SLIDE 1

Hybrid TLB Coal B Coalescing: I Improving g TLB Translati tion C Cover erage e under er D Diver erse e Fr Fragm gmented M Mem emory A y Allocations

Chang Hyun Park, Taekyung Heo, Jungi Jeong, and Jaehyuk Huh

SLIDE 2

Introduction

Virtual memory provides rich features
Requires an address translation
Workloads have grown in size pressuring TLB
Contiguous memory allocations to the rescue!

22

SLIDE 3

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

23

Physical Pages Virtual Pages V->P x 4

SLIDE 4

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

24

Physical Pages Virtual Pages Large page V->P x 4

SLIDE 5

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

25

Physical Pages Virtual Pages Large page Large page V->P x 4

SLIDE 6

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

26

Physical Pages Virtual Pages Large page Large page V->P x 4 V->P x 1

SLIDE 7

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

27

Physical Pages Virtual Pages Large page Large page V->P x 4 V->P x 1

SLIDE 8

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

28

Physical Pages Virtual Pages Large page Large page V->P x 4 V->P x 1

SLIDE 9

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

29

Physical Pages Virtual Pages Large page Large page Not Aligned V->P x 4 V->P x 1

SLIDE 10

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

30

Physical Pages Virtual Pages Large page Large page Not Aligned V->P x 4 V->P x 1

SLIDE 11

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

31

Physical Pages Virtual Pages Large page Large page Not Aligned V->P x 4 V->P x 1

SLIDE 12

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

32

Physical Pages Virtual Pages Large page Large page Not Aligned Size mismatch V->P x 4 V->P x 1

SLIDE 13

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

33

Physical Pages Virtual Pages Large page Large page Not Aligned Size mismatch

Efficient when large pages provided by OS

V->P x 4 V->P x 1

SLIDE 14

Past P Proposals: : Large p pages

Large pages represent larger mappings (2MB)
Strict alignment required
Exact size match required

34

Physical Pages Virtual Pages Large page Large page Not Aligned Size mismatch

Efficient when large pages provided by OS

V->P x 4 V->P x 1

SLIDE 15

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

35

Physical Pages Virtual Pages

[5] Pham et al. HPCA ’14

SLIDE 16

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

36

Physical Pages Virtual Pages 1 3 2 V->P

[5] Pham et al. HPCA ’14

SLIDE 17

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

37

Physical Pages Virtual Pages 1 3 2 V->P

Clustered

[5] Pham et al. HPCA ’14

SLIDE 18

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

38

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered

[5] Pham et al. HPCA ’14

SLIDE 19

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

39

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered

[5] Pham et al. HPCA ’14

SLIDE 20

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

40

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered Clustered

1 X 2 V->P

[5] Pham et al. HPCA ’14

SLIDE 21

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

41

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered Clustered

1 X 2 V->P

[5] Pham et al. HPCA ’14

SLIDE 22

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

42

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered Clustered

1 X 2 V->P

[5] Pham et al. HPCA ’14

SLIDE 23

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

43

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered Clustered

1 X 2 V->P

[5] Pham et al. HPCA ’14

SLIDE 24

Past P Proposals: Cluster r TLB

HW oriented clustering[5]
Cluster TLB represents flexible mapping within cluster
Provides flexible mapping within cluster block
However cluster size is fixed at design time

44

Physical Pages Virtual Pages 1 3 2 V->P

Clustered Clustered Clustered Clustered

1 X 2 V->P

Efficient with small clustering

pportunities

[5] Pham et al. HPCA ’14

SLIDE 25

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

45

Physical Pages Virtual Pages

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 26

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

46

Physical Pages Virtual Pages Base Limit Base Limit Offset

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 27

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

47

Physical Pages Virtual Pages Base Limit Base Limit Offset Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 28

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

48

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 29

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

49

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 30

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

50

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 31

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

51

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 32

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

52

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 33

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

53

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 34

Past Proposals: : Direct Segments

Segment based translation[1]
Three values represent contiguous translation of any size
Fully assoc. lookup for multiple segments (limits size of TLB)
Redundant Memory Mappings (RMM) [6] -> 32 Fully-associative TLB

54

Physical Pages Virtual Pages Base Limit Offset Base Limit Offset Direct Segment Direct Segment

Efficient with small number of big memory chunks

[1] Basu et al. ISCA ’13 [6] Karakostas et al. ISCA ‘15

SLIDE 35

Past P Proposals: Summary

Large pages
Affinity for large pages (2MB)
Cluster TLB
Affinity for clustering of mapping of up to 8 pages
Segment translations
Affinity for small number of large chunks (32 entry TLB)

55

SLIDE 36

Past P Proposals: Summary

Large pages
Affinity for large pages (2MB)
Cluster TLB
Affinity for clustering of mapping of up to 8 pages
Segment translations
Affinity for small number of large chunks (32 entry TLB)

56

Prior proposals efficiently support specific memory mapping scenarios

SLIDE 37

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

57

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

SLIDE 38

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

58

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

SLIDE 39

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

59

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 40

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

60

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 41

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

61

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 42

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

62

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 43

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

63

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 44

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

64

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 45

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

65

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 46

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

66

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 47

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

67

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 48

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

68

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 49

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

69

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 50

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

70

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 51

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

71

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 52

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

72

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 53

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

73

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Cold Pages

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 54

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

74

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Cold Pages Hot Pages

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 55

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

75

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Cold Pages Hot Pages

Heterogeneous memory worsens non-uniformity [3][4]

SLIDE 56

La Large C Conti tiguity vs. Memor

ry Non

Non-Uniform rmity

Conflicting goals of NUMA systems and large pages[2]
Memory traffic balance vs. efficient address translation

76

Node Node Node Node

Regular Pages

Node Node Node Node

Large Page

[2] Baptiste et al. ATC ’14 [3] Lee et al. ISCA ‘15 [4] Agarwal et al. ASPLOS ‘17

Cold Pages Hot Pages

Heterogeneous memory worsens non-uniformity [3][4]

Different systems have different memory mapping needs

SLIDE 57

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

77

[7] Kwon et al. OSDI ’16

SLIDE 58

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

78

CDF of process memory

[7] Kwon et al. OSDI ’16

SLIDE 59

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

79

Well suited for Cluster

CDF of process memory

[7] Kwon et al. OSDI ’16

SLIDE 60

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

80

Well suited for Cluster Well suited for Large pages

CDF of process memory

[7] Kwon et al. OSDI ’16

SLIDE 61

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

81

Well suited for Cluster Well suited for Large pages Well suited for ??

CDF of process memory

[7] Kwon et al. OSDI ’16

SLIDE 62

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

82

Well suited for Cluster Well suited for Large pages Well suited for ??

CDF of process memory

[7] Kwon et al. OSDI ’16

SLIDE 63

Contiguity distribution varies among workloads
Also varies within the same workload[7]

Need f for a r an Al All-Roun unde der Solution

83

Well suited for Cluster Well suited for Large pages Well suited for ??

CDF of process memory

[7] Kwon et al. OSDI ’16

Can we make a TLB scheme that works well for diverse scenarios?

SLIDE 64

Hyb ybrid T TLB LB C Coalesci cing

84

TLB Hardware Operating System Page Table

SLIDE 65

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

85

TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 66

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

86

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 67

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

87

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 68

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

88

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 69

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

89

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 70

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

90

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 71

Hyb ybrid T TLB LB C Coalesci cing

HW-SW Joint Effort
HW offers adjustable TLB

coverage

Number of TLB entries fixed
Coverage of entry adjustable
OS decides best TLB coverage
Adjusts TLB coverage per process
OS identifies contiguous chunks
Marks onto process page table

91

TLB TLB Hardware Operating System Page Table

We propose a TLB with adjustable coverage

SLIDE 72

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

92

Page Table Anchor Distance = 8

SLIDE 73

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

93

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 74

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

94

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 75

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

95

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 76

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

96

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 77

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

97

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 78

Anch nchor

Anchors are special entries in the page table
Placed at every alignments of anchor distance
Anchor distance is a power of 2 (for encoding efficiency)
Anchor distance configurable by OS

98

Anchor Distance = 4 Page Table Anchor Distance = 8

SLIDE 79

An Anchor r Page Table

Uses the Page Table
Anchor covers up to distance(4) contiguous pages
Each anchor represents contiguity that begins at anchor
OS marks contiguity onto the anchor page table

99

Physical Pages 2 3 4 1 4 Virtual Pages Anchor Mappings Regular Mappings

SLIDE 80

An Anchor r Page Table

Uses the Page Table
Anchor covers up to distance(4) contiguous pages
Each anchor represents contiguity that begins at anchor
OS marks contiguity onto the anchor page table

100

Physical Pages 2 3 4 1 4 Virtual Pages Anchor Mappings Regular Mappings

SLIDE 81

An Anchor r Page Table

Uses the Page Table
Anchor covers up to distance(4) contiguous pages
Each anchor represents contiguity that begins at anchor
OS marks contiguity onto the anchor page table

101

Physical Pages 2 3 4 1 4 Virtual Pages Anchor Mappings Regular Mappings

SLIDE 82

An Anchor r TLB

Integrated into the L2 TLB
L1 keeps regular entries
Caches both regular and anchor page table entries
Regular and anchor indexed differently

102

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 TLB Entries 3 | X 3 | X 3 | X Anchor Entry Regular Entry Tag | Contiguity

SLIDE 83

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

103

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry

SLIDE 84

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

104

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry

SLIDE 85

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

105

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

SLIDE 86

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

106

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

SLIDE 87

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

107

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

Offset (2) < Contiguity (3)

SLIDE 88

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

108

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

Offset (2) < Contiguity (3) HIT return Anchor PFN + offset

SLIDE 89

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

109

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

Offset (2) < Contiguity (3) HIT return Anchor PFN + offset MISS Start Page Walk

SLIDE 90

An Anchor r TLB Lookup

On L1 TLB Miss Anchor TLB looks up
Regular TLB first
Anchor TLB next

110

2 3 4 4 Virtual Pages Anchor TLB (4 sets) 0 | 2 0 | 3 0 | 4 1 | 4 3 | X 3 | X 3 | X Anchor Entry Regular Entry 0 | 3

Offset (2) < Contiguity (3) HIT return Anchor PFN + offset MISS Start Page Walk

SLIDE 91

Operati ting S System Responsibilities

OS periodically selects process anchor distance
Heuristic algorithm to minimize TLB entry count
OS adjusts anchor distance
Anchor distance based on selection algorithm
OS marks mapping contiguity
Memory mapping contiguity in anchor page table entry

111

SLIDE 92

Simulation

n M

Met ethodol

logy
Trace based TLB simulator (Based on Intel Haswell)

112

TLB Configuration

Common L1 4KB: 64 entry, 4 way 2MB: 32 entry, 4 way Baseline L2 / THP 4KB/2MB: 1024 entry, 8 way Cluster Regular (4KB/2MB): 768 entry, 6 way Cluster-8: 320 entry, 5 way RMM (Multiple segments) Baseline L2 TLB + RMM: 32 entry, fully-assoc. Anchor (Selected/Static Ideal) 4KB/2MB/anchor: 1024 entry, 8 way

SLIDE 93

Memory Mapping Scenarios

Two class of memory mapping scenarios
Two real system memory mappings
Four synthetic memory mappings

113

Name Trace information

demand Default Linux memory mapping eager ‘Eager’ allocation low 1– 16 pages (4KB – 64KB) medium 1 – 512 pages (4KB – 2MB) high 512 – 64K pages (2MB – 256MB) max Maximum contiguity

SLIDE 94

Evaluati tion – TLB LB M Misses of demand mappi ping ng

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

114

SLIDE 95

Evaluati tion – TLB LB M Misses of demand mappi ping ng

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

115

SLIDE 96

Evaluati tion – TLB LB M Misses of demand mappi ping ng

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

116

SLIDE 97

Evaluati tion – TLB LB M Misses of demand mappi ping ng

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

117

Anchor TLB adjusted to satisfy small contiguities

SLIDE 98

Evaluati tion – TLB LB M Misses of medium mappi ping

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

118

SLIDE 99

Evaluati tion – TLB LB M Misses of medium mappi ping

10 20 30 40 50 60 70 80 90 100

Relative TLB Misses (%) THP Cluster RMM Anchor Selected Anchor Ideal

119

Anchor adjusted coverage to provide best TLB reduction

SLIDE 100

Evaluati tion – TLB M Misses of all mappi ping ng

10 20 30 40 50 60 70 80 90 100 demand eager low cont. med cont. high cont. max cont.

Relative TLB Misses (%) Baseline THP Cluster RMM Anchor Selected Anchor Ideal

120

SLIDE 101

Evaluati tion – TLB M Misses of all mappi ping ng

10 20 30 40 50 60 70 80 90 100 demand eager low cont. med cont. high cont. max cont.

Relative TLB Misses (%) Baseline THP Cluster RMM Anchor Selected Anchor Ideal

121

Anchor TLB performs well for diverse mapping scenarios

SLIDE 102

Evaluati tion – TLB M Misses of all mappi ping ng

10 20 30 40 50 60 70 80 90 100 demand eager low cont. med cont. high cont. max cont.

Relative TLB Misses (%) Baseline THP Cluster RMM Anchor Selected Anchor Ideal

122

Anchor TLB performs well for diverse mapping scenarios

SLIDE 103

Conclusion

Hybrid TLB Coalescing is a HW-SW joint effort
Anchor TLB provides adjustable coverage
TLB entry coverage grows and shrinks dynamically
OS provides contiguity hint using the page table
OS picks adequate contiguity per-process
Hybrid TLB Coalesce performs:
Best for Small-Intermediate contiguities
Similar to best prior scheme for Large contiguities

123
