MediorNet 1 Title of Presentation (edit on Master) MediorNet Why - - PowerPoint PPT Presentation

Title of Presentation (edit on Master) MediorNet

1

MediorNet

Title of Presentation (edit on Master) MediorNet

2

Why MediorNet?

An international provider for... Fibre optical network solutions Real time Video- / Audio- / Data- / Intercom- / Sync- network solutions

Title of Presentation (edit on Master) MediorNet

3

What is MediorNet?

A distributed multimedia network solution for Video, Audio and Data

• ut of one box over an optimal TDM and WDM utilized optical fibre

Provides the freedom to flexibly build and combine any topology (ring, star, daisy chain) with redundant routing Combines cross-matrix switchers for Audio, Video and Data Glue processing like (De-)Embedder, Framestore, Framesync, up/down and cross Converter, Ident and Test Generator are included Can be integrated easily in a third party control management software

Title of Presentation (edit on Master) MediorNet

4

MediorNet – The movie…

SD HD

Title of Presentation (edit on Master) MediorNet

5

MediorNet – the advantage…

Only one data source and destination box needed transmit Audio, Video, Data and Intercom signals together over one fibre Plug and play solution due to self-detecting system the system recognizes newly added frames in any topology No hardware modification required in case of routing and distribution changes it is much more than a static CWDM point to point competitive product Only one configuration for different signal types

• nly one operator to route, distribute and process the various signals

Time saving to install, configure and maintain the MediorNet system

Title of Presentation (edit on Master) MediorNet

6

NO more additional hardware for processing needed Glue processing on any source and destination like De-embedder, Embedder, Framestore, Framesync, up-, down- and cross- Converter, Ident and Test Generator are included Traditionally used: different Hardware for different features

MediorNet – the savings…

• additional Signal Converter
• additional (De-)Embedder
• additional Test Generator
• additional Framesync
• additional Framestore
• additional Ident

Title of Presentation (edit on Master) MediorNet

7

MediorNet – the savings…

NO additional Genlock devices are needed All MediorNet frames have a Genlock output and can convert and provide Genlock to any location source in any given format (WordClock, Tri-level, BlackBurst) Traditionally used: additional Genlock Hardware

• additional Signal Converter
• additional Sync distribution
• additional redundancy

Title of Presentation (edit on Master) MediorNet

8

• All Features are software based
• No additional hardware needed
• Simple updates for feature releases

MediorNet – the savings…

Title of Presentation (edit on Master) MediorNet

9

MediorNet – the savings…

Only one Network to distribute all kinds of signals in a De-Centralized Fibre Topology Concept Traditionally used: Audio- / Video- Crossbar

• fixed route
• additional signal path needed

when the same source or destination is needed twice

• less flexible changing of

configuration

• no live changing of sources and

destinations

• one signal occupies one fiber
• ptimisation of the full

fiber capacity reducing the costs on additional hardware reducing the costs on devices per data signal

Title of Presentation (edit on Master) MediorNet

Freedom of Topology

10

Daisy Chain Topology Ring Topology Star Topology

Fiber 4.25 Gbit/s

MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET MEDIORNET

Ring Star Daisy Chain any combination of it

Title of Presentation (edit on Master) MediorNet

11

Signals and their Datarates

96kHz x 32 x 2 CH = 6.1Mbit 48kHz x 32 x 2 CH = 3 Mbit

72m 1.500Mbit/s HD-Video (720p 60 Hz uncompressed) 180m 270Mbit/s SD-Video 60m 125Mbit/s MADI Audio 150m 6Mbit/s AES Audio 35m 3.000Mbit/s HD-Video (1080p 60 Hz uncompressed) 72m 1.500Mbit/s HD-Video (1080i 60 Hz uncompressed) Max distance over copper Datarate Signal

Title of Presentation (edit on Master) MediorNet

12

Optimal utilization of fiber

Divide a carrierframe into subframes (TDM timeslots) Timeslot bandwidth 6.1Mbit/s (AES) 512 Timeslots available ( x 6,1 Mbit = 3.28 Gbit net bandwidth) Smallest signal: AES3 Audio (= 3 Mbit @ 48 kHz, = 6 Mbit @ 96kHz) Timeslots can be filled with all kinds of data (Audio, Video, Data, Intercom)

Subframe with 6,1 Mbit/s 4.25 Gbit/s gross / 3.27 Gbit/s net bandwidth AES AES MADI 1 x HD SDI 5 x SD SDI

Title of Presentation (edit on Master) MediorNet

13

MediorNet backbone

Fiber 4.25 Gbit/s Fiber 4.25 Gbit/s

MADI AES3

SD-SDI HD-SDI 3G-SDI

AES3 Hydra2

SD-SDI HD-SDI 3G-SDI

MediorNet Audio- Breakout

4.25 GBit/s 4.25 GBit/s 4.25 GBit/s 4.25 GBit/s Madi/ Hydra

Crosspoint-Matrix 3rd Party Controller Lowspeed-Breakout

Link up Link down

AES3

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Add any Topology to system

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Distribute Video, Audio and Data sources

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Connect to Riedel Intercom

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Fully integrate RockNet for Audio Distribution

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Title of Presentation (edit on Master) MediorNet

Mediornet System Overview

Flexibly use CWDM to Integrate Systems over 1 Fibre pair

Title of Presentation (edit on Master) MediorNet

• Use MADI or AES to connect Artist Intercom to Mediornet (Artist Node is required!)
• Artist is configured by Director; Mediornet by MediorWorks
• Panels are connected via AES ports on Processor Card or Breakout Panel

MADI Breakout

How to integrate Riedel Intercom via MADI and AES

Title of Presentation (edit on Master) MediorNet

• Use MADI to connect Artist Intercom to Mediornet (Artist Node is required!)
• Artist is configured by Director; Mediornet by MediorWorks
• Merge Artist Systems via Trunking

MADI MADI

How to integrate Riedel Intercom via Trunking

Title of Presentation (edit on Master) MediorNet

• Use MADI to connect Artist Intercom to Mediornet (Artist Node is required!)
• Artist is configured by Director; Mediornet by MediorWorks
• The Fibre Ring between the two Artist locations is tunnelled over CWDM

How to integrate Riedel Intercom via Ring Expansion

CWDM

Title of Presentation (edit on Master) MediorNet

How to Integrate RockNet

• Connect RockNet via Interface Card or MADI
• RockNet is configuration via RockWorks; Mediornet via MediorWorks
• Strategically place RockNet Breakouts anywhere in the location

RockNet Ring

MADI

RockNet Interface

Title of Presentation (edit on Master) MediorNet

25

4x HD SDI OUT 4x HD SDI IN 1 Gbit Ethernet

8x analog Audio IN/ OUT 8x digital Audio IN/OUT

4x AIO 4x AIO

MIDI / RS 422

2x MADI (128 Audio Channels) 2x MADI (128 Audio Channels) 1 Gbit Ethernet Fiber 4x HD SDI OUT 4x HD SDI IN

4x Camera Intercom

8x digital Audio IN/OUT 8x analog Audio IN/OUT

VSM Controller AES Analog Audio Fiber singlemode Digital Partyline CAT5 8 MIC/Line IN DM1000VCM 4x HD SDI OUT 4x HD SDI IN Fiber AES

Outside Broadcasting Van with up-Link

Title of Presentation (edit on Master) MediorNet

26

MediorNet – fast & flexible change of environment…

Title of Presentation (edit on Master) MediorNet

27

MADI over MediorNet, RockNet & Artist

Title of Presentation (edit on Master) MediorNet

28

Hardware overview

Mainframe Processor card I/O cards Link cards

Title of Presentation (edit on Master) MediorNet

29 Fan Redundant Power Supply – 230V X-Switch Processor Card 8 Slots for I/O-Cards 19” / 2RU 16 Channel Backplane Fiber 4.25 Gbit/s Single or Multi-Mode

MediorNet Frame MN-2RU

Title of Presentation (edit on Master) MediorNet

30

• Mediornet based on modular concept

– allows frame configuration to customer requirements

• Frame can be filled with various Media and Link cards
• Each Frame provides:

– 1 x Processing Card – 6 x high-speed card slots – Designed for high data rate connections (video) – Four slots with 2 x 4.25Gbit/s – Two slots with 4 x 4.25Gbit/s – 2 x low-speed card slots – Each with 2 x 125 Mbit/s – Designed for low data rate connections (audio, GPI, serial data) – Redundant Power Supply

MediorNet Frame MN-2RU – a modular system

Title of Presentation (edit on Master) MediorNet

31

Overview Processing card MN-XSS

1 Gbit/s Ethernet Sync

Blackburst NTSC, TriLevel 720p25, TriLevel 1080p29.97 Blackburst PAL, TriLevel 720p24, TriLevel 1080p25, TriLevel 720p60, TriLevel 720p23.98, TriLevel 1080p24, TriLevel 720p59.94, TriLevel 1080i60, TriLevel 1080p23.98, TriLevel 720p50, TriLevel 1080i59.94, WordClock 48kHz, TriLevel 720p30, TriLevel 1080i50, WordClock 96kHz, TriLevel 720p29.97, TriLevel 1080p30, WordClock 192kHz

System Management 3rd party control:

• Integrated Pro-Bell protocol
• Integrated VSM (Broadcast Solutions)

control system

64 Channel Optical MADI Riedel Intercom (Panel / AES) BNC or CAT5 Signaling 64 Channel Electrical MADI

Title of Presentation (edit on Master) MediorNet

32

Overview Processing card MN-XSS

Title of Presentation (edit on Master) MediorNet

33

Media - cards

MN-HDP6 (available mid Q2/2011) 6 ports electrical input- and output-card

2 input-, 2 output-, 2 configurable ports

included Signal Converter included (De-)Embedder included Test Generator included Framesync included Framestore included Ident included Quad Split

Title of Presentation (edit on Master) MediorNet

34

The card has a small independent router for the interconnections between signals and processing. This means that:

• A Quad Split or Format

Converter can receive signals from the backplane or from the card BNC inputs.

• The processed signal

can be used in the entire network as well as on the local outputs

MN-HDP6 2+2+2 SDI card with enhanced Processing

Title of Presentation (edit on Master) MediorNet

35

Enhanced Quad Split layout:

MN-HDP6 2+2+2 SDI card with enhanced Processing

• Configurable Audio

Meters, Background Colors, Text Colors, Tally Fields

• Can be cascaded to

7/10/13/16 tiles

Title of Presentation (edit on Master) MediorNet

36

A Quad Split can take a SDI signal from anywhere in the net and its

• utput can be routed to any SDI output in the system.

MN-HDP6 2+2+2 SDI card with enhanced Processing

Title of Presentation (edit on Master) MediorNet

37

Media - cards

MN-HD6 (available mid Q1/2011) 6 ports electrical input- and output-card

2 input-, 2 output-, 2 configurable ports

□

included Signal Converter included (De-)Embedder included Test Generator included Framesync included Framestore included Ident

□

included Quad Split

Title of Presentation (edit on Master) MediorNet

38

Media - cards

MN-HD4I / MN-HD4O 4 ports electrical input-card / 4 ports electrical output-card □

included Signal Converter included (De-)Embedder included Test Generator included Framesync included Framestore included Ident

□

included Quad Split

Title of Presentation (edit on Master) MediorNet

39

Media - cards

MN-HD4I-O / MN-HD4O-O 4 ports optical input-card / 4 ports optical output-card □

included Signal Converter included (De-)Embedder included Test Generator included Framesync included Framestore included Ident

□

included Quad Split

Title of Presentation (edit on Master) MediorNet

40

Media - cards

MN-MA2EO electrical / optical MADI input and output-card

2 independent MADI Ports 1 optical 1 electrical Each MADI-Channel provides 64 bidirectional mono Audio channels

Title of Presentation (edit on Master) MediorNet

41

Media - cards

MN-RN300 electrical RockNet breakout Interface-card

transports up to 128 mono- Audio channels into RockNet

Title of Presentation (edit on Master) MediorNet

42

8 analog Audio 8 AES Audio 4 serial Data 12 GPI + 12 GPO 2 x 44-pin connectors for connection to MN-MBP

Media - cards

MN-MIO-E / MN-MIO-T Multifunction Input Output-card

Title of Presentation (edit on Master) MediorNet

43

8 analog Audio 8 AES Audio 4 serial Data 12 GPI + 12 GPO 2 x 44-pin connectors for connection to MN-MIO card

Media - cards

MN-MBP Multifunction Breakout Panel

Title of Presentation (edit on Master) MediorNet

44

Media - cards

MN-ETH6 *

6 ports Ethernet-card

6 slots for SFP modules electrical or optical Ethernet Gigabit-Ethernet on each port * available in January 2011

Title of Presentation (edit on Master) MediorNet

45

Link - cards

MN-LNK2 2 bidirectional fiber links 3,2 Gbit/s net MN-LNK4 4 bidirectional fiber links 3,2 Gbit/s net Throughput of:

• 2 FHD + 1 SD
• or 2 HD + 12 SD
• or 20 SD + 8 MADI

Throughput of:

• 4 FHD + 2 SD
• or 4 HD + 25 SD
• or 40 SD + 16 MADI

Title of Presentation (edit on Master) MediorNet

46

CWDM Link - cards

MN-LNK8CWDM 4 int. SFP Wavelength 1271nm-1331nm 4 ext. Wavelength inputs 1351nm – 1411nm Throughput of up to 25.6 Gbit/s net with expansion to MN-LNK4

• 8 FHD + 4 SD
• or 8 HD + 50 SD
• or 80 SD + 32 MADI

Title of Presentation (edit on Master) MediorNet

47

CWDM Link - cards

MN-LNK10CWDM 8 int. SFP Wavelength 1271nm-1411nm 2 ext. Wavelength inputs, 1431nm-1451nm Throughput of up to 32.0 Gbit/s net with expansion to MN-LNK2

• 10 FHD + 6 SD
• or 20 HD + 15 MADI
• or 100 SD + 40 MADI

Title of Presentation (edit on Master) MediorNet

48

CWDM Link - cards

MN-LNK18CWDM 8 int. SFP Wavelength 1471nm-1611nm 1 Add/Drop Wavelength input, 1271nm-1451nm Throughput of up to 57.6 Gbit/s net with expansion to MN-LNK10 + MN-LNK2/4

• 18 FHD + 10 SD
• or 35 HD + 35 MADI
• or 200 SD + 20 MADI

Title of Presentation (edit on Master) MediorNet

49

currently we are running software-release 1.04.00 this release offers:

integrated sample rate converters in MediorNet Manual routing Automatic rerouting in case of fiber-loss Frame synchronizer with adjustable delay (min. 1 pixel, max. 5 frames SDI) Audio embedding and de-embedding (2 Groups, each group consists of 4 mono Audio channels 8 mono Audio channels per Video channel) User Group Editor, Matrix and Topology view On Screen Display adjustable Audio delay 0 - 1000 ms (in 1 ms steps)

Software

Title of Presentation (edit on Master) MediorNet

50

Software Framestore / Framesync

Framestore for each Video Output channel Adjustable delay from 1 pixel up to 1 frame for 3G, 5 frames for SDI De-embedding on Video Input Card (2 Groups, 8 Audio mono channels with SRC) Sample Rate Conversion and Audio delay (adjustable in steps of 1 ms) Embedding on Video Output Card (2 Groups, 8 Audio mono channels)

Title of Presentation (edit on Master) MediorNet

51

Software Matrix-View

Title of Presentation (edit on Master) MediorNet

52

Software Topology-View

Title of Presentation (edit on Master) MediorNet

53

Software

Manual Routing

You can include Frames and Link-cards in a route by drag and drop of that device into the white list You can exclude Frames and Link-cards in a route by drag and drop of that device into the black list White list Include in route Black list Exclude from route

Title of Presentation (edit on Master) MediorNet

54

Software

GPIO pop-up 8 embedded Audio

MN-MIO Parameter

Title of Presentation (edit on Master) MediorNet

55

• Integrate Video, Audio, Intercom, Data and Sync into one system
• Supports any combination of topologies

– True point-to-multipoint switching – Can simply add any topology to the system

• Integrated 18 Channel CWDM

–

• Max. 76.5 Gbit/s over 1 fibre
• Software based signal processing and conversion

– No extra hardware needed for features – Future proof

• Fibre optimization

– Less fibres and cabling

• Fully integrated audio network

– RockNet – MADI

• Open platform for 3rd party products

– Probel, VSM, Calrec, etc.

MediorNet Summary

Title of Presentation (edit on Master) MediorNet

56

MediorNet - That‘s it …

Title of Presentation (edit on Master) MediorNet

57

Title of Presentation (edit on Master) MediorNet

58

Thank you!

For any further questions please do not hesitate to contact us: Riedel Communications GmbH • Uellendahler Straße 353 • 42109 Wuppertal • Germany Phone +49.202.292.90 • Fax +49.202.292.9399 • www.riedel.net
