Images CS418 Computer Graphics John C. Hart Vector v. Raster Graphics Vector Graphics Raster Graphics Plotters, laser displays TVs, monitors, phones Clip art, illustrations Photographs PostScript, PDF, SVG

slide-1
SLIDE 1

Images

CS418 Computer Graphics John C. Hart

slide-2
SLIDE 2

Vector v. Raster Graphics

Vector Graphics

  • Plotters, laser displays
  • “Clip art,” illustrations
  • PostScript, PDF, SVG
  • Low memory (display list)
  • Easy to draw line
  • Solid/gradient/texture fills

Raster Graphics

  • TV’s, monitors, phones
  • Photographs
  • GIF, JPG, etc.
  • High memory (frame buffer)
  • Hard to draw line
  • Arbitrary fills
slide-3
SLIDE 3

Rasterization

3

Vertices Pixels Fills Aliasing Primitives

slide-4
SLIDE 4

Scalable Vector Graphics

<svg height=“500px” width=“500px” viewbox=“0 0 1 1”> <path d = “M 0.2 0.0 L 0.2 0.2 L 0.4 0.2 L 0.4 0.8 L 0.2 0.8 L 0.2 1.0 L 0.8 1.0 L 0.8 0.8 L 0.6 0.8 L 0.6 0.2 L 0.8 0.2 L 0.8 0.0 Z” fill = blue /> </svg>

(0,1) (1,1) (1,0) (0,0)

slide-5
SLIDE 5

Raster Images

  • 2-D Array of Color Values
  • Spatial Resolution: HRES × VRES
  • Image Aspect Ratio:

HRES/VRES (HDTV = 1920/1080 = 1.78 = 16:9)

HRES VRES

slide-6
SLIDE 6

Raster Images

  • 2-D Array of Color Values
  • Spatial Resolution: HRES × VRES
  • Image Aspect Ratio:

HRES/VRES (HDTV = 1920/1080 = 1.78 = 16:9)

  • Pixel Aspect Ratio:

(height/width) / (HRES/VRES) Square pixels are 1:1

HRES VRES width height

slide-7
SLIDE 7

Raster Images

  • 2-D Array of Color Values
  • Spatial Resolution: HRES × VRES
  • Image Aspect Ratio:

HRES/VRES (HDTV = 1920/1080 = 1.78 = 16:9)

  • Pixel Aspect Ratio:

(height/width) / (HRES/VRES) Square pixels are 1:1

HRES VRES width height HRES/2 VRES

slide-8
SLIDE 8

Raster Images

  • 2-D Array of Color Values
  • Spatial Resolution: HRES × VRES
  • Image Aspect Ratio: HRES/VRES

(HDTV = 1920/1080 = 1.78 = 16:9)

  • Pixel Aspect Ratio:

(HRES/VRES) / (height/width) Square pixels are 1:1

  • Color Resolution (bits per pixel)

1 bpp: 8 bpp: = 24 bpp: = #FF6D55

HRES VRES 1 1 1 0 1 1 0 1 1 width height VRES HRES/2
