Science and Technology

Park of BNTU

" Polytechnic "

Innovations in medicine

External fixator and components for orthopedics and traumatology

Implants with adjustment tool for external

• steosynthesis

Ilizarov frame

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Emergency external fixator of pelvis and long tubular bones

Advanced design of the xator joining units Reliable rigid xation of bones and bone fragments (in the required position) High mobility of elements in all directions Multiple dimensional conguration Minimization of stay time of injured person at the disaster area

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

The implant design is so ergonomic that it perfectly follows the anatomy and operates absolutely natural inside the knee joint

Knee joint endoprosthesis with unique geometry

• f femoral component surface

Optimize load distribution on joint Optimal conditions for operating

• f the extensor mechanism

Minimum saw of femur and tibia Reduction in contact stress at mating components by increasing the contact area No domestic analogues Low cost in comparison with foreign analogues

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

1

2

2

SWIFT

ARROW

Automatic biopsy gun for thin biopsy slices

High-velocity needle intake and tissue cut Optimal sampling biopsy slices length (10-20 mm) One-handed manipulation conduction Lower-priced by 30% than foreign analogues Complete warranty maintenance

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Guides are easy to remove Medical manipulations conduction (drainage) through adapter canal The surface is easy to clean from biological material and prevents contamination No analogues Increased carrying capacity while conducting biopsy by 3-5 times

Biopsy adapter for rectovaginal ultrasound sensor with removable guides

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Distal part Hypoallergenic bre Soft edge Strength seam

Stentgraft is an intravascular prosthesis consisting of a spring- type frame and a woven membrane intended for thoracic aorta aneurysm treatment and a woven membrane intended for thoracic aorta aneurysm treatment

Aortic stentgraft system for thoracic aorta aneurysm treatment

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Seamless weft structure

• f blood vessel prosthesis

using ultra-thin multifilament sutures

Corrugation

restores its initial shape after being expanded

Reinforced polyester bre

biocompatible material

Strength

elasticity, resistance to torsion and squeezing

Vascular implants for human's arterial vessels replacement

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Bllod clot filters from biocompatible materials with shape memory

The original design of the implant with two baskets and self-centering mechanisms to ensure the most efficient capture of blood clots

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Matrix stents for peripheral and coronary arteries

Peculiar stent structure, specially adjusted materials and laser production technology guarantee stent flexibility

High biocompatibility with human organs and tissues Gentle system insertion to the stenosis area Ultra low system prole Stent structure has low elastic rebound – less than 3% Minimal length contraction and low collapse rate after stent deployment Close t to vascular walls with their minimal injury rate The stent is radio opaque and provides hydrodynamic compatibility

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

The stent is produced from the material with higher level of biocompatibility and corrosion resistance

Aortic self-extending stents with unique interweaving of variable density and adjustable radial stiffness parameters

Better stent exibility in comparison with the analogues Gentle and easy insertion of stent into the area of artery expansion The structure is kink-resistant and easily penetrates through the artery areas even if its angle is less than 90 degrees The stent structure is light, inert, shape-changing and equal to anthropometric and physiological human capabilities

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

The unique basket structure and polymer filler provide interference to blood passage through defect area and subsequent complete defect closure by covering the device with own tissue

Occluder for minimally invasive closure of heart defects

High resistance to deformation and fracture The occluder does not prevent normal heart valve operation Minimally invasive operative intervention Made from Nitinol which does not react with blood and not rejected

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

The special design and weaving technology are to prevent thrombi embolization from left atrial appendage in patients with atrial fibrillation

Left atrial appendage occluder

Reliable deployment into left atrial appendage cavity Low thrombotic risk High probability of complete left atrial appendage occlusion Low probability of residual blood ow providing rapid isolation of left atrial appendage cavity from blood circulation and thrombosis of distal part

• f left atrial appendage, preventing blood clots migration

from left atrial appendage into general blood circulation High exibility and handling of the structure, thereby preventing occluder dislocation during implantation

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Valve-containing stents for repair of heart diseases

The stent does not provoke chemical reactions and allergic hypersensitivity upon contact to human tissues High biocompatibility "Sutureless" implantation technique, i.e. absence of necessity to suture Nitinol stent provides easy valve positioning during the implantation High elasticity, strength and resistance to calcication The prosthesis has low degree of biological tissue degeneration (the service life is up to 10 years) The prosthesis is close to the native aortic valve

The unique strut design for sutureless valve implantation. Nickel-titanium alloy and bovine pericardium are used as prosthetic material

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Method of ultrasonic condensation

• f endodontic filling materials provides

homogeneous filling of root canals and small lateral canals

Acoustic system and ultrasound equipment for formation of high-endurance homogeneous dentin-filling junction

Efciency improvement of endodontic root canals treatment Prevention of dental caries complications by low-frequency sound Original design of the ultrasonic transducer and the exible concentrator-waveguide for insertion lling material into root canal

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

The original design of the generator provides significant reduction of potential risks under ultrasonic endovascular treatment

Acoustic system for endovascular ablation for diabetic foot patients treatment

Special software to control supply

• f vibrations of different frequency

and intensity Waveguides with simultaneous controlled switching of suction and physiological uid management systems

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Method and ultrasound equipment for multimodality therapy of skin cancer

Ultrasonic ring waveguides reduce the gamma radiation dose for skin cancer treatment by 25% Increased efciency of contactless tumor therapy by shielding the back focus of ring operating element

The unique waveguide design implements a method

• f multimodality treatment of skin tumor mass

by combined effect of radiation and ultrasound

TRAUMATOLOGY

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

TECHNOLOGY SCIENCE KNOW-HOWMEDICINE

Individual approach to each customer!

echnopark –

high-tech equipment

Only unique technological equipment

• f leading world producers

(USA, Switzerland, Germany)

T R A U M A T O L O G Y

HEALTH

ORTHOPAEDICS

CARDIOLOGY

TECHN PARK

T E C H N O L O G Y SCIENCE

KNOW-HOWMEDICINE We are ready for mutually beneficial cooperation and further negotiations!

Science and Technology Park of BNTU "Polytechnic" 37/1 Surganova str., Minsk, 220013, Belarus +375 17 235 59 46 transfer icm.by @
