Measuring the Performance and Effectiveness of Critical security controls William Makatiani Name Here About Serianu Limited Serianu is a Pan Africa based Cyber Security and business consulting firm. We are an award winning company in the
Name Here
Serianu is a Pan Africa based Cyber Security and business consulting firm. We are an award winning company in the African Cybersecurity sector that helps our customers collect, protect, and analyze critical business information.
Our Partnerships
members
24/7 Cyber Security Command Centre Serianu Cyber-Threat Command Centre (SC3)
Africa Cyber Immersion Centre
Top 10 Cyber security Priorities for 2018
Introduce the inherent risk profiling methodology and approach Introduce the top critical cyber security controls and metrics measurement approach Discuss testing the Effectiveness of Critical Cyber Resilience and Visibility Controls Discuss how metrics can be used to facilitate decision making and improve performance and accountability. Discuss how to develop metrics that are quantifiable, observable, and objective data supporting metrics. Discuss how organisations can use metrics to apply corrective actions and improve performance. Discuss how metrics can be packaged and delivered to different stakeholders - senior management and board members
Objectives
Topic 1: Introduction to Cyber Security metrics and Performance Measurement approach Topic 2: Developing and Implementing monitoring use cases and scenarios Topic 3: Breach scenario analysis Topic 4: Cyber security visibility statements
Content
Topic 1: Introduction to Cyber Security metrics and Effectiveness Monitoring Topic 2: Developing and Implementing monitoring use cases and scenarios Topic 3: Breach scenario analysis Topic 4: Cyber security visibility statements
Content
Metrics are designed to facilitate decision making and improve performance and accountability through collection, analysis, and reporting of relevant performance-related data. Its important to understand the environment you are operating in i.e banking, Insurance, Academia etc. This involves understanding the: Top Risks Controls for mitigating these risks Testing of these controls
Cyber Security Metrics and Performance
Metrics are designed to facilitate decision making and improve performance and accountability through collection, analysis, and reporting
Its important to understand the environment you are operating. This involves understanding the: Top Risks and Inherent risks Controls for mitigating these risks Testing of these controls Cyber Security Metrics and Performance
These process enables institutions identify their risks and determine their cybersecurity maturity. The approach provides a repeatable process to measure preparedness over time. Cyber Security Metrics and Performance
Various frameworks provide guidelines for assessing security posture and the frequency of these assessment namely: ISO 27001 PCIDSS NIST CBK Guidelines Africa Cyber Security Framework (ACSF) Cyber Security Metrics and Monitoring
Three step approach: Inherent Risk Profiling – Semi-Annual Benchmarking and Maturing Assessment - Annual Visibility and Resilience Monitoring - Periodical Incident Trending and Reporting - Continuous Measuring cyber security performance and effectiveness
the following:
Inherent Risk Profiling
institution’s operations and threats directed at the institution. Inherent risk does not include mitigating controls.
categories with definitions for the least to most levels of inherent risk.
institution’s activities, services, and products individually and collectively pose to the institution. Inherent Risk Profiling
Inherent Risk Profiling and Monitoring
Category Sub-Category Data Point Least Minimal Moderate Significant Most Technology Technologies and Connection Types Total number of Internet service provider (ISP) connections (including branch connections) No connections Minimal Complexity (1-20 Connections) Moderate Complexity (21-100 Connections) Significant Complexity (101- 200 Connections) Substantial Complexity (>200 Connections) Technology Technologies and Connection Types Unsecured external connections, number of connections not users (e.g., file transfer protocol (FTP), Telnet, rlogin) None Few instances of unsecured connections (1–5) Several instances of unsecured connections (6–10) Significant instances of unsecured connections (11– 25) Substantial instances of unsecured connections (>25) Processes Organizational Characteristics Mergers and acquisitions (including divestitures and joint ventures) None planned Open to initiating discussions
In discussions with at least 1 party A sale or acquisition has been publicly announced within the past year, in negotiations with 1 or more parties Multiple ongoing integrations
People Organizational Characteristics Direct employees (including information technology and cybersecurity contractors) Number of employees totals <50 Number of employees totals 50– 2,000 Number of employees totals 2,001–10,000 Number of employees totals 10,001–50,000 Number of employees is >50,000 Processes Organizational Characteristics Changes in IT environment (e.g., network, infrastructure, critical applications, technologies supporting new products or services) Stable IT environment Infrequent or minimal changes in the IT environment Frequent adoption of new technologies Volume of significant changes is high Substantial change in
critical IT services; large and complex changes to the environment occur frequently Processes Organizational Characteristics Locations of branches/business presence 1 state 1 region 1 country 1-20 countries >20 countries Processes Organizational Characteristics Locations of operations/data centers 1 state 1 region 1 country 1-20 countries >10 countries Technology External Threats Attempted cyber attacks No attempted attacks
Few attempts monthly (<100); may have had generic phishing campaigns received by employees and customers Several attempts monthly (100– 500); phishing campaigns targeting employees or customers at the institution or third parties supporting critical activities; may have experienced an attempted Distributed Denial
within the last year Significant number of attempts monthly (501– 100,000); spear phishing campaigns targeting high net worth customers and employees at the institution
critical activities; Institution specifically is named in threat reports; may have experienced multiple attempted DDoS attacks within the last year Substantial number of attempts monthly (>100,000); persistent attempts to attack senior management and/or network administrators; frequently targeted for DDoS attacks
Designed to help management measure the institution’s level of risk and corresponding controls. The levels range from baseline to innovative. Cybersecurity Maturity includes statements to determine whether an institution’s behaviors, practices, and processes can support cybersecurity preparedness within the following four domains:
Benchmarking and Maturing Assessment
Cyber security Benchmarking and Maturity Framework
Cybersecurity Risk Management
Risk Management People & Culture Infrastructure Management Access & Data Management Third Party Management
Cybersecurity Vulnerability Management
Vulnerability Management Patch Management External Dependency Monitoring
Cybersecurity Incident Management
Event Detection Response and Mitigation Threat Intelligence
Cyberthreat Management
Cyber risk Remediation Information Sharing Metrics and Reporting Continuous Improvement
Benchmarking and Maturity Assessment
Overall Maturity Score
8.68
CYBER INFORMED
Anticipate
Domain(s) Not Implemented (0) Ad-Hoc (1) Defined (2) Measurable (3) Optimized (4) Weighted Score Maturity Score
DOMAIN 1: GOVERNANCE AND STRATEGY
1 5 4 23 2.30
DOMAIN 2: RISK MANAGEMENT
1 1 7 2 21 1.91
DOMAIN 3: PEOPLE AND CULTURE
4 1 3 2 13 1.30
DOMAIN 4: INFRASTRUCTURE MANAGEMENT
2 5 19 2.71
DOMAIN 5: ACCESS AND DATA MANAGEMENT
1 1 7 1 28 2.80
DOMAIN 6: THIRD PARTY MANAGEMENT
6 2 18 2.25
DOMAIN 7:BUSINESS CONTINUITY AND INCIDENT RESILIENCE PLANNING
3 2 12 2.40 Total 5 4 27 24 1 134 15.67
Detect
Domain(s) Not Implemented (0) Ad-Hoc (1) Defined (2) Measurable (3) Optimized (4) Weighted Score Maturity Score
DOMAIN 1:VULNERABILITY MANAGEMENT
1 1 6 3 22 2.00
DOMAIN 2: PATCH MANAGEMENT
1 2 8 2.67
DOMAIN 3: EXTERNAL DEPENDENCY MONITORING
1 1 6 21 2.63 Total 1 2 8 11 51 7.29
Respond
Domain(s) Not Implemented (0) Ad-Hoc (1) Defined (2) Measurable (3) Optimized (4) Weighted Score Maturity Score
DOMAIN 1: EVENT DETECTION
2 4 2 16 2.00
DOMAIN 2: RESPONSE AND MITIGATION
6 12 2.00
DOMAIN 3: THREAT INTELLIGENCE
1 2 4 1.33 Total 1 2 12 2 32 5.333333333
Contain
Domain(s) Not Implemented (0) Ad-Hoc (1) Defined (2) Measurable (3) Optimized (4) Weighted Score Maturity Score
DOMAIN 1: CYBER RISK REMEDIATION
4 2 14 2.33
DOMAIN 2: INORMATION SHARING
2 2 2 0.50
DOMAIN 3: METRICS AND REPORTING
3 1 9 2.25
DOMAIN 4: CONTINUOUS IMPROVEMENT
1 2 4 1.33 Total 3 2 9 3 29 6.42 Weighted Score = Sum (Weight of Control * No. of Control) Maturity Score = Weighted Score / No. of Controls E.g. Consider a "Domain X" which has total 6 controls. Assume out of the 6 controls, 1 is "Not Implemented"; 2 is "Defined" and 3 are "Optimized. The Weighted Score of Domain X = 1*0+2*2+3*4=16 and Maturity Score of Domain X = 16/ 6 = 1.66.
25
5
10 15 20
Score: 8.68
Cyber Security Visibility and Resilience Monitoring
posture, with the objective of providing senior business leadership with the appropriate understanding of the state of their information security efforts.
capture an overall view of their security posture and helps to identify significant risks. The components map to the different controls that have been identified as being weak.
Top 10 Critical Cyber security Controls - Monitoring
Visibility and Resilience Monitoring
EXISTENCE (0.3) COMPLETENESS (0.3) TIMELINESS (0.2) REPORTING (0.2) VISIBILITY SCORE 1.0 ASSET MANAGEMENT 2.0 USER MANAGEMENT 3.0 PRIVILEGED ACCOUNTS 4.0 CHANGE MANAGEMENT 5.0 VULNERABILITY MANAGEMENT 6.0 MALWARE MANAGEMENT 7.0 BREACH SCENARIO ANALYSIS 8.0 MONITORING AND ANALYSIS 9.0 INCIDENT RESPONSE AND RECOVERY 10.0 TRAINING AND AWARENESS
Existence and Completeness
Perimeter and Boundary Network and Applications Database and Transactions Websites and Portals Employees and Third Parties
compliant with established policy. Verify that the system does not allow weak passwords to be used. Fully Implemented
used for the account. Verify that the system requires unique new passwords during each update. Not Implemented
successful, identify whether passwords are cryptographically secured. Fully Implemented N/A
Access Management
Timeliness and Effectiveness
Perimeter and Boundary Network and Applications Database and Transactions Websites and Portals Employees and Third Parties
user accounts? Effective
network and security device user accounts? Not Effective
Partially Effective
Not Effective
Access Management
Reporting and Trending Perimeter and Boundary Network and Applications Database and Transactions Websites and Portals Employees and Third Parties
detected within a period of time?
Fully Reports
time?
Does not Report
system have been detected within a period of time?
Partially Reports
network that are not utilizing Network Access Control (NAC) with client certificates to authenticate to the organization's network (by business unit)?
Not Available
Access Management
Automated Metrics Perimeter and Boundary Network and Applications Database and Transactions Websites and Portals Employees and Third Parties
been detected within a period of time?
Fully Reports
period of time?
Does not Report
the system have been detected within a period of time?
Partially Reports
network that are not utilizing Network Access Control (NAC) with client certificates to authenticate to the
Not Available
Access Management
This focuses on the following areas: Incident Trending and Reporting
Incident Trending and Reporting
DESIGN OPERATING SIGNIFICANT MATERIAL TOTALS
1.0 ASSET MANAGEMENT 2.0 USER MANAGEMENT 3.0 PRIVILEGED ACCOUNTS 4.0 CHANGE MANAGEMENT 5.0 VULNERABILITY MANAGEMENT 6.0 MALWARE MANAGEMENT 7.0 BREACH SCENARIO ANALYSIS 8.0 MONITORING AND ANALYSIS 9.0 INCIDENT RESPONSE AND RECOVERY 10.0 TRAINING AND AWARENESS
Topic 1: Introduction to Cyber Security metrics and Performance Measurement approach Topic 2: Developing and Implementing monitoring use cases and scenarios Topic 3: Breach scenario analysis Topic 4: Cyber security visibility statements
Content
Regardless of the size, architecture or industry, a security analyst succeeds or fails by their ability to collect and understand:
When it comes down to it, we have two things: Assets and Users.
.
.
.
Key Static Metrics
Unauthorized Access Vulnerabilities Changes Configurations
.
An Analysts key focus should revolve around the following:
Threshold Analysis Volume Velocity Limits Multiplicity Profile Analysis Correlation
Perimeter and Boundary
Control Devices Control Metric Source for the log Is the source collecting the log Log retention
device Status Reports Rules Alerts Tested? Comments
Firewall, NAC, NAT, VPN, routers, proxy systems, wireless Access Point (WAP), attacks and violations, ports, anomalous request types, denial of service and false positives, Network and host IDS/IPS WIDS Malware Partially Pending Pending Pending Pending Pending IPS Implementation Authentication Closed a a a a Pending DLP implementation Exploits Partially Pending Pending Pending Pending Pending IPS Implementation Access Closed a a a a N/A Scanning Closed a a a a N/A Performance Closed a a a a N/A Availability Closed a a a a N/A Data Loss Prevention Pending Pending Pending Pending Pending Pending DLP implementation Configuration changes Closed a a a a N/A Network and Applications
Topic 1: Introduction to Cyber Security metrics and Performance Measurement approach Topic 2: Developing and Implementing monitoring use cases and scenarios Topic 3: Breach scenario analysis Topic 4: Cyber security visibility statements
Content
Breach Scenario Analysis
What can go wrong in with our current business processes? Which systems are most likely to be used to leverage the attack? Who is most likely to attack us? Insider? How will the attack us?
Topic 1: Introduction to Cyber Security metrics and Performance Measurement approach Topic 2: Developing and Implementing monitoring use cases and scenarios Topic 3: Breach scenario analysis Topic 4: Cyber security visibility statements
Content
Cyber security Resilience and Visibility Statement
The cyber security balance sheet. Reports the level of visibility that management have into cyber security posture of the organisation It is based on the cyber security resources, investments and details of a company security posture on a specific day. This is a snapshot of what the company looked like at a certain time in history.
Cyber security Deficiency and Incident Statement
‘the cyber security income statement’
Report incidents, activities, and resulting impact positive or negative of an
Compares the number of incidents in a certain period over a previous period. Shows key stakeholders and shareholders how efficiently the company is at mitigating cyber security threats from available resources.
Visibility as at March 30, 2018 Asset Management Control Devices Year Existence Completeness Timeliness Reporting Visibility Score 2018 80% 80% 60% 60% 70% 2017 70% 70% 60% 50% 63% Control Devices Year Existence Completeness Timeliness Reporting Visibility Score 2018 60% 50% 40% 30% 45% 2017 30% 30% 25% 25% 28% Control Devices Year Existence Completeness Timeliness Reporting Visibility Score 2018 70% 66% 70% 70% 69% 2017 40% 40% 33% 40% 38% Control Devices Year Existence Completeness Timeliness Reporting Visibility Score 2018 80% 78% 71% 78% 77% 2017 68% 63% 63% 40% 59% Monitoring and Analysis 1) Logging 2) Static Metric Analysis 3) Threshold Analysis 4) Profiling 5) Correlation
THE CYBER SECURITY RESILIENCE AND VISIBILITY STATEMENT
Hardware and Software (Databases, Servers, Laptops, Routers) User Management 1) Employees 2) Vendors 3) System Accounts 4) Customer Accounts Breach Scenarios 1) Insider Threats 2) External Threats
User Management Design Operating Significant Material
2018
30 60 58 60
2017
66 56 53 56
2016
56 46 36 46 Privileged Accounts Design Operating Significant Material
2018
80 75 70 75
2017
77 70 67 70
2016
70 65 60 65 Malware and Viruses Design Operating Significant Material
2018
56 42 33 42
2017
55 40 30 40
2016
20 32 26 32 Monitoring and Analysis Design Operating Significant Material
2018
68 63 61 63
2017
63 60 55 60
2016
60 55 51 55 THE CYBER SECURITY DEFICIENCY AND INCIDENT STATEMENT
