Invites you to discover Excellence in Dentistry MEDICAL

Research & Development

Clinical Research, University partnerships International culture

• Production in France
• Sales in over 20 countries
• 4 Continents
• More than 5 000 LOKKI users

worldwide

French Design & Manufacture Product Reliability, Efficient services

For over 22 years, LOBEL MEDICAL, develops, manufactures and markets equipment under the brand ”LOKKI” to simplify and optimize the daily activity of practitioners.

YAP CRISTAL

L.A.S.E.R. : Light Amplification by Stimulated Emission of Radiation

Physical principle :

YAP CRISTAL

Flash pumping system

Reflecting Mirror Semireflecting mirror

Laser Beam 1341 nm

Energy Input

Visible Infrared 635

• 680

632 532 488

• 514

KTP 800 830 980 DIODES 1064

Nd YAG

1341 Nd YAP 2780

• 2940

Er and Cr YAG

10600

CO2

• Pulsed through :

Optical Fiber

• Wavelength :

1341nm

• Peak Power :

2.6 kW

• Pulse width :

150μs

• Frequency :

5-10-30Hz.

• Aiming Laser :

red 655nm

• Transmission :

self strippable optical fibers 200μm & 320μm

Ergonomic Handpieces Intuitive Keyboard

LOBEL MEDICAL takes care of you : local service continuously Improved quality through updated technology Continued development of your clinic Patients have a new image of your clinic (Laser Nd:Yap next your dental chair) Clinical protocols approved by Universities Possibility to make new treatments Comfort and time saving for the daily painful treatments Less post-operative pain Reliable technology and equipment …

Conservative dentistry

Endodontics Minor surgery Periodontics

Decay Removal Treatment of cavity bottom Enamel Etching Treatment of pits and fissures. Treatment of sensitive collar necks. Treatment of abscesses. Frenotomy. Hemostasis of soft tissues. Managing dental sockets after extraction. Vestibular deepening

• Fast treatment
• Little post-operative pain
• No edema
• Less Surgery
• Non Invasive Treatment
• Hemostasis Control
• Non Bleeding Treatment
• Disinfection
• Biomodulation
• Periodontics specialist treatment at a general practice
• Root Canal Disinfection
• Removal of the smear-layer
• Removal of broken Instruments
• Post Removal
• De-Obturation
• Root Canal Retreatment
• Hemostasis
• Disinfection
• Endodontics specialist in a general practice

Prevention and Treatment

3 Preset functions :

Gum Dentin Canal

Soft tissue treatment : “GUM” Function

Three settings: + 330 mJ = 250 mJ

• 160 mJ

Frequency : 30 Hz

Soft tissue treatment : “GUM” Function Interests Hemostasis Disinfection Precise excision, bloodless No edema Very little post-operative pain Biomodulation

Hard tissues treatment : “DENTINE“ function

Three settings: + 400 mJ = 300 mJ

• 200 mJ

Frequency : 10 Hz

Hard tissues treatment : “DENTINE“ function Interests Disinfection Increase in micro hardness Closing tubules Increasing adhesion No caries recurrence

Three settings: + 360 mJ = 280 mJ

• 180 mJ

Frequency : 5 Hz

Root canal treatment : “CANAL” Function

Hemostasis Smear Layer elimination Obstacles and materials elimination Sterilization Root canal treatment : “CANAL” Function Interests

Les Cas Cliniques.

Day 1

Same day , after Lokki Nd:Yap treatment

7 days after

11mm pocket

Traitement des poches avec le Lokki YAP.

Before treatment 21 days after Lokki Nd:Yap Laser treatment 1 month after Lokki Nd:Yap laser treatment and provisional restorations.

Vidéo clinique du traitement des poches avec le Lokki YAP.

On July 3 months after On April 9 months after Before 4 years later

FRENOTOMY and gain of attached gingiva without grafts

On April 1 month after

GINGIVECTOMY

APHTHAE treatment

 First distant and

defocus shots at G =

 After, shots in contact

at D =, D +

HEMOSTASIS during surgery

Less post-operative pain No surgery Full Mouth Treatment in 2 sessions Non-invasive treatment Hemostasis Disinfection Bloodless eviction of tissues No edema Less anesthesia Biomodulation Saving time and money Obtaining new patients Easy access to a new type of treatment …

ENDODONTICS Cases

Photo med Laser Surg. 2005 Dec;23(6):582-5. Links In vivo study of the Nd:YAP laser in persistent periapical lesion. Ricardo AL, Britto ML, Genovese WJ. School of Dentistry Universidade de São Paulo, Brazil. anaricardo@uol.com.br OBJECTIVE: The aim of this study was to evaluate the therapeutic effect of ND:YAP laser in persistent lesions through signs and symptoms such as the presence of fistulas and pain, respectively. BACKGROUND DATA:. RESULTS: After a 7-day interval, the signs and symptoms were absent, even after a follow-up of 18 months. It was also observed, through a microbiological study, the decrease of the local microbiota. CONCLUSIONS: Our results supported the use of Nd:YAP laser, in part since it created an unfavorable environment for the continuing development of microorganisms. J Clin Laser Med Surg. 2003 Oct;21(5):279-82.Links Cleaning of the root canal using Nd:YAP laser and its effect on the mineral content of the dentin.Moshonov J, Peretz B, Brown T, Rotstein I. Department of Endodontics, Hebrew University Hadassah School of Dental Medicine, Jerusalem, Israel. moshon@cc.huji.ac.il OBJECTIVE: The aim of this study was to compare the efficacy of root canal cleanliness with and without Nd:YAP laser and to assess the effect of the laser on the mineral content of the dentin. BACKGROUND DATA: A high degree of cleanliness of the canal when using the Nd:YAG laser has been shown while the laser is in contact with the canal wall. A new Nd:YAP laser has been studied recently, which is considered to be superior to the Nd:YAG with regard to antibactericidal ability due to its 1.34 micro m wavelength, which is in the infra-red

• range. This wavelength is absorbed better in water than that of Nd:YAG. MATERIALS AND METHODS: Fourteen extracted single rooted

premplars were divided into two groups. In group 1, canals were cleaned, instrumented, and shaped with K files. In group 2, initial preparation was done using K files and completed with a Nd:YAP laser. Teeth were then split longitudinally and submitted to scanning electron microscopy. RESULTS: The cleanliness of the laser-treated teeth was significantly greater than teeth treated with K files alone (p < 0.05). No difference in Ca and P content was detected when the use of K files was compared to the use of laser.

Sterilization of root canals Removal of the smear layer Removal of broken instruments Post Removal Obturation Drying Canals Pulp capping Removal of smear layer Closing tubules Canal retreatment Hemostasis Disinfection …

Preserved by LOKKI

The LOKKI YAP Laser allows you to have real time saving Below, time gains recorded by our users :

Hemostasis 50% Gingivoplasty 30 à 50% Fourth degree 1 session Bio-pulpectomy 50 % De-obturation and retreatment 80% Frenotomy 40 to 70% without suture Loosening of pivots 20 à 50% Periapical abscess 30 to 40%

The LOKKI YAP is more than equipment : it is a "Practice builder!" It generates on average 20% of extra turnover in 2 years Nd :YAP Laser helps improve the Dental Office providing more comfort to the patient (who will know it!)

• A very significant reduction of post-operative pain
• Reduction in the number of sessions and the chair time
• Quantitative and Qualitative increase of patients

The Lokki Nd:Yap Laser makes you benefit from the “LOKKI Community” which permanent objective is : Treatments & Patient Care Development. LOBEL MEDICAL is service partner of the Odontology Department of the University Hospital La Pitié-Salpêtrière, in Paris. There research on the development of new treatments of great importance to public health is done. LOBEL MEDICAL and its academic partners are developing new applications whose interest is public health :

• The treatment of osteonecrosis caused by bisphosphonates
• The management of pain in dentistry
• The elimination of obstacles in Endodontics

PARIS – The Pitié-Salpêtrière Hospital

BELGIUM - UZ Gent

Need more information about the various applications of Lokki Nd:Yap Laser ?

S A S LOBEL MEDICAL

14, rue Fréderic Mistral F-38370 LES ROCHES DE CONDRIEU Tél 04 74 31 61 00 Fax 04 74 31 61 37 WebSite : www.lobel-medical.fr

Elexadent Ltd. (Authorised Distributor) 152 City Road, London, EC1V 2NX - UK Tel: 0845 6801065 Email: sales@elexadent.com
