How am I going to skim through these data …?

1

Trends

• Computers keep getting faster
• But data grows faster yet!

– Remember? BIG DATA!

• Queries are becoming more complex

– Remember? ANALYTICS!

2

Analytic Queries

• Analytic queries typically involve aggregates
• Simple query – report the total

sales of each region

SELECT SUM(S.sales) FROM SALES S GROUP BY region

• A query involving multiple aggregates

─ find the average supplier‐quantity supplied by suppliers of a particular part

SELECT AVG(quantity) FROM (SELECT supp, part, SUM(quantity) as quantity FROM lineitem WHERE part = 10 GROUP BY supp, part);

3

• A CUBE operator in OLAP – allows

users to drill down or roll up between multiple nodes of the data cube operation

SELECT SUM(S.sales) FROM SALES S GROUP BY CUBE(pid, locid, timeid)

{pid, locid, timeid} {pid, locid} {pid, timeid} {locid, timeid} {pid} {locid} {timeid} { }

4

System perspective

• Aggregation queries

– read a large amount of data – a long time to compute – return a very small final result

• answers are or derived from summary data

4

User perspective

5

Time System 1 System 2 System 3 1.0000 3.01325 4.32445 7.5654 2.0000 4.54673 6.56784 8.6562 3.0000 5.46571 6.87658 10.3343

VS

• “Big Picture” analytics

– Decision makers want to know something about some data quickly – Precise answers typically not required; approximate results are ok – Real‐time interaction and control over processing – Visually oriented interface

Challenge

6

Mismatch between user needs and system functionality

Drawbacks of Current Systems

• Only exact answers are available

– A losing proposition as data volume grows – Hardware improvements not sufficient

• HCI solution: interactive tools don’t do big jobs

– E.g., spreadsheet programs (1 M row, 16k column limit)

• Systems solution: big jobs aren’t interactive

– No user feedback or control in big DBMS queries (“back to the 60’s”) – Long processing time – Fundamental mismatch with preferred modes of HCI

• Best solutions to date

– precompute (store answers of queries beforehand), e.g. OLAP – Don’t handle ad hoc queries or data sets well

7

Time



100%

Online Traditional

Desirable features for Big Picture Analytics

• Early (approximate) answers with guarantees!
• Refinement over time
• Interaction and ad‐hoc control (human in the

loop)

8

Did you see any problem with “Online”?

Example (Conventional)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

9

After Conventional database 1 second 30 seconds 5 minutes

Example (Conventional)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

10

After Conventional database Avg Stock Price = 1000 30 minutes

Example (Online)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

11

After 1 second With online aggregation

5% Avg Stock Price $2031+/‐$523 90% Sampling Progress

Example (Online)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

12

After 30 seconds With online aggregation

15% Avg Stock Price $1890+/‐$420 95% Sampling Progress

Example (Online)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

13

After 5 minutes With online aggregation

40% Avg Stock Price $1150+/‐$210 97% Sampling Progress

Example (online)

• Find the average stock price from the nasdaq‐

db where company = ‘abc’

14

After 30 minutes With online aggregation

95% Avg Stock Price $1040+/‐$70 99% Sampling Progress

Example: Online Aggregation

Additional Features:

Speed up Slow down Terminate

15

Example: Online visualization

16

Example: Browsing

17

Key benefit: “Premature” termination

• If acceptably

accurate answer reached quickly, the query can be aborted

18

After 5 minutes Conventional database With online aggregation

40% Avg Stock Price $1150+/‐$210 97% Sampling Progress

Stop early

Why Stop Early??

• Save human time (30 min vs 5 min)

– Precise vs estimate answers

• For exploratory applications
• Save machine time

– Save cost $$

• Very important when dealing with BIG DATA in

the cloud

– Pay for what you used (users need to justify the cost to the organization)

19

Analytic queries are costly!

QphH = Query‐per‐Hour Performance

20 20

21

Solution: Online aggregation

• Users must get continual feedback on results
• f processing

– Observe the progress of their queries – Give continually improving partial results: aggregates have running output and confidence interval

• Control execution on‐the‐fly

15% 20% 35% 40% Average Sales: $22,131+/‐$523 85% $21,255+/‐$286 90% $21,795+/‐$105 95% $21,712+/‐$47 98% Sampling Progress For a retailer, approximate result, such as $21,712+/‐$47, can provide a good estimation for its daily sale’s statistics. And it is more cost effective.

21

22

Statistical estimation

• Users do not need to set a priori specification
• f stopping condition
• The interface is easier for users with no

statistical background

• It requires more powerful statistical

estimation techniques (Hoeffding’s inequality versus Chebyshev’s inequality)

22

23

Usability goals

• Continuous observation
• Control of time/precision
• Control of fairness/partiality

23

24

Performance goals

• Minimum time to accuracy

– produce a useful estimate of the final answer ASAP

• Minimum time to completion

– secondary goal, assume user will terminate processing long before the final answer is produced

• Pacing

– guarantee a smooth and continuous improving display

24

What are the tools??

25

26

Random access to data

• We need to retrieve data in random order to

produce meaningful statistical estimation

• At any time, the input to the query is a sample
• Input grows over time until
• the query is terminated prematurely or
• all data examined

26

Sampling – design issues

• Granularity of sample

– Record‐level: high I/O cost – Block‐level: high variability from clustering

• Types of sample

– Often simple random sample (SRS) – With/without replacement??

• Data structures from which to sample

– Files or relational tables – Indexes (B+ trees, etc)

27

Row‐level sampling techniques

• Maintain file in (pseudo) random order

– Sampling = scan – Is file initially in random order?

• Statistical tests needed: e.g., Runs test, Kolmogorov‐Smirnov test

– Can start scans from random positions

• Best I/O behavior

– Must “freshen” ordering (online reorg)

• On‐the‐fly sampling

– Index scan via index on “random” column

• Indexed attributes are different from (and not correlated to)

aggregated attributes, e.g., name is not correlated to salary

– Else get random page, then row within page

• Less efficient
• Problem: variable number of records on page

28

Sampling from Index

29

2* 3*

Root

17 30 14* 16* 33* 34* 38* 39* 13 5 7* 5* 8* 22* 24* 27 27* 29*

How expensive is row‐level sampling?

30

20 40 60 80 100 . 2 . 4 . 6 . 8 1 1 . 2 1 . 4 1 . 6 1 . 8 2 Sampling Rat e (% ) Pages fet ched (% )

Group By operation

• Aggregate queries involve “grouping”, e.g.,

count of grades of students, average sales per month, etc

• How are “group‐by” queries processed?

– Sort on “group‐by” attributes, e.g., sort by grades, then count – Hash on “group‐by” attributes

• Same attribute values will be hashed to the same

bucket, e.g., students with the same grade will be grouped together

31

32

Non‐blocking GROUP BY and DISTINCT

• Blocking operator

– Cannot work on another operator while the current

• perator is being processed
• Sorting is a blocking algorithm

– only one group is computed at a time after sorting

• Hashing is non‐blocking, but …

– hash table need to fit in memory to have good performance

32

33

Index striding

• For fair Group By:

– Want to update all groups

• Challenging for groups with small number of

records

– Want random tuple from Group 1, random tuple from Group 2, ... – Idea

• Index gives tuples from a single group
• Opens many cursors in index, one per group
• Fetch records in round‐robin
• Can control speed by weighting the schedule

– Gives fairness/partiality, info/speed match!

33

Conclusion

• Big data analytics is becoming increasingly

important

• Online aggregation (OLA) is a promising

direction

• OLA mechanisms

– Random sampling – Non‐blocking schemes – Index striding

• Online Hadoop is a variant of Hadoop that
• ffers a flavor of “online aggregation”

34
