High speed CMOS image sensors

Wim Wuyts – Sr. Staff Applications Engineer Cypress Semiconductor Corporation Belgium Vision 2006

slide-2
SLIDE 2

2

High speed CMOS image sensors – Vision 2006

Outline

  • Introduction
  • Architecture
  • Analog high speed CIS
  • Digital high speed CIS
  • 6T snapshot pixel type
  • Applications
  • Holographic data storage
  • Line sensors
  • Standard high speed products: LUPA-family
  • Conclusion
slide-3
SLIDE 3

3

High speed CMOS image sensors – Vision 2006

Why? Why high speed? High speed motion/data analysis for various application fields e.g. military ballistics

slide-4
SLIDE 4

4

High speed CMOS image sensors – Vision 2006

  • Cypress has huge experience in high-speed CMOS

Image Sensor (CIS) design

  • (almost) All big players works with us
  • Current max. pixel throughput of 13.2 Gpixels/s
  • Typical with multiple parallel analog output tabs
  • Now high-speed ADCs, LVDS output and on-chip

timing sequencer available

  • Both array and linear sensors
  • Typical applications: high-speed motion analysis

(crash and impact test), holographic data storage, digital film slow motion capture

Introduction

slide-5
SLIDE 5

5

High speed CMOS image sensors – Vision 2006

Introduction

  • What’s high speed?
  • Typically > 100 MPixels/s
  • Requirements for high speed sensor

design:

  • High speed read out architecture

(> 50 MPixels / internal tab)

  • High sensitive snapshot shutter pixel with low

Parasitic Light Sensitivity (PLS)

  • High speed ADCs
  • High speed interface (LVDS)
slide-6
SLIDE 6

6

High speed CMOS image sensors – Vision 2006

Technology: architecture

  • High-speed read out architecture:

60+ MPixels/s / internal analog tab

  • Parallel analog outputs e.g. 128*60 Mhz =

7.68 Gpixels/s throughput @ output

  • Windowing (ROI) to boost frame rate (both

in X and Y e.g. 100*100 @ 768k fps)

  • Two trends:
  • Analog ‘naked’ image sensor: no sequencing
  • r digital logic on-chip

=> requires complex camera system

  • System-on-a-chip approach (as much

integration as possible): on-chip ADC, sequencer, interface

slide-7
SLIDE 7

7

High speed CMOS image sensors – Vision 2006

Technology: architecture

Typical analog high speed image sensor:

  • 6T-pixel core (e.g. 1024 * 1024

divided in multiple sections

  • pixel drivers and column

buffers

  • parallel analog output tabs

(128+)

  • no timing sequencer on-chip

(full external control on pixel array and read out timing).

e.g. custom high-speed CIS architecture

slide-8
SLIDE 8

8

High speed CMOS image sensors – Vision 2006

Technology: architecture

Typical system-on-a-chip high speed image sensor:

  • Timing sequencer on-

board

  • Multiple ADCs on-chip
  • Single clock input
  • Multiple parallel digital

LVDS outputs

  • Different read-out

schemes possible to fit different needs

e.g. LUPA-1300-2 architecture

slide-9
SLIDE 9

9

High speed CMOS image sensors – Vision 2006

Technology: 3T pixel

PD GND T1 T2 T3

Ipd Vpd Cpd Vout

VDD row select column output reset

PD node reset time

Volts Sample & Read Out

Classic 3T-pixel with rolling shutter

slide-10
SLIDE 10

10

High speed CMOS image sensors – Vision 2006

Technology: Pixel type: 6T

T1 T2 T3 T4 T5 T6 Vpix Vpix Vmem Row-select Sample Precharge Reset

Vpd Vpd Vpd - Vt

A B High speed applications requires: snapshot shutter, high sensitivity, low PLS => solution: 6T-pixel architecture

slide-11
SLIDE 11

11

High speed CMOS image sensors – Vision 2006

Rolling vs. snapshot

Snapshot shutter Rolling shutter Distorted motion Freezed motion

Electronic snapshot shutter required for high-speed motion analysis

slide-12
SLIDE 12

12

High speed CMOS image sensors – Vision 2006

Snapshot shutter

Reset frame In parallel x y Integrate and Sample frame In parallel Burst readout sequential

Time axis Line number Integration time Burst Readout time COMMON RESET COMMON SAMPLE&HOLD Flash could occur here

slide-13
SLIDE 13

13

High speed CMOS image sensors – Vision 2006

Snapshot shutter

True Snapshot Shutter: Pipelined and Triggered type

Integration frame I+1 Integration frame I+2 Readout frame I Readout frame I+1

Pipelined mode (6T-pixel): Triggered mode (IBIS5 alike pixel):

Integration frame I Integration frame I+1 Readout frame I Readout frame I+1

slide-14
SLIDE 14

14

High speed CMOS image sensors – Vision 2006

Frame rate calculation (fps)

The frame rate depends on:

  • 1. Pixel throughput in MPixels/s
  • 2. Frame Overhead Time (FOT) typical 10us
  • 3. Row Overhead Time (ROT) typical 300ns
  • 4. Window size in X and Y

→ Frame period calculation:

Frame period = FOT + Nr. Lines * (ROT + Nr. Pixels * clock period)

Example: LUPA-300 (VGA resolution at 80MPixels/s)

Frame period = 7.8 µs + (480 * (400 ns + 12.5 ns * 640) = 4.039 ms

=> 247.6 fps.

Frame rate increases with reduced window size in X and Y

slide-15
SLIDE 15

15

High speed CMOS image sensors – Vision 2006

Packaged high speed CIS

Analog high speed CIS Digital high speed CIS

slide-16
SLIDE 16

16

High speed CMOS image sensors – Vision 2006

Applications

  • Examples of high speed applications:
  • Motion analysis:
  • Military ballistics and impact
  • Crash tests analysis
  • Sport analysis
  • Machine vision – inspection
  • Slow motion digital movie capture
  • Holographic mass data storage
slide-17
SLIDE 17

17

High speed CMOS image sensors – Vision 2006

High speed motion analysis:

Example of applications

Crash test analysis:

slide-18
SLIDE 18

18

High speed CMOS image sensors – Vision 2006

FEATURES

  • Ultrahigh storage densities:
  • Optical interference technique with coherent laser beams
  • Data storage in 3 dimensions!
  • Storage density > 31.5 Gbits/in2 => 200 GB on DVD disk)
  • Parallel access to data using data matrix and matrix

reader instead of conventional photo diode

  • Fast data transfers upto 1 Gbps (high speed data read
  • ut with CMOS image sensor)
  • Durable, reliable, low cost media (polymer media)
  • Possible due to technology breakthrough on: SLM,

CMOS image sensor technology, storage media

Application focus: Holographic data storage

slide-19
SLIDE 19

19

High speed CMOS image sensors – Vision 2006

RECORDING DATA

  • A single laser beam is split into two: the

signal beam that carries the data and a reference beam

  • The data is encoded on the signal beam

with a Spatial Light Modulator (SLM)

  • Data is stored as a hologram that is

recorded onto a light-sensitive storage medium at the point where the signal and reference beam intersect

  • Angle of incidence reference beam sets

depth of writing

Application focus: Holographic data storage

slide-20
SLIDE 20

20

High speed CMOS image sensors – Vision 2006

Application focus: Holographic data storage

Writing data

slide-21
SLIDE 21

21

High speed CMOS image sensors – Vision 2006

READING DATA

  • A laser with the properties as the reference

beam is trained on the media

  • By changing the angle of incidence a new

page is read out

  • The laser projects the entire hologram, or

page, onto a detector, a high speed CMOS image sensor

  • Spinning disk is scanned similar to CD

principle

Application focus: Holographic data storage

slide-22
SLIDE 22

22

High speed CMOS image sensors – Vision 2006

Application focus: Holographic data storage

High speed CMOS image sensor Reading data Read out system

slide-23
SLIDE 23

23

High speed CMOS image sensors – Vision 2006

Application focus: Holographic data storage

Custom high-speed sensor for holographic read out

  • Resolution: 1696 X * 1710 Y
  • Pixel size: 8 um * 8 um
  • Shutter type: Snapshot (6T-pixel)
  • Pixel rate: 13.2 GHz (using 32 LVDS outputs)
  • Frame rate: 485 fps
  • 10-bit on-chip ADC
  • Sensitivity: 650 V.m2 / W.s
  • Power dissipation: 1100 mWatt
slide-24
SLIDE 24

24

High speed CMOS image sensors – Vision 2006

Application focus (2): high-speed linear sensor

Key features on linear high-speed CISs:

  • High speed pixel read out (> 200 MHz, with multiple
  • utputs)
  • Very high spatial resolution
  • Large area imaging area (possible with stitching)
  • Linear pixel array with high sensitivity
  • Low power consumption
  • High on-chip integration of digital logic (lower system

cost)

  • Typical applications: bar-code readers, dimensions

measuring, position inspection devices

slide-25
SLIDE 25

25

High speed CMOS image sensors – Vision 2006

Custom high-speed linear sensor project:

  • Resolution: 8200 * 1 line sensor
  • Pixel size: 7 um * 7 um
  • Image area length: 57,4 mm
  • Chip size: 58.5 * 3.5 mm2
  • Snapshot shutter
  • Line rate: 28.5k / s
  • Data rate: 240 MHz
  • 10-bit ADC on-chip
  • Sensitivity: 21 V.cm2/uJ

CMOS IS

Application focus (2): high-speed linear sensor

slide-26
SLIDE 26

26

High speed CMOS image sensors – Vision 2006

Standard high speed sensors

3T 3T 6T 6T 6T 4T 3T 3T 3T Pixel type 11 fps 29 fps 15 fps 442 fps 247 fps 27 fps 3 fps 5 fps 7 fps 24 fps Frame rate 1” 15 um Rolling 1 MP STAR-1000 1” 25 um Rolling 250k STAR-250 F-mount 12 um Snapshot 4 MP LUPA-4000 1” 14 um Snapshot 1.3 MP LUPA-1300 1/2” 9.9 um Snapshot VGA LUPA-300 2/3” 6.7 um Rolling Snapshot 1.3 MP IBIS5-B-1300 F-mount 8 um Rolling 13.85 MP IBIS4-14000 1” 3.5 um Rolling 6.6 MP IBIS4-A-6600 2/3” 7 um Rolling 1.3 MP IBIS4-1300 Optical format Pixel pitch Shutter type Resolution Name

slide-27
SLIDE 27

27

High speed CMOS image sensors – Vision 2006

LUPA family sensors

LUPA-4000 – Traffic monitoring and surveillance LUPA-300 – Fast machine vision applications

slide-28
SLIDE 28

28

High speed CMOS image sensors – Vision 2006

LUPA-1300-2

  • Current LUPA-1300 has 16 parallel analog
  • utput tabs + no on-chip ADCs

=> difficult and expensive system design

  • Custom developed high speed technology

= state-of-the-art (13.2 GPixels/s)

  • New LUPA-1300-2 standard product:
  • Use of state-of-the-art high speed IP
  • High sensitive, high efficient snapshot shutter pixel
  • ADCs on chip for easy integration
  • High-speed LVDS interface
slide-29
SLIDE 29

29

High speed CMOS image sensors – Vision 2006

LUPA-1300-2

  • Samples expected Q2 2007
  • Product brief available
  • Specs:
  • Resolution: 1.3 MP: 1280 X *1024 Y
  • 14 um pixel: pipelined snapshot shutter (6T-

architecture)

  • 310 MHz master clock => > 500 fps @ 1.3MP
  • Frame rate increase with ROI read out (in X and Y)
  • 10-bit ADC on-chip
  • 12 LVDS output taps @ 480 Msps
  • < 700 mWatt (ADC power on) @ 500 fps
  • 150 pin PGA
  • Mono and color
slide-30
SLIDE 30

30

High speed CMOS image sensors – Vision 2006

LUPA-1300-2

1/3000 – 99.97% 1/500 - 99.8% PLS - Shutter efficiency < 700 mWatt 900 mWatt Power 14 * 14 um2 14 * 14 um2 Pixel size 1280 * 1024 1280 * 1024 Resolution Multi slope + NDR Multi slope + NDR

  • Ext. dynamic range

12 10-bit LVDS tabs 16 analog outputs Output 10-bit No ADC on-board ADC 0-500+ fps 0-450 fps Frame rate 64.6 dB 60.7dB S/N ratio

LUPA-1300-2 LUPA-1300

slide-31
SLIDE 31

31

High speed CMOS image sensors – Vision 2006

Conclusion

  • Very high speed imaging still necessary

with increasing speeds and resolutions

  • High speed imaging with on-board features

for easier implementation

  • Generic high speed image sensors for

wide variety of applications

  • New challenges on combining a very high

data rate image with a lot of on-board features like LVDS and image processing

slide-32
SLIDE 32

32

High speed CMOS image sensors – Vision 2006

  • Thank you for your attention
  • Questions?
