R&D ADOPTION OF INNOVATIONS AND TECHNOLOGIES FOR SUSTAINABLE ROAD INFRASTRUCTURE

PRESENTED BY:

E-mail: eyothom@yahoo.com Website: www.eyotb.com Mobile: +234-803-370-5986

1

INTRODUCTION

• Research begins where Why and How are asked.
• Questioning conventional wisdom is the origin of

research.

• Innovation is the answered question to a

successful research while adoption is the application of innovation.

• Sustainability is the application of innovations to

meet the needs of the present without compromising the ability of future generations to meet their own needs.

2

WHAT TO EXPECT

1.0 FERMA ROAD PRODUCTS/MATERIALS



Cold Asphalt



Road Mat



Bitumen Emulsion



Liquid Soil Stabiliser. 2.0 FERMA ROAD TECHNOLOGY



Pavement Resurfacing by Fumigation Cold planning. 3.0 FERMA INTERMEDIATE EQUIPMENT



Bitumen Sprayer Air lance 4.0 FERMA PUBLICATIONS



READOP Series



FERMA NUGGET 5.0 RECOMMENDED TECHNOLOGY FOR ADOPTION



Asphalt Recycling.



Slope Protection using Gabion Mattresses & Geotextile.



Warm mix asphalt.



Polymer modified asphalt.



Asphalt rubber.



Pavement Management System as Preventive Maintenance Supplement.



Percent Within Limit Specification.



Marshal and Superpave Mix Design.



NCAT Test Track.

3

FERMA ROAD PRODUCTS & MATERIALS

ROAD MAT

• FERMA Road mat is a prefabricated road maintenance

product on kraft paper onto which bitumen mixed with crumb rubber holds a compacted aggregate of various sizes depending on the intended usage.

• Sheet size: 1.0m x 0.75m.

Aggregate sizes : 2.75mm – 19mm.

• Weight 4kg and 25kg.
• Local cost N900/mat as against the imported price of

N3000/mat.

• The product is highly flexible and totally waterproof.
• Road mat is used for Road Patching, Crack Sealing, Traffic

Calming and Safety Devices.

4

FERMA ROAD PRODUCTS & MATERIALS Cont’d

5

FERMA ROAD MAT AT IPELE-IFERA ROAD JUNCTION, ONDO STATE 5 YEARS AFTER

FERMA ROAD PRODUCTS & MATERIALS Cont’d

COLD ASPHALT

 FERMA Cold Asphalt;

100 % locally available materials.

 Unlike HMA concentrate

produces superior bonding strength resulting in a strong, trafficable, long lasting and skid resistance waterproof surface.

 Satisfies binder and

wearing course Marshal mix design specification in addition to boil test.

 FERMA Cold Asphalt

used in almost all states including highly trafficked Benin- Shagamu Road and Third Mainland Bridge in Lagos.

 The report has been very

promising.

6

7

FORMER WORKS MINISTER AND SENATORS MARVEL AT COLD ASPHALT STOCKPILE

FERMA ROAD PRODUCTS & MATERIALS Cont’d

PATCHING OF POTHOLE WITH ASPHALT ON THIRD MAINLAND BRIDGE, LAGOS

8

9

LAYING OF COLD ASPHALT ON JOS-BAUCHI ROAD, BAUCHI STATE

70/80 TPH ASPHALT PLANT WITH HOT AND COLD FACILITY

10

Covered Stockpile Produced from 70/80 TPH FERMA Asphalt Plant

FERMA BITUMEN EMULSION

 Bitumen emulsion;

bitumen, water, and an emulsifying agent.

• Bitumen / Kerosene =

Volatile Organic Compound (VOC) is a popular solvent used in the preparation of cutback bitumen for road works.

 Bitumen-kerosene

(cutback) mixture more harmful than carbon dioxide (CO2) which is greenhouse gases that causes global warming. USAGE

 Tack Coat, Priming,

Surface Dressing, Slurry Seal,Cold asphalt etc.

 Identified and well

labelled for use.

• Quality Control Tests.

Distillation, Viscosity,

• Particle charge and float

test

11

BITUMEN EMULSION CONT’D

ADVANTAGES

 Reduces carbon dioxide

emission by almost 2/3 while reducing the production of photo chemical smog generating VOCs emission.

 It saves energy since it does

not require heating or the use of a petroleum solvent.

 Reduces atmospheric

pollution as heating is not involved

 Road maintenance works

easier in remote areas and cold weather where heating might be cumbersome.

 Asphalt emulsions can coat

damp aggregate surfaces thereby reducing the fuel requirement for heating and drying aggregates.

 Improved workers health

and safety.

 Non toxic.  24 hours to fully cure.  Cutbacks 72 hours to fully

cure.

12

13

Emulsion Production in Progress

14

PACKAGED BITUMEN EMULSION

15

APPLICATION OF BITUMEN

POOR TACK COATING EMULSION NOT ALLOWED TO BREAK HOW NOT SPRAY EFFECT OF POOR SPRAYING

16

PAVEMENT RESURFACING BY FUMIGATION

• Pavement Resurfacing by Fumigation - a

jargon by the author, is the application of solvent to a film of excess bitumen on the surface

• f

the road and rolling in

• f

aggregate size of 3/8 to dust leaving a non skidding surface.

• First used to control bleeding on Km3+00-

km7+00 on Damaturu-Maiduguri Road, North East, Nigeria.

FERMA ROAD TECHNOLOGY

17

PAVEMENT RESURFACING BY FUMIGATION

INTERMEDIATE EQUIPMENT

18

19

INTERMEDIATE EQUIPMENT Cont’d

Sealed Surface 3 Weeks After

ASPHALT RECYCLING

 Reuse of material that have served its first

intended purpose.

 Types:

Cold In-Place, Hot In-Place, Central Plant, Cold planning. Advantages:

 Saving of about 40-80% in the use pavement

material.

 Reuse and conservation of bitumen and

aggregate.

 Energy conservation.  Shorter construction period.  Reduction in user delays during construction.

20

21

Hot-in place (HIP) Recycling Mobile Hot Asphalt Recycling Equipment Suitable For Direct Labor Works Cold- In Place (CIP) Recycling

22

Monumental Waste of 100% Recyclable Resource

SLOPE PROTECTION USING GABION MATTRESSES AND GEOTEXTILE

 Traditionally slope

protection ;top soiling, grassing and stone pitching etc.

 Reinstatement of failed

slope; no work space for compaction.

 Quality and compaction of

the reinstated material is not always ascertained. Advantages:

 Permeability, Reduces pore

water pressures behind the structure and allowing free drainage.

 Cost effective, aesthetically

pleasing and environmentally friendly. No heavy plant or machinery.



Rapidly constructed making it ideal for emergency works.

 The geotextile underlayer

allows for filtration to prevent loss of subsoil material as a result of drainage flow through the gabion.

23

24

Scouring Effect on Traditional Stone-Pitched Embankment

THE PROBLEM: SLOPE FAILURE ON A HIGH FILL MATERIAL SECTION

25

Proposed Innovative Solution: Gabion Boxes& Geotextile

26

Engineers and Chemist incorporate Rubber into Asphalt with the Following Benefits:

• Resistance to bleeding.
• Reduction in traffic noise.
• Reduction in mat thickness.
• Last longer, chemical in scrap tyre retards aging

and oxidation.

• Bitumen rubber could be used as crack sealant.

ASPHALT RUBBER

Conclusion

 We owe the Nigerian engineering community and the

general public a duty if we fail to commence the needed reform in the nation’s highway sector.

 There should be synergy between NUC or Individual

Universities and MDAs, Civil Engineering contractors and consultancy firms so as to replace the volume of theoretical or abstract subjects or topics as it is contained in the present engineering curriculum in Nigerian Universities.

28

Conclusion cont’d

 Professional lecturers in the Universities should be encouraged

to do their sabbatical in MDAs and companies so as to bridge the gap between theory and practice.

 Universities should discourage students embarking on research

that would forever remain an academic adventure on the University library shelves e.g. using periwinkle shelve as aggregate for production

• f

concrete

• r

using bamboo sticks as reinforcement bars in concrete.

 The present curriculum of engineering degrees in Nigerian

Universities needs a radical change.
