SuSA and Mean-Field based models: Summary 2019 Ral Gonzlez Jimnez Ral Gonzlez Jimnez Grupo de Fsica Nuclear, IPARCOS, Universidad Complutense de Madrid NuSTEC meeting, December 12, 2019 In collaboration with... SuSA and RMF

slide-1
SLIDE 1

Raúl González Jiménez Raúl González Jiménez

Grupo de Física Nuclear, IPARCOS, Universidad Complutense de Madrid

NuSTEC meeting, December 12, 2019

SuSA and Mean-Field based models: Summary 2019

slide-2
SLIDE 2

2

In collaboration with...

SuSA and RMF Juan A. Caballero (Sevilla) Guillermo D. Megias (Sevilla/Saclay/Tokyo)

  • Maria. B. Barbaro (Torino)
  • A. De Pace (Torino)
  • T. William Donnelly (MIT)

Martin V. Ivanov (Sofia) Anton Antonov (Sofia) J.E. Amaro (Granada)

  • I. Ruiz-Simo (Granada)

Jose M. Udías (Madrid) SuSA and RMF Juan A. Caballero (Sevilla) Guillermo D. Megias (Sevilla/Saclay/Tokyo)

  • Maria. B. Barbaro (Torino)
  • A. De Pace (Torino)
  • T. William Donnelly (MIT)

Martin V. Ivanov (Sofia) Anton Antonov (Sofia) J.E. Amaro (Granada)

  • I. Ruiz-Simo (Granada)

Jose M. Udías (Madrid) Ghent University Natalie Jachowicz Alexis Nikolakopoulos Nils Van Dessel Kajetan Niewczas (Ghent/Wroclaw) Ghent University Natalie Jachowicz Alexis Nikolakopoulos Nils Van Dessel Kajetan Niewczas (Ghent/Wroclaw) CEA Saclay Stephen Dolan Sara Bolognesi CEA Saclay Stephen Dolan Sara Bolognesi Vishvas Pandey (Virginia Tech) Vishvas Pandey (Virginia Tech)

slide-3
SLIDE 3

3

slide-4
SLIDE 4

4

Plane waves Distorted waves Inclusive electron scattering at low q:

  • Phys. Rev. C 100 045501 (2019)
slide-5
SLIDE 5

5

Plane waves Distorted waves Inclusive electron scattering at low q:

  • Phys. Rev. C 100 045501 (2019)
slide-6
SLIDE 6

6

Plane waves Distorted waves Inclusive electron scattering at low q:

  • Phys. Rev. C 100 045501 (2019)

Orthogonalization

slide-7
SLIDE 7

7

Plane waves Distorted waves Inclusive electron scattering at low q:

  • Phys. Rev. C 100 045501 (2019)
slide-8
SLIDE 8

8

Plane waves Distorted waves Inclusive electron scattering at low q:

  • Phys. Rev. C 100 045501 (2019)

When the outgoing nucleon has small momentum its wavelength is comparable to the distance between nucleons: Quantum Mechanics is important !!

slide-9
SLIDE 9

9

Distortion of the outgoing nucleon (= FSI in a Quantum Mechanical way) Important at intermediate energies too !!!

  • Phys. Rev. C 100 045501 (2019)
slide-10
SLIDE 10

10

slide-11
SLIDE 11

11

???

ne QE cross section

  • ----------------------------------------- = 1

nm QE cross section

For a given neutrino energy and scattering angle of the final lepton:

slide-12
SLIDE 12

12

??? ???

ne QE cross section

  • ----------------------------------------- = 1

nm QE cross section ne QE cross section

  • ----------------------------------------- > 1

nm QE cross section

For a given neutrino energy and scattering angle of the final lepton:

slide-13
SLIDE 13

13

??? ???

ne QE cross section

  • ----------------------------------------- = 1

nm QE cross section ne QE cross section

  • ----------------------------------------- > 1

nm QE cross section ne QE cross section

  • ----------------------------------------- < 1

nm QE cross section

For a given neutrino energy and scattering angle of the final lepton:

???

slide-14
SLIDE 14

14

slide-15
SLIDE 15

15

slide-16
SLIDE 16

16

slide-17
SLIDE 17

17

SuSAv2 SuSAv2-MEC

slide-18
SLIDE 18

18

slide-19
SLIDE 19

19

SuSAv2-MEC versus MINERvA nub 0pions

slide-20
SLIDE 20

20

Full propagator vs real propagator in the delta current.

slide-21
SLIDE 21

21

slide-22
SLIDE 22

22

The 2p2h response scales very differently from the quasielastic one, in full accord with what is predicted by the model.

slide-23
SLIDE 23

23

The 2p2h response scales very differently from the quasielastic one, in full accord with what is predicted by the model. QE: MEC:

slide-24
SLIDE 24

24

Comparison with recent JLab data. Ei = 2222 MeV, qe= 15.541 deg

slide-25
SLIDE 25

25

slide-26
SLIDE 26

26

The SuSAv2 QE response is very similar to that from a model that solves the wave equation in presence of a real energy-dependent optical potential. The coincidence between these two completely independent approaches, which satisfactorily agree with the inclusive data, reinforces the reliability of our predictions and sets constraints for the modeling of the QE response.

slide-27
SLIDE 27

27

Carbon Argon Titanium

Recent JLab data. Ei = 2222 MeV qe= 15.541 deg

slide-28
SLIDE 28

28

slide-29
SLIDE 29

29

slide-30
SLIDE 30

30

slide-31
SLIDE 31

31

What do we need?

slide-32
SLIDE 32

32

nucleus neutrino muon

X

Inclusive cross section?

slide-33
SLIDE 33

33

Inclusive cross section?

Many models are good for the inclusive xs (at typical QE kinematics).

slide-34
SLIDE 34

34

slide-35
SLIDE 35

35

slide-36
SLIDE 36

36

Inclusive cross section?

Many models are good for the inclusive xs (at typical QE kinematics). SuSAv2+MEC is the state of the art among the inclusive models: + Extensively tested against electron and neutrino scattering data: systematically on the data. + Fully relativistic. + Extremely efficient from computational point of view. + For neutrino interactions, it needs to be extended to the DIS region. + Not suppose to work at very low q, but a few things could be done.

slide-37
SLIDE 37

37

Information about the hadrons? What do we need?

slide-38
SLIDE 38

38

1 2 nucleus neutrino muon/neutrino nucleus*

Elastic scattering (difficult) Initial State Final State

slide-39
SLIDE 39

39

1 2 3 nucleus neutrino muon nucleus*

Quasielastic scattering (difficult)

nucleon

Initial State Final State

slide-40
SLIDE 40

40

1 2 3 nucleus neutrino muon nucleus*

2N knockout (extremely difficult)

nucleon 4 nucleon

Initial State Final State

slide-41
SLIDE 41

41

1 2 3 4 nucleus neutrino muon nucleus* nucleon pion

Single-pion production (extremely difficult) Initial State Final State

slide-42
SLIDE 42

42

1 2 3 4 nucleus neutrino muon nucleus* pion

Two-pion production (impossible?)

5 pion nucleon

Initial State Final State

slide-43
SLIDE 43

43

. . .

1 2 3 nucleus neutrino muon nucleus*

Impossible

N nucleon

Initial State Final State

4 5

slide-44
SLIDE 44

44

Problem:

We are not able to model with accuracy any of the non-inclusive cross sections.

slide-45
SLIDE 45

45

Problem:

We are not able to model with accuracy any of the non-inclusive cross sections. One exception: Exclusive A(e,e’p)A-1 in a narrow missing energy window (= one nucleon knock out from the

  • uter shells)
slide-46
SLIDE 46

46

Exclusive A(e,e’p)A-1 in a narrow missing energy window (outer shells)

slide-47
SLIDE 47

47

Conclusions and Outlook:

+ Modeling all reaction channels with high precision is (and will be) impossible. + Actually, we can describe very well only one channel: QE scattering with only one nucleon in the final state and small missing energy left in the residual nucleus, Em<20 MeV. ++ For such events, the neutrino energy could be reconstructed with few percent accuracy. (Van Orden and Donnelly, arXiv:1908.00932) + We are working on this.

slide-48
SLIDE 48

48

Back up slides

slide-49
SLIDE 49

49

We have presented a real energy-dependent potential that can be used in a large energy range: + For low energies of the outgoing nucleons it is identical to RMF potential, thus:

  • rthogonality, current conservation and dispersion relations are fulfilled.

+ The phenomenology suggests that for high energies of the outgoing nucleon the potential should become softer. New energy-dependent potential = RMF potential x f(TN)

slide-50
SLIDE 50

50

Superscaling Approach Scaling phenomenon - definition

It happens when the inclusive cross section can be written as the product

  • f a single-nucleon cross section times a specific function (scaling

function) that depends on only one variable (scaling variable) Most of the models based on IA present scaling at some level. The scaling function incorporates itself all nuclear information.

slide-51
SLIDE 51

51

Scaling phenomenon

slide-52
SLIDE 52

52

slide-53
SLIDE 53

53
