JF62 INTERSECTION CONTROL July 2018 FDOTS MANUAL ON INTERSECTION CONTROL EVALUATION Adopted November 2017 Why ICE? When ICE is Required? Applicability and Process Tools and Resources D1 Training 2 ICE PURPOSE

slide-1
SLIDE 1

INTERSECTION CONTROL

July 2018

JF62

slide-2
SLIDE 2

2

D1 Training

FDOT’S MANUAL ON INTERSECTION CONTROL EVALUATION

  • Adopted November 2017
  • Why ICE?
  • When ICE is Required?
  • Applicability and Process
  • Tools and Resources
slide-3
SLIDE 3

3

D1 Training

ICE PURPOSE

  • Consistently consider multiple context‐sensitive control strategies when

planning a new or modified intersection through…

  • Informed decision‐making considering
  • purpose and need, context classification, safe travel facilities for all road users, with the
  • verall best value
  • Select a context‐sensitive control strategy considering
  • the goals and needs of the community and all road users
  • Measure the control strategy’s value using
  • performance‐based criteria
  • Promotes thoughtful consideration of alternative intersection types

through quantitative analysis

slide-4
SLIDE 4

4

D1 Training

INTERSECTION TYPES

 Roundabout

ICE will replace the 3 step roundabout evaluation process in 2020

slide-5
SLIDE 5

5

D1 Training

INTERSECTION TYPES

 Median U‐Turn (MUT)

No left turns allowed at main signalized intersection

slide-6
SLIDE 6

6

D1 Training

INTERSECTION TYPES

 Median U‐Turn (MUT)

No left turns allowed at main signalized intersection

slide-7
SLIDE 7

7

D1 Training

INTERSECTION TYPES

 Restricted Crossing U‐Turn (RCUT) Unsignalized Signalized

slide-8
SLIDE 8

8

D1 Training

INTERSECTION TYPES

 Jughandle

slide-9
SLIDE 9

9

D1 Training

INTERSECTION TYPES

 Displaced Left Turn  Left turns and

through movements

  • perate concurrently

 Also called

continuous flow intersection

 Could have displaced

lefts on 2 legs instead

  • f all 4
slide-10
SLIDE 10

10

D1 Training

INTERSECTION TYPES

 Continuous Green T

Will be eliminated from ICE

slide-11
SLIDE 11

11

D1 Training

INTERSECTION TYPES

 Quadrant Roadway

No left turns allowed at main signalized intersection

slide-12
SLIDE 12

12

D1 Training

INTERSECTION TYPES

 Quadrant Roadway

No left turns allowed at main signalized intersection

slide-13
SLIDE 13

13

D1 Training

INTERSECTION TYPES

 Quadrant Roadway

No left turns allowed at main signalized intersection

slide-14
SLIDE 14

14

D1 Training

FDOT ICE IMPLEMENTATION PLAN

  • 2018: Training and Acclimation
  • Implementation Focus: District Training
  • Two intersections per district
  • 2019: Districts Identify & Conduct ICE Analysis for Additional

Locations

  • Implementation Focus: Refine ICE Process
  • Evaluate minimum of three projects in these offices/focus areas
  • PD&E
  • Traffic Operations
  • Access Management/Permitting
  • 2020: Full ICE Procedure Implementation by Districts
  • Implementation Focus: Mainstream ICE Process
  • ICE Manual Procedures fully effective January 1, 2020
  • 3 Step Roundabout Analysis replaced by ICE
  • Quality Assistance Reviews (QAR) starting in Year 4
slide-15
SLIDE 15

15

D1 Training

ICE STAGE 1 PROCESS

Reference: FDOT Manual of Intersection Control Evaluation; Nov. 1, 2017; Figure 2; Page 10
