[PPT] - Language Models with Transformers Chenguang Wang, Mu Li, Alexander PowerPoint Presentation

SLIDE 1

Language Models with Transformers

Chenguang Wang, Mu Li, Alexander J. Smola Amazon Web Services

SLIDE 2

Background

2

SLIDE 3

Language Model (LM)

3

Predict what word comes next

Start to learn English

SLIDE 4

Language Model (LM)

4

Predict what word comes next
Useful in many NLP applications

Start to learn English

SLIDE 5

Language Model (LM)

5

Predict what word comes next
Useful in many NLP applications
Many NLP problems share similar definition

Start to learn English Learn to start business Word order matters!

SLIDE 6

Language Model with RNNs

6

RNN uses one-hot encoding

Start

input

SLIDE 7

Language Model with RNNs

7

RNN models the word order in hidden state

Start RNN to

input hidden state

utput

SLIDE 8

Language Model with RNNs

8

RNN models the word order in hidden state

Start RNN to to RNN learn

input hidden state

utput

SLIDE 9

Language Model with RNNs

9

RNN models the word order in hidden state

Start RNN to to RNN learn learn RNN English

input hidden state

utput

SLIDE 10

SOTA NLP with Transformers

10

Positional encoding Transformer Other components are omitted for simplicity [Devlin, Jacob, et al 2018] With less word order

SLIDE 11

SOTA NLP with Transformers

11

Self-attention Positional encoding Transformer Other components are omitted for simplicity [Devlin, Jacob, et al 2018]

Parallelizable
Efficient

SLIDE 12

SOTA NLP with Transformers

12

Self-attention Positional encoding Transformer Other components are omitted for simplicity [Devlin, Jacob, et al 2018]

With less word order
Parallelizable
Efficient
With word order
Sequential
Less efficient

RNN

SLIDE 13

SOTA NLP with Transformers

BERT: a stack of 12 (or 24) Transformer blocks

13

Transformer 0 Transformer 1 Transformer 11

. . .

SLIDE 14

SOTA NLP with Transformers

BERT: a stack of 12 (or 24) Transformer blocks
Trained on large language model datasets
Full training cost in excess of $10,000 (16 TPU, 4 days)
Achieved SOTA results on 11 NLP applications
Sentence level tasks: care less about word order

14

Transformer 0 Transformer 1 Transformer 11

. . .

SLIDE 15

Approach: Make Best Use of BERT for Language Model

15

SLIDE 16

LM: Adapted BERT

16

. .

embedding Linear

Fixed weights Tunable weights

Transformer 11 Transformer 0

BERT with Linear Layer

SLIDE 17

LM 1: Adapted BERT with Fixed Weights

17

. .

embedding Linear

Fixed weights Tunable weights

Transformer 11 Transformer 0 Model Test PPL BERT 69.32 RNN 42.25

Only moderate results (the Lower, the Better)

SLIDE 18

18

. .

embedding Linear

Fixed weights Tunable weights

Transformer 11 Transformer 0 Model Test PPL BERT 69.32 BERT-All 67.43 RNN 42.25

Overfitting

LM 2: Adapted BERT with All Weights

SLIDE 19

LM 3: Adapted BERT with Partial Weights

19

. .

embedding Linear

Fixed weights Tunable weights

Transformer 11 Model Test PPL BERT 69.32 BERT-All 67.43 BERT-Subset 40.56 RNN 42.25

Fix a subset of weights is promising

Transformer 0

However, enumerating is not feasible

SLIDE 20

LM 4: Adapted BERT with RNN

20

. .

embedding Linear

Fixed weights Tunable weights

Model Test PPL BERT 69.32 BERT-RNN 41.64 RNN 42.25

Add RNN to capture word order is promising

Transformer 0

However, enumerating is not feasible

Where
How many

Transformer 11 RNN

SLIDE 21

21

Where to add the RNN layers?

SLIDE 22

22

Which layer’s pre-trained weights should be fixed? Where to add the RNN layers?

SLIDE 23

Coordinate Architecture Search (CAS)

23

Step 1: Choose a layer’s weights to fix
Step 2: Choose a position to add a RNN layer
Step 3: Go to Step 1 or Terminate
Greedy strategy: fine-tune the resulting BERT and keep the best

embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1

Fixed weights Tunable weights

Fix Transformer 0’s weights

SLIDE 24

Coordinate Architecture Search (CAS)

24

Step 1: Choose a layer’s weights to fix
Step 2: Choose a position to add a RNN layer
Step 3: Go to Step 1 or Terminate
Greedy strategy: fine-tune the resulting BERT and keep the best

embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 RNN

Fixed weights Tunable weights

Add a RNN layer

SLIDE 25

Coordinate Architecture Search (CAS)

25

Step 1: Choose a layer’s weights to fix
Step 2: Choose a position to add a RNN layer
Step 3: Go to Step 1 or Terminate
Greedy strategy: fine-tune the resulting BERT and keep the best

embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 RNN embedding Transformer 0 Transformer 1 RNN Linear

Fixed weights Tunable weights

Add a linear layer

SLIDE 26

Coordinate Architecture Search (CAS)

26

Step 1: Choose a layer’s weights to fix
Step 2: Choose a position to add a RNN layer
Step 3: Go to Step 1 or Terminate
Greedy strategy: fine-tune the resulting BERT and keep the best

embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 embedding Transformer 0 Transformer 1 RNN embedding Transformer 0 Transformer 1 RNN Linear

Fixed weights Tunable weights

SLIDE 27
