N.C. Department of Transportation Condition Assessment and Funding Needs for North Carolinas Highway System Report to the Joint Legislative Transportation Oversight Committee December 14, 2010 Lacy D. Love, PE Biennial Report on

slide-1
SLIDE 1

Report to the Joint Legislative Transportation Oversight Committee December 14, 2010 Lacy D. Love, PE Condition Assessment and Funding Needs for North Carolina’s Highway System

N.C. Department of Transportation

slide-2
SLIDE 2

Biennial Report on Maintenance Requirements

G.S. 136-44.3 Requires NCDOT to:

  • Establish Performance Standards
  • Project an annual cost to meet and sustain the performance

standards for routine maintenance and operations

  • Develop a cost for Pavement and Bridge Preservation
  • Develop a cost for Pavement and Bridge Rehabilitation
  • Project System Condition at optimal funding for 7 years
slide-3
SLIDE 3
  • 79,185 road miles
  • 160,630 paved lane miles
  • 4,592 miles of unpaved roads
  • 18,205 structures
  • 88.1 M square feet bridge deck area
  • 8,900 signals

North Carolina State Highway System 2009

slide-4
SLIDE 4

North Carolina Freight Movement

In 2007:

  • 281 million tons moved across N.C.

annually

  • 770,000 tons per day

In 2030:

  • Expect more than 324 million tons to

be moved across N.C. annually

  • 15% increase
slide-5
SLIDE 5

Highway System Usage

(Vehicle Miles Traveled)

Growth

0% 5% 10% 15% 20% 25% 30% 2 2 2 2 4 2 6 2 8 2 1 2 1 2 2 1 4 2 1 6 2 1 8 2 2

slide-6
SLIDE 6

History of Routine Maintenance Funding

Millions

$0 $100 $200 $300 $400 $500 $600 $700 $800 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 Year Allocation CPI Adjusted

$292.0 million $83.0 million

slide-7
SLIDE 7

History of Resurfacing Funding

$0 $50 $100 $150 $200 $250 $300 $350 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 Year Allocation CPI Adjusted

Millions

$186.0 million $86.0 million

slide-8
SLIDE 8

Policy to Projects Framework

N.C. Transportation Plan (20 Year)

  • Documents mission, goals, objectives, and strategies
  • Guides investment decisions

NCDOT Program and Resource Plan (10 Year)

  • Allocates funds for all programs (Highway, Rail, Aviation, Public

Transportation, Ferry, Bicycle and Pedestrian, etc.)

  • Projects ranked (prioritized) based on data
  • Includes realistic STIP

NCDOT Work Program (5 Year)

  • Comprehensive list of projects, programs and services
  • Reliable and fiscally constrained
  • 95% delivery rate
slide-9
SLIDE 9

Performance Based Management

Benefits include:

  • Moving towards uniformly constructed, maintained and
  • perated Highway System
  • Data driving decision making
  • Increased focus on preventive maintenance
  • Targeting Level Of Service by system
  • Highest and best use of resources
  • Challenging and rewarding workplace
  • Accountability
slide-10
SLIDE 10

Performance Measures

Sets clearly defined outcomes such as:

  • No unsealed cracks in pavements
  • Bridge decks rating in good condition
  • No pipes blocked or damaged
  • Pavement markings visible at night

Since 2008:

  • Reviewed targets to ensure accuracy
  • Made modifications as necessary
  • Simplified and streamlined
slide-11
SLIDE 11

Transportation Reform:

Measuring Performance

slide-12
SLIDE 12

Rating the Condition of the Highway System

Pavement Condition Survey Bridge Condition Maintenance Condition Survey Survey

slide-13
SLIDE 13

Maintenance Condition Survey Results

2010 State Average 2010 State Average 2010 State Average FEATURE ELEMENT PERFORMANCE MEASURE Target Score Target Score Target Score Unpaved Shoulders No drop-offs greater than 3" and no shoulder higher than 2" 95 91 90 89 85 91 Ditches No blocked or eroded ditches 95 98 90 94 85 94 Crossline Pipe (Blocked) Greater than 50% diameter open 95 87 90 78 85 74 Crossline Pipe (Damaged) No damage or structural deficiency 95 93 90 95 85 91 Curb & Gutter (Blocked) No obstruction > 2" for 2 feet 95 97 90 96 85 96 Boxes (Blocked or Damaged) Not blocked > 50%, damaged or broken 95 82 90 87 85 85 Vegetation (Brush & Tree) Cleared to Freeway and Non-Freeway standards 90 90 85 85 80 80 Vegetation (Turf Condition) Areas free of erosion 95 84 90 83 85 86 Stormwater Devices (NPDES) Functioning as designed 90 94 90 94 90 94 Landscape Plant Beds Minimum condition score of 2 90 90 80 90 N/A N/A Rest Areas & Welcome Ctrs Condition rating of 90 90 96 90 95 N/A N/A Long Line Pavement Markings Present, visible 90 93 85 90 80 81 Words and Symbols Present, visible 90 73 85 85 80 77 Pavement Markers Present and reflective 90 84 85 59 N/A N/A Ground Mounted Signs Visible and legible 90 94 85 91 85 85 Overhead Signs Visible and legible 92 93 85 80 85 100 NBIS Culverts Condition rating ≥ 6 85 86 85 86 85 89 Non-NBIS Culverts Condition rating = Good 80 84 80 74 80 56 Overhead Sign Structure Condition rating = Good 95 95 95 93 95 88 Totals 91.27 89.79 87.28 86.04 84.49 85.04 Interstate Primary Secondary Roadway DRAINAGE ROADSIDE TRAFFIC BRIDGE

slide-14
SLIDE 14

Performance Measure Trends

(Maintenance Condition Survey Results)

slide-15
SLIDE 15

Pavements

slide-16
SLIDE 16

Pavement Preservation

  • Seals off pavement surface
  • Reconditions underlying

asphalt

  • Refreshes driving surface

Treatments include:

  • Crack sealing
  • Chip seals
  • Slurry pavement
  • Micro-surfacing
slide-17
SLIDE 17

Contract Resurfacing

  • Provides renewed

driving surface

  • Improves ride quality
  • Reduces patching and

frequent maintenance

slide-18
SLIDE 18

Pavement Rehabilitation

  • Restores pavement condition
  • Increases pavement structure

Treatments include:

  • Mill and replace
  • Overlay with thicker lifts
slide-19
SLIDE 19

Pavement Condition 2000 - 2010

10 20 30 40 50 60 70 80 90 2000 2002 2004 2006 2008 2010 Percent Target PCT_GOOD PCT_FAIR PCT_POOR

Interstate Primary

10 20 30 40 50 60 70 80 90 2000 2002 2004 2006 2008 2010 Percent Target PCT_GOOD PCT_FAIR PCT_POOR

10 20 30 40 50 60 70 80 2000 2002 2004 2006 2008 2010 Percent Target PCT_GOOD PCT_FAIR PCT_POOR

10 20 30 40 50 60 70 80 90 2000 2002 2004 2006 2008 2010 Year Percent Target PCT_GOOD PCT_FAIR PCT_POOR

Secondary Total

slide-20
SLIDE 20

Bridges

slide-21
SLIDE 21

Bridge Management Comprehensive Strategy

  • Bridge Preservation

For bridges in good to fair condition

  • Bridge Rehabilitation

For bridges in fair to poor condition

slide-22
SLIDE 22

Bridge Preservation

  • Painting Structural Steel
  • Cleaning Bearings
  • Repair and Replace Expansion Joints
  • Apply Material to Slow Corrosion
  • Waterproofing and Resurfacing Decks
slide-23
SLIDE 23

Bridge Rehabilitation

  • Restore Bridge Components
  • More Expensive than Preservation
  • Cost Effective on some bridges
slide-24
SLIDE 24

Bridge Condition Survey Results

82 80 81 85 91 90 Concrete Piers 81 80 84 85 91 90 Steel Pile 81 80 75 85 80 90 Concrete Pile 42 80 40 85 NA 90 % of substructure rated greater than or equal to 6 Timber Substructure 69 80 43 85 NA 90 Timber 94 80 95 85 96 90 P/S Concrete 81 80 82 85 89 90 Steel 65 80 60 85 81 90 % of superstructure rated greater than or equal to 6 Concrete Superstructure 33 75 50 80 NA 85 Open Grid Steel 84 75 71 80 NA 85 Steel Planks 88 75 86 80 NA 85 Timber 84 75 79 80 85 85 % of decks rated greater than or equal to 6 Concrete Bridge Deck State Average Score 2010 Target State Average Score 2010 Target State Average Score 2010 Target PERFORMANCE MEASURE ELEMENT Secondary Primary Interstate Bridges

slide-25
SLIDE 25

10 20 30 40 50 60 70 80 2000 2002 2004 2006 2008 2010 P e rc e n t TARGET PCT_GOOD

10 20 30 40 50 60 70 80 2000 2002 2004 2006 2008 2010 TARGET PCT_GOOD

Bridge Condition 2000 – 2010

Interstate Secondary Total

10 20 30 40 50 60 70 80 90 100 20 00 20 02 2 00 4 2 00 6 20 08 2 010 TARGET PCT_GOOD

10 20 30 40 50 60 70 80 90 2 000 2002 2004 200 6 2008 2010 TARGET PCT_GOOD

Secondary All Systems Primary

slide-26
SLIDE 26

Highway Operations

  • 8900 Traffic Signals Statewide
  • Signal maintenance provides:

Improved safety Reduction in delays Reduced fuel consumption Improved air quality

slide-27
SLIDE 27

Highway Operations

  • Overhead dynamic message boards
  • Camera systems
  • Speed detection devices
  • Motorist Assistance Patrol
slide-28
SLIDE 28

Infrastructure Health Index

  • Calculates an overall system score
  • Measures NCDOT’s success for maintaining and

improving the health of the highway network Weights asset categories

  • 25% for roadsides features
  • 35% for bridges
  • 40% for pavements
slide-29
SLIDE 29

Infrastructure Health Index

0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 INTERSTATE PRIMARY SECONDARY COMPOSITE System Score Target Actual

slide-30
SLIDE 30

American Reinvestment & Recovery Act of 2009 (ARRA)

  • $735 million for North Carolina Highways and bridges
  • Required to obligate 50% of funds within 120 days
  • Required to obligate remainder of funds within 1 year
  • $584 million of projects affect roadway and bridge maintenance

Expended $393 million to date

slide-31
SLIDE 31

Interstate Maintenance Preservation Program (IMPP)

  • Strategy of cost effective treatments
  • Designed to extend the life of

bridges, pavements, and roadside features Not intended to increase structural

  • r traffic capacity $10 million per year
slide-32
SLIDE 32

Alternate Funding (millions)

TIP Funds

  • Signal Preventive Maint. Program

$ 20.0

  • Intelligent Trans. Sys./Incident Resp.

$ 18.0

  • Positive Guidance

$ 6.0

  • Bridge Preventive Maint. Program

$ 5.0

  • Interstate Maintenance

$ 10.0

HB 1825 (Secondary Roads) estimate $ 70.0 Total $ 129.0

slide-33
SLIDE 33

Maintenance Operational Improvements

  • 47% of M&O Expenditures spent in the

private sector

  • LED replacement for signal bulbs
  • Signal preventive maintenance
  • ITS (IMAP) initiatives
  • DOC litter pickup program
  • Winter anti-icing operations
  • Low growing turf
slide-34
SLIDE 34

Maintenance Funding Needs FY 2011-2012 (millions)

Needs

  • Maintenance Operations

$ 814.6

  • Disasters

$ 15.0

  • Contract Resurfacing

$ 330.0

  • Pavement and Bridge Preservation

$ 233.2 Total Maintenance and Preserv. Needs $1,392.9 Alternate Maintenance Funds

  • $ 129.0

Adjusted Maintenance Funding Needs $1,263.9 System Rehabilitation Needs $ 340.0

slide-35
SLIDE 35

Statewide Annual Maintenance Funding Plan

Maintenance Programs 2011-2012 2012-2013 2013-2014 2014-2015 2015-2016 Maintenance and Operations 814.61 845.67 880.15 916.01 953.41 Disasters/Emergencies 15.00 15.00 15.00 15.00 15.00 Contract Resurfacing 330.00 343.86 358.30 373.35 389.03 Pavement and Bridge Preserv 233.24 243.04 253.24 263.88 274.96 Total Maint. Funding Needed 1,392.85 1,447.57 1,506.69 1,568.24 1,632.40 Supplemental Maint. Funds 129.00 129.00 129.00 129.00 129.00 Estimated Maint. Fund Allocation 933.55 933.55 933.55 933.55 933.55

Shortfall (330.30) (385.02) (444.14) (505.69) (569.85)

Fiscal Year ($ millions)

slide-36
SLIDE 36

LOS at Current Funding Level

Infrastructure Health Index

0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 2011 2012 2013 2014 2015 2016 2017

Year

slide-37
SLIDE 37

Estimated Dollars to Maintain Current LOS

Millions

$0 $200 $400 $600 $800 $1,000 $1,200 $1,400 2011 2012 2013 2014 2015 2016 2017 Year `

Year Millions

slide-38
SLIDE 38

$0 $200 $400 $600 $800 $1,000 $1,200 $1,400 $1,600 $1,800 $2,000 2011 2012 2013 2014 2015 2016 2017

Year

Funding Needed to Meet Target LOS

Millions

slide-39
SLIDE 39

Questions?
