k -core decomposition Applications How the k -core decomposition helps in understanding the Internet Topology J. Ignacio Alvarez-Hamelin Luca DallAsta Alain Barrat Alessandro Vespignani Laboratoire de Physique

slide-1
SLIDE 1

k-core decomposition Applications

How the k-core decomposition helps in understanding the Internet Topology

  • J. Ignacio Alvarez-Hamelin∗‡

Luca Dall’Asta∗ Alain Barrat∗ Alessandro Vespignani†∗

∗Laboratoire de Physique Théorique, Université Paris-Sud XI †School of Informatics and Department of Physics, Indiana University ‡CONICET and Departamento de Electrónica, Universidad de Buenos Aires

Worshop on Internet Topology :: San Diego :: May 10-12

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-2
SLIDE 2

k-core decomposition Applications

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-3
SLIDE 3

k-core decomposition Applications Definition Examples Applicability of k-cores

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-4
SLIDE 4

k-core decomposition Applications Definition Examples Applicability of k-cores

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-5
SLIDE 5

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Definition

Given G = {V, E} a undirected graph, where V is the vertices set and E is the edges set. Definition (Seidman, 1983 [4]) : A subgraph H = (C, E|C) induced by the set C ⊆ V is a k-core

  • r a core of order k iff ∀v ∈ C : degreeH(v) ≥ k, and H is the

maximum subgraph with this property. Then, a minimal degree k is imposed to the core of order k.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-6
SLIDE 6

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Definition

Given G = {V, E} a undirected graph, where V is the vertices set and E is the edges set. Definition (Seidman, 1983 [4]) : A subgraph H = (C, E|C) induced by the set C ⊆ V is a k-core

  • r a core of order k iff ∀v ∈ C : degreeH(v) ≥ k, and H is the

maximum subgraph with this property. Then, a minimal degree k is imposed to the core of order k.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-7
SLIDE 7

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Definition

Given G = {V, E} a undirected graph, where V is the vertices set and E is the edges set. Definition (Seidman, 1983 [4]) : A subgraph H = (C, E|C) induced by the set C ⊆ V is a k-core

  • r a core of order k iff ∀v ∈ C : degreeH(v) ≥ k, and H is the

maximum subgraph with this property. Then, a minimal degree k is imposed to the core of order k.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-8
SLIDE 8

k-core decomposition Applications Definition Examples Applicability of k-cores

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-9
SLIDE 9

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : 1-core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-10
SLIDE 10

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : 2-core ?

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-11
SLIDE 11

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : ✘✘✘

✘ ❳❳❳ ❳

2-core ?

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-12
SLIDE 12

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : 1-core cycle : 2-core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-13
SLIDE 13

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : 1-core cycle : 2-core clique n : (n − 1)-core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-14
SLIDE 14

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

tree : 1-core cycle : 2-core clique n : (n − 1)-core

Remark : a k-connected graph is a k-core.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-15
SLIDE 15

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

A graph :

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-16
SLIDE 16

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

A graph :

3−core 2−core 1−core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-17
SLIDE 17

k-core decomposition Applications Definition Examples Applicability of k-cores

k-core decomposition

Examples

A graph :

3−core 2−core 1−core

Definition A vertex i has a shell index c, if it belongs to the c-core but not to (c + 1)-core.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-18
SLIDE 18

k-core decomposition Applications Definition Examples Applicability of k-cores

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-19
SLIDE 19

k-core decomposition Applications Definition Examples Applicability of k-cores

Why the connectivity is interesting ?

k-core decomposition

The connectivity is mainly related to : robustness

faults, attacks

routing (to find a path between two vertices)

QoS, efficiency (of several parameters).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-20
SLIDE 20

k-core decomposition Applications Definition Examples Applicability of k-cores

Why the connectivity is interesting ?

k-core decomposition

The connectivity is mainly related to : robustness

faults, attacks

routing (to find a path between two vertices)

QoS, efficiency (of several parameters).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-21
SLIDE 21

k-core decomposition Applications Definition Examples Applicability of k-cores

Why the connectivity is interesting ?

k-core decomposition

The connectivity is mainly related to : robustness

faults, attacks

routing (to find a path between two vertices)

QoS, efficiency (of several parameters).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-22
SLIDE 22

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-23
SLIDE 23

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-24
SLIDE 24

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core k-core ⇒ k-connectivity ?

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-25
SLIDE 25

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core

✭✭✭✭✭✭✭✭✭✭✭✭✭✭✭✭ ✭ ❤❤❤❤❤❤❤❤❤❤❤❤❤❤❤❤ ❤

k-core ⇒ k-connectivity ?

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-26
SLIDE 26

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core Some results on k-core and k-connectivity :

Bollobas [1] : a random graph with large < d > has a minimum degree k when n → ∞, and it is k-connected. Dimes project : study [2] the number of distinct paths as function of k-shell. k-edge-connectivity : we show a theorem (kmax-core has diameter 2, and sets of vertices in s-shell are connected with at least s edges to higher cores).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-27
SLIDE 27

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core Some results on k-core and k-connectivity :

Bollobas [1] : a random graph with large < d > has a minimum degree k when n → ∞, and it is k-connected. Dimes project : study [2] the number of distinct paths as function of k-shell. k-edge-connectivity : we show a theorem (kmax-core has diameter 2, and sets of vertices in s-shell are connected with at least s edges to higher cores).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-28
SLIDE 28

k-core decomposition Applications Definition Examples Applicability of k-cores

relation between connectivity and k-cores ?

k-core decomposition

k-connectivity ⇒ k-core Some results on k-core and k-connectivity :

Bollobas [1] : a random graph with large < d > has a minimum degree k when n → ∞, and it is k-connected. Dimes project : study [2] the number of distinct paths as function of k-shell. k-edge-connectivity : we show a theorem (kmax-core has diameter 2, and sets of vertices in s-shell are connected with at least s edges to higher cores).

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-29
SLIDE 29

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-30
SLIDE 30

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-31
SLIDE 31

k-core decomposition Applications Properties analysis Temporal analysis Visualization

k-shell size vs k

1 10 100

k

10 10

1

10

2

10

3

10

4

|k-shell|

RV 04/2005 CAIDA 04/2005 DIMES 05/2005 INET-3.0

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-32
SLIDE 32

k-core decomposition Applications Properties analysis Temporal analysis Visualization

cumulative degree distribution

10

  • 3

10

  • 2

10

  • 1

10

P> (d)

1-core 4-core 7-core 10-core 14-core 1-core 4-core 7-core 10-core 14-core

10 10

1

10

2

d/<d>

10

  • 4

10

  • 3

10

  • 2

10

  • 1

P> (d)

1-core 5-core 10-core 15-core 20-core

10 10

1

10

2

10

3

d/<d>

1-core 2-core 3-core 4-core 5-core

RV 2005/04 CAIDA 2005/04 DIMES 2005/05 INET 3.0

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-33
SLIDE 33

k-core decomposition Applications Properties analysis Temporal analysis Visualization

cumulative degree distribution

10

  • 3

10

  • 2

10

  • 1

10

P> (d)

1-core 4-core 7-core 10-core 14-core 1-core 4-core 7-core 10-core 14-core

10 10

1

10

2

d/<d>

10

  • 4

10

  • 3

10

  • 2

10

  • 1

P> (d)

1-core 5-core 10-core 15-core 20-core

10 10

1

10

2

10

3

d/<d>

1-core 2-core 3-core 4-core 5-core

RV 2005/04 CAIDA 2005/04 DIMES 2005/05 INET 3.0

  • Self-similarity of the k-cores

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-34
SLIDE 34

k-core decomposition Applications Properties analysis Temporal analysis Visualization

average neighbor degree vs degree

10

  • 1

10

dnn (d)/<dnn>

1-core 4-core 7-core 10-core 14-core 1-core 4-core 7-core 10-core 14-core

10 10

1

10

2

d/<d>

10

  • 1

10

dnn (d)/<dnn>

1-core 5-core 10-core 15-core 20-core

10 10

1

10

2

10

3

d/<d>

1-core 2-core 3-core 4-core 5-core

RV 2005/04 CAIDA 2005/04 DIMES 2005/05 INET 3.0

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-35
SLIDE 35

k-core decomposition Applications Properties analysis Temporal analysis Visualization

cluster coefficient vs degree

10

  • 2

10

  • 1

10

cc (d)/<cc>

1-core 4-core 7-core 10-core 14-core 1-core 4-core 7-core 10-core 14-core

10 10

1

10

2

d/<d>

10

  • 2

10

  • 1

10

cc (d)/<cc>

1-core 5-core 10-core 15-core 20-core

10 10

1

10

2

10

3

d/<d>

1-core 2-core 3-core 4-core 5-core

RV 2005/04 CAIDA 2005/04 DIMES 2005/05 INET 3.0

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-36
SLIDE 36

k-core decomposition Applications Properties analysis Temporal analysis Visualization

average betweenness vs shell index

1 10 10

3

10

4

10

5

10

6

10

7

10

8

<g>

1 10 10

2

10

3

10

4

10

5

10

6

10

7

10 10

1

10

2

shell index

10

3

10

4

10

5

10

6

10

7

<g>

1 10

shell index

10

3

10

4

10

5

10

6

RV DIMES INET3.0 CAIDA

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-37
SLIDE 37

k-core decomposition Applications Properties analysis Temporal analysis Visualization

average betweenness vs shell index

1 10 10

3

10

4

10

5

10

6

10

7

10

8

<g>

1 10 10

2

10

3

10

4

10

5

10

6

10

7

10 10

1

10

2

shell index

10

3

10

4

10

5

10

6

10

7

<g>

1 10

shell index

10

3

10

4

10

5

10

6

RV DIMES INET3.0 CAIDA

betweenness : O(n2 log n) k-core : O(e)

k-core decomposition establish a hierarchy in the network :

  • it can identify the vertex’s centrality.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-38
SLIDE 38

k-core decomposition Applications Properties analysis Temporal analysis Visualization

average betweenness vs shell index

1 10 10

3

10

4

10

5

10

6

10

7

10

8

<g>

1 10 10

2

10

3

10

4

10

5

10

6

10

7

10 10

1

10

2

shell index

10

3

10

4

10

5

10

6

10

7

<g>

1 10

shell index

10

3

10

4

10

5

10

6

RV DIMES INET3.0 CAIDA

betweenness : O(n2 log n) k-core : O(e)

k-core decomposition establish a hierarchy in the network :

  • it can identify the vertex’s centrality.

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-39
SLIDE 39

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-40
SLIDE 40

k-core decomposition Applications Properties analysis Temporal analysis Visualization

AS Oregon R. V. : april -> may 2005

1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

04/2005 -> 05/2005

05/2005 04/2005

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-41
SLIDE 41

k-core decomposition Applications Properties analysis Temporal analysis Visualization

AS maps of Oregon R. V.

1e-05 1e-04 0.001 0.01 0.1 1 2 4 6 8 10 12 14 16 18 5 10 15 20

2001 -> 2002

2002 2001 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 5 10 15 20

2002 -> 2003

2003 2002 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 5 10 15 20 25

2003 -> 2004

2004 2003 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

2004 -> 2005

2005 2004

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-42
SLIDE 42

k-core decomposition Applications Properties analysis Temporal analysis Visualization

AS maps of CAIDA

1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25 30

2001 -> 2002

2002 2001 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 30 5 10 15 20 25

2002 -> 2003

2003 2002 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

2003 -> 2004

2004 2003 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

2004 -> 2005

2005 2004

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-43
SLIDE 43

k-core decomposition Applications Properties analysis Temporal analysis Visualization

AS maps : 2004->2005

1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

2004 -> 2005

2005 2004 1e-05 1e-04 0.001 0.01 0.1 1 5 10 15 20 25 5 10 15 20 25

2004 -> 2005

2005 2004

Oregon_RV CAIDA

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-44
SLIDE 44

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Outline

1

k-core decomposition Definition Examples Applicability of k-cores

2

Applications Properties analysis Temporal analysis Visualization

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-45
SLIDE 45

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Network fingerprints

CAIDA AS map

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-46
SLIDE 46

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Network fingerprints

CAIDA AS map a portion of www.***.fr

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-47
SLIDE 47

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Network fingerprints

CAIDA AS map CAIDA Router level map

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-48
SLIDE 48

k-core decomposition Applications Properties analysis Temporal analysis Visualization

Network fingerprints

CAIDA AS map Dimes AS map

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-49
SLIDE 49

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-50
SLIDE 50

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-51
SLIDE 51

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-52
SLIDE 52

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-53
SLIDE 53

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-54
SLIDE 54

k-core decomposition Applications

Summary

Using k-core decomposition, we can determine :

a hierarchical and self-similar structure centrality connectivity

Comparative analysis of different maps Fingerprints (Visualization) http ://xavier.informatics.indiana.edu/lanet-vi/ http ://arxiv.org/abs/cs.NI/0504107/

(Large scale networks fingerprinting and visualization using the k-core decomposition, Advances in Neural Information Processing Systems 18, 2006),

and http ://arxiv.org/abs/cs.NI/0511007/

J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-55
SLIDE 55

k-core decomposition Applications

  • B. Bollobasr.

Graph Theory and Combinatorics, conference in honor of Paul Erdos, Academic Press, 35–57, 1983. Shai Carmi, Shlomo Havlin1, Scott Kirkpatrick, Yuval Shavitt and Eran Shir. MEDUSA – New Model of Internet Topology Using k-shell Decomposition arXiv, cond-mat/0601240, January 2006.

  • V. Batagelj and M. Zaversnik.

Generalized Cores. CoRR, cs.DS/0202039, 2002.

  • S. B. Seidman.

Network structure and minimum degree. Social Networks 5, 269–287, 1983. LArge NETwork VIsualization tool. http ://xavier.informatics.indiana.edu/lanet-vi/. Router-Level Topology Measurements" "Cooperative Association for Internet Data Analysis. http ://www.caida.org/tools/measurement/skitter/ router_topology/. University of Oregon Route Views Project. http ://www.routeviews.org/. "Distributed Internet MEasurements and Simulations". http ://www.netdimes.org. Jared Winick and Sugih Jamin. Inet-3.0 : Internet topology generator. Technical Report UM-CSE-TR-456-02, Department of EECS, University of Michigan, 2002. J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-56
SLIDE 56

k-core decomposition Applications

  • J. I. Alvarez-Hamelin, L. Dall’Asta, A. Barrat, and A. Vespignani.

k-core decomposition : a tool for the visualization of large scale networks. arxiv.org, cs.NI/0504107, 2005.

  • M. A. Serrano, M. Boguña and A. Díaz-Guilera.

Competition and Adaptation in an Internet Evolution Model.

  • Phys. Rev. Letters, 94 :038701, 2005.
  • J. I. Alvarez-Hamelin and N. Schabanel.

An Internet Graph Model Based on Trade-Off Optimization.

  • Eur. Phys. J. B, special issue on “Applications of networks”, 38(2) :231–237, march II 2004.

P . Erdös and A. Rényi. On random graphs I.

  • Publ. Math. (Debrecen), 6 :290–297, 1959.
  • A. Fabrikant, E. Koutsoupias, and C. H. Papadimitriou.

Heuristically Optimized Trade-Offs : A New Paradigm for Power Laws in the Internet. LNCS, 2380 :110–, Jun 2002. J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...

slide-57
SLIDE 57

k-core decomposition Applications

k-edge-connectivity

kmax-core is k-edge-connected (or diameter 2) cluster in s-shell is s-edge-connected and it has at least s edges towards (s + 1)-core. then, the graph is k-edge-connected

−1)−shell

k

(

−core

max

k

k

(

k

( −2)−shell −3)−shell J.I.Alvarez-Hamelin :: ISMA 2006 WIT :: CAIDA :: May 10–12 How the k-core decomposition helps in understanding ...
