Low Impact Focus Group

Monthly Meeting November 14, 2017

Forward Together • ReliabilityFirst

Opening Comments

2

• This meeting is being recorded
• All lines will be muted.
• In order to comment, you may:
• Use the WebEx “Raise Hand” feature.
• Send a message to the presenter via WebEx chat.
• On the “Participants” window, manually unmute your line

by clicking on the red microphone.

• When commenting, be mindful that this is an
• pen call. RF cannot pre-screen the attendees.

Forward Together • ReliabilityFirst

Announcements

• NERC’s Antitrust Guidelines are available at:
• http://www.nerc.com/pa/Stand/Resources/Documents/NER

C_Antitrust_Compliances_Guidelines.pdf

• This is a public call. RF cannot pre-screen the

attendees.

3

Forward Together • ReliabilityFirst

Mailing List

• ciplifg@lists.rfirst.org
• This list is intended as a discussion forum.
• List changes, such as additions or removals,

should be sent to: lew.folkerth@rfirst.org

4

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• CIP-012-1 Draft 1 was posted for comments and

initial ballot through 9/11/2017.

• CIP-012-1 Draft 2 is posted for comment through

12/11/2017.

• CIP-012-1 Draft 2 will have an “additional ballot”

window open from 12/1/2017 through 12/11/2017.

• The draft RSAW for CIP-012-1 Draft 2 should be

posted during the week of 11/6/2017.

• The proposed Standard is posted here:

http://www.nerc.com/pa/Stand/Pages/Project%202016-02%20Modifications%20to%20CIP%20Standards.aspx 5

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• Changes from Draft 1
• Title changed
• Purpose statement modified and clarified
• Revised definition of “Control Center” dropped
• Applicability consolidated – all applicability criteria are now

in the Applicability section

• Rationale section dropped
• R1 has more specifics regarding protections
• R2 is unchanged
• Implementation window increased from 12 months to 24

months after approval

6

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• Applicability
• Functional registration:

‒ Reliability Coordinator (RC) ‒ Balancing Authority (BA) ‒ Generator Owner or Operator (GO/GOP) ‒ Transmission Owner or Operator (TO/TOP)

• Why are GO and TO included in Applicability when the

definition of Control Center doesn’t include them?

• Because some entities (such as PJM entities) are

registered only as a TO but also perform “the functions of” a TOP as delegated by the registered TOP. There may be similar considerations for the GO/GOP relationship.

7

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• Applicability
• Own or operate a Control Center:

‒ “One or more facilities hosting operating personnel that monitor and control the Bulk Electric System (BES) in realtime to perform the reliability tasks, including their associated data centers, of: 1) a Reliability Coordinator, 2) a Balancing Authority, 3) a Transmission Operator for transmission Facilities at two or more locations, or 4) a Generator Operator for generation Facilities at two or more locations.”

• Note that there is no size limit to the Control Center. Any

BES facility that meets the definition of Control Center will be in scope for this Requirement.

8

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• R1 – Develop a plan
• Mitigate the risk of loss of confidentiality or integrity of

data transmitted between Control Centers

‒ Real-time Assessment data

• “An evaluation of system conditions using Real-time data to assess

existing (pre-Contingency) and potential (post-Contingency)

• perating conditions. The assessment shall reflect applicable inputs

including, but not limited to: load, generation output levels, known Protection System and Special Protection System status or degradation, Transmission outages, generator outages, Interchange, Facility Ratings, and identified phase angle and equipment limitations. (Real-time Assessment may be provided through internal systems or through third-party services.)”

‒ Real-time monitoring and control data ‒ Excludes verbal communications

9

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• R1 – Develop a plan
• Identify data communications paths to be protected

(implied requirement)

‒ Real-time Assessment data ‒ Real-time monitoring and control data

• Identify security protection for each path
• Identify demarcation (demarc) point for each path
• If path is to another entity, identify roles and responsibilities

for each path

10

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• R2 – Implement the plan
• 24 months from the Effective Date of CIP-012-1

‒ This is not as much time as it sounds like!

• Provision for CIP Exceptional Circumstances

‒ Intended for emergency operations only.

• Watch out for problems introduced by latency in encryption

devices

‒ Encryption is not explicitly required, but there is not much else that will meet these requirements. ‒ There are no provisions for Technical Feasibility Exceptions. ‒ Test! Test! Test!

11

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• Possible Compliance Evidence (suggestions only!)
• R1 - One or more documented plans

‒ If more than one plan, make sure there are no gaps between the plans ‒ Make sure all the Parts of R1 are covered:

• How to identify data paths to be protected
• For each identified path, how it will be protected
• For each identified path, where the protections will be applied
• For each identified path, define the roles of responsibility

Implementation Monitoring Maintenance Key management Etc.

• For each identified path, define who is responsible for each role

12

Forward Together • ReliabilityFirst

Standards Update – CIP-012-1 Draft 2

• Possible Compliance Evidence (suggestions
• nly!)
• R2 – Implementation

‒ Show how the applicable data paths were identified ‒ List of identified data paths ‒ Evidence of the application of security protection to each identified data path ‒ Evidence identifying the demarc for each identified data path ‒ Evidence showing performance of the applicable roles ‒ Evidence of the effectiveness of the security protections

• Logs showing state of encrypted channel
• Alerts, or the ability to generate alerts, if the encryption is bypassed

Trigger CIP Exceptional Circumstance

• Etc.

13

Forward Together • ReliabilityFirst

Future Meetings

• Next conference call (WebEx):
• Tuesday, December 19, 2017 at 11:00AM EST

‒ Is this call needed? No, next call in January.

• Tuesday, January 16, 2018 at 11:00AM EST

14

Forward Together • ReliabilityFirst

Questions & Answers

Forward Together ReliabilityFirst

15
