Lecture 2 Annotation tools & Segmentation

• Annotation theory
• Guidelines
• Inter-Annotator agreement
• Inter-subjective annotations
• Annotation exercise
• Discuss disagreements with your neighbor
• Improve annotation guidelines

University of Stuttgart 2

Summary of Part 1

• Tools can support the annotation process at various stages
• Managing multiple annotators
• Assign documents to annotate
• Supervise their progress
• Analyse disagreements
• Display disagreements (only)
• Calculate quantitative IAA (κ)
• Create a gold standard
• Make decisions on disagreements
• Record final decisions
• Usable tools: See handout

University of Stuttgart 3

Tool Support Annotation

Segmentation

University of Stuttgart 4

University of Stuttgart 5

Segmentation Tool Download

http://tinyurl.com/cretanetworker = http://www2.ims.uni-stuttgart.de/gcl/reiterns/creta/CRETANetworker.jar

• Abstract definition
• No meaning of a segment implied
• The task of separating a text into multiple parts (“segments”)
• Segmentation according to various criteria based on
• Structure (chapters, acts, letters, speeches)
• Linguistics (sentences, paragraphs)
• Narrative content (scenes, time, place)
• Content (topics under discussion)
• No generic criterion covering multiple research questions

Segmentation

University of Stuttgart 6

• Focus on segments
• Spans of text
• Focus on segment boundaries
• Positions in a text
• Views are equivalent – we will switch between them when appropriate

University of Stuttgart 7

Viewpoints Segmentation

Segment 1 Segment 2 Segment 3 Segment 4 Segment Boundary Segment Boundary Segment Boundary

University of Stuttgart 8

Entities + Segments = Networks

Mary Peter Paul Co-Occurrence Network

• Segmented text with the appearing entities

⟨{A, B}, {A, B, B, B, A}, {A, C}⟩

• Convert into an (quadratic) adjacency matrix
• Diagonal is typically uninteresting
• Matrix is symmetric
• Create network
• A node is created for each row (or cell)
• An edge is created for each cell,

weighted according to cell value

University of Stuttgart 9

Slightly more abstract description Entities + Segments = Networks

A B C A 2 1 B 2 C 1

A B C

• Theoretically
• Segments can be annotated just like entity references
• Both cover sequences of words
• Appropriate annotation guidelines would define when to annotate segments
• Practically
• Segmentation criterion closely tied to research question
• No reasonable generic abstraction layer
• That works for multiple research questions and/or text corpora
• Single texts only contain a few segments
• Much more annotated texts needed for any kind of automatisation

University of Stuttgart 10

Segmentation Annotation

• Web-based UI
• Beta-Software
• Automatic annotation through rules and tools
• Entity annotation
• Stanford Named Entity Recognizer (Finkel et al., 2005)
• Only proper names, no descriptive noun phrases
• Rules (regular expressions) – to specify the entity references
• Segment annotation
• Rules (regular expressions) – to specify the segment boundaries
• Unsupervised segmentation algorithm (TextTiling; Hearst, 1994)
• Network export → Gephi

University of Stuttgart 11

Segment Annotation Tool

• Free and open source
• https://gephi.org
• Wide range of metric, filter and layout algorithms
• Network editing (e.g., merge nodes)
• Plugins
• Export into static images

University of Stuttgart 12

Network Tool Gephi

University of Stuttgart 13

demo

• A powerful way to describe sets of character sequences
• Many search tools support REs, and all programming languages do
• Looks cryptic, but is quite systematic
• REs on slides/handout are marked in forward slashes / / for readability
• they don’t need to be typed in the tool
• Basics
• Many regular characters stand for themselves
• The RE /a/ finds occurrences of the character “a”
• Sequences of characters stand for sequences of themselves
• The RE /the/ finds occurrences of the string “the”

University of Stuttgart 14

Useful text processing skills 101 Regular Expressions

• Many regular characters stand for themselves
• The RE /a/ finds occurrences of the character “a”
• Sequences of characters stand for sequences of themselves
• The RE /the/ finds occurrences of the string “the”
• Meta characters (“quantifiers”) are applied on the previous character
• ?: previous character optional (0-1 times)
• /them?/ finds both “the” and “them”
• +: Previous character one or more times
• /ab+/ finds ”ab”, “abb”, ”abbb”, …
• The kleene star * finds the previous character zero or more times
• /ab*/ finds “a”, “ab”, “abb”, ”abbb”, …

University of Stuttgart 15

Basics Regular Expressions

• /(re1|re2)/ finds everything that finds either re1 or re2
• /(good|better|best)/ finds comparative and superlative forms of

the adjective “good”

• /great(er|est)?/ finds comp. and sup. forms of “great”
• The question mark makes the suffixes optional
• We can mark alternatives on character level in square brackets: […]
• /[Tt]he/ finds upper and lower case forms of “the”
• Square brackets support ranges of characters
• /[A-Z]/ finds upper-case characters (beware: locale)
• /[0-9]/ finds digits

University of Stuttgart 16

Alternations and Character Classes Regular Expressions

• The dot . matches everything
• /a.*b/ finds everything that begins with a and ends with b
• Escape character: Backslash
• In order to find a dot, we need to prevent its special meaning
• /.*\.doc/ finds everything that ends on “.doc” (e.g., filenames)

University of Stuttgart 17

Special cases and exceptions Regular Expressions

• Chapter 10.
• /Chapter

[0-9]+\./

• Chapter V. (Roman numbers)
• /Chapter

[IVXCM]+\./

• Beware: Possible over-matching
• Dates: MAY 22., AUGUST 23.
• /[A-Z]+

[0-9]+\./

• Beware: Possible over-matching

University of Stuttgart 18

Real examples Regular Expressions

• Unsupervised segmentation algorithm, developed for expository texts
• Compares lexicon in a window left and right of a target sentence gap

University of Stuttgart 19

Hearst (1994) TextTiling

window size = 2

sentence boundary

2 1 7 3 2 9

v1= v2= dist(v1, v2) =

n n+1

dn

step size = 3

• Unsupervised segmentation algorithm, developed for expository texts
• Compares lexicon in a window left and right of a target sentence gap

University of Stuttgart 20

Hearst (1994) TextTiling

sentence boundary

n n+1

dn dn+3

• More powerful algorithms are available
• E.g., topic segmentation
• Clear adaptation possibilities
• How to create word vectors?
• Which words are included (function/content words)?
• Which value is represented in the vector (frequency, tf*idf, information, …)
• How to calculate similarity/distance?
• Cosine, manhattan, …
• But: Evaluation is hard
• No gold standard available
• Different expectations

University of Stuttgart 21

Hearst (1994) TextTiling

• Go to …
• Load a text of your liking (it‘s better if you are familiar with it)
• Add entity references by applying the Stanford NER system
• Make a brief check, if the important entities are included

(“Passepartout”, for instance, is not)

• You can add specific names by specifying regular expressions
• Add reasonable segment annotations
• Export a GEXF file and load it into Gephi
• Play with various options and see how the network changes

University of Stuttgart 22

Hands-On Session 2
