HORIZONTAL PUMPING SYSTEM

 What is HPS?

HPS classification, Pumps, Stages, Impellers, Curves/Performance, Components

 Why use HPS?

Delivery/Cost/Modular, Radial Loads, Comparison vs. Traditional Pumps

 What are common HPS Applications/Installation?

Produced Water/Injection, Lean Amine, Crude Oil, NGL, Liquid CO2, etc.

Horizontal Pumping System

Horizontal Pumping System

• Horizontal Multistage Centrifugal Diffuser Pump
• Consisting of the following components…

What is HPS?

* * * * * *

HPS classification

HPS classification vs. API

Horizontal Foot‐mounted OH1 Flex Coupling Centerline‐mounted OH2 Vertical in‐line OH3 w/ Bearing Bracket Overhung Rigid Coupling Vertical in‐line OH4 Close Coupled Vertical in‐line OH5 High Speed Gear OH6 Multistage Radially Split Centerline‐mounted HPS Double‐casing Centrifugal 1 and 2 Stage Axially Split BB1 Pump Between‐ Radially Split BB2 Bearings Axially Split BB3 Multistage Radially Split Single‐casing BB4 Double‐casing BB5 Discharge Diffuser VS1 through Volute VS2 Vertically Single‐casing column Axial‐flow VS3 Suspended Separate Line‐shaft VS4 Discharge Cantilever VS5 Double‐casing Diffuser VS6 Volute VS7

Pumps

• The HPS unit is a multistage diffuser pump; containing a selected number

(application dependent) of impellers equipped with vanes, inside a closely fitted diffuser, located in series an axial shaft, driven by the electrical motor.

• Radial / Francis / Mix-Flow Impeller Types
• Casing is radial split.

Stages

• Each "stage" consists of

an impeller and a diffuser. Again, the impeller takes the fluid and imparts kinetic energy to it. The diffuser converts this kinetic energy into potential energy (head).

Operation

• Fluid enters through the intake,

into the lower diffuser.

• Impeller moves the fluid along

the opening vane to the diffuser.

• Diffuser directs the fluid direction

up and changes the kinetic force into potential force or pressure.

• Number of stage determine head

developed, and also determines the horsepower requirement.

Radial Flow Stage

• Discharges fluid at a 90° angle

away from the rotation of the shaft

• Higher head per stage compared to

mixed flow pumps

• Smaller vein clearance
• Used for lower volume pumps

Mixed Flow Stage

• Discharges fluid at a about 45° angle

away from the rotation of the shaft

• Lower head per stage compared to

radial flow pumps

• Large vein clearance
• Used for high volume pumps

Impellers

• Radial flow

(Pancake), usually for small range production capacity

• Mixed flow , usually

for high production pump

Pancake Francis Mixed flow

Impeller & Curves

Typical Performane, Efficency & Thrust Curve

Pumps come in two basic varieties:

• “Floater" construction - each impeller is free to move side to

side on the shaft as it wants to so it is said to "float" on the shaft.

• “Compression" construction - every impeller is fixed to the

shaft rigidly so that it cannot move without the shaft moving. All the impellers are "compressed" together to make one rigid rotating assembly.

Pumps

Stage Types

Thrust Chamber & Intake

Modular Design Minimal Moving Parts Largest Thrust Bearings 7315 Oil Flood Lubrication 2 bearing = 4000# thrust 3 bearing = 6000# thrust 4 bearing = 12000# thrust Standard 316 S/S or Carbon Steel Construction Standard ANSI B16.5 Class Flange Ratings

• 150/300/600/900/1500/2500 lb

Suction Flange Locations Rotates

Mechanical Seals & Flush Plans

Only one sealing area on low pressure suction side Various sealing options available up to 2800 psi Single Spring Component Seal API 682 Single Cartridge Seal API 682 Dual Cartridge Seal API Environmental Controls – Flush Plan Non-Contacting Gas Seals Split Mechanical Seals

Thrust Chamber Intake Pump

Or…

Skids, Saddles, Motor, Coupling, Guard & Instrumentation

3 Skid Models Double-beam, Single-beam, & Channel …for Front/Back Pullout & LowPro I-Beam Welded Fabricated Construction Power Coated Finish Mechanical Switches or Transmitters… Cast iron saddles Laser aligned to TC axis Easily adjustable Close mounting/support; 48” Powder coated finish Electric motor, engine, etc. Full range of HPs 2, 4, 8 Pole speeds Low & medium voltage ODP, WPII, TEFC, EX-Proof, etc. API Motor Coupling & Non-Spark Guard

 Intake pressure (min., norm., & max)  Discharge pressure (min., norm., & max)  Flow & pressure requirements (“ “)  Fluid properties (SG, Viscosity, Vapor Pressure, Temp)  Material of Construction  Seal Type & Flush Plans  Site Conditions & Classifications  Expansion flexibility (future flow & psi)  Motor controls (direct, soft start & psi)  Instrumentation requirements (psi, temp., & vibration)  Electrical available and motor enclosure

HPS Considerations

 Quick Delivery - 8 to 12 Weeks  Low Capital Cost  Extended Run Life Increased Reliability & MTBF Low Maintenance  High Quality Standards  Modular Design Easy replacement & minimal “down-time” Easy to Re-rate in the future Minimal Spare Parts Inventory  Environmentally Friendly  Low Life Cycle Cost

Why use HPS?

 Reduced Radial Shaft Loads

Diffuser Style Advantage

Radial Loads

(-) Delivery (-) Capital Cost (-) Repair Cost (-) Repair Time (-) Two Mechanical Seals (-) Re-rate Flexibility (=) Reliability (=) Vibration, Noise (=) Pump Efficiency (+) Base Footprint

API Split-case

(-) Frequent Maintenance (-) Vibration & Pulsation (-) Delivery (-) Leakage at Packing (-) Repair Time / Cost (-) Re-rate Flexibility (+) Pump Efficiency (+) Pressure Variation (+) Base Footprint

Positive Displacement Plunger

Comparison

• Petroleum:
• Produced Water Injection (Disposal, Waterflood, Pressure Maintenance)
• Power Fluid Pump (for downhole Jet/Hydraulic pump)
• Liquid CO2 for Transfer or Injection
• Crude Oil Transfer
• Boiler Feed for steam generators - SAGD
• Industrial & Mining:
• Boiler Feed Water
• High Pressure Wash Down
• Descaling
• Effluent Disposal
• High Pressure Transfer
• De-Watering

What are HPS Applications/Installation?

Direct Coupled Low Pro Up to 200 HP Patented Pending

Low Thrust Low Cost Simple Design Direct Drive

Single Beam Model Up to 300 HP

Double Beam Model Up to 2000 HP

Back Pullout Thrust Chamber API Flush Plan

Back Pullout TC 2 units 1 skid

Belt Drive

Crude Oil Transfer – Texas, USA

Water flood – Alberta, Canada

75,000 BPD Disposal – Texas, USA

53’ Trailer Mounted – Rocky Mountains, USA

Boiler Feed Pumps SAGD – Canada

Produced Water Disposal – Texas, USA

Crude Oil Transfer Pumps - Russia

DNV Certified – North Sea

Produced Water Disposal – Texas, USA

1250hp Power Fluid Pumps – Alaska, USA

600hp Natural Gas Engine – USA

Enclosed Mounted Disposal - Manitoba

70,000 BPD Salt Cavern Gas Storage - USA
