LPC - 1

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Title Sheet, Historic Designation District Map, Block Plan

Crown Heights North Historic District

B r o o k l y n B r o o k l y n M a n h a t t a n M a n h a t t a n Atlantic Avenue Eastern Parkway Ocean Parkway

Park Pl Dean St Pacific St Bergen St Sterling Pl Atlantic Av Herkimer St St Mark's Av N

  • s

t r a n d A v B r

  • k

l y n A v N e w Y

  • r

k A v Prospect Pl K i n g s t

  • n

A v R

  • g

e r s A v Bedford Av Herkimer Pl S t A n d r e w ' s P l P e r r y P l A t l a n t i c A v

Brower Park

1182 1200 1 3 2 7 1351 19-29* 1123 1122 638 607 622 585 1325 1361 1284 1314 1265 1285 100 121 1 1 1161 1188 787 828 907 961 1 7 2 905 144 1 2 1297 1308 860 9 6 143 1402 1417 1454 1477 1435 1392 73 70 * AKA: 1363 Bedford Av

St Andrews Playground

Historic District Boundaries NYC LANDMARKS PRESERVATION COMMISSION Proposed Crown Heights North Historic District Calendared June 20, 2006 Public Hearing September 19, 2006 Designated April 24, 2007 The street numbers indicate the last building in the district on each street.

THE CITY OF NEW YORK LANDMARK PRESERVATION COMMISION ARCHITECTURAL DRAWINGS

SCOPE OF WORK:

Proposed interior and exterior renovation is for an existing 1970s building, 1 story high, used as a place of worship. Renovation includes replacement of existing roof and the HVAC rooftop unit, replacing and improvement of existing facade features and installing a new ADA compliant sidewalk ramp.

BLOCK PLAN HISTORIC DISTRICT BOUNDARY MAP

for Proposed Renovation and Alteration of : Kingdom Hall of Jehovah’s Witnesses 1260 Bergen Street Brooklyn, NY 11213

slide-2
SLIDE 2

LPC - 001.A

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Previously Proposed Front (South) Elevation and Currently Proposed Elevation

PROPOSED FRONT (SOUTH) ELEVATION

PROPOSED FRONT (SOUTH) RENDERING 2 4

FIRST ROOF FLOOR FIRST FLOOR FINISH EL 0’-0” EL 12’-3”

SECOND ROOF FLOOR EL 16’-4” PROPOSED LEAD COPPER AWNING W/ BLACK METAL BRACKETS

RECONDITION EXTG BRICK PROPOSED ADA COMPLIANT SIDEWALK RAMP AND RAILING OF HALL KINGDOM JEHOVAH’SWITNESSES

REPLACE AND REPAIR BRICK TO CORRECT COURSING

  • EXTG. SAFETY

RAILING TO REMAIN

NON-ILLUMINATED IDENTIFICATION

  • SIGNAGE. ALUMINUM ARCHITECTURAL

GRADE, FLAT CUT, PAINTED BLACK SQUARE LOGO SIGN, PAINTED BLUE 9’-0” 1’-9”

SIDE FENCE TO REMAIN SIDE FENCE TO REMAIN PARAPET CAP TO BE REPLACED IN-KIND

PREVIOUSLY PROPOSED FRONT (SOUTH) ELEVATION

1

9’-0” FIRST ROOF FLOOR EL 12’-3” EL 0’-0” NICHIHA SANDSTONE FACADE PANEL IN DESERT BEIGE, ED642 EXISTING FENCE TO REMAIN OUTLINE OF AN EXISTING PARAPET FRONT NICHIHA VINTAGE BRICK ARCHITECTURAL WALL PANEL FINISH: WHITEWASH, ED 452 GLASS AWNING WITH BRONZE CONNECTING RODS NON-ILLUMINATED IDENTIFICATION SIGNAGE BRUSHED BRONZE FINISH FONT: WT KNOLL MEDIUM TEXT DEMI, OR COMPARABLE FONT SQUARE LOGO SIGN, PAINTED BLUE PAINTED CELLULAR PVC PROFILE TO MATCH SANDSTONE AWP COLOR 1’-9” OF HALL KINGDOM JEHOVAH’SWITNESSES FIRST FLOOR FINISH

  • EXTG. SAFETY

RAILING TO REMAIN

PREVIOUSLY PROPOSED FRONT (SOUTH) RENDERING

3

slide-3
SLIDE 3

LPC - 001.B

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Previously Proposed East and West Elevations and Currently Proposed East and West Elevations

PROPOSED WEST ELEVATION RENDERING

PROPOSED EAST ELEVATION RENDERING 2 4

PREVIOUSLY PROPOSED WEST ELEVATION RENDERING

1

PREVIOUSLY PROPOSED EAST ELEVATION RENDERING

3

slide-4
SLIDE 4

LPC - 2

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Block Plan Plan, Exisiting Facade Photos

VIEW OF EXISTING FACADE LOOKING EAST

1 2 3

1 VIEW FROM ACROSS THE STREET OF EXISTING FACADE (SOUTH) 2 VIEW OF EXISTING FACADE LOOKING WEST 3

slide-5
SLIDE 5

LPC - 3

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Existing Front (South) Elevation and Photo Proposed Front Elevation and Rendering

EXISTING FRONT (SOUTH) ELEVATION

PROPOSED FRONT (SOUTH) ELEVATION

EXISTING FRONT (SOUTH) PHOTO PROPOSED FRONT (SOUTH) RENDERING

SECOND ROOF FLOOR EL 16’-4” EXTG SAFETY RAILING TO REMAIN FIRST ROOF FLOOR EL 12’-3” REMOVE EXISTING LIGHT FIXTURE REMOVE EXISTING SIGNS FRONT FACING PORTION OF FENCE TO BE

  • REMOVED. SIDE

FACING FENCE TO REMAIN FIRST FLOOR FINISH EL 0’-0” REMOVE EXISTING ROLLING GATE, DOOR AND DOOR FRAME REMOVE EXISTING LIGHT FIXTURE EXISTING GAS METER TO BE RELOCATED REMOVE EXISTING ROLLING GATE, DOOR AND DOOR FRAME

  • EXTG. SAFETY

RAILING TO REMAIN REMOVE EXISTING SIGN

1 2 3 4

FIRST ROOF FLOOR FIRST FLOOR FINISH EL 0’-0” EL 12’-3”

SECOND ROOF FLOOR EL 16’-4” PROPOSED LEAD COPPER AWNING W/ BLACK METAL BRACKETS

RECONDITION EXTG BRICK PROPOSED ADA COMPLIANT SIDEWALK RAMP AND RAILING OF HALL KINGDOM JEHOVAH’SWITNESSES

REPLACE AND REPAIR BRICK TO CORRECT COURSING

  • EXTG. SAFETY

RAILING TO REMAIN

NON-ILLUMINATED IDENTIFICATION

  • SIGNAGE. ALUMINUM ARCHITECTURAL

GRADE, FLAT CUT, PAINTED BLACK SQUARE LOGO SIGN, PAINTED BLUE 9’-0” 1’-9”

SIDE FENCE TO REMAIN SIDE FENCE TO REMAIN

  • EXTG. PARAPET

CAP TO BE REMOVED AND REPLACED IN-KIND PARAPET CAP TO BE REPLACED IN-KIND

slide-6
SLIDE 6

LPC - 4

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

Proposed Front (South) Elevation Rendering

slide-7
SLIDE 7

LPC - 5

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

EXISTING AND PROPOSED SIDE ELEVATION

EXTG SAFETY RAILING TO REMAIN SECOND ROOF FLOOR EL 16’-4” FIRST ROOF FLOOR EL 12’-3” FIRST FLOOR FINISH EL 0’-0” EXISTING FENCE SIDE TO REMAIN

EXISTING TYPICAL SIDE ELEVATION

1

PROPOSED TYPICAL SIDE ELEVATION

2

TOP OF EXISTING ADJACENT BUILDING EL 32’-0” FIRST FLOOR FINISH EL 0’-0” FIRST ROOF FLOOR EL 12’-3” SECOND ROOF FLOOR EL 16’-4” ROOF HEIGHT CHANGE MECHANICAL ROOFTOP UNIT OUTLINE OF ADJACENT BUILDING OUTLINE OF ADJACENT STAIR EXISTING FENCE SIDE TO REMAIN

  • EXTG. SAFETY

RAILING TO REMAIN APPLY NEW STUCCO FINISH OVER EXTG. MASONRY BLOCK PROPOSED LEAD COPPER AWNING W/ BLACK METAL BRACKETS

slide-8
SLIDE 8

LPC - 6

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

PROPOSED ROOF PLAN

PROPOSED ROOF PLAN

1

ADJACENT BUILDING 34-11” +/- 14’-0”

LOWER ROOF

NEW ROOF SLOPED TOWARD DRAINS. DESIGN AND DRAING LOCATIONS TBD. NEW R00F LADDER TO UPPER ROOF MECHANICAL ROOFTOP UNIT NEW ROOF HATCH W/ SAFETY LADDER AND RAILING SYSTEM 12’-8” ADJACENT BUILDING ROOF LEVEL CHANGE FIXED WALL W/ GALVANIZED STEEL RAILING SYSTEM, MIN. 42” HEIGHT TO TOP RAIL

UPPER ROOF

NEW ROOF SLOPED TOWARD DRAINS. DESIGN AND DRAING LOCATIONS TBD. 39’-3” +/- GALVANIZED STEEL RAILING SYSTEM.

  • MIN. 42” HEIGHT

TO TOP RAIL EXISTING STEPPED PARAPET WALL

  • EXTG. SAFETY

RAILING TO REMAIN

  • EXTG. SAFETY

RAILING TO REMAIN PARAPET CAP TO BE REPLACED IN-KIND

slide-9
SLIDE 9

LPC - 7

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

SIGHTLINE SECTION

slide-10
SLIDE 10

LPC - 8

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

PROPOSED FIRST FLOOR PLAN

PROPOSED FIRST FLOOR PLAN

1

PLATFORM AUDITORIUM

34-11” +/-

ADJACENT BUILDING

14’-0” NEW FULL TEMPERED GLASS DOUBLE METAL DOOR NEW RECESSED ROLL DOWN SECURITY DOOR OUTLINE OF AWNING ABOVE NEW METAL EGRESS DOOR

ADJACENT BUILDING

EXISTING FIRE DOOR TO REMAIN

EMERGENCY HALLWAY MEETING ROOM 1 WOMEN’S MEN’S UTILITY ROOM LOBBY MULTI-PURPOSE ROOM

STEP UP NEW ADA RAMP & RAILING SIDE OF EXTG.FENCE TO REMAIN SIDE OF EXTG.FENCE TO REMAIN 12’-8”

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING STEPS DOWN TO STREET LEVEL 3’-8” RELOCATED GAS METER

slide-11
SLIDE 11

LPC - 9

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

DEMOLITION PLAN

DEMOLITION PLAN

1

EMERGENCY HALLWAY MEETING ROOM 1 WOMEN’S MEN’S UTILITY ROOM LOBBY MULTI-PURPOSE ROOM COAT ROOM OFFICE DASHED LINES REPRESENT WALL TO BE DEMOLISHED AUDITORIUM

EXISTING FENCE 14’-0” SIDE OF EXTG.FENCE TO REMAIN

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING SIDE OF EXTG.FENCE TO REMAIN 12’-8”

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING

  • EXTG. PLANTING &

TOPSOIL TO BE REMOVED

  • EXTG. PLANTING &

TOPSOIL TO BE REMOVED

  • EXTG. FENCE

TO BE REMOVED RELOCATE EXTG. GAS METER

slide-12
SLIDE 12

LPC - 9

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

DEMOLITION PLAN

DEMOLITION PLAN

1

EMERGENCY HALLWAY MEETING ROOM 1 WOMEN’S MEN’S UTILITY ROOM LOBBY MULTI-PURPOSE ROOM COAT ROOM OFFICE DASHED LINES REPRESENT WALL TO BE DEMOLISHED AUDITORIUM

EXISTING FENCE 14’-0” SIDE OF EXTG.FENCE TO REMAIN

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING SIDE OF EXTG.FENCE TO REMAIN 12’-8”

  • APPX. DISTANCE TO FACADE

OF ADJACENT BUILDING

  • EXTG. PLANTING &

TOPSOIL TO BE REMOVED

  • EXTG. PLANTING &

TOPSOIL TO BE REMOVED

  • EXTG. FENCE

TO BE REMOVED

slide-13
SLIDE 13

LPC - 10

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

EAST AND WEST RENDERING OF THE PROPOSED ELEVATION

VIEW OF EXISTING FACADE LOOKING EAST

1

VIEW OF EXISTING FACADE LOOKING WEST

3

RENDERING OF THE PROPOSED FACADE LOOKING EAST

2

RENDERINGG OF THE PROPOSED FACADE LOOKING WEST

4

slide-14
SLIDE 14

LPC - 11

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

EXISTING AND PROPOSED STREETSCAPE BLOCK PLAN DATED 1929

EXISTING STREETSCAPE

1

PROPOSED STREETSCAPE

2

BLOCK PLAN, dated 1929 PHOTOCOPY TAKEN FROM DESK ATLAS OF THE BOROUGH OF BROOKLYN CITY OF NEW YORK 1929, VOLUME 1 LOT #19 IS SHOWN AS AN UNDEVELOPED PROPERTY

slide-15
SLIDE 15

OF HALL KINGDOM JEHOVAH’SWITNESSES

LPC - 12

ZACHARY CLANAHAN, AIA 14 GRAVEL HILL RD. HAMPTON BAYS, NY 11946 631-379-8435 BERGEN STREET KINGDOM HALL 1260 BERGEN STREET BROOKLYN, NY 11213

EXTERIOR SIGNAGE DETAILS

1” 1-1/2” 2-1/2”

9’-0” 1’-8”

EXPANSION ANCHOR 10-24 ALUMINUM STUD EX BRICK FACADE SPACER SLEEVE, PAINTED BLACK, SATIN FINISH

JW

.ORG

CUT VINYL ADHERED TO ALUMINUM PLATE MOUNTED TO BUILDING WALL BACKGROUND COLOR RGB 74 109 167 TEXT COLOR: WHITE NON-ILLUMINATED, FLAT CUT ALUMINUM LETTERS, ARCHITECTURAL GRADE, PAINTED BLACK, SATIN FINISH EX BRICK FACADE SIGN SS WASHER BEHIND SIGN SET IN SEALANT SS BOLT W/ WASHER PVC SLEEVE

1 2

TYP . SECTION THROUGH ALUM. LETTSIGNAGE LETTERS 1 SECTION THROUGH ALUMINUM PLATE SIGN 2

SIGN MOUNTING NOTES:

  • 1. PENETRATIONS THRU SURFACES TO BE WATERTIGHT.
  • 2. FASTENERS AND RELATED TO BE NON-FERROUS METALS.
