SLIDE 1
1
OUTLINE
2
- Quadratic Bezier Surfaces
- Cubic Bezier Surfaces
BEZIER SURFACES 1 OUTLINE Quadratic Bezier Surfaces Cubic - - PowerPoint PPT Presentation
BEZIER SURFACES 1 OUTLINE Quadratic Bezier Surfaces Cubic - - PowerPoint PPT Presentation
BEZIER SURFACES 1 OUTLINE Quadratic Bezier Surfaces Cubic Bezier Surfaces 2 DE CASTELJAU RECURSION REVISITED l 0 =p 0 , r 3 =p 3 l 1 =1/2(p 0 +p 1 ), r 2 =1/2(p 2 +p 3 ) l 2 =1/2(l 1 +1/2(p 1 +p 2 )), r 1 =1/2(r 2
SLIDE 2
SLIDE 3
DE CASTELJAU RECURSION REVISITED
3
- l0=p0, r3=p3
- l1=1/2(p0+p1), r2=1/2(p2+p3)
- l2=1/2(l1+1/2(p1+p2)), r1=1/2(r2+1/2(p1+p2))
SLIDE 4
CURVED SURFACE
SLIDE 5
CONTROL POINTS AND RESULTING SURFACE
SLIDE 6
QUADRATIC BLENDING FUNCTIONS
- These are the same as the quadratic
Bezier curve blending functions
- Except that now we use them in two
dimensions
SLIDE 7
BEZIER PATCHES
- Double summation used for surfaces as opposed to curves
- The set of points generated for the Bezier surface is called a Bezier patch
SLIDE 8
CUBIC BEZIER PATCHES
SLIDE 9
CUBIC BEZIER SURFACES
SLIDE 10
CUBIC BEZIER SURFACE BLENDING FUNCTIONS
SLIDE 11
11
SURFACES
- Can apply the recursive method to surfaces - a
Bezier patch curves of constant u (or v) are Bezier curves in u (or v)
- First subdivide in u
- Process creates new points
- Some of the original points are discarded
- riginal and kept
new
- riginal and discarded
SLIDE 12
12
SECOND SUBDIVISION
16 final points for 1 of 4 patches created
SLIDE 13
BASE CONDITION
- With Bezier curves, the base condition was whether the curve was “straight”
enough
- With surfaces, the base condition is whether the surface is “flat” enough
SLIDE 14
14
UTAH TEAPOT
- Most famous data set in computer graphics
- Widely available as a list of 306 3D vertices and the
indices that define 32 Bezier patches
SLIDE 15
TESSELLATION
15
SLIDE 16
RECURSIVE SUBDIVISION
16
SLIDE 17
ADDING SHADING
17
SLIDE 18
GEOMETRY SHADER
- Basic limitation on rasterization is that each execution of a vertex shader is
triggered by one vertex and can output only one vertex
- Geometry shaders allow a single vertex and other data to produce many vertices
- Example: send four control points to a geometry shader and it can produce as
many points as needed for Bezier curve
18
SLIDE 19
TESSELLATION SHADERS
- Can take many data points and produce triangles
- More complex since tessellation has to deal with inside/outside issues
and topological issues such as holes
- We’ll be looking at geometry and tessellation shaders in upcoming
topics
19
SLIDE 20
SUMMARY
20
- Quadratic Bezier Surfaces
- Cubic Bezier Surfaces
