SLIDE 1

Microfacet models for refraction through rough surfaces

Bruce Walter Steve Marschner Hongsong Li Ken Torrance Cornell University Program of Computer Graphics

SLIDE 2

Diffuse transmission

SLIDE 3

10 5 1

measured transmission ground glass interface n = 1.51

SLIDE 4

10 5 1

measured transmission ground glass interface n = 1.51

SLIDE 5

10 5 1

measured transmission ground glass interface n = 1.51

SLIDE 6

10 5 1

measured transmission ground glass interface n = 1.51

SLIDE 7

10 5 1

measured transmission ground glass interface n = 1.51

SLIDE 8

10 5 1

measured transmission ground glass interface n = 1.51 critical angle

SLIDE 9

Prior work

Microfacet models in graphics

Blinn 1977 introduced Torrance-Sparrow model
Cook & Torrance 1982 Torrance-Sparrow specular
Ashikhmin et al. 2000 microfacet BRDF generator
Stam 2001 skin subsurface scattering model

Work outside graphics we build on

Smith 1967 shadowing–masking framework
Nee & Nee 2004 single-interface measurement idea

SLIDE 10

Contributions

Microfacet transmission model

new geometric formulation
clean, simple generalization of reflection

Microfacet distribution functions

evaluate three choices against data
new GGX distribution fits some surfaces better

Importance sampling Measurement and validation

single interface transmission

SLIDE 11

SLIDE 12

air dielectric microsurface macrosurface

Microfacet scattering models

Assumptions

rough dielectric surface
single scattering

m n

SLIDE 13

Microfacet reflection models

Incident irradiance Ei illuminates macrosurface area dA from direction i.

i

dA Ei

SLIDE 14

Microfacet reflection models

Incident irradiance Ei illuminates macrosurface area dA from direction i. Reflected radiance Lr measured at direction o in solid angle dωo.

dωo

i

Bidirectional Reflectance Distribution Function: fr(i, o) = Lr

Ei Ei Lr

SLIDE 15

Microfacet reflection models

Incident irradiance Ei illuminates macrosurface area dA from direction i. Reflected radiance Lr measured at direction o in solid angle dωo.

i

Bidirectional Reflectance Distribution Function: fr(i, o) = Lr

Ei Ei

Bidirectional Transmittance Distribution Function: ft(i, o) = Lt

Ei

Lt dωo

SLIDE 16

fr(i, o) = F(i, m) D(m) G(i, o, m) 4|i·n| |o·n|

Reflection to transmission

Traditional microfacet reflection model:

SLIDE 17

geometric

fr(i, o) = F(i, m) D(m) G(i, o, m) 4|i·n| |o·n|

Reflection to transmission

We generalize the geometric analysis dealing with the surface area where scattering occurs. Traditional microfacet reflection model:

ptical

SLIDE 18

G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

SLIDE 19

G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 20

m

G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

m=h(i,o)

h gives the one microsurface normal m that will scatter light from i to o.

selects m

SLIDE 21

dωm m G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

m=h(i,o)

h gives the one microsurface normal m that will scatter light from i to o.

dωo

selects m
determines size of dωm

SLIDE 22

dωm m G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 23

D measures density of microsurface area with respect to microsurface normal m.

dωm m G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 24

D measures density of microsurface area with respect to microsurface normal m.

dA dAm dωm

m

dAm = ) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 25

D measures density of microsurface area with respect to microsurface normal m.

dA dAm dωm

m

G measures the fraction of points with microsurface normal m that are visible.

dAm = ) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 26

D measures density of microsurface area with respect to microsurface normal m.

dA dAm dωm

m

G measures the fraction of points with microsurface normal m that are visible.

dAm = ) D(m) dωm dA = G(i, o, m) G(i, o, m)

shadowing–masking

D(m)

normal distribution

h(i, o)

“half-vector” function

i

h gives the one microsurface normal m

that will scatter light from i to o.

SLIDE 27

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) dAm dA dωo

For reflection or transmission:

h(i, o)

“half-vector” function

dAm = G(i, o, m) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

SLIDE 28

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo

For reflection or transmission:

h(i, o)

“half-vector” function

dAm = G(i, o, m) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

SLIDE 29

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo

easy to generalize

For reflection or transmission:

h(i, o)

“half-vector” function

dAm = G(i, o, m) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

SLIDE 30

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo

key contribution easy to generalize

For reflection or transmission:

h(i, o)

“half-vector” function

dAm = G(i, o, m) D(m) dωm dA G(i, o, m)

shadowing–masking

D(m)

normal distribution

SLIDE 31

i

m

i + o parallel to m

Construction of half-vector

reflection refraction

SLIDE 32

i

m

i + o parallel to m

Construction of half-vector

reflection refraction

hr = normalize(i + o)

SLIDE 33

i

m

i

m

i + o parallel to m

Construction of half-vector

reflection refraction

hr = normalize(i + o)

SLIDE 34

i

m

i m

i + o parallel to m

Construction of half-vector

no

parallel to m

i + no

reflection refraction

hr = normalize(i + o)

SLIDE 35

i

m

i m

i + o parallel to m

Construction of half-vector

no

parallel to m

i + no

reflection refraction

hr = normalize(i + o) ht = −normalize(i + no)

SLIDE 36

i

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no)

SLIDE 37

i

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no)

SLIDE 38

i

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) dωo

SLIDE 39

i

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr dωo

SLIDE 40

i

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr dωm = |o · hr| i + o2 dωo dωm dωo

SLIDE 41

i

i
dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr dωm = |o · hr| i + o2 dωo dωm dωo dωo

SLIDE 42

i

i
dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr dωm = |o · hr| i + o2 dωo dωm no dωo dωo

SLIDE 43

i

i
dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr n2dωo dωm = |o · hr| i + o2 dωo dωm no dωo dωo

SLIDE 44

i

i
ht

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr n2dωo dωm = |o · hr| i + o2 dωo dωm no dωo dωo

SLIDE 45

i

i
ht

dωo

reflection refraction

Construction of half-vector solid angle

hr = normalize(i + o) ht = −normalize(i + no) hr n2dωo dωm = |o · hr| i + o2 dωo dωm no dωm dωo dωo

dωm =

|o · ht| i + no2 n2dωo

SLIDE 46

Result: scattering functions

reflection transmission

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo

SLIDE 47

Result: scattering functions

reflection transmission

fs(i, o) = |i · m| |i · n| |o · n| ρ(i, o) D(m) G(i, o, m) dωm dωo fr(i, o) = |i·hr| |i·n| |o·n| F(i, hr) D(hr) G(i, o, hr) |o·hr| i + o2

SLIDE 48

Result: scattering functions

reflection transmission

fr(i, o) = |i·hr| |i·n| |o·n| F(i, hr) D(hr) G(i, o, hr) |o·hr| i + o2 ft(i, o) = |i·ht| |i·n| |o·n| (1 − F(i, ht)) D(ht) G(i, o, ht) n2|o·ht| i + no2

SLIDE 49

Result: scattering functions

reflection transmission

fr(i, o) = |i·hr| |o·hr| |i·n| |o·n| F(i, hr) D(hr) G(i, o, hr) i + o2 ft(i, o) = |i·ht| |i·n| |o·n| (1 − F(i, ht)) D(ht) G(i, o, ht) n2|o·ht| i + no2

SLIDE 50

Result: scattering functions

reflection transmission

fr(i, o) = |i·hr| |o·hr| |i·n| |o·n| F(i, hr) D(hr) G(i, o, hr) i + o2 ft(i, o) = |i·ht| |o·ht| |i·n| |o·n| n2(1 − F(i, ht)) D(ht) G(i, o, ht) i + no2

SLIDE 51

Result: scattering functions

reflection transmission

fr(i, o) = F(i, hr) D(hr) G(i, o, hr) 4|i·n| |o·n| ft(i, o) = |i·ht| |o·ht| |i·n| |o·n| n2(1 − F(i, ht)) D(ht) G(i, o, ht) i + no2

SLIDE 52

SLIDE 53

8 20 –20 40 –40

Normal distributions

Phong

Choice of distribution is determined by surface

Phong describes same surfaces as Beckman
new GGX distribution fits some surfaces better
analytical Smith shadowing–masking

D(θm)

SLIDE 54

8 20 –20 40 –40

Normal distributions

Phong Beckman

Choice of distribution is determined by surface

Phong describes same surfaces as Beckman
new GGX distribution fits some surfaces better
analytical Smith shadowing–masking

D(θm)

SLIDE 55

8 20 –20 40 –40

Normal distributions

Phong Beckman GGX (new)

Choice of distribution is determined by surface

Phong describes same surfaces as Beckman
new GGX distribution fits some surfaces better
analytical Smith shadowing–masking

D(θm)

SLIDE 56

8 20 –20 40 –40

Normal distributions

Phong Beckman GGX (new)

Choice of distribution is determined by surface

Phong describes same surfaces as Beckman
new GGX distribution fits some surfaces better
analytical Smith shadowing–masking

1 90 –90

D(θm) G1(θi,o)

SLIDE 57

Importance sampling

Sampling procedure

choose normal according to D(m) |m • n|

explicit formulas in paper

compute o by reflection or refraction
compute pdf of o using dωm/dωo

leaves G and some cosines for the weight

can adjust sampling roughness to control weight

SLIDE 58

SLIDE 59

Measuring transmission

SLIDE 60

Measuring transmission

SLIDE 61

Measuring transmission

SLIDE 62

Measuring transmission

SLIDE 63

Measuring transmission

SLIDE 64

Measuring transmission

SLIDE 65

Measuring transmission

SLIDE 66

Measuring transmission

SLIDE 67

Measurement setup
