Modelling with Differential Equations Modelling with Differential Equations Modelling with Differential Equations Problems with inflow/outflow Modelling with Differential Equations Problems with inflow/outflow Equation for

slide-1
SLIDE 1

Modelling with Differential Equations

Modelling with Differential Equations

slide-2
SLIDE 2

Modelling with Differential Equations

slide-3
SLIDE 3

◮ Problems with inflow/outflow

Modelling with Differential Equations

slide-4
SLIDE 4

◮ Problems with inflow/outflow ◮ Equation for concentration/mass/volume of a

fluid/element/product

Modelling with Differential Equations

slide-5
SLIDE 5

◮ Problems with inflow/outflow ◮ Equation for concentration/mass/volume of a

fluid/element/product

◮

rate of change = ratein − rateout

Modelling with Differential Equations

slide-6
SLIDE 6

Problem #5 in Section 2.3

Modelling with Differential Equations

slide-7
SLIDE 7

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt.

Modelling with Differential Equations

slide-8
SLIDE 8

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

Modelling with Differential Equations

slide-9
SLIDE 9

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

Modelling with Differential Equations

slide-10
SLIDE 10

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time

Modelling with Differential Equations

slide-11
SLIDE 11

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph.

Modelling with Differential Equations

slide-12
SLIDE 12

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level.

Modelling with Differential Equations

slide-13
SLIDE 13

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level. What is this level?

Modelling with Differential Equations

slide-14
SLIDE 14

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level. What is this level? What is the amplitude of the oscillation.

Modelling with Differential Equations

slide-15
SLIDE 15

Model

Modelling with Differential Equations

slide-16
SLIDE 16

Model

◮ y(t) amount of salt at time t

Modelling with Differential Equations

slide-17
SLIDE 17

Model

◮ y(t) amount of salt at time t ◮ y(0) = 50

Modelling with Differential Equations

slide-18
SLIDE 18

Model

◮ y(t) amount of salt at time t ◮ y(0) = 50 ◮ Volume = constant = 100. ◮ Equation

Modelling with Differential Equations

slide-19
SLIDE 19

Model

◮ y(t) amount of salt at time t ◮ y(0) = 50 ◮ Volume = constant = 100. ◮ Equation

dy(t) dt = 1 2

  • 1 + 1

2 sin(t)

  • − 1

50y(t)

Modelling with Differential Equations

slide-20
SLIDE 20

Model

◮ y(t) amount of salt at time t ◮ y(0) = 50 ◮ Volume = constant = 100. ◮ Equation

dy(t) dt = 1 2

  • 1 + 1

2 sin(t)

  • − 1

50y(t)

◮ Solution

Modelling with Differential Equations

slide-21
SLIDE 21

Model

◮ y(t) amount of salt at time t ◮ y(0) = 50 ◮ Volume = constant = 100. ◮ Equation

dy(t) dt = 1 2

  • 1 + 1

2 sin(t)

  • − 1

50y(t)

◮ Solution

y(t) = 63150 2501 e−t/50 + 25 + 25 5002 sin(t) − 625 2501 cos(t)

Modelling with Differential Equations

slide-22
SLIDE 22

Plot of y(t)

Modelling with Differential Equations

slide-23
SLIDE 23

Plot of y(t)

200 400 600 800 1000 25 30 35 40 45 50 x f

Modelling with Differential Equations

slide-24
SLIDE 24

Plot of y(t)

200 400 600 800 1000 25 30 35 40 45 50 x f

Modelling with Differential Equations

slide-25
SLIDE 25

Problem #5 in Section 2.3

Modelling with Differential Equations

slide-26
SLIDE 26

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt.

Modelling with Differential Equations

slide-27
SLIDE 27

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

Modelling with Differential Equations

slide-28
SLIDE 28

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

Modelling with Differential Equations

slide-29
SLIDE 29

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time

Modelling with Differential Equations

slide-30
SLIDE 30

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph.

Modelling with Differential Equations

slide-31
SLIDE 31

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level.

Modelling with Differential Equations

slide-32
SLIDE 32

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level. What is this level?

Modelling with Differential Equations

slide-33
SLIDE 33

Problem #5 in Section 2.3

◮ A tank contains 100 gal of water and 50 oz of salt. ◮ Water containing a salt concentration of 1 4(1 + 1 2 sin(t)) oz/gal flows into the tank at a rate of

2 gal/min and

◮ The mixture of the tank flows out at the same rate.

(a) Find the amount of salt in the tank at any time (b) Plot the solution for a time period long enough so that you see the ultimate behavior of the graph. (c) The long time behavior of the solution is an oscillation about a certain constant level. What is this level? What is the amplitude of the oscillation.

Modelling with Differential Equations
