Molecular Quantum-dot Cellular Automata (QCA): Beyond Transistors Craig S. Lent University of Notre Dame ND Collaborators : Greg Snider, Peter Kogge, Mike Niemier, Marya Lieberman, Thomas Fehlner, Alex Kandel, Alexei Orlov, Mo Liu,Yuhui Lu


slide-1
SLIDE 1

Center for Nano Science and Technology

Craig S. Lent University of Notre Dame

Molecular Quantum-dot Cellular Automata (QCA): Beyond Transistors

Supported by National Science Foundation ND Collaborators: Greg Snider, Peter Kogge, Mike Niemier, Marya Lieberman, Thomas Fehlner, Alex Kandel, Alexei Orlov, Mo Liu,Yuhui Lu

slide-2
SLIDE 2

Center for Nano Science and Technology

Outline of presentation

  • Introduction and motivation
  • QCA paradigm
  • QCA implementations

– Metal-dot – Semiconductor-dot – Magnetic – Molecular

  • Circuit and system architecture
  • Summary
slide-3
SLIDE 3

Center for Nano Science and Technology

Goal: Electronics at the single-molecule scale

slide-4
SLIDE 4

Center for Nano Science and Technology

The Dream of Molecular Transistors

Why don’t we keep on shrinking transistors until they are each a single molecule?

slide-5
SLIDE 5

Center for Nano Science and Technology

Dream molecular transistors

V

  • ff

low conductance state V high conductance state

  • n

I 1 nm fmax=1 THz Molecular densities: 1nm x 1nm 1014/cm2

slide-6
SLIDE 6

Center for Nano Science and Technology

Transistors at molecular densities

Suppose in each clock cycle a single electron moves from power supply (1V) to ground. V

Frequency (Hz) 1014 devices/cm2 1013 devices/cm2 1012 devices/cm2 1011 devices/cm2 1012 16,000,000 1,600,000 160,000 16,000 1011 1,600,000 160,000 16,000 1,600 1010 160,000 16,000 1,600 160 109 16,000 1600 160 16 108 1600 160 16 1.6 107 160 16 1.6 0.16 106 16 1.6 0.16 0.016

Power dissipation (Watts/cm2)

ITRS roadmap: 7nm gate length, 109 logic transistors/cm2 @ 3x1010 Hz for 2016

slide-7
SLIDE 7

Center for Nano Science and Technology

slide-8
SLIDE 8

Center for Nano Science and Technology

The Dream of Molecular Transistors

slide-9
SLIDE 9

Center for Nano Science and Technology

New paradigm: Quantum-dot Cellular Automata

Revolutionary, not incremental, approach Beyond transistors – requires rethinking circuits and architectures

Use molecules, not as current switches, but as structured charge containers. Represent information with molecular charge configuration. Zuse’s paradigm

  • Binary
  • Current switch
  • charge configuration
slide-10
SLIDE 10

Center for Nano Science and Technology

Quantum-dot cellular automata

Represent binary information by charge configuration of cell. “0” “null” “1”

QCA cell

  • Dots localize charge
  • Two mobile charges
  • Tunneling between dots
  • Clock signal varies relative

energies of “active” and “null” dots active Clock need not separately contact each cell.

slide-11
SLIDE 11

Center for Nano Science and Technology

“null”

Quantum-dot cellular automata

Neighboring cells tend to align in the same state. “1”

slide-12
SLIDE 12

Center for Nano Science and Technology

Quantum-dot cellular automata

Neighboring cells tend to align in the same state. “1” “1”

slide-13
SLIDE 13

Center for Nano Science and Technology

Quantum-dot cellular automata

Neighboring cells tend to align in the same state. “1” “1”

This is the COPY operation.

slide-14
SLIDE 14

Center for Nano Science and Technology

QCA cell-cell response function

Neighbor Polarization Neighbor Polarization Cell Polarization Cell Polarization Clock: off Clock: on

slide-15
SLIDE 15

Center for Nano Science and Technology

Majority Gate

“1” “1” “0” “null”

slide-16
SLIDE 16

Center for Nano Science and Technology

Majority Gate

“1” “1” “0” “1”

slide-17
SLIDE 17

Center for Nano Science and Technology

Majority Gate

Three input majority gate can function as programmable 2-input AND/OR gate.

“A” “C” “B” “out”

M

A B C

slide-18
SLIDE 18

Center for Nano Science and Technology

QCA single-bit full adder

Hierarchical layout and design are possible. Simple-12 microprocessor (Kogge & Niemier)

result of SC-HF calculation with site model

slide-19
SLIDE 19

Center for Nano Science and Technology

Outline of presentation

  • Introduction and motivation
  • QCA paradigm
  • QCA implementations

– Metal-dot – Semiconductor-dot – Magnetic – Molecular

  • Circuit and system architecture
  • Summary
slide-20
SLIDE 20

Center for Nano Science and Technology

QCA devices exist

“dot” = metal island electrometers 70-300 mK

Al/AlOx on SiO2 Metal-dot QCA implementation

Greg Snider, Alexei Orlov, and Gary Bernstein

slide-21
SLIDE 21

Center for Nano Science and Technology

Metal-dot QCA cells and devices

  • Majority Gate

M

A B C

Amlani, A. Orlov, G. Toth, G. H. Bernstein, C. S. Lent, G. L. Snider, Science 284, pp. 289-291 (1999).

slide-22
SLIDE 22

Center for Nano Science and Technology

QCA Shift Register

slide-23
SLIDE 23

Center for Nano Science and Technology

QCA Shift Register

Gtop Gbot

electrometers

V

IN+

V

IN–

V

CLK1

V

CLK2

D1 D4

slide-24
SLIDE 24

Center for Nano Science and Technology

Metal-dot QCA devices exist

  • Single electron analogue of molecular QCA
  • Gates and circuits:

– Wires – Shift registers – Fan-out – Power gain demonstrated – AND, OR, Majority gates

  • Work underway to raise operating temperatures
slide-25
SLIDE 25

Center for Nano Science and Technology

Power Gain in QCA Cells

  • Power gain is crucial for practical devices

because some energy is always lost between stages.

  • Lost energy must be replaced.

– Conventional devices – current from power supply – QCA devices – from the clock

  • Unity power gain means replacing exactly as

much energy as is lost to environment. Power gain > 3 has been measured in metal-dot QCA.

slide-26
SLIDE 26

Center for Nano Science and Technology

GaAs-AlGaAs QCA cell

  • Dots defined by top gates depleting 2DEG
  • Direct measurement of cell switching
slide-27
SLIDE 27

Center for Nano Science and Technology

Silicon P-dot QCA cell

  • Dots defined by implanted phosphorus
  • Single-donor creation foreseen
  • Direct measurement of cell switching
slide-28
SLIDE 28

Center for Nano Science and Technology

Magnetic QCA

  • Dots defined by magnetic

domains

  • Room temperature operation
slide-29
SLIDE 29

Center for Nano Science and Technology

Molecular QCA

“dot” = metal island 70 mK Mixed valence compounds “dot” = redox center room temperature+

Metal tunnel junctions

Key strategy: use nonbonding orbitals (π or d) to act as dots.

slide-30
SLIDE 30

Center for Nano Science and Technology

Experiments on molecular double-dot

Thomas Fehlner et al. (Notre Dame chemistry group) Journal of American Chemical Society, 125:15250, 2003

Ru Ru Fe Fe

“0” “1” Fe group and Ru group act as two unequal quantum dots.

trans-Ru-(dppm)2(C≡CFc)(NCCH2CH2NH2) dication

slide-31
SLIDE 31

Center for Nano Science and Technology

Surface attachment and orientation

N Si Si

3.8 Α 2.4 Α 106o

PHENYL GROUPS “TOUCHING” SILICON

Molecule is covalent bonded to Si and oriented vertically by “struts.”

Si(111) molecule Si-N bonds “struts”

slide-32
SLIDE 32

Center for Nano Science and Technology Fe Ru Fe Ru Fe Ru Si Hg Fe Ru Si Hg Fe Ru Si Hg Fe Ru ac Capacitance voltage excited state switching Energy ground state

Applied field equalizes the energy of the two dots

When equalized, capacitance peaks.

applied potential

Measurement of molecular bistability

  • 1.5
  • 1.0
  • 0.5

0.0 0.5 1.0 1.5 1.0 1.1 1.2 1.3 1.4 1.5 1.6 1.7

C (oxidized) C (reduced) ∆C

V

H g (V)

C (nF)

  • 0.25
  • 0.20
  • 0.15
  • 0.10
  • 0.05

0.00 0.05 0.10 0.15

∆C (nF) layer of molecules

Ru Fe Ru Fe

2 counterion charge configurations on surface

slide-33
SLIDE 33

Center for Nano Science and Technology

Longer molecular double-dot

Isopotential surface HOMO

  • rbital
slide-34
SLIDE 34

Center for Nano Science and Technology

Double-dot click-clack

  • 1.5
  • 1.0
  • 0.5

0.0 0.5 1.0 1.5 0.9 1.0 1.1 1.2 1.3

COxidized Cas prepared ∆C

VHg (V)

C (nF)

  • 0.2
  • 0.1

0.0 0.1

∆C (nF)

Ph2 P Ru P Ph2 Ph2 P P Ph2 Ph2 P R u P Ph2 Ph2 P P Ph2N N H2N NH2

3+

d1=1.8 nm dm=2.8 nm

Hua & Fehlner

slide-35
SLIDE 35

Center for Nano Science and Technology

Square 4-dot QCA molecules

0.6 nm

slide-36
SLIDE 36

Center for Nano Science and Technology

Imaging molecular double-dot

structure toluene solution Goal: single-molecule imaging on surfaces

Kandel group

Molecules are pulse-injected from solution into vacuum onto a clean, crystalline gold [Au(111)] surface.

Ru-Ru molecule with no surface binding. Not mixed-valence species.

slide-37
SLIDE 37

Center for Nano Science and Technology

Ru2 clustering

Some clustering and alignment of molecules

  • ccurs automatically during
  • deposition. (50 nm image

shown.) We should be able to compare isolated molecules with those in larger clusters.

Experimental conditions: 0.5 V, 20 pA, 298 K

slide-38
SLIDE 38

Center for Nano Science and Technology

Molecular motion

Changing tunneling conditions (from 1.0 V, 20 pA to 1.0 V, 100 pA) increases tip/molecule interaction. We observe a change in orientation for one Ru2 molecule. This suggests the possibility of using the STM tip for controlled manipulation of these molecules on the surface.

Experimental conditions: 250 ×180 Å, 1.0 V, 20 (100) pA, 298 K

slide-39
SLIDE 39

Center for Nano Science and Technology

Imaging charge localization

Neutral molecules Mixed-valence molecules Preliminary results for Fe-Fe fabricated by Claude Lapinte (Rennes)

slide-40
SLIDE 40

Center for Nano Science and Technology

Single-atom quantum dots

slide-41
SLIDE 41

Center for Nano Science and Technology

Outline of presentation

  • Introduction and motivation
  • QCA paradigm
  • QCA implementations

– Metal-dot – Semiconductor-dot – Magnetic – Molecular

  • Circuit and system architecture
  • Summary
slide-42
SLIDE 42

Center for Nano Science and Technology

Field-clocking of QCA wire: shift-register

slide-43
SLIDE 43

Center for Nano Science and Technology

Computational wave: majority gate

slide-44
SLIDE 44

Center for Nano Science and Technology

Computational wave: adder back-end

slide-45
SLIDE 45

Center for Nano Science and Technology

Permuter

Deep pipe-lining at very small scale

slide-46
SLIDE 46

Center for Nano Science and Technology

Wider QCA wires

Redundancy results in defect tolerance.

slide-47
SLIDE 47

Center for Nano Science and Technology

Molecular circuits and clocking wires

Next: zoom out to dataflow level

slide-48
SLIDE 48

Center for Nano Science and Technology

Universal floorplan

Peter Kogge

slide-49
SLIDE 49

Center for Nano Science and Technology

QCA design tools

Design tools are starting to enable new systems ideas.

QCADesigner Konrad Walus

  • U. British Columbia
slide-50
SLIDE 50

Center for Nano Science and Technology

System + Application Architectures

Grounded in device physics & simulation Incorporate clock driven dataflow

A B C D A B

Device architecture maps well to many system architectures…

A A’ B B’ C C’ AB AC AND Plane OR Plane AB + BC + AC BC

Reconfigurable General Purpose Systolic

Good for FIR, FT, Matrix multiply, graph algorithms, etc.

Mike Niemier

slide-51
SLIDE 51

Center for Nano Science and Technology

slide-52
SLIDE 52

Center for Nano Science and Technology

slide-53
SLIDE 53

Center for Nano Science and Technology

slide-54
SLIDE 54

Center for Nano Science and Technology

slide-55
SLIDE 55

Center for Nano Science and Technology

Summary

  • QCA offers possible path to limits of downscaling –

molecular computing.

– General-purpose computing – New architecture – Low power dissipation which is essential

  • Single-electron metal-dot QCA devices exist.
  • First steps in molecular-scale QCA
  • Clear path but much research remains to be done.

– Rethinking architecture to match problem – Chemistry, physics, electrical engineering, computer science

Thanks for your attention.
