Mobile Application Security Testing and Code Review 19 Nov 2013 Mobile and Smart Device Security 2013 Boston, MA Presen sented ted by: Francis Brown & Joe DeMesy Bishop Fox www.bishopfox.com Introductions VERY QUICKLY

slide-1
SLIDE 1

Mobile Application Security

Testing and Code Review

19 Nov 2013 – Mobile and Smart Device Security 2013 – Boston, MA Presen sented ted by: Francis Brown & Joe DeMesy Bishop Fox www.bishopfox.com

slide-2
SLIDE 2

Introductions

2

  • Hi, I’m Fran
  • Partner at Bishop Fox
  • You may remember me from such hacks as:
  • RFID Thief
  • Diggity Search Tool Suite
  • SharePoint Hacking

VERY QUICKLY…

slide-3
SLIDE 3

Introductions

3

  • Hi, I’m Joe
  • Sr. Security Analyst at Bishop Fox
  • I like Python, Linux, and cryptography
  • Phones / embedded devices are pretty cool too

VERY QUICKLY…

slide-4
SLIDE 4

Today We’re Covering

4

  • Attacks against mobile apps
  • Real world examples
  • Defense against the dark arts

HACKING MOBILE APPS

slide-5
SLIDE 5
  • Breaki

king ng iOS Apps

  • Static Analysis
  • Dynamic Analysis
  • Counter-measures
  • Breaki

king ng Andro roid id Apps

  • Static Analysis
  • Dynamic Analysis
  • Counter-measures

Agenda

5

TECHNICAL BRIEF

slide-6
SLIDE 6

App Security Requirements

6

  • Online finance
  • Point-of-sale
  • Streaming media and DRM
  • Mobile Device Management (MDM)

A FEW SCENARIOS

slide-7
SLIDE 7

OF APP SECURITY

The Golden Rule

7

slide-8
SLIDE 8

Users are Ev Evil il

8

  • They have complete control
  • Do not trust them
  • Design apps & APIs accordingly

EVERY LAST ONE OF ‘EM

slide-9
SLIDE 9

iOS Applications

9

STATIC ANALYSIS

slide-10
SLIDE 10
  • Jailbroken iOS Device
  • SSH Access (scp)
  • Mac & Xcode
  • HTTP Proxy
  • Burp Suite Free/Pro ($300)
  • Zed Attack Proxy
  • ARM Disassembler
  • Hopper ($50)
  • IDA Pro ($600+)

iOS Perquisites

10

WHAT YOU NEED TO START

slide-11
SLIDE 11

HTTP Proxy Setup

11

NETWORK ANALYSIS

slide-12
SLIDE 12

Burp Suite Setup

12

slide-13
SLIDE 13

Python –m SimpleHTTPServer

13

slide-14
SLIDE 14

Install You Own CA

14

slide-15
SLIDE 15

WiFi Settings > Proxy

15

slide-16
SLIDE 16

You’re Done!

16

WELL SORT OF…

slide-17
SLIDE 17

DECRYPTING BINARIES

AppStore Encryption

17

slide-18
SLIDE 18
  • Encrypted Binaries
  • AppStore
  • Clutch
  • Rasticrac
  • No Encryption
  • Provisioned Device
  • Test Flight, etc.

Binary Encryption

18

GETTING PLAIN-TEXT BINS

slide-19
SLIDE 19

Clutch

19

  • Decrypts iOS applications and repackages them
  • Saves apps in:

/var/root/Documents/Cracked

  • Saves apps as .ipa files (they’re just ZIPs)
  • Use: clutch <app name>

AWESOME TOOL

slide-20
SLIDE 20
  • Foobar.ipa
  • iTunesMetadata.plist
  • iTunesArtwork
  • Payload/
  • Foobar.app
  • Foobar
  • …

AppStore Archive Structure

20

GETTING PLAIN-TEXT BINS

slide-21
SLIDE 21

Bundle Identifier

21

ITUNES METADATA PLIST

slide-22
SLIDE 22

Static Analysis

22

IOS APP SECURITY

slide-23
SLIDE 23

Static Analysis

23

DUMPING CLASS INTERFACES

slide-24
SLIDE 24

class-dump-z

24

  • Dump class information from a Mach-O binary
  • Shows Objective-C classes, methods, properties
  • Useful for peering into iOS apps
  • Great for searching for keywords

ANOTHER AWESOME TOOL

slide-25
SLIDE 25

#import <XXUnknownSuperclass.h> // Unknown library @class NSString; @interface XXasymEncryptor : XXUnknownSuperclass { NSString* _publicKeyID; NSString* _privateKeyID; } @property(copy, nonatomic) NSString* privateKeyID; @property(copy, nonatomic) NSString* publicKeyID;

  • (id)privateQueryDict;
  • (id)publicQueryDict;
  • (void)decryptWithPrivateKey;
  • (void)encryptWithPublicKey;
  • (void)KeysPlease;
  • (id)decryptData:(id)data;
  • (id)encryptData:(id)data;
  • (id)init;

@end

slide-26
SLIDE 26

#import <XXUnknownSuperclass.h> // Unknown library @class NSString; @interface XXasymEncryptor : XXUnknownSuperclass { NSString* _publicKeyID; NSString* _privateKeyID; } @property(copy, nonatomic) NSString* privateKeyID; @property(copy, nonatomic) NSString* publicKeyID;

  • (id)privateQueryDict;
  • (id)publicQueryDict;
  • (void)decryptWithPrivateKey;
  • (void)encryptWithPublicKey;
  • (void)KeysPlease;
  • (id)decryptData:(id)data;
  • (id)encryptData:(id)data;
  • (id)init;

@end

slide-27
SLIDE 27

Jailbreak Detection

27

#import <Foundation/NSObject.h> @interface FoobarUtil : NSObject { } +(id)getMACUID; +(id)getMACBasedUID; +(id)hashDataToHexString:(char*)hexString length:(int)length; +(id)hashData:(id)data; +(id)iTunesMetadataPlist; +(BOOL)appIsCracked; +(BOOL)deviceIsJailbroken; +(int)deviceCPUFrequency;

slide-28
SLIDE 28

Jailbreak Detection

28

Me Metho hods

  • Fork()
  • Stat() / Lstat()
  • Cydia
  • /apt/
  • Etc
  • dyld_count()
  • dyld_get_image_name()

COMMON DETECTION METHODS

slide-29
SLIDE 29

ARM Assembly

29

slide-30
SLIDE 30

30

slide-31
SLIDE 31

31

slide-32
SLIDE 32

32

Pseudo Code

NO ASSEMBLY REQUIRED

slide-33
SLIDE 33

XOR is Not Obfuscation

33

slide-34
SLIDE 34

Dynamic Analysis

34

IOS APP SECURITY

slide-35
SLIDE 35

iOS Device Logs

35

  • Window > Organizer
  • Cmd + Shift + 2
  • Real-time logs 

XCODE DEVICE CONSOLE

slide-36
SLIDE 36

iOS Device Logs

36

WALL OF TEXT

slide-37
SLIDE 37

HOOKING MADE EASY

Mobile Substrate

37

slide-38
SLIDE 38

Mobile Substrate

38

OBJ-C RUNTIME MANIPULATION

  • Written by Jay Freeman “Saurik”
  • Dynamic library injection framework
  • Cydia “Tweaks”
  • Included with Cydia by default
slide-39
SLIDE 39

Obj-C Message Passing

39

iOS App Objective-C Call Native C Call Run Code

slide-40
SLIDE 40

Obj-C Message Passing

40

iOS App Mobile Substrate Objective-C Call Native C Call Run Code

Our code runs here

slide-41
SLIDE 41

Class Dump Example

41

IMPLEMENTING THE ATTACK

@class NSString; @interface DeviceSecurity: { BOOL _jbstatus; } @property(assign, nonatomic) BOOL jbstatus; +(BOOL)isJailbroken; @end

slide-42
SLIDE 42

Class Dump Example

42

IMPLEMENTING THE ATTACK

@class NSString; @interface DeviceSecurity: { BOOL _jbstatus; } @property(assign, nonatomic) BOOL jbstatus; +(BOOL)isJailbroken; @end

slide-43
SLIDE 43

Tweak Syntax

43

IMPLEMENTING THE ATTACK

#import “substrate.h” %hook DeviceSecurity

  • (BOOL) isJailbroken {

%log; // Logos built-in logging return NO; // Return FALSE } %end

slide-44
SLIDE 44

Generating Function Hooks

44

LOG ALL THE THINGS

$ class-dump-z FoobarApp –H $ ./ios-hooker.py --target Foobar.h –g –s –l [*] Successfully parsed 1 of 1 file(s) [*] Generated 120 function hook(s) [*] Hooks written to: Tweak.xm (8954 bytes) $ make package

slide-45
SLIDE 45

GIVES YOU SUPERPOWERS

Cycript

45

slide-46
SLIDE 46

Cycript Magic

46

  • JavaScript REPL
  • JavaScript + Cycript

language extensions

  • Objective-C runtime is

merged into the REPL

  • Attach to running apps

IOS HACKER’S BEST FRIEND

slide-47
SLIDE 47

Cycript

47

ALIEN BLUE APP

slide-48
SLIDE 48

Cycript

48

IOS HACKER’S BEST FRIEND

iphone:~root# cycript –p AlienBlue cy# cy# UIApp @"<UIApplication: 0x8ba2c0>" cy# cy# UIApp.keyWindow.delegate @"<CustomNavigationController: 0x836900>” cy#

slide-49
SLIDE 49

Cycript Extended

49

IOS HACKER’S BEST FRIEND

$ ./slcycript AlienBlue [+] Launching cycript wrapper... [+] Attaching to process AlienBlue with PID 4831 [+] Importing JavaScript helper functions, please wait... cy# cy# ui(UIApp.keyWindow, "Reddits") <UILabel: 0x82f0d0; frame = (132 12; 55 21); text = 'Reddits'; clipsToBounds = YES; userInteractionEnabled = NO; layer = <CALayer: 0x82f190>>

slide-50
SLIDE 50

Cycript Extended

50

IOS HACKER’S BEST FRIEND

cy# label = new Instance(0x82f0d0) @"<UILabel: 0x82f0d0; frame = (132 12; 55 21); text = 'Reddits'; clipsToBounds = YES; userInteractionEnabled = NO; layer = <CALayer: 0x82f190>>" cy# cy# label.text @"Reddits" cy# label.text=@"Diggs" @"Diggs" cy#

slide-51
SLIDE 51

Cycript Extended

51

IOS HACKER’S BEST FRIEND

cy# hexdump(label.text,64) " c8 02 20 3f 8c 07 00 06 05 44 69 67 67 73 00 00 .........Diggs.. 12 48 65 6c 76 65 74 69 63 61 4e 65 75 65 2d 42 .HelveticaNeue.B 6f 6c 64 00 00 00 00 00 00 00 00 00 00 00 00 00 old............. c8 02 20 3f ad 07 00 01 b0 2b 84 00 12 00 00 00 ................ " cy# cy# [ label setHidden: 1 ] cy#

slide-52
SLIDE 52

MDM Security Policy

52

slide-53
SLIDE 53

DE DEMO MONSTRA NSTRATION TION

Cycript & iOS Mobile Substrate

53

slide-54
SLIDE 54

REALISTIC CONSIDERATIONS

Recommendations

54

slide-55
SLIDE 55

Defense Against Dark Arts

55

EXPECTO PATRONIS

  • Mobile security can be defeated
  • It comes down to context and difficulty
  • For example…
slide-56
SLIDE 56

iOS Recommendations

56

HARDENING YOUR APP

  • 1. Assembly and/or C
  • 2. Inline functions
  • 3. Obj-C obfuscation
  • 4. Certificate pinning
  • 5. Change release
  • Metaforic – Commercial
  • AppMinder – BSD Licensed

a) http://appminder.nesolabs.de/

slide-57
SLIDE 57

Free ‘n Easy Obfuscation

57

DEFENSIVE SHELLCODE

slide-58
SLIDE 58

Android Applications

58

STATIC ANALYSIS

slide-59
SLIDE 59

APK PACKAGES

Google Play Store

59

slide-60
SLIDE 60
  • APKs are signed, not encrypted
  • APK Extractor
  • Direct Download

Android Packages

60

EASILY ACQUIRED

slide-61
SLIDE 61
  • Root’d Device
  • Cydia Substrate
  • ADT Eclipse Bundle
  • Procyon
  • Dex2jar
  • Substrate Plug-in
  • HTTP Proxy
  • Burp Suite Free/Pro ($300)
  • Zed Attack Proxy

Android Perquisites

61

WHAT YOU NEED TO START

slide-62
SLIDE 62

Decompile the Bytecode

62

BYTECODE REFLECTION

dex2jar <App>.apk

slide-63
SLIDE 63

Dex2jar & Procyon

63

MORE THAN JUST INTERFACES

$ dex2jar Foobar.apk dex2jar foobar.apk -> Foobar-dex2jar.jar $ procyon –jar Foobar-dex2jar.jar –o src/ Decompiling com/foobar/Parser... Decompiling com/foobar/XMLWriter... …

slide-64
SLIDE 64

Decompiled Java Code

64

MORE THAN JUST INTERFACES

slide-65
SLIDE 65

Dynamic Analysis

65

ANDROID RUNTIME

slide-66
SLIDE 66

Android Zygote

66

slide-67
SLIDE 67

SUBSTRATE FOR ANDROID

Cydia Substrate

67

slide-68
SLIDE 68

Class Hook Example

68

IMPLEMENTING THE ATTACK

Class to hook Method to hook

slide-69
SLIDE 69

Class Hook Example

69

IMPLEMENTING THE ATTACK

slide-70
SLIDE 70

Class Hook Example

70

IMPLEMENTING THE ATTACK

slide-71
SLIDE 71

Class Hook Example

71

IMPLEMENTING THE ATTACK

slide-72
SLIDE 72

Class Hook Example

72

IMPLEMENTING THE ATTACK

slide-73
SLIDE 73

Class Hook Example

73

IMPLEMENTING THE ATTACK

slide-74
SLIDE 74

ADT’s Logcat

74

ANOTHER BEAUTIFUL WALL OF TEXT

Filter by tag

slide-75
SLIDE 75

DE DEMO MONSTRA NSTRATION TION

Android Substrate

75

slide-76
SLIDE 76

REALISTIC CONSIDERATIONS

Recommendations

76

slide-77
SLIDE 77

Android Recommendations

77

HARDENING YOUR APP

  • 1. NDK + assembly and/or C
  • 2. Inline functions
  • 3. Avoid kernel calls if possible
  • 4. Java bytecode obfuscation
  • 5. Certificate pinning
  • Java Obfuscator
slide-78
SLIDE 78

ON MOBILE SECURITY

Conclusions

78

slide-79
SLIDE 79

Management Not Security

79

BYOD VERTICAL CLOUD INTEGRATION

  • MDM is Mobile Device Management
  • Client-side enforcement
  • Devices lie

lie

slide-80
SLIDE 80

Mobile Security

80

IN A NUTSHELL

  • Do NOT make security decisions on a mobile device
  • But if you must…
slide-81
SLIDE 81

Client-side Enforcement

81

IF YOU MUST…

  • Your architecture is probably broken
  • Fix that instead
  • But if the business model dictates that you must…
  • Perhaps the revenue model depends on it
  • Perhaps you have to integrate with legacy code
  • Perhaps there’s some other crazy reason for on-device

security

slide-82
SLIDE 82

Questions & Thank You

82

http://github.com/moloch-- @bishopfox

Bishop

  • p Fox – see for more info:

http://www.bishopfox.com/
