Investigation of the NRG #40 Anemometer Slowdown Steven Clark, Mechanical Engineer NRG Systems, Inc. AWEA WINDPOWER Conference and Exhibition 2009 Chicago, IL May 4-7, 2009 Global Leader in Wind Measurement Technology www.nrgsystems.com

slide-1
SLIDE 1

www.nrgsystems.com

Global Leader in Wind Measurement Technology

Investigation of the NRG #40 Anemometer Slowdown

Steven Clark, Mechanical Engineer

NRG Systems, Inc.

AWEA WINDPOWER Conference and Exhibition 2009 Chicago, IL May 4-7, 2009

slide-2
SLIDE 2

Page 2 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Outline

History Problem Definition Investigation Highlights Outcome of Investigation Design Validation Conclusions

Global Leader in Wind Measurement Technology

slide-3
SLIDE 3

Page 3 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

History

February 2007 – customer informed NRG Systems some #40s were exhibiting “drag” November 2007 – Received 12 sensors from field for engineering evaluation Intensive investigation into the #40 sensor – Feb „08 Laboratory and data analyses now reveal that a portion of the population of the NRG #40 sensors dating back to the middle of 2006 exhibit slowdown

– Affected sensors all passed initial calibration – Affected sensors exhibit slowdown within 2-26 weeks Global Leader in Wind Measurement Technology

slide-4
SLIDE 4

Page 4 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Problem Definition

Sensor slow-down is defined by:

  • 1. Excess scatter:
  • Qualitative by sensor pair scatter plots
  • Quantitative by sensor pair statistics
  • 2. Performance change in time
  • Calibration values

Global Leader in Wind Measurement Technology

slide-5
SLIDE 5

Page 5 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Problem Definition

Excess scatter - Qualitative by scatter plots

Global Leader in Wind Measurement Technology

slide-6
SLIDE 6

Page 6 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Problem Definition

Sensor slow-down is defined by:

  • 1. Excess scatter:
  • Quantitative by sensor pair statistics

Global Leader in Wind Measurement Technology

Statistic Expected normal performance Mean bias ≤ ±0.2 m/s Ratio Within 0.98-1.02 Correlation coefficient ≥ 0.995 Standard deviation of the wind speed ratio ≤ 0.02

slide-7
SLIDE 7

Page 7 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Problem Definition

Problem of sensor slow-down is defined by:

  • 2. Performance change in time
  • Change in wind tunnel calibration results

– Abnormal residual pattern AND – Standard Error is greater than 0.12 AND – Offset increase > 0.15 m/s from initial calibration Global Leader in Wind Measurement Technology

slide-8
SLIDE 8

Page 8 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Problem Definition

Global Leader in Wind Measurement Technology

Initial calibration with normal residual pattern

Residual: Reference WS – Transfer Function WS 4 m/s – (0.757*5 Hz + 0.36) = -0.14

Post calibration with abnormal residual pattern

slide-9
SLIDE 9

Page 9 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Global Leader in Wind Measurement Technology

Naming Convention Manufacturing Date

Pre-2006 Before middle of 2006 Post-2006 After middle of 2006 and before January 1, 2009 Post-1/1/2009 After January 1, 2009 (manufactured with design improvement)

slide-10
SLIDE 10

Page 10 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Dimensional analysis between normal and affected sensors showed no obvious dimensional differences Intensive review of affected sensors revealed visual signature termed “spirograph” motion

Global Leader in Wind Measurement Technology

slide-11
SLIDE 11

Page 11 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Global Leader in Wind Measurement Technology

Investigation Highlights

Vibration mode – “spirograph”

slide-12
SLIDE 12

Page 12 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Quantified spirograph motion using video and accelerometers

  • GE Bently-Nevada validated NRG-developed

vibration measurement system

Associated visual spirograph with vibration

– Vibration signature correlated to slowdown and termed “vibratory mode” – Verified “vibratory mode” in lab and field

Global Leader in Wind Measurement Technology

slide-13
SLIDE 13

Page 13 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Global Leader in Wind Measurement Technology

Investigation Highlights

Vibration signature and correlation to slowdown

slide-14
SLIDE 14

Page 14 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Global Leader in Wind Measurement Technology

Investigation Highlights

Vibration signature and correlation to slowdown

Peak power difference (previous plots at 12 m/s)

slide-15
SLIDE 15

Page 15 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Boom/sensor interaction

Studied boom/sensor interaction (ie., external excitation)

– Booms not root cause of vibratory mode

  • Contribute to the „dynamic system‟ that initiates the

sensor vibratory mode

– Source of vibration sensor-borne

Global Leader in Wind Measurement Technology

Stem mount 2.4 m boom

slide-16
SLIDE 16

Page 16 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Spinning bearing hypothesis

Observed lower and upper bearings rotate during vibratory mode

– Determined spinning bearing is a symptom, not a cause,

  • f the vibration

– Securing the lower bearing in an affected sensor exacerbated the problem

Measured upper and lower radius-to-clearance ratio in normal and affected sensors

– Determined to be poor predictor of performance (R2 ~ 0)

Global Leader in Wind Measurement Technology

slide-17
SLIDE 17

Page 17 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Vibration characteristics

Characteristics of the slowdown due to vibratory mode (based on wind tunnel results):

  • 0.2 m/s – 0.6 m/s slow-down when in mode
  • Preferentially occurs at 5-10 m/s wind speeds
  • Can sustain in mode for long periods of time
  • Can enter and exit mode
  • Onset of mode occurs more often in decelerating speeds

than in constant or accelerating speeds

Global Leader in Wind Measurement Technology

slide-18
SLIDE 18

Page 18 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Investigated self-excited vibratory phenomena Retained rotor dynamic experts to help identify specific vibratory mode

  • Dr. Dara Childs (Texas A&M)
  • Dr. Fred Ehrich (MIT)

Identified vibratory mode as Dry Friction Whip (DFW) via its properties:

– Self-excited – Super-synchronous – Asynchronous – Counter-rotating whip direction

Global Leader in Wind Measurement Technology

slide-19
SLIDE 19

Page 19 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Investigation Highlights

Focused investigation on published causes of DFW:

1. Friction above a minimum threshold 2. Friction above lower threshold and:

a) Excessive bearing clearances and/or b) Similarity of rotor/stator natural frequency Global Leader in Wind Measurement Technology

Confirmed friction is a necessary but not sufficient condition to cause DFW Bearing clearances not a factor (R2~0)

slide-20
SLIDE 20

Page 20 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Outcome of Investigation

Global Leader in Wind Measurement Technology

Guided by theory that similarity in rotor/stator natural frequency can cause DFW Searched for design changes that could impact rotor or stator natural frequency

– In-spec dimensional change in mid-2006 to Well ID

Small dimensional and material property changes to stator govern sensor response to DFW

slide-21
SLIDE 21

Page 21 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab verifications of new Post-1/1/2009 sensor Global Leader in Wind Measurement Technology

Design-of- Experiment (DOE) of design space

slide-22
SLIDE 22

Page 22 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Outcome of Investigation

Global Leader in Wind Measurement Technology

Root cause of sensor slowdown is dry friction whip (DFW) Causes of DFW in NRG #40 anemometer:

  • Friction is a necessary but not sufficient condition
  • Heuristically DFW is well understood – can instigate or

eliminate DFW on command

  • Theoretical mechanism of sufficient condition under

investigation:

– 8 degree-of-freedom (DOF), 2 contact point mathematical model derived – Numerical analysis underway

slide-23
SLIDE 23

Page 23 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Global Leader in Wind Measurement Technology

Validation of Design Fix:

–Lab verification –Field validation

slide-24
SLIDE 24

Page 24 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab Verifications of new Post-1/1/2009 sensor Global Leader in Wind Measurement Technology

One Factor at a Time (OFAT) and Design-of- Experiments (DOE) of design space (extreme dimensional limits, exploratory tests) Run-in of old Post 2006 and new Post-1/1/2009 sensors Extensive wind tunnel testing (at NRG Systems and OTECH Engineering, Inc.)

  • Confirmed dry friction whip cause of abnormal residual

pattern

  • Confirmed that modifying an affected sensor corrects

calibration results

slide-25
SLIDE 25

Page 25 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Global Leader in Wind Measurement Technology

Design Validation

Lab Verification – NRG Wind Tunnel Testing

slide-26
SLIDE 26

Page 26 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab Verification – OTECH Wind Tunnel Testing Global Leader in Wind Measurement Technology

Stock Sensor - vibe mode present at speeds 12,14,10,6 m/s Vibratory mode present

slide-27
SLIDE 27

Page 27 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab Verification - OTECH Wind Tunnel Testing Global Leader in Wind Measurement Technology

Same sensor with well ID and o-ring fix - vibe mode absent

slide-28
SLIDE 28

Page 28 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab Verification - OTECH Wind Tunnel Testing Global Leader in Wind Measurement Technology

Stock Sensor - vibe mode present at Speeds 12,14,10,6 m/s Abnormal residual pattern present

12 14 10 6 14 10 6 12

slide-29
SLIDE 29

Page 29 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Lab Verification - OTECH Wind Tunnel Testing Global Leader in Wind Measurement Technology

Same sensor with well ID and o-ring fix- vibe mode and abnormal residual pattern absent

slide-30
SLIDE 30

Page 30 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Field Validation

Global Leader in Wind Measurement Technology

slide-31
SLIDE 31

Page 31 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Field Validation

Global Leader in Wind Measurement Technology

Participants in field test campaign include AWS Truewind, Garrad Hassan, DNV-GEC, Genivar, GPCo, KB Energy, NRG Systems Field time: 10-20 weeks as of April 17, 2009 122 new Post-1/1/2009 sensors deployed

– 52 pairs – 18 single sensors paired with other sensors

slide-32
SLIDE 32

Page 32 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Field Validation Global Leader in Wind Measurement Technology

Field Performance

  • No. of Sensors

Scatter Statistics 96 Normal Normal 1 Inconsistent Normal 1 Inconsistent Bias (-0.2 m/s) Total = 98

  • No. of Sensors

Status 98 Sufficient data 24 Insufficient data due to icing Total = 122

slide-33
SLIDE 33

Page 33 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Field Validation – Performance Summary

Global Leader in Wind Measurement Technology

6 Post-2006 sensors field tested concurrently

  • Field time: 17-20 weeks as of April 17, 2009
  • 5 sensors exhibit excess scatter
slide-34
SLIDE 34

Page 34 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Design Validation

Field Validation – Initial Post Calibration Results

Global Leader in Wind Measurement Technology Sensor Scatter Statistics Post-Cal Vibratory mode Post-2006 Excess Ratio SD high Poor Present Post-2006 Excess Ratio SD high Poor Present Post-1/1/2009 Normal Normal Normal Absent Post-1/1/2009 Normal Normal Normal Absent

Pair Pair

4 sensors post calibrated

  • Pair of Post-2006 sensors; Pair of Post-1/1/2009 sensors
  • Field time: 8 weeks
slide-35
SLIDE 35

Page 35 AWEA WINDPOWER 2009 CHICAGO, IL MAY 4-7, 2009

Conclusions

Root cause of sensor slowdown is dry friction whip Design improvement has eliminated dry friction whip and the associated slowdown Manufacturing and shipping new sensor as

  • f :

– January 1, 2009 – SN 95000 transition

Global Leader in Wind Measurement Technology
