Kon-Who?

• Presence in 12 countries worldwide
• Production facilities in Augsburg, Deggendorf, Toulon, San Diego, Montreal, Beijing
• Kontron Communications is proudl

dly y Canad adian an with headquarters in Montreal, Quebec!

BEIJING SAN DIEGO AUGSBURG PENANG BANGALORE TOKYO TOULON MONTREAL

REGIONAL SALES & PARTNER OFFICES R&D CENTERS GLOBAL HEADQUARTERS

Sym-What?

2x Modular, Hot-Swappable Top of Rack Switches 5x Hot-Swappable Chassis Fans Customizable Face Plate MSH8920 (100Gbps) Series

Sym-What?

Up to 9x Compute Sleds Per 2U Chassis Redundant 1500W PSUs 2U MSP8060 Series (2x Single Xeon-D) A TOTAL OF 18 INDEPENDENT SERVERS PER 2U!

Nodes For All Workloads

MSP8060 Series MSP8050 Series MSP8040 Series TESTED APPLICATIONS

• OpenStack
• Canonical OpenStack
• Wind River Titanium Cloud
• Red Hat OpenStack
• SUSE OpenStack (In Progress)
• Kubernetes
• OpenDaylight
• Deployment Tools (i.e. Canonical MaaS)
• Monitoring
• Nagios
• Promotheus
• GPU-Based
• TensorFlow
• Intel Media Server Studio
• Low-profile PCIe cards
• FPGAs
• SmartNICs
• Networking
• DPDK Enhanced Applications
• P4-based offloading

1x HHHL PCIe Device

1x 2.5” drive (HDD

• r SSD)

1x 2.5” drive (HDD

• r SSD)

Replacing COTS With MS29s

CAPEX SAVINGS Up to 30% CAPEX savings versus COTS servers INTEGRATED ToR MS29 systems includes TOR switches saving space and cabling CONSOLIDATION Up to 9-to-1 processor consolidation ratio versus COTS servers OPEX SAVINGS 80% in power & rack space savings versus COTS servers AUTOMATION TOOLS Tools available to deploy multi systems at scale from one config HIGH DENSITY 36x 1U servers replaced by 2x SymKloud MS29 systems

Validated Software

Upcoming Projects

• f Interest

Networking Infrastructure & Orchestration

Partners for Edge & SDN/NFV

Within 6 Months

• Edge Computing OEM Hardware Designs
• Service Providers & Telcos POCs
• Webinar with Verizon & Tigera @ Light Reading
• Making MEC a Reality – Lessons Learned From Multi-Party MEC Platform Benchmarking

Project

• http://www.lightreading.com/webinar.asp?webinar_id=1061

Community Involvement

Ed Edge e Comput puting ing Gr Group up

• Helping to review the Dublin PTG

requirements on #edge-computing-group

• Provide guidance as a hardware

manufacturer with active edge deployments

• Provide insight from companies deploying

5G infrastructure

Commits & Reviews

• Rally
• Canonical Charms
• Charm-neutron-gateway
• Charm-ceilometer-agent

http://stackalytics.com/?release=all&company=kontron&metric=commits http://stackalytics.com/?release=all&company=kontron&metric=marks

Queens on SymKloud MS29

• Fully redundant hardware including PSUs,

switches and shelf managers

• Redundant OpenStack platform across

multiple compute nodes

• Optimized with 6WIND Virtual Accelerator

(DPDK) for line-rate speeds without breaking Neutron

• Bare Metal capabilities with Ironic for

workloads using PCIe GPU, FPGA, etc

• Deployment scripts and automation tools

to deploy multiple systems as compute nodes for scalability

SymKloud MS29 VS Commodity Servers

1000 2000 3000 4000 5000 Commodity Server - AMD Epyc Commodity Server - Xeon Scalable SymKloud MSP806x SymKloud MSP804x Watts

Power Consumption (Less Is Better)

SymKloud has the upper hand on power consumption by up to 4X SymKloud uses 4.5X less space than commodity servers

2 4 6 8 10 Commodity Server - Xeon Scalable Commodity Server - AMD Epyc SymKloud MSP806x SymKloud MSP804x Rack Mount Unit Taken (U)

Rack Space Used For The Same VM Count (Less Is Better)

SymKloud MS29 VS Commodity Servers

$- $50,000.00 $100,000.00 $150,000.00 $200,000.00 $250,000.00

MSFT Azure D2-64 (East) GCE n1-std-2 (Iowa) AWS EC2 m5.L (Ohio) SymKloud MSP806x Commodity Server - AMD Epyc Commodity Server - Xeon Scalable SymKloud MSP804x

Total Cost of Ownership ($USD)

SymKloud is king on TCO when compared to public clouds and provides carrier grade equipment at commodity hardware price points

Comparison is made on the amount of systems required in order to run 32x 2vCPU (2 threads) with 8GB Memory, 30GB ephemeral storage per VM. Excludes outbound traffic fee for public clouds. All data sets are based on list price of systems from multiple vendors across system integrators from the US and Canada along with average colocation price across North America and the average American Kilowatt/hr Industrial price point of 2018 by their respective regulating entity. All public cloud prices were taken in February 2018. Data available upon request at our booth and by email to the Kontron Canada Inc. Marketing team.

Kubernetes on SymKloud MS29

• Fully redundant hardware including

PSUs, switches and shelf managers

• Redundant Kubernetes Masters for

true High Availability deployments

• Fixed an issue with K8S recovery when

the HAProxy instance dies

• Deployment scripts and automation

tools to deploy multiple systems as compute nodes for scalability

Container Density on SymKloud MS29

• Our focus, Bare Metal containers for all types of

workloads

• Why Bare Containers instead of VM containers?
• No virtualization overheads
• Lower network latency
• More CPU resources available per worker
• No need to deploy full fledged operating systems
• Easier to interface with PCIe devices such as GPU cards
• Some metrics about our capabilities
• Based on one MS2920 system with 18 sockets
• Network-wise, up to 3550 instances supported in a

2U system depending on your storage needs!

CPU Memory Instances 2 400Mi 166 1 200Mi 333 500m 150Mi 669 150m 100Mi 2234

• 3550

Hardware Monetization & Scheduling

• Use cases showcased at our booth powered by Kubernetes:
• TensorFlow & Nvidia P4s GPU running image recognition algorithms
• https://blog.symkloud.com/fun-with-kubernetes-and-tensorflow-serving
• BlockChain implementation over Canonical Kubernetes to leverage idle

processor cycles for crypto-mining.

• https://itnext.io/opportunistically-mining-cryptocurrencies-in-kubernetes-

94934d095c4d

• Kubernetes still has a long way to be considered by Telcos:
• Flannel doesn’t support SDN/NFV use cases;
• No notion of MAC addresses is Kubernetes is a tremendous show stopper.

Announcements

Kontron Communications joined the Linux Foundation, Networking in January 2018 to get involved in open source communities. Kontron Communications joined the Metro Ethernet Forum (MEF) to further its momentum around Mobile Edge Computing. Kontron Communications is opening a new Pharos Lab in Montreal, QC. Anyone wanting access to the lab (we’re not keeping it to ourselves) can do so at SYMKLOUD.COM/OPNFV- PHAROS

Speaking Slots @ Vancouver Summit

BREAKOUT SESSION TODAY @ 1330H!

How to use OPNFV Testing tools to test/validate an OpenStack provided by a vendor

Level Two - Room 208-209

THE CUBE INTERVIEW Interview at The Cube with Arturo Suarez, Product Strategy, Alliances and Program Director at Canonical Ltd. covering the journey to OpenStack and Kubernetes

AVAILABLE ONLINE AFTER THE SUMMIT!

KONTRON ON COMMUNICA ICATIONS IONS

Eric c Sarault rault

KONTRON ON COMMUNICA ICATIONS IONS

Artu turo Suarez rez

CANONICA ONICAL

Kontron Booth @ Vancouver Summit

COME SEE US - BOOTH B12

• Grab a T-Shirt!
• Prize Drawing Mon-Wed!
• Awesome Hardware
• OpenStack Queens Demo
• Kubernetes Demos

YOU ARE HERE
