1 Northwest Shelf Horizontal San Andres Play Russell K. Hall 2 Russell K. Hall Graduated by University of Oklahoma, BS Mechanical Engineering, 1978 Worked for 3 E&P Companies (Amoco Production, Cleary Petroleum, Southwest

slide-1
SLIDE 1

1

Russell K. Hall

Northwest Shelf Horizontal San Andres Play

slide-2
SLIDE 2

2

Russell K. Hall

  • Graduated by University of Oklahoma, BS

Mechanical Engineering, 1978

  • Worked for 3 E&P Companies (Amoco Production,

Cleary Petroleum, Southwest Royalties) for 4 years

  • Worked in Energy Lending (Bank of America) for 14

years

  • Founded Consulting Engineer Firm in 1996
slide-3
SLIDE 3

3

HUMILITY

  • Reservoirs are Complex
  • Compartmentalization !
  • Additional Data Does Not Simplify Analysis
  • Interpretations Will Always Change
  • Estimates are ESTIMATES
  • “Ball Park” Perspective
slide-4
SLIDE 4

4

Permian Basin

MIDLAND

slide-5
SLIDE 5

5

San Andres Development in Northwest Shelf

  • 1936 – Duggan no. 1 – 396 bopd
  • 1937 – Slaughter no. 1 – 512 bopd
  • 1950’s & 1960’s – Waterflood Development –

Cumulative Production 560 Million Barrels

  • Cumulative Today – 4 Billion Barrels +
  • 2013 – Horizontal San Andres Play
  • Today HZ SA Play ≈ 65 wells, 9,000 bopd
slide-6
SLIDE 6

6

Northwest Shelf Horizontal San Andres Play

  • Geologic Setting
  • Well Performance
  • Reservoir Interpretation
  • Future Development
slide-7
SLIDE 7

7

Geologic Setting

slide-8
SLIDE 8

8

Carbonate Platform Environment

Northwest Shelf Midland Basin

Dolomite (CaMg(CO3)2), Anhydrite (CaSO4)

slide-9
SLIDE 9

9

After Ramondetta

Basin Restricted Marine

slide-10
SLIDE 10

10

Transgressive / Regressive Cycles Result in Multiple SA Intervals

slide-11
SLIDE 11

11

5,227 5,396 5,366 5,318

slide-12
SLIDE 12

12

slide-13
SLIDE 13

13

slide-14
SLIDE 14

14

Well Performance

slide-15
SLIDE 15

15

Typical Well Performance

slide-16
SLIDE 16

16

Typical Well Performance

Depressurizing Near Wellbore

slide-17
SLIDE 17

17

Typical Well Performance

Increasing Oil Cut

slide-18
SLIDE 18

18

Typical Well Performance

Stabilized Oil Cut

slide-19
SLIDE 19

19 100 1000 10000 1 10 100 1000 BARRELS OF FLUID PER DAY CUM DAYS

PUMP PROBLEMS? LINEAR FLOW

  • 1/2 SLOPE
slide-20
SLIDE 20

20

Typical Well Performance

Flow Will Eventually Change to Boundary Dominated Flow

slide-21
SLIDE 21

21

Typical Well Performance

Hyperbolic “n” Factor May Decrease

slide-22
SLIDE 22

22 0.0% 5.0% 10.0% 15.0% 20.0% 25.0% 30.0% 35.0% 40.0% 45.0% 50.0% 100,000 200,000 300,000 400,000 500,000 600,000 700,000 800,000 CUM FLUID (BBLS)

SNOW STORM SI 39 DAYS MESSING WITH PUMP

Initially Well Produces Only Water

slide-23
SLIDE 23

23 0.0% 5.0% 10.0% 15.0% 20.0% 25.0% 30.0% 35.0% 40.0% 45.0% 50.0% 100,000 200,000 300,000 400,000 500,000 600,000 700,000 800,000 CUM FLUID (BBLS)

SNOW STORM SI 39 DAYS MESSING WITH PUMP

Depressurize Reservoir Oil Flows – Cut Increases

slide-24
SLIDE 24

24 0.0% 5.0% 10.0% 15.0% 20.0% 25.0% 30.0% 35.0% 40.0% 45.0% 50.0% 100,000 200,000 300,000 400,000 500,000 600,000 700,000 800,000 CUM FLUID (BBLS)

SNOW STORM SI 39 DAYS MESSING WITH PUMP

SNOW STORM

slide-25
SLIDE 25

25 0.0% 5.0% 10.0% 15.0% 20.0% 25.0% 30.0% 35.0% 40.0% 45.0% 50.0% 100,000 200,000 300,000 400,000 500,000 600,000 700,000 800,000 CUM FLUID (BBLS)

SNOW STORM SI 39 DAYS MESSING WITH PUMP

SI FOR 39 DAYS

slide-26
SLIDE 26

26

Well Performance Hypothesis

  • Reservoir Requires Depressurizing to Produce

Oil

  • Near Wellbore Pressure Falls to Bubble Point

Pressure

  • Expanding Gas Alters Oil Properties (Three

Phase Relative Permeability), Oil Flows

  • Shut-In Allows Reservoir Pressure to Stabilize
  • Repeat Depressurizing After Shut-In
slide-27
SLIDE 27

27

Oil Cut Performance

2 4 6 8 10 12 14 16 18 20 0% 5% 10% 15% 20% 25% 30% 35% 40% 50,000 100,000 150,000 200,000 250,000

WELL COUNT OIL CUT (PERCENT) CUM TOTAL FLUID (BBL)

P1 COMPLETIONS P2 HIGH COMPLETIONS P1 WELL COUNT P2 HIGH WELL COUNT

Chambliss Interval

slide-28
SLIDE 28

28

2 4 6 8 10 12 14 16 18 20 0% 5% 10% 15% 20% 25% 30% 35% 40% 50,000 100,000 150,000 200,000 250,000

WELL COUNT OIL CUT (PERCENT) CUM TOTAL FLUID (BBL)

P1 COMPLETIONS P2 HIGH COMPLETIONS P1 WELL COUNT P2 HIGH WELL COUNT

Oil Cut Performance

Brahaney Interval

slide-29
SLIDE 29

29

2 4 6 8 10 12 14 16 18 20 0% 5% 10% 15% 20% 25% 30% 35% 40% 50,000 100,000 150,000 200,000 250,000

WELL COUNT OIL CUT (PERCENT) CUM TOTAL FLUID (BBL)

P1 COMPLETIONS P2 HIGH COMPLETIONS P1 WELL COUNT P2 HIGH WELL COUNT

Oil Cut Performance

slide-30
SLIDE 30

30

Oil Cut Performance

  • Plots of Oil Cut vs Cumulative Fluid
  • Normalized to Time Zero
  • Compare Chambliss (Upper) to Brahaney

(Lower)

  • Chambliss and Brahaney Exhibit Similar Oil

Cut Performance

slide-31
SLIDE 31

31

P2 P5 P10 P20 P30 P40 P50 P60 P70 P80 P90 P95 P98

  • 2

10 20 30 40

OIL CUT (PERCENT)

Input data samples LMS FIT (Normal Distribution)

Oil Cut Exhibits Normal (Gaussian) Distribution

HZ San Andres Performance

slide-32
SLIDE 32

32

36,854 64,374 112,444 27,372 46,475 78,910 P2 P5 P10 P20 P30 P40 P50 P60 P70 P80 P90 P95 P98

  • 2

1,000 10,000 100,000 1,000,000

Oil EUR (barrels)

SHORT LATERAL LONG LATERAL

SHORT LATERALS SWANSON'S MEAN 70,500 BBL / 1000 FT LONG LATERALS SWANSON'S MEAN 50,500 BBL / 1000 FT

Oil EUR Analysis

slide-33
SLIDE 33

33 0% 10% 20% 30% 40% 50% 60% 70% <10% OIL CUT 10% TO 20% OIL CUT > 20% OIL CUT

15.2% 27.3% 57.6% 5.6% 66.7% 27.8% PEAK OIL CUT

SHORT LATERAL WELLS LONG LATERAL WELLS

Oil EUR Analysis

slide-34
SLIDE 34

34

Reservoir Interpretation

slide-35
SLIDE 35

35

Genesis of Northwest Shelf ROZ

Original Depositional Conditions Change in Hydrodynamic Conditions

After Trentham, Melzer

Rainfall Causes Lateral Water Movement

Laramide Orogeny

slide-36
SLIDE 36

36

ROZ Fairways

Lateral Water Movement

After RPSEA

slide-37
SLIDE 37

37

ROZ Evidence

  • Microbes change water-wet system to oil-wet

system

  • H2S Produced by Microbes
  • Water Saturation
  • Additional Dolomitization
  • Tilting Oil / Water Contact
  • Log Presentation
slide-38
SLIDE 38

38

Shifting of Relative Permeability

Oil Perm > Water Perm

slide-39
SLIDE 39

39

Shifting of Relative Permeability

Water Perm > Oil Perm

slide-40
SLIDE 40

40

Below Bubble Point Gas Saturation Increases

Relative Perm

  • f Non-Wetting

Phase Shifts

slide-41
SLIDE 41

41

Oil / Water Contact Tilt

slide-42
SLIDE 42

42

Horizontal San Andres Play

  • Conclusion 1 – Chambliss and Brahaney

Intervals Are In Communication

  • Conclusion 2 – Productive Pays are Partially

Swept Residual Oil Zones (ROZ)

  • Conclusion 3 – Larger Fracs Improve

Performance In Certain Areas

slide-43
SLIDE 43

43

Stimulation Analysis

Fair Correlation to Frac Volume

slide-44
SLIDE 44

44

Horizontal San Andres Play

  • Conclusion 1 – Chambliss and Brahaney

Intervals Are In Communication

  • Conclusion 2 – Productive Pays are Partially

Swept Residual Oil Zones (ROZ)

  • Conclusion 3 – Larger Fracs Improve

Performance in Certain Areas

  • Conclusion 4 – Performance Controlled by

Rock Fabric and Fluid Saturations

slide-45
SLIDE 45

45

Future Development

slide-46
SLIDE 46

46

Economic Parameters

  • CAPEX Increases With Oil Price

$ 200,000 For Every $ 10 Per bbl

  • LOE -

$ 10,000 per Month, $ 2.00 per bbl Oil, $ 0.20 per bbl Water

  • 100% WI, 75% NRI
  • Oil Deduct $ 1.35 Below Posted
slide-47
SLIDE 47

47

Economics Look Good

50 100 150 200 250 20 30 40 50 60 70 80 90 RATE-OF RETURN (PERCENT) OIL PRICE ($ PER BBL) 10 PERCENT OIL CUT 15 PERCENT OIL CUT 20 PERCENT OIL CUT

slide-48
SLIDE 48

48

Economics Look Good

0.00 1.00 2.00 3.00 4.00 5.00 6.00 20 30 40 50 60 70 80 90 PAYOUT (YRS) OIL PRICE ($ PER BBL) 10 PERCENT OIL CUT 15 PERCENT OIL CUT 20 PERCENT OIL CUT

slide-49
SLIDE 49

49

Future Development

  • Expect Continued Drilling
  • Operators May Slow Development Until Oil

Price Improves

  • Regional Geologic Setting Favors Expansive

Development

  • More Well Control Needed To Define

Boundaries

slide-50
SLIDE 50

50

Thank You

Russell K. Hall, P.E. Russell K. Hall and Associates, Inc. Midland, Texas 432-683-6622
