Theme of the Workshop How the Railways contribute to improving quality of life? High Speed Rail in UK and HS2 Professor John Roberts Professor of Practice Rail Safety - Newcastle University Adjunct Professor - Kasetsart University Chairman

slide-1
SLIDE 1

Theme of the Workshop

How the Railways contribute to improving quality of life?

slide-2
SLIDE 2

High Speed Rail in UK and HS2

Professor John Roberts

Professor of Practice Rail Safety - Newcastle University Adjunct Professor - Kasetsart University Chairman KURail - Kasetsart University Bangkok Director Asian Region NewRail - Newcastle University

slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5

The Race for Speed

5

The Companies go head to head

  • The era is the 1930s
  • The companies in the race are the LMS and LNER
  • The winner Mallard
  • World speed record for steam - 126 mph (203 km/h)
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9

Standard A4 tank locomotive introduced 1951

slide-10
SLIDE 10

BR Standard Class 8P 1954

slide-11
SLIDE 11

11

The Race for Speed

1964 the introduction of Japan’s Shinkansen Maximum speed 220 km/h

slide-12
SLIDE 12

Advanced Passenger Train 1970 (APT) tilting train speed record on 10 August 1975 when it reached 152 miles per hour (245 km/h)

slide-13
SLIDE 13

Intercity 125 introduced 1975 125 mph (238 km/h)

slide-14
SLIDE 14

14

The Race for Speed

Alstom built TGV high speed train. Maximum speed 270 km/h introduced in 1978

slide-15
SLIDE 15

15

The Race for Speed

Japanese Type 500 HS train. Maximum speed 300 km/h. Introduced in 1990

slide-16
SLIDE 16

16

The Race for Speed

Alstom built AGV high speed train. Maximum speed 360 km/h Introduced in service 2011

slide-17
SLIDE 17

17

The Race for Speed

Bombardier Zefiro 360 high speed train platform used in China as the CRH1E Maximum speed 360 km/h Introduced in service 2012

slide-18
SLIDE 18
slide-19
SLIDE 19

The Race for Speed

slide-20
SLIDE 20

20

  • Class 1: RST having max speed of at least 250 km/h
  • Class 2: RST having a max speed of at least 190 km/h
  • But less than 250 km/h
  • Technical standard exists for 190 to 350 km/h
  • Over 351 km/h technical requirements down to supplier
  • Authorisation only for trains up to 350 km/h
  • Articulated v/s Non-articulated

Definition of High Speed RST

slide-21
SLIDE 21

21

  • Long headway
  • High distance between stations
  • Braking distance
  • Seats for all occupants
  • Train management systems
  • Interface with infrastructure tunnels etal
  • Track layout

High Speed Operation

slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24

HS2 Route Phase 1

slide-25
SLIDE 25

HS2 Route Phase 2

slide-26
SLIDE 26

HS2 Technology

  • 1. Utilising existing proven technology

2.Capacity 18 trains per hour 3.Design speed of 250 mph (400 km/h) 4.Limited hours of operation 5.Dynamic gauge 6.Specify classic compatible trains

slide-27
SLIDE 27

HS2 Technology

  • 7. Reliability
  • 8. Impact on other rail services
  • 9. Freight on HS2

10.Interconnectivity

  • 11. Operational safety
slide-28
SLIDE 28

Utilising existing proven technology

  • 1. Technical Specification
  • 2. Internationally accepted practice
  • 3. Established European standards
  • 4. Unproven technology
slide-29
SLIDE 29

Line capacity

slide-30
SLIDE 30

Design speed

  • 1. Designed to accommodate future speeds

2.Up to 250mph (400 km/h) 3.Phase 1 operation up to 225 mph ( 360 km/h)

slide-31
SLIDE 31

Limited hours of operation

  • 1. 05:00 to 23:59 hours Monday to Saturday

2.08:00 to 23:59 hours on Sunday 3.No trains during the night?

slide-32
SLIDE 32

Dynamic gauge

  • 1. New track GC gauge

2.Upgrade the existing network 3.Single and Double deck trains 4.Utilise existing European proven RST 5.In line with HS1 6.CrossRail?

slide-33
SLIDE 33

Classic compatible trains

  • 1. Move passenger traffic from the existing routes

2.Free up urban capacity on existing routes 3.Move some existing intercity trains to HS2 4.Slow down HS2? 5.No freight 6.High speed freight

slide-34
SLIDE 34

Reliability

  • 1. Segregated HS networks more reliable

2.Example Japan 3.Services moved from existing routes less reliable 4.Import poor reliability 5.Confine route transfer to outside core times

slide-35
SLIDE 35

Impact on other rail services

  • 1. Diversion of long distance services

2.Free up capacity on WCML 3.Improve commuter traffic 4.London to Birmingham 5.Better links with other services 6.Increase freight capacity

slide-36
SLIDE 36

Freight on HS2

  • 1. In principle no freight

2.Problem where HS2 will use existing upgraded routes 3.Address the issue left by Beeching 4.Re-establish multi-tracking

slide-37
SLIDE 37

37

High Speed Freight

slide-38
SLIDE 38

38

The rationale behind High Speed Freight

slide-39
SLIDE 39

Interconnectivity

  • 1. Careful planning of interchanges

2.East Midlands Interchange 3.Crewe 4.Birmingham

slide-40
SLIDE 40

Operational safety

  • 1. Dedicated two track HS passenger route

2.Continuous train movement monitoring 3.Continuous Train to Controller communication 4.Continuous infrastructure monitoring 5.Security fencing 6.Design bridges to prevent vehicular incursion 7.Regular inspection of RST and track

slide-41
SLIDE 41
slide-42
SLIDE 42

HS2 RST Reference train Alstom AGV

slide-43
SLIDE 43

HS2 RST

  • 1. High Speed dedicated single deck train set

2.High Speed dedicated double deck train set 3.High Speed to conventional interoperable train set

slide-44
SLIDE 44

Bombardier Zefiro

slide-45
SLIDE 45

CRRC CRH

slide-46
SLIDE 46

CRRC CRH Hitachi ETR

slide-47
SLIDE 47
slide-48
SLIDE 48

HS2 Ltd has named its chosen contractors for the construction of the London to Birmingham high speed rail line. Among the winners are the CEK joint venture of Carillion, Eiffage, Kier, which has been awarded two lots that are together worth a keenly bid £1.4bn, and Balfour Beatty Vinci JV which has also won two lots, together worth £2.5bn The other big winner is SCS JV (Skanska Construction UK, Costain, Strabag), which has won two lots of tunnelling under London. Half of the contactors involved in the project are foreign owned.

slide-49
SLIDE 49
slide-50
SLIDE 50

Professor John Roberts Director Asian Region NewRail NCL Chairman KURail Kasetsart University e-Mail: fengjor@ku.ac.th UK Mobile: +44 (0) 7963 159 233 Thai Mobile: +66 (0) 854 081 682

Questions

slide-51
SLIDE 51
slide-52
SLIDE 52

Discussion points

  • 1. Is a ground up HS railway on a new site the right thing?
  • 2. Is there a viable option of upgrading the existing route?
  • 3. Should freight be given access?
  • 4. Is a dedicated HS railway necessary in either Brazil or UK?
  • 5. Is it ethical to plan for a VHS train with no technical standards?
