Barium Beryllium Boron Cadmium Calcium Chloride Chromium Cobalt Copper* Fluoride Iron Lead Lithium Magnesium Manganese Mercury Molybdenum pH Potassium Radium 226 & 228 Selenium Sodium Sulfate Thallium TDS TOC

2010 X X X X X X X X X X X X X X X 2011 X X X X X X X X X X X X X X X 2012 X X X X X X X X X X X X X X X 2013 X X X X X X X X X X X X X X X 2014 X X X X X X X X X X X X X X X 2015 X X X X X X X X X X X X X X X X X X X X X X X X X X X X X 2016 X X X X X X X X X X X X X X X X X X X X X X X X X X X X X 2017 X X X X X X X X X X X X X X X X X X X X X X X X X X X X 2018 X X X X X X X X X X X X X X X X

* NOT REQUIRED BY PERMIT OR EPA

SLIDE 10

Periodic Monitoring Reporting Periodic Monitoring Reporting

 Groundwater, Surface Water, and Stormwater Monitoring results are reported to the Department within sixty (60) days of sampling event  An updated hydrogeological report is submitted annually  Groundwater Background Report submitted November 2017 for Federal Coal Combustion Residual Rule  Groundwater, Surface Water, and Stormwater Monitoring results are reported to the Department within sixty (60) days of sampling event  An updated hydrogeological report is submitted annually  Groundwater Background Report submitted November 2017 for Federal Coal Combustion Residual Rule

SLIDE 11

Plot of Select Parameters Plot of Select Parameters

SLIDE 12

0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16 0.18 0.2 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Arsenic (mg/L)

MCL Phase I Capped Total Metals

326B 103C 103CR 103A 326C 327A

SLIDE 13

0.01 0.02 0.03 0.04 0.05 1/1/2016 3/31/2016 6/29/2016 9/27/2016 12/26/2016 3/26/2017 6/24/2017 9/22/2017 12/21/2017 3/21/2018 6/19/2018 9/17/2018 12/16/2018

Arsenic (mg/L) (focus on 2016 – 2018 data only)

MCL Phase I Capped Total Metals

326B 103C 103CR 103A 326C 327A

SLIDE 14

0.001 0.002 0.003 0.004 0.005 0.006 0.007 0.008 0.009 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Beryllium (mg/L) (CCR Rule only)

MCL Phase I Capped Total Metals

103A 327A

SLIDE 15

5 10 15 20 25 30 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Boron (mg/L) (CCR Rule to present)

Phase I Capped Total Metals

SLIDE 16

0.01 0.02 0.03 0.04 0.05 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Cobalt (mg/L) (CCR Rule only)

Phase I Capped Total Metals

SLIDE 17

0.5 1 1.5 2 2.5 3 3.5 4 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Lithium (mg/L) (CCR Rule only)

Phase I Capped Total Metals

103C 103CR 327C 103B 327B

SLIDE 18

0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Manganese (mg/L)

SDWS Phase I Capped Total Metals

SLIDE 19

0.0005 0.001 0.0015 0.002 0.0025 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Mercury (mg/L) (Analysis Ceased 2018)

MCL Phase I Capped Total Metals

P-1R 2.1 mg/L on 10/10/2013 on AshTracker was Turbidity. 10/10/2013 Mercury value was <0.0005 mg/L

SLIDE 20

1 2 3 4 5 6 7 8 9 10 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Molybdenum (mg/L) (CCR Rule only)

Phase I Capped Total Metals

103C 103CR 327C 103B 327B 326C

SLIDE 21

0.05 0.1 0.15 0.2 0.25 0.3 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Selenium (mg/L)

MCL Phase I Capped Total Metals

103A 326C

SLIDE 22

500 1000 1500 2000 1/1/2010 9/8/2010 5/16/2011 1/21/2012 9/27/2012 6/4/2013 2/9/2014 10/17/2014 6/24/2015 2/29/2016 11/5/2016 7/13/2017 3/20/2018 11/25/2018

Sulfate (mg/L)

SDWS Phase I Capped Total Metals

SLIDE 23

Compliance History 2010 - present Compliance History 2010 - present

 April 15, 2014 NOV – temporary interior slopes not compliant with operations plan

 RTC January 9, 2014 (compliance achieved prior to NOV being issued)

 December 9, 2014 NOV – failure to conduct hazardous waste determination

 RTC October 29, 2014 (compliance achieved prior to NOV being issued)

 February 15, 2017 LOW – prohibited waste accumulated in Phase II

 RTC March 14, 2017

 April 15, 2014 NOV – temporary interior slopes not compliant with operations plan

 RTC January 9, 2014 (compliance achieved prior to NOV being issued)

 December 9, 2014 NOV – failure to conduct hazardous waste determination

 RTC October 29, 2014 (compliance achieved prior to NOV being issued)

 February 15, 2017 LOW – prohibited waste accumulated in Phase II

 RTC March 14, 2017

SLIDE 24

Looking Toward the Future… Looking Toward the Future…

 Rising sea level has the potential to impact the landfill units

 Seasonal influences  Tidal influences  Surface Water and Groundwater Interface influences

 Monitoring is expected to occur until the end of the Post-Closure Care period  Rising sea level has the potential to impact the landfill units

 Seasonal influences  Tidal influences  Surface Water and Groundwater Interface influences

 Monitoring is expected to occur until the end of the Post-Closure Care period
