Metal Halide Perovskites: a New Family of Semiconductors for Photovoltaics and Optoelectronics Henry J. Snaith Department of Physics Clarendon Laboratory Parks Road Oxford OX1 3PU Photovoltaics and henry.snaith@physics.ox.ac.uk e-mail:
Perovskites
Perovskite is a calcium titanium oxide, with the chemical formula CaTiO3. The mineral was discovered in the Ural Mountains of Russia by Gustav Rose in 1839 and is named after Russian mineralogist Count Lev Alekseevich Perovski (1792–1856).” All materials with the same crystal structure as CaTiO3, namely ABX3, are termed perovskites.
1892: 1st paper on lead halide perovskites
Structure deduced 1959: Kongelige Danske Videnskabernes Selskab, Matematisk-Fysike Meddelelser (1959) 32, p1-p17 Author: Moller, C.K. Title: The structure of cesium plumbo iodide Cs Pb I3
First Solar Cells
Perovskite solar cells
Meso-Al2O3 η =10.9% Meso-TiO2 η =7.6% Planar Junction η =1.8%
Efficient Planar Heterojunction Solar Cells
- M. Liu et al. Nature 2013
Publications on perovskites
High T
c Superconductors
Perovskite solar cells
Publications Vs Efficiency
Perovskite Solar Cells
Crystallisation of Perovskite Thin Films
PbX2+ 3 CH3NH3I CH3NH3PbI3+ 2 CH3NH3X (X= Cl, I, Ac)
- W. Zhang et al. 2014 Nature Communications
Crystallisation of perovskite thin films
XRD The more volatile the MAX component, the faster crystallisation occurs
“Anti-solvent” quenching crystallisation
(a) (c)
Routes developed by Seok et al. and Spiccia et al.
Anti-solvent + Excess organic
Excess organic + excess PbI2
3MAI:PbCl2 2% PbI2 5% PbI2 40% PbI2 100% PbI2 3MAI:(PbCl(2-2x)PbI(2x))
- N. Saki et al. Small 2017 (in-press)
Excess organic + excess PbI2
3MAI:PbCl2 2% PbI2 5% PbI2 30% PbI2 100% PbI2
Control over “nucleation” and growth
Formulation 1 Formulation 2 Formulation 3 Formulation 1 Formulation 2 Formulation 3 Formulation 1 Jsc Formulation 1 SPO Formulation 2 Jsc Formulation 2 SPO Formulation 3 Jsc Formulation 3 SPO
19.1% Efficiency
What are the cation options?
Goldshmidt Tolerance factor
- G. Eperon et al. 2014
Adding a small amount of Cs to FAPb(I1-xBrx)3
Ability to crystallise throughout the entire I-Br compositional range
Influence of Colloids In solution
Influence of Addition of Acid (HI and HBr)
Increased crystallinity and crystal orientation
Microstrain and Charge Carrier Mobility
Crystallinity Matters
- D. McMeekin et al. 2017 Submitted
A new route for single crystal Growth
Breaking up of colloids
Breaking up of colloids
Nature Communications 2016 ( Accepted )
What we think about the mechanism
Solvent Mixtures
H2O/MA EtOH/MA ACN ACN/MA
- Solvent needs
to be polar and aprotic.
- N. Noel et al. EES 2016 In-press
Devices from ACN/MA solvent mix
annealed unannealed inverted
- N. Noel et al. EES 2016 In-press
Enhanced Stability Perovskite Solar Cells
Thermal stability good
400 500 600 700 800 1.0 1.5 2.0 2.5 3.0 3.5
MAPb(I0.6Br0.4)3
Absorption (a.u.) Wavelength (nm)
t = 0h t = 1h t = 2h t = 3h t = 4h t = 6h
B
400 500 600 700 800 1 2 3 4 5
C
FA0.83Cs0.17Pb(I0.6Br0.4)3
Absorption (a.u.) Wavelength (nm)
t = 0h t = 1h t = 2h t = 3h t = 4h t = 6h
- D. McMeekin et al. Science 2016
1.6eV gap
Champion Devices
PCBM n-type PCBCB n-type
C60 derivative
Inverted Cell Architecture
ITO Substrates NiO FA(MA)CsPb(I0.9Br0.1)3 PCBM ZnO nanocrystal Ag/Au
JSC (mA cm-2) VOC(V) FF PCE (%) FB-SC 23.27 1.04 0.78 18.9 SC-FB 23.30 1.03 0.76 18.1 JSC (mA cm-2) VOC(V) FF PCE (%) FB-SC 23.05 1.08 0.79 19.7 SC-FB 23.15 1.07 0.78 19.2
FA0.79MA0.16Cs0.05Pb(I0.9 Br0.1)3 SPO: 19.3%
FA0.85Cs0.15Pb(I0.9Br0.1)3 SPO: 18.2%
- S. Bai et al. (In preparation) 2017
Non-encapsulated solar cells
The devices are aged under full spectrum simulated AM1.5, 76 mWcm-2 average irradiance at VOC in air without a UV filter, 53 ̊C. The Suntest XLS+ aging box irradiates pulsed light.
Burn-in
t80 = 694 h t80 = 1050 h t80 = 20.7 h
Sealed vs unsealed
But…
And cheaper…
Best Way to Raise Efficiency
Epitaxially Grown Single Crystal III-V Tandem
46% efficient >$40,000/m2
Perovskite on Conventional Silicon Tandem
Up to 33% efficient <$100/m2
Image: US Naval Research Lab
Perovskite on Si
- Eg. See papers by
Baliff et al and McGehee et al,
Simple 4-T configuration
Ai
- (p)a-Si:H (~10nm)
(n)c-Si (~200µm) ITO (80 nm) (n+)a-Si:H (~30nm) Al (i)a-Si:H (<10nm) (i)a-Si:H (<10nm) + Glass FTO SnO2/PCBM Perovskite Spiro-OMeTAD ITO Buffer layer
Demonstrates Feasibility for > 25% efficiency
- D. McMeekin et al. Science 2016 DOI 10.1126/science.aad5845
Perovskite-on-Si Tandem EQE and 1-R
10 20 30 40 50 60 70 80 90 100 300 400 500 600 700 800 900 1000 1100 1200 EQE and 1-R (%) Wavelength (nm) EQE Sum IR HIT2 - Perovskite EQE - 18.57mA IR HIT2 - Silicon EQE - 18.26mA IR HIT 2 - 1-R
In collaboration with m. McGehee et al. in Stanford University
23.6%-Efficient Monolithic Perovskite/Silicon Tandem Solar Cells with Improved Stability
Kevin A. Bush†1, Axel F. Palmstrom†1, Zhengshan J. Yu†2, Mathieu Boccard2, Rongrong Cheacharoen1, Jonathan P. Mailoa3, David P. McMeekin4, Robert L. Z. Hoye3, Colin D. Bailie1, Tomas Leijtens1, Ian Marius Peters3, Maxmillian C. Minichetti1, Nicholas Rolston1, Rohit Prasanna1, Sarah Sofia3, Duncan Harwood5, Wen Ma6, Farhad Moghadam6, Henry J. Snaith4, Tonio Buonassisi3, Zachary C. Holman*2, Stacey F. Bent1, and Michael D. McGehee*1
1 Stanford University, Stanford, 94305, USA. 2 Arizona State University, Tempe, 85281, USA. 3 Massachusetts Institute of Technology, Cambridge, 02139,
USA.
4 University of Oxford, Oxford, UK. 5 D2 Solar LLC, San Jose, 95131, USA. 6 SunPreme, Sunnyvale, 94085, USA.
Can we go to “All-Perovskite” tandem
We need a low band gap perovskite cell
1.2eV planar devices?
…not so promising morphology. Tin-based materials seem to crystallise very rapidly, during spin-coating
1:1 MAI:SnI2 in DMF? Noel et al, EES 2014
Precursor-phase Antisolvent Immersion for high quality films
- 1. After spin-coating
- 2. After immersion
in anisole bath
- 4. After annealing.
50um 10um 2um
FAPb1-xSnxI3: Photoluminescence
700 750 800 850 900 950 1000 1050 0.0 0.2 0.4 0.6 0.8 1.0
PL counts (norm) Wavelength (nm) Sn percentage 0% 12.5% 25% 37.5% 50% 62.5% 75% 87.5% 100%
0% 12.5% 25% 37.5% 50% 62.5% 75% 87.5% 100% 1.20 1.25 1.30 1.35 1.40 1.45 1.50 1.55
Eg from absorption(Tauc) (eV) PL peak (BP measured - new samples) (eV) Bandgap (eV) Sn %
Cs addition enables a very high VOC for a 1.2 eV band gap material
- G. Eperon et al. Science 2016
All perovskite tandems
- G. Eperon et al. Science 2016
Sn-Pb devices show unprecedented stability
Is it worth “going tandem” without the low gap perovskites?
Calculated EQE and JVs assuming KRICT record cell parameters
A 22.1% APbX3 single junction becomes a 25.9% APbX3/APbX3 tandem Target: cell with a band gap of 2.06eV and Voc of 1.59V On Silicon, a 30.1% hybrid-tandem becomes a 33.6% “triple junction” (+ 0.7V Voc due to Si rear, and FF boost to 0.85)
Beyond Group XIV elements:
- G. Volonakis et al. JPCL 2016
ALSO See: Slavney, A. H et al. JACS 2016 McClure, E. T. et al. Chem. Matter. 2016
Calculated Band-gaps and effective mass
Single Crystal Data
- G. Volonakis et al. JPCL 2016
Device and mini-module development
Present Target:
- Develop stable and efficient materials stack
- Develop processing methodology to deliver
Efficient perovskite/Silicon tandem cells at high yield
- Partner with existing Si-PV industry to
manufacture
Commercialisation
Test and reliability laboratory Requirements:
- Climatic testing to IEC61646
- 85̊C/85% RH >1000hrs
- +85 to -40̊C cycling >200 cycles
- “Full Spectrum” Light soaking to AM1.5G
3000hrs (not IEC)
- High UV exposure
- Etc etc etc
IEC Stability testing
- 85 ̊C for 1000’s of hrs
- 85 ̊C 85% RH for 1000’s hrs
- High levels of UV light exposure
- Thermal Cycling from -40 to
+85 ̊C
- Full sun light exposure at 60 to
85C
Important note: IEC = 1000hrs
25 years = 218,850 hrs
20 40 60 80 100 120 200 400 600 800 1000 1200
Normalised perovskite Colour Intensity (%) Stressing Time (hours)
Control (140) Control (115) A B C
Proper Encapsulation of Cells
Interlayer assembly only
Encapsulation selection using 1000hr 85oC/85% baseline
Perovskite layer degradation by moisture ingress after early lamination failure
350hrs 0 hrs
Moisture ingress accelerates degradation
Cover Glass Interlayer Perovskite Film Module Glass
Stability: IEC61646 Results
Thermal Cycling: Pass Full sun light soaking: Pass Damp heat: Pass
Next Steps: Development Through to Manufacturing
Oxford PV acquires thin-film development line for perovskite scale-up
It has acquired the production site previously operated by Bosch Solar CISTech GmbH. The site, located in Brandenburg an der Havel, Germany, will be equipped to provide modern, pilot-scale capacity to scale-up Oxford PV’s perovskite technology to industry-standard wafer size and to perfect the manufacturing processes necessary for commercial deployment.
S-Q from R.Milo,WIS
qVhν – qVoperation(=MP) [eV]
Evolution of Operational loss in perovskite cells
1.0 1.2 1.4 1.6 1.8 2.0 0.2 0.4 0.6 0.8 1.0 1.2
CdTe a-Si
22.1% 20.1% 17.9% 14.1% 10.9%
GaAs
Absorption Edge (eV)
SQ- Limit Loss
GaInP c-Si
9.7%
Nayak et al. Adv. Mater., 5-2011,3-2014; updated 09-2016
Why are metal halide perovskites such good solar cell materials???
Sharp and strong absorption edge
Urbach energy as low as 13 meV Steepness of absorption edge depicts quality of semiconductor Steeper = lower disorder = higher voltage
Technology Urbach Energy (meV)
GaAs 7 c-Si 11 Perovskite 15 CIGS 25 Organics 25-50
Christoph Baliff and co workers JPCL 2014 5 (6), pp 1035–1039
Electroluminescence vs Absorption onset.
PLQE and lasing!!
500 1000 1500 2000 30 40 50 60 70 PLQE (%) Excitation power (mW/cm²)
Very High Photo Luminescent quantum yield Negligible non- radiative decay
740 760 780 800 820 0.0 0.5 1.0 1.5 2.0 Counts (x10
6)
Fluence (J/cm
2)
100 4 (scaled x25) PL Spectrum
Wavelength (nm)
Even room temperature lasing of as cast films within a cavity
Felix Deschler et al. JPCL 2014
Acknowledgements
Funding EPSRC, ERC & FP7, Oxford John Fell Fund, Oxford Martin School, Royal Society.
Research group
Collaborators: Oxford: Laura Herz, Michael Johnston, Robin Nicholas, Moritz Reide Cambridge: Richard Friend and co-workers Stanford: M. McGehee et al. GT: Seth Marder et al. Bordeaux: Guillaume Wantz et al.
