Manchester North West Quadrant

Stakeholder Conference - 10 October 2018

Welcome

Jacqui Allen

MNWQ SRN Project Director Highways England 2

Agenda

1. Welcome 2. Key note speakers 3. MNWQ Strategic Road Network (SRN) 4. MNWQ Multi Modal (MM) 5. The Road Ahead 6. Panel Q&A 7. Lunch - Market Place and Networking 8. Focus Groups

Housekeeping

Fire exits Facilities Refreshments

Safety moment

Keynote Speaker

Henri Murison

Director, Northern Powerhouse Partnership 6

Keynote Speaker

Philip Andrews

Deputy Director, RIS Futures & RIS2, Strategic Roads Directorate Department for Transport 7

Road Investment Strategy (RIS2) Update

Road continues to dominate transport choices

The National Roads Fund

In July 2015, the government announced the creation of a new National Roads Fund. From 2020 onwards, all of the revenue from Vehicle Excise Duty (VED) raised in England will be reserved for spending on the road

• network. This means there is will be a committed, ring-fenced source
• f funding for future roads.

Strategic Road Network RIS2 – Statement of Funds Available Major Road Network Consultation on scope and process for funding MRN later 2017

Raising the pace of investment

100 200 300 0.0 1.0 2.0 3.0 1960-61 1970-71 1980-81 1990-91 2000-01 2010-11 2020-21

Traffic (bn vehicle miles) Investment (£bn)

What is RIS2?

Strategic Vision What government wants to achieve with the network Performance Specification What performance is expected across the network Statement of Funds Available What money is available to fund activities and improvements Investment Plan Where improvements will be made to the network

RIS2, like RIS1, will be more than just a list of investments

Key Aims of RIS2

Surrounding Influences

New Partners

We are also dealing with the emergence of four new sub- national transport bodies:

• Transport for the North
• Midlands Connect
• England’s Economic Heartland
• Transport for the South East

Add these to the existing devolved transport administrations, local authorities and local enterprise partnerships, plus a host of local campaigns.

Which means – more connection

There is now more scope for roads policy to join up with other government priorities or other aspects

• f transport.

Which means –more ambition

Key dates

MNWQ Update

Jacqui Allen

MNWQ SRN Project Director Highways England 19

MNWQ Scene Setting

MNWQ is being delivered in two parts:

TfN and TfGM are responsible for delivering the Multi Modal and Local Road Network study, known as the MNWQ MM study. Highways England are responsible for delivering the Strategic Road Network study known as the MNWQ SRN study

MNWQ Scene Setting

Wider Context

The Northern Powerhouse RIS 2 Manchester North West Quadrant Greater Manchester Spatial Framework Clean Air Zones The Northern Powerhouse HS2 Strategic Development Corridors Smart Motorways Manchester City Centre Transport Strategy GM 2040 Transport Strategy

Delivery Timescales

The Project Control Framework

6 7 Closeout Construction, commissioning and handover

Key Outcomes Options for Further Development Public Consultation & PRA DCO Submission SoS Decision Notice to Proceed to Construction Open to Traffic Defects and Aftercare Indicative Timescales October 2019 Autumn 2020 TBC TBC TBC TBC TBC

SRN Update

Dave Riley

MNWQ SRN Design Project Director 24

MNWQ Objectives

Economy/Growth

Support the delivery of the Northern Powerhouse by ensuring the MNWQ enables transformational growth in the employment, housing and the economic

• utput of the North

Network Capability

Create a more reliable, less congested and better connected transport network that works for the users who rely on it.

Environment

Maximise opportunities for a net improvement to the environment and minimise adverse impacts particularly to air quality and noise

Stage 1 – Where are we?

Key challenges – strategic planning and growth

Connectivity

Peter Farrer

MNWQ SRN Engineering Lead 28

Connectivity – Interventions

Topography

High Medium Low

This heat map shows the topography around the M60 Junction 15 (M61) There is over 50m difference between the lowest and highest points in the area The Irwell Valley presents a constraint on tunnel vertical alignments, particularly if links are to be provided to the M61 due to its close proximity.

Ground Engineering and Coal Mining

This plan shows the recorded coal mine workings in the area, there will also be deeper workings present that are unrecorded

Environment

Pete Simpson

MNWQ SRN Environmental Lead 32

Environmental Constraints

Example high level environmental constraints Flood risk Constraints mapping is carried out for two main purposes at Stage 1:

• To provide a clear, visual tool

showing locations of key environmental constraints, to be used in the development of options

• To capture details of all relevant

environmental constraints to inform the environmental assessment of

• ptions

The maps on the slides show an example of some of the constraints data collected; flood risk, ecology and cultural heritage

Environmental Constraints

Example high level environmental constraints Ecology

Environmental Constraints

Example high level environmental constraints - Heritage

Tunnelling Pros and Cons

• Avoidance of habitats / protected sites
• Avoiding noise impacts on communities
• Potential to improve air quality
• Fewer visual/landscape impacts
• Avoidance of shallow contaminated soils
• Surface features – portals/ventilation shafts
• Construction Impacts - getting to depth
• Groundwater contamination / drainage impacts
• Sterilisation of mineral resources
• Volume of materials used/waste

Growth

Mark Jeffcott

MNWQ SRN Growth Lead 37

Long distance traffic using MNWQ

ANPR Cordon (24hr period) Vehicles per day 125,000 189,000 170,000 133,000

All Vehicles – 00:00 to 23.59

Demand (veh) Lane Equivalent Movement (Two-way)

Junction 12 – Junction 15

41,000 2.3 M60 (S) to M61/A666 14,000 0.9 M61/A666 to M62 (W) 13,000 0.8 M61/A666 to M602 28,000 1.8 M62 (W) TO M62 (E) 96,000 5.8 out of 8 (J12 – J13)

Junction 15 – Junction 18

28,000 1.8 M62 (W) TO M62 (E) 24,000 1.6 M61 to M62 (E) 18,000 1.1 M61 to M60 (E) 70,000 4.5 out of 8

ANPR data analysis – movement summary

Top 5 Local Movements through ANPR Cordon (24hr period)

All Vehicles – 00:00 to 23.59

Rank Demand (veh) Lane Equivalent Movement (Two way) 1 42,000 2.8 M60 J21 (M602) - M60 J12 (M62) 2 28,000 1.9 M60 J14 (A580E) – M60 J15 (M61/A666) 3 23,000 1.5 M60 J14 (A580E) – M60 J14 (A580(W) 4 18,000 1.2 M60 J20 (A664(W) – M60 J20 (A664E)) 5 16,000 1.1 M60 J16 (Manchester Road (N) – M60 J16 (Manchester Road (S)

Multi Modal (MM) Update

Nicola Kane

Head of Strategic Planning and Research, Transport for Greater Manchester 40

• Revisit the non-SRN interventions to increase confidence in their scope and deliverability
• Explore additional opportunities on the local road network and sustainable modes to further support the

SRN project.

• Explore the broader impacts of the SRN interventions on the local transport network
• Ensure the overall package meets both strategic and local needs.

Purpose of the Study

Scope Considerations

Public Transport Capacity Rail Freight Capacity Travel Demand Management Impacts of SRN interventions GMSF Allocations Local Transport Policy Objectives

Multi Modal Strategic Case

Development of the Strategic Case to identify issues and opportunities relating to the local transport

• network. This considers:
• Impact of the SRN interventions on the network.
• Implications of development proposals relating to the Greater Manchester Spatial Framework.
• Walking and cycling issues, particularly at intersections with the SRN.
• Issues and opportunities for the rail, bus and Metrolink networks.
• Air quality and noise issues.

Challenges in relationship to the key spatial themes:

The M60 Role Profile

A Globally Connected City City to City Links A Regional Centre Wider City Region

Globally Connected City

Limited direct and frequent public transport connections to district centres

Manchester Airport

Wigan Bolton Bury Rochdale Altrincham

Access to Manchester Airport

46

Reliability and resilience of port access and long distance freight on M62 Capacity issues for rail freight travelling east-west Port Salford

Manchester Airport

Impacts on local road network from increased freight traffic at Port Salford Impacts on local road network from increased freight traffic at the airport

Kingsway Business Park Future development site at Carrington Logistics North Heywood Distribution Park

Freight

47

City-to-City Links

Quality of links into Lancashire Competition between local and long distance trips on M60 Resilience of M62 Trans-Pennine route

Severance caused by Manchester Ship Canal

Conflict and resilience on highways

49

Quality of bus routes into Lancashire, including service via Prestwich Competition between local and long-distance service

• n Chat Moss line

Capacity on Trans- Pennine routes Quality of rail links to Lancashire, particularly to Blackburn and Burnley Competition between local and long-distance service on CLC line Frequency and capacity on Calder Valley Line Regional centre corridor capacity

Frequency and capacity on key bus and rail routes

50

Getting into and around the regional centre

Light and heavy rail capacity constraints in regional centre Quality of service on Chat Moss line Quality of service on CLC line Overcrowding on Bolton rail corridor Capacity and frequency limits on Atherton line Overcrowding and bottlenecks on Bury line

Frequency and capacity issues on rail and Metrolink

54

A580 A57 A56 A56 A6

Congestion on radial highway corridors into regional centre

55

Travel across the wider city region

Peak time congestion on A56 and A6144 Peak time congestion on A57 Limited journey

• ptions between GM

economic centres Severance caused by Manchester Ship Canal

Manchester Airport Wigan Bolton Bury Rochdale Altrincham

NG1 NG2 NG3 Logistics North Carrington Elton Reservoir Walshaw

Need for appropriate access to GMSF developments Peak time congestion on A56

Travel across the wider city region

57

Existing Multi Modal Components

Connected Neighbourhoods

Connected Neighbourhoods

Active travel connections to local centres Active travel connections to district centres Severance caused by motorway network Severance caused by Manchester Ship Canal Severance caused by district centre ring roads Additional challenges:

• Quality and extent of existing active travel networks and streets
• Active travel access and connections to public transport links

52

Assessing Options

Long List Short List Preferred package and strategic outline programme Delivery Plans Further project development and delivery

Packaging, based on scheme objectives

Informed by GMSF Transport Study

Objective based sifting process

Summary

Jacqui Allen

MNWQ SRN Project Director Highways England 61

Road Ahead

Seek approval regarding what to take into stage 2 Consider Multi-Modal impacts Consider technology implications Develop a supporting consenting strategy Develop a delivery strategy Prepare 3 delivery plans for Multi-Modal

Stakeholder Engagement

Q&A Panel
