K a r i m B e n c h e n a n e Importance of rhythms for cell assemblies synchronization Master BIP - Dec 1th 2015 << Importance of rhythms in cell assemblies synchronization 1) Cell assemblies 2) Rhythms 3) Rhythms and cell

slide-1
SLIDE 1

K a r i m B e n c h e n a n e Importance of rhythms for cell assemblies synchronization

Master BIP - Dec 1th 2015

<<

slide-2
SLIDE 2

1) Cell assemblies 2) Rhythms 3) Rhythms and cell assemblies

Importance of rhythms in cell assemblies synchronization

slide-3
SLIDE 3

Extracellular electrophysiological recordings

slide-4
SLIDE 4

PPSE PPSI PPSE PPSE PPSE PPSI PPSI

Local Field Potential = Sum of all PPSE and PPSI

Action potential (spike) Action potential (spike) Action potential (spike) Action potential (spike)

LFP = Input Spike = Output

slide-5
SLIDE 5

Excitatory** input*

?*

slide-6
SLIDE 6

Excitatory** input*

slide-7
SLIDE 7

LFP$electrode$ superficial+ LFP$electrode$ deep+ Excitatory** input*

?* ?*

slide-8
SLIDE 8

LFP$electrode$ superficial+ LFP$electrode$ deep+ Excitatory** input*

slide-9
SLIDE 9

LFP$electrode$ superficial+ LFP$electrode$ deep+ Inhibitory* input*

?* ?* ?*

slide-10
SLIDE 10

LFP$electrode$ superficial+ LFP$electrode$ deep+ Inhibitory* input*

slide-11
SLIDE 11

LFP$electrode$ superficial+ LFP$electrode$ deep+ Excitatory** input*

slide-12
SLIDE 12

LFP$electrode$ superficial+ LFP$electrode$ deep+ Inhibitory* input*

?* ?* ?*

slide-13
SLIDE 13

LFP$electrode$ superficial+ LFP$electrode$ deep+ Inhibitory* input*

slide-14
SLIDE 14

LFP$electrode$ superficial+ LFP$electrode$ deep+ Excitatory** input*

slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

Reference' Cortex'pariétal'

slide-18
SLIDE 18

Reference' Cortex'pariétal'

slide-19
SLIDE 19

Reference' Cortex'pariétal'

slide-20
SLIDE 20

Reference' Cortex'pariétal'

slide-21
SLIDE 21

Extracellular electrophysiological recordings

slide-22
SLIDE 22

Extracellular electrophysiological recordings

slide-23
SLIDE 23

Extracellular electrophysiological recordings

slide-24
SLIDE 24

Note that in a particular condition 90% of the neurons are silent Extracellular electrophysiological recordings

slide-25
SLIDE 25

Extracellular electrophysiological recordings

slide-26
SLIDE 26

Extracellular recordings in human (epileptic patients)

slide-27
SLIDE 27

Quian Quiroga et al., Nature 2005

Neural bases of semantic memory

slide-28
SLIDE 28

Neural bases of semantic memory

Quian Quiroga et al., Nature 2005

slide-29
SLIDE 29

Neural bases of semantic memory

Quian Quiroga et al., Nature 2005

slide-30
SLIDE 30

Response in IT : ~130 ms (primate) Response in MTL: ~250-300 ms Recognition in human : ~150ms

The cell responding to pictures of Darth Vador might not be involved in recognizing him Crucial for the storage of new long-term memories and related to the fact that the patient viewed his pictures in the clinic.

slide-31
SLIDE 31

1/ Presentation of several movies with different actors 2/ Recollection task: which movies have you seen? Gelbard-Sagiv, et al., Science, 2008

Neural bases of semantic memory

slide-32
SLIDE 32

Place cell

Jung, Wiener et McNaughton,1994

The position of the animal can be predicted by the neuronal activity in the hippocampus

Internal representation of space in the hippocampus

slide-33
SLIDE 33

The position of the animal can be predicted by the neuronal activity in the hippocampus

Place cell

Internal representation of space in the hippocampus

slide-34
SLIDE 34
  • Place cells properties:

– Discharge a pyramidal neurons related to the position of the animal – Place Field is formed after few minutes and is stable for months – Rotation of external cues induce the rotation of place fields – A particular place cells have different place fields in different contexts

Internal representation of space in the hippocampus

slide-35
SLIDE 35
  • Place cells properties:

– Discharge a pyramidal neurons related to the position of the animal – Place Field is formed after few minutes and is stable for months – Rotation of external cues induce the rotation of place fields – A given place cell can have different place fields in different contexts

Internal representation of space in the hippocampus

slide-36
SLIDE 36

Internal representation of space in the hippocampus

Contexte A Contexte B

time time

slide-37
SLIDE 37

Neural bases of semantic memory

Quian Quiroga et al., Nat rev Neurosci

slide-38
SLIDE 38

Quian Quiroga et al., Trends Cog Sci & Nat rev Neurosci

Sparse coding with cell assemblies or grandmother’s cell ?

(1) Probability to find the item selective for the recorded neuron is

  • ne over 1 million

(2) Images already known by the subjects were used (3) Two million neurons represent a given percept over few hundred millions neurons in MTL (bayesian estimation) (4) One neuron could fire for different items.

slide-39
SLIDE 39

Cell assemblies

slide-40
SLIDE 40

Donald Hebb, The Organization of Behavior, 1949

"The general idea is an old one, that any two cells or systems of cells that are repeatedly active at the same time will tend to become 'associated', so that activity in one facilitates activity in the other." (p. 70) "When one cell repeatedly assists in firing another, the axon of the first cell develops synaptic knobs (or enlarges them if they already exist) in contact with the soma of the second cell." (p. 63)

Assemblée cellulaire

slide-41
SLIDE 41

"If the inputs to a system cause the same pattern of activity to occur repeatedly, the set

  • f active elements constituting that pattern will become increasingly strongly
  • interassociated. That is, each element will tend to turn on every other element and (with

negative weights) to turn off the elements that do not form part of the pattern. To put it another way, the pattern as a whole will become 'auto-associated'. We may call a learned (auto-associated) pattern an engram." (p. 44) Donald Hebb, The Organization of Behavior, 1949

slide-42
SLIDE 42

(d’après Bi & Poo 1998)

Spike 'ming dependent plas'city Cell assemblies: synchroniza'on within 'me period compa'ble with STDP

slide-43
SLIDE 43

synchronization

Synchroniza'on & cell assemblies

slide-44
SLIDE 44

synchronization

Synchroniza'on & cell assemblies

slide-45
SLIDE 45

global noise local noise claping period Average noise intensity correlation

Neda et al Nature 2000

slide-46
SLIDE 46

Cell assemblies, rhythms and the binding problem

slide-47
SLIDE 47
slide-48
SLIDE 48

Cell assemblies synchronization and the binding problem

slide-49
SLIDE 49

Cell assemblies synchronization and the binding problem

slide-50
SLIDE 50

Cell assemblies synchronization and the binding problem

slide-51
SLIDE 51

"This situation was instantaneously and radically changed by a historical event, the symposium on visual perception at the Society for Neuroscience meeting in Washington, DC, in the fall of 1993. I have never seen so many neuroscientists attending any lecture on any topic of neuroscience than at that milestone

  • event. ... After a long vacuum in systems research, a radicaly different and

comprehensive theory was on the horizon.The protagonist of the symposium was Wolf Singer from the Max-Planck Institute in Frankfurt- am-Main, Germany." György Buzsáki, Rhythms of the brain

Wolf Singer

slide-52
SLIDE 52

Cell assemblies synchronization and the binding problem

slide-53
SLIDE 53

Cell 1 Cell 2 Synchronisation ???

Cell assemblies synchronization and the binding problem

slide-54
SLIDE 54

if you’re interested, read this…

« It needs still to be clarified, however, if the temporal code could solve the riddles of perceptual grouping. As things are at present, the binding problem reflects at least three correlated subquestions: (1) the segmentation of a complex visual scene, or figure- ground segregation; (2) the integration of a single perceptual object as from its components, and (3) the recognition of an object in spite of its variation in position, size, perspective, etc. » « An important aspect of this hypothesis, is that for the first time in the history of neuroscience, it has accounted for perceptual processes without invoking the idea of a superior area or center, where all processed information would converge. Accordingly, the fallacy of the homunculus (a torment for philosophers à la Daniel Dennett [51]) would be exorcised forever. » « For reasons largely unresolved until now, it appeared difficult to replicate in some laboratories the seminal results reported by Wolf Singer and his colleagues at the Max-Planck-Institute for Brain Research in Frankfurt, and by Reinhard Eckhorn and his group at the Philipps- University in

  • Marburg. Some critical observations, moved by Martin Tovée and Edmund Rolls [16, 17] and by

Geoffrey Ghose and Ralph Freeman [18] in 1992, deserve particular attention in this context: either oscillations were not found in the visual cortex, or if they were, they appeared to be rhythmic responses not correlated to the stimulus. »

slide-55
SLIDE 55
slide-56
SLIDE 56
slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62

Delta waves - Delta rhythm(s)

slide-63
SLIDE 63

Deep Sup

Pfc

Deep Sup

Par Cx

Deep Sup

Aud Cx Aud Th Hpc

Delta waves - Delta rhythm(s)

slide-64
SLIDE 64

Deep Sup

Pfc

Deep Sup

Par Cx

Deep Sup

Aud Cx Aud Th Hpc

* * * * * * * * * *

Delta waves - Delta rhythm(s)

slide-65
SLIDE 65

Theta oscillations

slide-66
SLIDE 66

INTERNEURONS PYRAMIDAL CELLS

Theta oscillations

slide-67
SLIDE 67

Theta

π 2π π 2π

π 2π

Modulation of hippocampal neurons by theta

slide-68
SLIDE 68

Pyramidal neurons





Interneurones


25-30 classes of interneurons

Cellular types within the hippocampus

slide-69
SLIDE 69

Modulation of hippocampal neurons by theta

Somogyi and Klauberger, Science, 2008

slide-70
SLIDE 70

Theta oscillations

slide-71
SLIDE 71

Rhythm generator

Vertes et al 2004

medial septum inactivation

slide-72
SLIDE 72

EC3 CA1 CA3 EC5 DG EC2 Current generator

slide-73
SLIDE 73

Current generator

slide-74
SLIDE 74

Coupling theta - Gamma

slide-75
SLIDE 75
slide-76
SLIDE 76

Cross-frequency coupling

slide-77
SLIDE 77
slide-78
SLIDE 78
slide-79
SLIDE 79

INTERNEURONS PYRAMIDAL CELLS

slide-80
SLIDE 80

INTERNEURONS PYRAMIDAL CELLS

slide-81
SLIDE 81

INTERNEURONS PYRAMIDAL CELLS

slide-82
SLIDE 82

INTERNEURONS PYRAMIDAL CELLS

slide-83
SLIDE 83

INTERNEURONS PYRAMIDAL CELLS

slide-84
SLIDE 84

Geisler PNAS 2008

slide-85
SLIDE 85

Köning et al. TINS 1996

Rate coding “Integrator” Temporal coding “Coincidence detector” Importance of Rhythms: Temporal versus rate coding

slide-86
SLIDE 86

threshold AP 5me

Importance of Rhythms: Temporal versus rate coding

slide-87
SLIDE 87

threshold AP 5me

Importance of Rhythms: Temporal versus rate coding

slide-88
SLIDE 88

threshold AP 5me

Importance of Rhythms: Temporal versus rate coding

slide-89
SLIDE 89

threshold AP 5me

rythmical inhibi4on

Gilles Laurent (olfactory system in locust)

Importance of Rhythms: Temporal versus rate coding

slide-90
SLIDE 90

Inhibition could act by a non intuitive way …

slide-91
SLIDE 91

Schreiber J Neurophy 2004

slide-92
SLIDE 92

Schreiber J Neurophy 2004

slide-93
SLIDE 93

93

What are the experimental evidences of the importance of rhythms

slide-94
SLIDE 94

94

slide-95
SLIDE 95

Phase

0° 360° 180°

Modulation of hippocampal neurons by theta: Phase precession

slide-96
SLIDE 96

Modulation of hippocampal neurons by theta: Phase precession

Phase

0° 360° 180°

slide-97
SLIDE 97

Modulation of hippocampal neurons by theta: Phase precession

Phase

0° 360° 180°

slide-98
SLIDE 98

Modulation of hippocampal neurons by theta: Phase precession

Phase

0° 360° 180°

slide-99
SLIDE 99

Modulation of hippocampal neurons by theta: Phase precession

Phase

0° 360° 180°

slide-100
SLIDE 100

Phase precession

O'Keefe et Recce 1993 Modulation of hippocampal neurons by theta: Phase precession

slide-101
SLIDE 101

The phase of spikes improves their spatial information content

Modulation of hippocampal neurons by theta: Phase precession

slide-102
SLIDE 102

Modulation of hippocampal neurons by theta: Phase precession

slide-103
SLIDE 103

Modulation of hippocampal neurons by theta: Phase precession

slide-104
SLIDE 104

Modulation of hippocampal neurons by theta: Phase precession

slide-105
SLIDE 105

Modulation of hippocampal neurons by theta: Phase precession

slide-106
SLIDE 106

Modulation of hippocampal neurons by theta: Phase precession

slide-107
SLIDE 107

Modulation of hippocampal neurons by theta: Phase precession

slide-108
SLIDE 108

Modulation of hippocampal neurons by theta: Phase precession

slide-109
SLIDE 109

Modulation of hippocampal neurons by theta: Phase precession

slide-110
SLIDE 110

Modulation of hippocampal neurons by theta: Phase precession

slide-111
SLIDE 111

Modulation of hippocampal neurons by theta: Phase precession

slide-112
SLIDE 112

Modulation of hippocampal neurons by theta: Phase precession

slide-113
SLIDE 113

Modulation of hippocampal neurons by theta: Phase precession

slide-114
SLIDE 114

Modulation of hippocampal neurons by theta: Phase precession

slide-115
SLIDE 115

In a theta cycle: where I was, where I am, where I am going. Temporal compression of sequence in time delays compatible with STDP

Modulation of hippocampal neurons by theta: Phase precession

slide-116
SLIDE 116

(d’après Bi & Poo 1998)

Spike 'ming dependent plas'city Cell assemblies: synchroniza'on within 'me period compa'ble with STDP

slide-117
SLIDE 117

In a theta cycle: where I was, where I am, where I am going. Temporal compression of sequence in time delays compatible with STDP

Modulation of hippocampal neurons by theta: Phase precession

slide-118
SLIDE 118

Robbe & Buzsaki J Neurosci 2009

slide-119
SLIDE 119

CA1 CA3 EC5 DG EC2

Grid cells / Place cells Theta rhythm

Holly grail of electrophysiologists in freely moving rodents

slide-120
SLIDE 120

CA1 CA3

Place cells not affected by CA3 removal > Place signal comes from Entorhinal cortex (Grid cells) Grid cells > Place cells Theta rhythm

slide-121
SLIDE 121
slide-122
SLIDE 122

Koenig et al. Science 2011

Theta inactivation by lidocaine in the septum

slide-123
SLIDE 123
slide-124
SLIDE 124
slide-125
SLIDE 125
slide-126
SLIDE 126

Team Memory, Oscillations and Brain States

Laboratoire de Neurobiologie, UMR 7637 CNRS ESPCI Paris Tech (directeur Thomas Preat) Karim Benchenane CR1 CNRS Gaetan De Lavilléon PhD student Marie Lacroix PhD student Noelia Do Carmo Blanco Master 2 Matthieu Koroma Master 1
