INGLESIDE AT ROCK CREEK

ANC Meeting • 11 July 2016

Perkins Eastman DC

Perkins Eastman DC

AGENDA

Existing Campus:

• Site Plan

As Approved:

• Site Plan
• Site Elevation
• Zoning Data

As Since Refined by Ingleside Team:

• Site Plan
• Site Elevation
• Zoning Data

Comparative Analysis of Approved v. Refined:

• Site Plan Overlay
• Site Elevation Overlay
• Zoning Data Recap

Perkins Eastman DC

SITE PLAN | EXISTING

MILITARY ROAD NW JOCELYN STREET 29th STREET NW CARNEGIE INSTITUTION TEMPLE SINAI EMBASSY OF TUNISIA EMBASSY OF THE IVORY COAST

AL SUITES HEALTH SERVICES MANOR HOUSE BUILDING 4 BUILDING 5 BUILDING 6 McCRACKEN

31ST STREET NW

Perkins Eastman DC

SITE PLAN | APPROVED

MILITARY ROAD NW

HEALTH SERVICES 8 9

JOCELYN STREET CARNEGIE INSTITUTION TEMPLE SINAI EMBASSY OF TUNISIA EMBASSY OF THE IVORY COAST

1 2 6 5 4 3

29th STREET NW 31ST STREET NW

Perkins Eastman DC

MILITARY ROAD ELEVATION | APPROVED

L E VE L1 L E VE L G L E VE L 2 L E VE L 3 L E VE L 4 ROOF

HEALTH SERVICES BUILDING | NORTH ELEVATION

Perkins Eastman DC

WEST ELEVATION | APPROVED

G2 G1 1 2 3 4 5 6 7 1 2 3 4 5 6 7

HEALTH SERVICES BUILDING MULTI-PURPOSE / INDEPENDENT LIVING BUILDING INDEPENDENT LIVING BUILDING MANOR HOUSE

Perkins Eastman DC

ZONING DATA | APPROVED Approved Zoning Data:

• GFA is 378,829 sf
• Lot occupancy is 20.54%
• Setbacks are 52’ from the West, 48’-3” from the North
• Building 1 is four stories; height is 45’
• Building 8 is eight stories; height is 70’
• Building 9 is eight stories; height is 55’-6”
• Number of:
• New Independent Living units: 97
• New AL units: 12
• New Memory Care units: 32
• Skilled Nursing beds: 64
• 367 total parking spaces
• Traffic impact per traffic study

Perkins Eastman DC

SITE PLAN | REFINED

MILITARY ROAD NW

HEALTH SERVICES

JOCELYN STREET CARNEGIE INSTITUTION TEMPLE SINAI EMBASSY OF TUNISIA EMBASSY OF THE IVORY COAST 29th STREET NW 31ST STREET NW

8 9 1 2 6 5 4 3

Perkins Eastman DC

L E VE L G L E VE L 2 L E VE L 3 L E VE L 4 ROOF

MILITARY ROAD ELEVATION | REFINED

HEALTH SERVICES BUILDING | NORTH ELEVATION

L E VE L 1 L E VE L G

Perkins Eastman DC

WEST ELEVATION | REFINED

G2 G1 1 2 3 4 5 6 7 1 2 3 4 5 6 7

HEALTH SERVICES BUILDING MULTI-PURPOSE / INDEPENDENT LIVING BUILDING INDEPENDENT LIVING BUILDING MANOR HOUSE

Perkins Eastman DC

ZONING DATA | REFINED Refined Zoning Data:

• GFA is increased by 13,100 sf to 391,929 sf
• Lot occupancy is 20.54%
• Setbacks are 52’-0” from the West, 48’-3” from the North
• Building 1 is four stories; height is 45’
• Building 8 seven stories; height is 70’
• Building 9 is seven stories; height is 55’-6”
• Number of:
• New Independent Living units: increased by 8 to 105
• New AL units: increased by 9 to 21
• New Memory Care units: remains the same at 32
• Skilled Nursing beds: decreased by 30 to 34
• 367 total parking spaces
• Traffic impact per traffic study

Perkins Eastman DC

SITE PLAN | OVERLAY

Outline of Approved

MILITARY ROAD NW JOCELYN STREET CARNEGIE INSTITUTION TEMPLE SINAI EMBASSY OF TUNISIA EMBASSY OF THE IVORY COAST 29th STREET NW 31ST STREET NW

Perkins Eastman DC

L E VE L1 L E VE L G

MILITARY ROAD ELEVATION | OVERLAY

L E VE L 2 L E VE L 3 L E VE L 4 ROOF

Outline of approved HEALTH SERVICES BUILDING | NORTH ELEVATION

L E VE L 1 L E VE L G

Perkins Eastman DC

WEST ELEVATION | OVERLAY

G2 G1 1 2 3 4 5 6 7 1 2 3 4 5 6 7

Outline of approved HEALTH SERVICES BUILDING MULTI-PURPOSE / INDEPENDENT LIVING BUILDING INDEPENDENT LIVING BUILDING MANOR HOUSE

Perkins Eastman DC

ZONING DATA | RECAP Recap of Zoning Data:

• GFA increased by 13,100 sf from 378,829 to 391,929 sf
• Lot occupancy remains the same
• Setbacks either remain the same or increase
• Building 1 height remains the same
• Building 8 height remains the same
• Building 9 height remains the same
• Total number of new units decreased by 13
• Number of parking spaces remains the same
• Traffic impact remains the same

Perkins Eastman DC

TRAFFIC IMPACT STUDY
