Interactive Rendering of Large Unstructured Grids Using Dynamic Level-of-Detail Steven P. Callahan , Joo L. D. Comba Peter Shirley , and Cludio T. Silva University of Utah UFRGS, Brazil Dynamic Level-of-Detail 100%

slide-1
SLIDE 1

Interactive Rendering of Large Unstructured Grids Using Dynamic Level-of-Detail

Steven P. Callahan†, João L. D. Comba‡ Peter Shirley†, and Cláudio T. Silva†

† University of Utah ‡ UFRGS, Brazil

slide-2
SLIDE 2

Dynamic Level-of-Detail 100% 2.0 fps 5% 16.1 fps 25% 5.3 fps

slide-3
SLIDE 3

Level-Of-Detail Background

➤ Geometric Approach

[Cignoni et al. 2004]

slide-4
SLIDE 4

Level-Of-Detail Background

➤ Texture Approach

[Leven et al. 2002]

slide-5
SLIDE 5

Level-Of-Detail Background

➤ Tetrahedra

  • Farias et al. 2000
  • Leven et al. 2002
  • Cignoni et al. 2004
  • Museth and Lombeyda 2004

➤ Regular Grids

  • Danskin and Hanrahan 1992
  • LaMar et al. 1999
  • Weiler et al. 2000

➤ Triangles or Points

  • Funkhouser and Séquin 1993
  • Luebke and Erikson 1997
  • Luebke et al. 2002
  • Duessen et al. 2002
slide-6
SLIDE 6

Definitions Given a scalar field An approximation can be made such that and . A ray passing through the domain forms a continuous function

slide-7
SLIDE 7

Domain-Based Simplification

slide-8
SLIDE 8

Sample-Based Simplification

slide-9
SLIDE 9

Triangle Sampling

➤ Sample the triangles

  • Boundary + Internal triangles

LOD B1,B2,...,Bn I1,I2,...,Im

➤ LOD index updated at each pass

slide-10
SLIDE 10

Hardware-Assisted Visibility Sorting

➤ Sort in object-space and image-space

CPU GPU

[Callahan et al. 2005, Silva et al. 2005]

slide-11
SLIDE 11

Hardware-Assisted Dynamic Level-of-Detail

CPU GPU

➤ Sample in object-space

slide-12
SLIDE 12

Ranking Strategies Topology: target continuity

slide-13
SLIDE 13

Ranking Strategies Field: target histogram

slide-14
SLIDE 14

Ranking Strategies View: target screen-space coverage

slide-15
SLIDE 15

Ranking Strategies Area: target faces that cause greater error

slide-16
SLIDE 16

Visual Quality 100% 1.3 fps 15% 4.5 fps 5% 10.0 fps

slide-17
SLIDE 17

Movie

slide-18
SLIDE 18

Movie

slide-19
SLIDE 19

Movie

slide-20
SLIDE 20

Preprocessing 15.3 s 15.3s 13.9 s 75.6 s 1.4 M Fighter 11.2 s 11.6 s 10.5 s 87.2 s 1.0 M Torso 13.9 s 5.3 s 4.5 s 17.8 s 0.8 M Spx2 Area View Field Topology Tets Dataset

slide-21
SLIDE 21

Strategy Analysis

slide-22
SLIDE 22

Strategy Analysis

slide-23
SLIDE 23

Strategy Analysis

Full Quality Topology View Field Area

slide-24
SLIDE 24

Domain and Sample Comparison Full Quality

100% @ 20 fps

Sample

50% @ 30 fps

Domain

50% @ 23 fps

g(t) g1(t) g2(t) t t t

slide-25
SLIDE 25

g(t) g1(t) g2(t) t t

Domain and Sample Comparison Full Quality

100% @ 20 fps

Sample

50% @ 30 fps

Domain

25% @ 30 fps

t

slide-26
SLIDE 26

g(t) g1(t) g2(t) t t

Domain and Sample Comparison Full Quality

100% @ 20 fps

Domain

1% @ 60 fps

Sample

10% @ 60 fps

t

slide-27
SLIDE 27

Conclusion

➤ New sampling approach which simplifies LOD ➤ Well-suited for a GPU implementation ➤ Dynamic changes to LOD are simple and require no explicit

hierarchies

➤ Tetmesh 0.1 code will be available soon at

www.sci.utah.edu/~vgc

slide-28
SLIDE 28

Open Research

➤ Better ranking strategies ➤ Handle even larger data

  • Sample the boundaries
  • Sample points instead of triangles

➤ Adaptive time-varying visualization

slide-29
SLIDE 29

Acknowledgments

➤ Carlos Scheidegger , Huy Vo, and John Schreiner ➤ Datasets

  • Bruno Notrosso (Electricite de France)
  • Neely and Batina (NASA)
  • SCI Institute, University of Utah

➤ Funding

  • DOE
  • CNPq
  • MICS
  • NSF
  • University of Utah
