INTEGRATED MARINE APPROACH FOR PREPARATION, TRANSPORT AND - - PowerPoint PPT Presentation

\

1

BASTIAAN LAMMERS, BUSINESS DEVELOPMENT MANAGER GERRY SARLIS, SENIOR SALES MANAGER

SNAME LUNCHEON, CALGARY APRIL 16, 2014

INTEGRATED MARINE APPROACH FOR PREPARATION, TRANSPORT AND INSTALLATION OPERATIONS IN THE ARCTIC

\

2

\

3

INDEX

01 INTRODUCTION 02 COMPANY OVERVIEW 03 ARCTIC WORK 04 INNOVATION PROCESS 05 MALAMPAYA, MULTITASKING 06 07 08 09

\

4

• Leading global dredging & maritime expert
• With 11,000 employees and 1,000 vessels
• Active in 75 countries across 6 continents
• Customers in Energy, Ports and Infra
• Headquarters in Papendrecht, The Netherlands
• Revenue 2013: EUR 3.5 bln
• Net profit 2013: EUR 366 mln
• EBITDA 2013: EUR 800 mln
• Order book EY13: EUR 4.0 bln
• Listed in AEX Euronext

COMPANY OVERVIEW

\

5

BOSKALIS OVERVIEW

\

6

OFFSHORE EXPLORATION IN THE ARCTIC WITH SPECIFIC CHALLENGES:

• 1. REMOTE AREA ,
• 1. Efficient execution with minimum mobilization
• 2. An integrated solution of seabed preparation, logistics and installation
• 3. Mobilize and approve limited number of vessels
• 2. LIMITED OPEN ICE SEASON
• 1. Timing is of the essence
• 2. Minimize contract interfaces
• 3. MULTITASKING ON MALAMPAYA PHASE 3 PROJECT (PHILIPPINES)
• 1. Integration of seabed preparation and transport and installation
• 2. Multiple technologies on one vessel

WORKING IN THE ARCTIC

\

7

PLAYS IN THE PAST

\

8

PLAYS IN THE PAST

1999: Terra Nova excavated ‘glory holes’ Petro-Canada

\

9

• 1. CLIENT: SHELL PHILIPPINES EXPLORATION'S
• 2. PHILIPPINES ONLY MAJOR SOURCE OF NATURAL GAS SUPPLY.
• 3. THE MALAMPAYA RESERVOIR, IS PRODUCED VIA A 10-SLOT SUBSEA

MANIFOLD IN 820 METER WATER DEPTH TIED BACK TO A PLATFORM 30KM AWAY IN 43 METER WATER DEPTH.

• 4. PHASE 3, IS PART OF THE OPTIMIZATION OF THE FIELD.
• 5. TO MAINTAIN THE GAS PRESSURE IN THE FIELD, AN OFFSHORE

DEPLETION COMPRESSION PLATFORM (DCP), WILL BE INSTALLED ALONGSIDE THE EXISTING PRODUCTION PLATFORM.

• 6. COMBINED (UNIQUE) PROPOSAL FOR SEABED WORKS AND T&I,

AWARD IN APRIL 2013

• 7. THE FIRST PHASE OF SEABED PREPARATION BEGINS IN Q1, THIS

YEAR, AND THE T&I PHASE IN Q4

MALAMPAYA PHASE 3 PROJECT

\

10

MALAMPAYA: DEPLETION COMPRESSION PLATFORM

\

11

PHASE 1:

• 1. Seabed Preparation: 1) Removal of top layer, 2) Installation of engineered

rock and 3) Installation of 4 seabed preparation pads PHASE 2

• 1. Transport DPC to location
• 2. Position and install DPC by using 3-4 100/200-tonne anchor handling tugs
• 3. Install temporary equipment in DPC
• 4. Dense iron ore gravel ballast is put into all four footings
• 5. Rock will be placed around the four footings (Scour protection)
• 6. Then, a permanent bridge, linking the gas production platform to the new

compressor platform, will be installed between the two platforms

MALAMPAYA: KEY ACTIVITIES

\

12

INNOVATION PROCESS

• EMBED INNOVATION AS PART OF OUR CULTURE COMPANY WIDE
• BOSKALIS INNOVATION CHALLENGE,

THE FORUM TO MAKE YOUR IDEAS KNOWN TO THE WORLD

\

13

• 1. COMBINED CONTRACT FOR SEABED PREPARATION AND T&I
• 2. NEW MULTIPURPOSE CONSTRUCTION VESSEL NDEAVOR
• 1. Sea trials in November 2013
• 2. 99m-long, 30m-wide, a 4.7m draught, and weigh 7500 DWT.
• 3. 62 cabins, for 104 people
• 3. NDEAVOR, WITH DP 2 CAPABILITY, WILL BE USED FOR:
• 1. the excavation (dredging) and rock-placement work.
• 2. the command vessel during installation of the platform (max 104 persons),
• 3. placing ballast in the footings,
• 4. and during the positioning of a bridge between the two platforms (barge

master)

MULTITASKING ON MALAMPAYA

\

14

NDEAVOR CONSTRUCTION SUPPORT VESSEL

\

15

\

16

\

17

\

18

\

19

\

20

WHERE ARE WE NOW?

THE ROCK STORAGE / SSD UNIT IS IN FABRICATION

\

21

\

22

\

23

NDEAVOR AT WORK AT MALAMPAYA

\

24

UNION SOVEREIGN (180 tons)

\

25

ONE CONTRACT FOR SEABED PREPARATION AND T&I MULTIPLE USE OF ONE VESSEL LIMITED MOBILIZATION LIMITED VESSEL APPROVAL NO CONTRACT INTERFACES AND RISK FOR DELAY

ADVANTAGES

\

26
