T-Type Acoustic Inspection System Acoustic Measurement of Storage Tank Sludge Crude Oil Storage Tanks Sludge Settles in Bottom of Tank Reduces Storage Capacity Sludge Surface Topology Not Uniform Monitoring Required for Capacity Accounting
SLIDE 2
SLIDE 3
SLIDE 4
T-Type Acoustic Inspection System
Acoustic Measurement of Storage Tank Sludge
SLIDE 5
Sludge Settles in Bottom of Tank Reduces Storage Capacity Sludge Surface Topology Not Uniform Monitoring Required for Capacity Accounting Potential Hazard to Landing Floating Roofs
Crude Oil Storage Tanks
SLIDE 6
Current Measurement Technology Manual Dipstick Labour Intensive Slow Data Acquisition No Topology Inaccurate Sludge Volume Estimations
Planned Maintenance
SLIDE 7
Tank Farms
SLIDE 8
Acoustic Measurement Technology No contact with Sludge Complete Sludge Surface Topology Accurate Sludge Volume Calculation Fast Data Acquisition
Planned Maintenance
SLIDE 9
Acoustic Inspection System
SLIDE 10
Operator Station PC Based Data Acquisition UPS Power Supply Cable Reel Input nominal 220V-240Vac 50/60Hz Output Power 24Vdc to Inspection Tool Inspection Tool ATEX Certified
Acoustic Inspection System
SLIDE 11
PC Based Data Acquisition Microsoft Windows Operating System Ruggedized Industrial PC Data Communications to Inspection Tool UPS Power Supply Input nominal 220V-240Vac 50/60Hz Output Power 24Vdc to Inspection Tool
Operator Station
SLIDE 12
Operator Station
SLIDE 13
150m Cable Zone 1 Rated Armoured and Sheathed Ex rated Socket Interface Disconnect Interface to Inspection Tool ATEX Rated Zone 1
Cable Reel
SLIDE 14
Cable Reel
SLIDE 15
ATEX Certified Zone 1 Rated Operates in Crude Oil and other Liquid Media Ex rated Plug Interface Disconnect Interface to Cable Reel Zone 1 Rated Multi-Element Acoustic Array Solid State No Moving Parts High Reliability
Acoustic Inspection Tool
SLIDE 16
Acoustic Inspection Tool
SLIDE 17
ATEX Housing
SLIDE 18
Acoustic Inspection Tool
SLIDE 19
Stem Rotator
Acoustic Inspection Tool
SLIDE 20
Operator Station Safe Area Cable Reel Safe Area Inspection Tool Operates Immersed in Storage Tank Liquid ATEX Certified Zone 1
Hazardous Area Operations
SLIDE 21
Tank Floor Cone Up Cone Down Sloping Tank Roof Floating Fixed Diameter up to 110m
Storage Tank Types
SLIDE 22
Man Portable Tool Weight <50kg Tool Disconnects from Data/Power Cable Tank Entry Enters Tank through Nominal 4” Pipe (SCH40) in Roof Single or Multiple Entry Height Adjusted with Stem Mobile Truck Mounted Cable Reel Truck Mounted Operator Station
Tank Deployment
SLIDE 23
Tank Deployment
SLIDE 24
T-Type In Action
SLIDE 25
Tank Deployment
SLIDE 26
Sludge Volume Calculation Topology Display Data Sets from Multiple Entry Points Saved to Disk Data Merged for Tank Report Output Survey Report Burn to CD
Data Processing
SLIDE 27
Operator Station Roto-moulded Transit Case Cable Reel Powder Coated Steel Inspection Tool Flameproof Stainless Steel / Nickel Bronze
Construction
SLIDE 28
Hazardous Area Zone 1 Temperature
- 5°C to +65°C Operating
- 20°C to +60°C Storage
Ingress Protection IP68
Environmental
Hazardous Area Zone 1 Temperature
- 20°C to +85°C Operating
- 20°C to +60°C Storage
Ingress Protection IP68
Environmental
SLIDE 29
Microsoft Windows Operating System Data Forms Keyboard Entry
User Interface
SLIDE 30
Sludge 2D Display Single Entry Shown
User Interface
SLIDE 31
Sludge 2D Display Multiple Entries Merged
- n Same Display
User Interface
SLIDE 32
Sludge Profile Between Points User Selects Points on 2D Display
User Interface
SLIDE 33
Sludge 3D Display Merged Display from Multiple Entries Tank Wall Mimic Shown
User Interface
SLIDE 34
Report Output
