MI MILITARY SE SEALIFT COMMA MMAND MSC SHIPBOARD LUBE OIL SAMPLING 29 APR 2020 N7 MSC LUBE OIL SAMPLING What a are t e the g goa oals ls of of L Lube O Oil l Samp mpling? g? 1) Determine Condition of Equipment 2) Determine


slide-1
SLIDE 1

MI MILITARY SE SEALIFT COMMA MMAND

29 APR 2020

MSC SHIPBOARD LUBE OIL SAMPLING

N7

slide-2
SLIDE 2

N7

MSC LUBE OIL SAMPLING

What a are t e the g goa

  • als

ls of

  • f L

Lube O Oil l Samp mpling? g?

1) Determine Condition of Equipment 2) Determine Condition of Lubricant

THIS IS THE TARGET!

slide-3
SLIDE 3

N7

MSC LUBE OIL SAMPLING

Wh Why d do we c care? e?

  • 1. Reduced cost
  • 2. Pre-damage indicators
  • 3. Early damage detection
slide-4
SLIDE 4

N7

MSC LUBE OIL SAMPLING

How do w we p pick w what n need eds s sampled led?

  • 1. Manufacturer requirement
  • 2. Equipment cost, impact on mission or safety
  • 3. RCM (MER) review indicates there is an

advantage

  • 4. ABS survey item for extending open and

inspect

  • 5. Volume of lubricant justifies cost (MPDE,

MRG, SSDG)

slide-5
SLIDE 5

N7

MSC LUBE OIL SAMPLING

How t to sample? le?

  • 1. Equipment has a location where sample

can be taken

  • 2. No safety or logistic difficulties in
  • btaining a representative sample
  • 3. Volume of lubricant
slide-6
SLIDE 6

N7

MSC LUBE OIL SAMPLING

How do we make sure that the sample is representative of the goals?

  • 1. Lubricant is in circulation (homogenous)
  • 2. Sample is taken from area of circulation
  • 3. Sampling system is flushed

(uncontaminated)

slide-7
SLIDE 7

N7

MSC LUBE OIL SAMPLING

What are some sample collection methods?

  • A. Drop Tube

B. Sample from Drain Port C. Sampling During Oil Change

  • D. Sample on Pressurized Line
slide-8
SLIDE 8

N7

SAFETY & PRECAUTIONS

  • Before starting or stopping ANY equipment, ensure

that supervisory and watch personnel are informed. NEVER start any equipment without permission/knowledge of supervisory personnel.

  • Moving equipment can cause personnel injury.

ALWAYS use caution when working around moving equipment.

  • Some lubricants are carcinogenic or otherwise

hazardous if they contact skin, are inhaled or

  • therwise ingested. ALWAYS wear appropriate PPE

when working with lubricants.

  • Sampled lubricants may be hot. Use caution and wear

appropriate PPE to prevent injury.

slide-9
SLIDE 9

N7

SAMPLING METHODS

Sampling utilizing a drop tube with a vacuum pump is an acceptable method for obtaining a representative

  • sample. The sample is typically obtained while the

equipment is not running from a dipstick or fill port.

Method A d A: Drop T p Tube be

slide-10
SLIDE 10

N7

SAMPLING METHODS

Method A d A: Drop T p Tube be

1. Cut end of drop tube at a 45° angle to reduce risk of sampling sludge. 2. Insert drop tubing and flush 5 to 10 volumes of the sample tubing to a waste container prior to drawing sample (properly dispose of waste oil or return to sump as directed). 3. Fill sample bottle to 3/4 full; loosen bottle to release vacuum and stop flow (or depress vacuum release button). 4. Remove sample bottle from pump, secure lid to top of bottle and place sample bottle into shipping container and secure protective lid. 5. Remove tubing by cutting just above the knurled knob and pull through from below to prevent pump contamination. 6. Ensure sump oil level is within the recommended operating range.

slide-11
SLIDE 11

N7

SAMPLING METHODS

Method B d B: S Sampl ple f from D Drain P n Port

  • Sampling utilizing a drain port is an acceptable

method for obtaining a representative sample.

  • The sample is typically obtained from a drain port on

an equipment sump or reservoir while the equipment is not running,.

  • The oil from the low point of an equipment sump or

reservoir near the drain valve will not initially be a representative sample, since the low point collects higher quantities of contaminants (wear particles, silica/sand, etc.) and water. Therefore, before collecting a sample of oil from drain port, flush the drain into a disposal/waste bucket a minimum of 5 to 10 volumes of the drain line and until oil is a consistent color.

slide-12
SLIDE 12

N7

SAMPLING METHODS

Method B d B: S Sampl ple f from D Drain P n Port

slide-13
SLIDE 13

N7

SAMPLING METHODS

Method B d B: S Sampl ple f from D Drain P n Port

1. Verify the equipment has been running for one (1) hour minimum under normal operating conditions and has not been secured more than 10 minutes. If not, run equipment under normal operating conditions for at least 10 minutes before proceeding. 2. Shut down equipment and wait no more than 10 minutes to pull sample. 3. Remove drain plug and/or open drain valve. 4. Monitor draining oil for change in appearance to a consistent color (a minimum of 5 to 10 volumes of the drain line). 5. Fill bottle 3/4 full, install drain plug and/or close drain valve. 6. Ensure sump oil level is within the recommended operating range.

slide-14
SLIDE 14

N7

SAMPLING METHODS

Method C d C: S Sampl pling ing D During ng O Oil C Chang nge

  • 1. Remove drain plug and drain oil into an

uncontaminated container.

  • 2. Use the vacuum pump and 10” of tubing to draw the
  • il sample from the waste container.
  • 3. When bottle is 3/4 full, loosen bottle to release

vacuum and stop flow (or depress vacuum release button).

  • 4. Remove tubing by cutting just above the knurled knob

and pull through from below to prevent pump contamination.

  • 5. Refill sump with new oil per Vessel Lube Chart.
  • 6. Properly dispose of waste oil.
slide-15
SLIDE 15

N7

SAMPLING METHODS

Method D d D: P Pressur urized L d Line ne S Sampl pling ng

  • Sampling from a pressurized line is the

preferred method of obtaining a representative sample, since a pressurized line provides the most accurate and repeatable data.

  • The sample is obtained from a system return

line, typically while the equipment is running, from a line that utilizes the pressure of the equipment's circulation system.

slide-16
SLIDE 16

N7

SAMPLING METHODS

Method D d D: P Pressur urized L d Line ne S Sampl pling ng

  • 1. Verify the equipment has been running for one (1)

hour minimum under normal operating conditions.

  • 2. Wipe sample valve port with clean cloth.
  • 3. Flush 5 to 10 volumes sample line volume to a

waste container prior to drawing sample (properly dispose of waste oil or return to sump as directed).

  • 4. Fill sample bottle 3/4 full.
  • 5. Ensure sump oil level is within the recommended
  • perating range.
slide-17
SLIDE 17

N7

NOTES ON SPECIAL SAMPLES

Notes o es on Refriger eration, Chi hiller er a and A d Air Con

  • ndit

itionin ing u unit it sample les

  • Refrigerant oil has entrained refrigerant that can be released

during changes in pressure. It is also hydroscopic. This means it will collect moisture out of the air, which artificially inflates the water content in the analysis

  • To minimize these effects, the oil sample should be left under a

heat lamp/incandescent desk lamp with the cap slightly loosened to allow the sample to de-gas for approximately 60 minutes.

  • The cap must remain slightly loose to allow entrained refrigerant

gas to escape, but not let ambient air to contact the surface of the

  • il during this process, which would absorb water from the air.
  • Failure to do this can result in the bottle breaking during transit,

and the sample being lost.

slide-18
SLIDE 18

N7

SAMPLE TUBE FLUSHING

Sample le T Tub ube Fl Flus ushing *B

*Bas ased o

  • n 1

10x d x dead v volume

Pipe Details Suggested flush volume (milliliters) per pipe length* Pipe ID (in) 1 Inch 2 Inches 3 Inches 4 Inches 5 Inches 6 Inches 1 Foot 1/2 in. Schedule 40 0.622 50 100 150 200 250 300 600 3/8 in. Schedule 40 0.493 32 64 96 128 160 192 384 1/4 in. Schedule 40 0.634 16 32 48 64 80 96 192 1/8 in. Schedule 40 0.269 9 18 27 36 45 54 108 Steel Tubing 1/2 in. .049 Wall 0.402 21 42 63 84 105 126 252 3/8 in. .049 Wall 0.277 10 20 30 40 50 60 120 5/16 in. .049 Wall 0.215 6 12 18 24 30 36 72 1/4 in. .049 Wall 0.152 3 6 9 12 15 18 36 3/16 in. .032 Wall 0.124 2 4 6 8 10 12 24 1/8 in. .032 Wall 0.061 1 2 3 4 5 6 12 Microbore Hose 2mm Bore 0.0786 1 2 3 4 5 6 12 Sample Hose 1/2 in. .062 Wall 0.376 18 36 54 72 90 108 216 5/16 in. .037 Wall 0.2385 7 14 21 28 35 42 84 1/4 in. .037 Wall 0.176 4 8 12 16 20 24 48 3/16 in. .025 Wall 0.1375 2 4 6 8 10 12 24

slide-19
SLIDE 19

N7

LUBE OIL TEST & ANALYSIS GUIDE

Lub ube O Oil T Test a and A nd Ana naly lysis is G Guid uide ( (LTAGs)

  • These guides provide sample point specific instructions
  • n where and how to draw a REPRESENTATIVE sample

for each measurement point in the vessel oil analysis program.

  • Developed by vessel class, they are groomed through

feedback to exactly define the process for each vessel.

  • A number of failures, un-identified by oil analysis; as well

as a significant number of samples being collected in the wrong location, prompted this effort.

slide-20
SLIDE 20

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-21
SLIDE 21

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-22
SLIDE 22

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-23
SLIDE 23

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-24
SLIDE 24

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-25
SLIDE 25

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-26
SLIDE 26

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-27
SLIDE 27

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-28
SLIDE 28

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-29
SLIDE 29

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-30
SLIDE 30

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-31
SLIDE 31

N7

LUBE OIL TEST & ANALYSIS GUIDE

slide-32
SLIDE 32

N7

LUBE OIL BOTTLE LABELING

L. L.O. S Sample le Bottle le La Labelin ling

  • Printed Lube Oil Labels should be placed on the Sample Bottle

itself and NEVER the white plastic shipping container.

  • Information that should be entered on the label includes Date,

Oil Hours (if available), Equipment Hours (if available) and any comments for the lab. An example label is shown below.

slide-33
SLIDE 33

N7

MAKING CHANGES

The following information is required for submitting a feedback on existing equipment in the ship’s LTAG:

  • Equipment name and SPID number,
  • LTAG page number
  • Reason for change: (Circle all that apply):
  • Update sample method (Pressurized line, drop tube, drain

port, sampling during oil change)

  • Test conditions
  • Procedures
  • Update sample point picture

Note: Provide the information requested above and pictures as attachments.

slide-34
SLIDE 34

N7

ADDING EQUIPMENT

The following information is required for submitting a feedback on new equipment to be added to the ship’s LTAG:

  • Equipment name
  • Measurement point
  • Registered lubricant
  • Proposed sample method

When using Method A acquire the inserted drop tube length one of two ways;

  • Measure the dipstick length and add 10 inches.
  • Insert tube into sampling point
  • Proposed conditions required for taking the sample (energized, de-

energized, sample on drain etc.)

  • Picture of equipment
  • Picture of sampling point

Note: Provide the information requested above and pictures as attachments.

slide-35
SLIDE 35

N7

QU QUESTI TIONS?
