SLIDE 1
Safety First
10,700 Man hours worked to date
- No lost time accidents to date
- No recordable accidents to date
Harrisburg Overpass Construction Update September 1, 2015 Safety - - PowerPoint PPT Presentation
Harrisburg Overpass Construction Update September 1, 2015 Safety - - PowerPoint PPT Presentation
Harrisburg Overpass Construction Update September 1, 2015 Safety First 10,700 Man hours worked to date No lost time accidents to date No recordable accidents to date West Bound Phase I Traffic Control Traffic Plan Phase 1A East Bound
SLIDE 2
SLIDE 3
West Bound Phase I Traffic Control
SLIDE 4
Traffic Plan Phase 1A
SLIDE 5
Safety First
East Bound Phase I Traffic Control
SLIDE 6
Safety First
SLIDE 7
School began August 24th LOOK OUT FOR THE KIDS!
Speed limit 20 MPH
SLIDE 8
Traffic Control
- Traffic moved to middle of Harrisburg
(1 lane each way)
- Access from Harrisburg:
- Side streets maintain access
- Some weekend and night intersection
closures for utility work
- Advanced coordination with property
- wners for new driveway construction
Phase 1 – May
ay 20 2015 15 to
- November
r 20 2015 15
Construction Activities
- New waterlines, storm sewers,
sanitary sewers
- New private driveways, curbs
- New sidewalks
- New landscape
- New roadways
Union Pacific
NE SE SW NW
SLIDE 9
Union Pacific
NE SE SW NW
Job Limit Job Limit
Project Phase 1
Water Line: 900 LF Storm Line: 1100 LF
- San. Line: 0 LF
Water Line: 900 LF Storm Line: 750 LF
- San. Line: 130
Water Line: 950 LF Storm Line: 1200 LF
- San. Line: 0 LF
Water Line: 950 LF Storm Line: 700 LF
- San. Line: 370 LF
SLIDE 10
West Side Phase 1 Work
SW Quadrant + NW Quadrant
Unexpected/Unknown Underground encounters so far: 31
SLIDE 11
Gas Lines Unexpected Water Line Barziza St. & Harrisburg Blvd. Caylor St. & Harrisburg Blvd.
SLIDE 12
North West Quadrant
Dorsey Dental
Lot and House Field Office Vacant Lot
Abandoned Strip Mall Linwood St. Caylor St. Storm Sewer Water Line
Warehouse Demolition
Vacant Lot Ware- House
Bent 1 Union Pacific Bent 2 Bent 3 Bent 4 Bent 5 Bent 6
Existing Lines Total Installed % Completed 1100 LF 900 LF 0 LF 0 LF 0% 0%
SLIDE 13
South West Quadrant
Linwood St. Caylor St.
Key Station #93
Houston Armature
C&R Auto Sales Gameroom Warehouse Union Pacific
Linwood St. Storm Sewer Water Line Existing Lines Total 1200 LF 950 LF
Bent 1 Bent 2 Bent 3 Bent 4 Bent 5 Bent 6
Installed % Completed 850 LF 950 LF 71% 100% (Service Taps Remaining)
SLIDE 14
East Side Phase 1 Work
NE Quadrant + SE Quadrant
Unexpected/Unknown Underground encounters so far: 59
SLIDE 15
In front of Value Village In front of Tornado Bus Working under existing power lines
SLIDE 16
North East Quadrant
Hendrick Grain Co. Storage Yard
Value Village 65th ST. 66th ST.
9
Cesar Chavez Blvd.
Popeye’s, Gas Station, Washateria
Tornado Bus Co. Vacant Lot
8 10 7 6 5
Sanitary Line
Union Pacific
65th ST. 66th ST. Hughes ST. Cesar Chavez Blvd. Storm Sewer Water Line Existing Lines Total Installed % Completed 750 LF 900 LF 130 LF 550 LF 900 LF 110 LF 73 % 100 % (Service Taps Remaining) 85 %
SLIDE 17
South East Quadrant
65th ST. 66th ST. Cesar Chavez Blvd.
Jorge’s Car and Truck #2
Vacant Lot
Texas Belting
Pegasso Bus Tours
Marbella Banquet Hall
Chonchino Auto Sales Guanajuato Barber Shop #2 Taqueria Tierra Caliente
Family Dollar Store
10 9 8 7 6 5 Union Pacific
Cesar Chavez Blvd. 65th ST. 66th ST. Sanitary Line Storm Sewer Water Line Existing Lines Total Installed % Completed 750 LF 900 LF 240 LF 0 LF 30 LF 0 LF 0 % 1 % 0%
SLIDE 18
Paving Phase 1 West Side
Fast Track Paving for Intersections Phase 1 Access Roads Sidewalks Asphalt
SLIDE 19
Paving Phase 1 East Side
Fast Track Paving for Intersections Phase 1 Access Roads Sidewalks Asphalt
SLIDE 20
MSE Wall Mock-Up
SLIDE 21
Thank you
See you in November
