HYDRATHERM IMS HYDRATHERM IMS FIREPROOF PRODUCT SEMINAR FIREPROOF PRODUCT SEMINAR Cemkrete s Product Range 1. Concrete Admixture 2. Concrete Repair, Grout and Anchors 3 3. Formwork Aids/ Curing Agent Formwork Aids/ Curing Agent 4.


slide-1
SLIDE 1

HYDRATHERM IMS HYDRATHERM IMS

FIREPROOF PRODUCT SEMINAR FIREPROOF PRODUCT SEMINAR

slide-2
SLIDE 2

Cemkrete ‘s Product Range

  • 1. Concrete Admixture
  • 2. Concrete Repair, Grout and Anchors

3 Formwork Aids/ Curing Agent

  • 3. Formwork Aids/ Curing Agent
  • 4. Waterproof
  • 5. Flooring
  • 6. Jointing Compound

g p

  • 7. Protective Coating

8 Machine and Accessories Hydratherm IMS

  • 8. Machine and Accessories
slide-3
SLIDE 3

Why Fireproof Coating?

  • Extended the escape time
  • Protect the steel structures from collapse
slide-4
SLIDE 4

Type of Fireproof Coating?

  • Not Expanse when heated
  • Expanse when heated

Intumescent

Intumescent comes from the Latin word "tumesco" Intumescent comes from the Latin word tumesco which means to expand or swell up.

“HYDRATHERM IMS”

slide-5
SLIDE 5

What is “Hydratherm IMS”?

  • Intumescent Coating
  • Solvent Base
  • Meets ASTM E-119, BS476 Pt21
slide-6
SLIDE 6

How “Hydratherm IMS” work?

  • Hydratherm IMS will protect the steel in 2 Phase.
  • 1. Gas Phase

2.Physical Phase

slide-7
SLIDE 7

How “Hydratherm IMS” work?

  • Hydratherm IMS will protect the steel in 2 Phase.
  • 1. Gas Phase

2.Physical Phase Heat + = Heat + + =

slide-8
SLIDE 8

How “Hydratherm IMS” work?

  • Hydratherm IMS will protect the steel in 2 Phase.

2.Physical Phase

  • 1. Gas Phase

Heat = + Heat + = +

slide-9
SLIDE 9

How “Hydratherm IMS” work?

  • Hydratherm IMS will protect the steel in 2 Phase.

2.Physical Phase

  • 1. Gas Phase
slide-10
SLIDE 10

Why Hydratherm IMS?

  • High Performance Quality
  • Manufacture Under ISO 9001 : 2000

ISO 14001 : 2004 ISO 14001 : 2004

  • Easy to Apply
  • Competitive Price
  • Good Adhesion with Various Type of Primer

and Top Coat

slide-11
SLIDE 11

How to apply “Hydratherm IMS” ?

Surface Preparation : Sand Blast, Sand Paper, etc. Primer : Red Oxide, Red Lead, Epoxy, Zinc,etc Fire Proof : Hydratherm IMS Apply by roller, brush or spray Approx 250 300 micron/coat

  • Approx. 250-300 micron/coat

Top Coat : Alkyd Paint, Acrylic, Epoxy, etc. Top Coat : Alkyd Paint, Acrylic, Epoxy, etc.

slide-12
SLIDE 12

How to QC on site?

By Weight Use : 0.9 – 1.0 kg./sq.m @ 500 micron y g g q @ By Thickness Guage : Elecometer 456

slide-13
SLIDE 13

Installation Problem

Problem : Dissolve

  • Problem : Dissolve
  • Cause : Raining when the applied film still wet
slide-14
SLIDE 14

Installation Problem

Problem : Dissolve

  • Problem : Dissolve
  • Solution : Protective Sheet
slide-15
SLIDE 15

Installation Problem

Problem : Blistering

  • Problem : Blistering
  • Cause : Raining when the applied film dry already
slide-16
SLIDE 16

Installation Problem

Problem : Blistering

  • Problem : Blistering
  • Solution : Protective Sheet
slide-17
SLIDE 17

Installation Problem

Problem : Peel Off

  • Problem : Peel Off
  • Cause : Surface Preparation not good enough
slide-18
SLIDE 18

Installation Problem

Problem : Peel Off

  • Problem : Peel Off
  • Solution : The surface should be clean by

y abrasive blast-clean. Coating should be apply before the degradation of the surface take place. g p (normally within 4 hr.) If oxidation takes place the steel must be remove. The surface must be clean

  • ut of rust, laitance, oil, grease and dust.
slide-19
SLIDE 19

Installation Problem

Problem : Expansed

  • Problem : Expansed
  • Cause : Fired or Weld the IMS ‘s film
slide-20
SLIDE 20

Installation Problem

Problem : Expansed

  • Problem : Expansed
  • Solution : Remove the expansed and burned film

Solution : Remove the expansed and burned film and re-apply.
