SLIDE 1
H263O110C106N16P1
http://www.smithsonianmag.com/
H 375 O 132 C 88 N 6 Ca 1 P 1 H 263 O 110 C 106 N 16 P 1 - - PowerPoint PPT Presentation
H 375 O 132 C 88 N 6 Ca 1 P 1 H 263 O 110 C 106 N 16 P 1 - - PowerPoint PPT Presentation
H 375 O 132 C 88 N 6 Ca 1 P 1 H 263 O 110 C 106 N 16 P 1 http://www.smithsonianmag.com/ H 263 O 110 C 106 N 16 P 1 H 375 O 132 C 88 N 6 Ca 1 P 1 N Fixation? Biological Nitrogen Fixation Evolved 3.5 billion years ago Converts N 2 into NH 3
SLIDE 2
SLIDE 3
H375O132C88N6Ca1P1 H263O110C106N16P1
SLIDE 4
SLIDE 5
N Fixation?
SLIDE 6
Evolved ≈3.5 billion years ago Converts N2 into NH3 Energetically expensive (16ATP for 1 N) Poisoned by oxygen
Biological Nitrogen Fixation
SLIDE 7
Photosynthesis requires nitrogen
C55H72O5N4Mg
SLIDE 8
Oxygenic photosynthesis and N fixation evolve in an anoxic world, but are so important that they remain basically unchanged for 3 billion years.
SLIDE 9
Today photosynthesis and
- ther key processes are
limited by nitrogen
SLIDE 10
Nitrogen Cycle Basics
Transformations mediated by microbes (auto and heterotrophic) Inputs via fixation + deposition Outputs via leaching and gas losses (denitrification) + Mineral forms used by plants (NO3
- and NH4
+) + little DON
Losses of nitrate discriminate against 15N, leaving it behind. The N cycle, like life, is a redox driven process.
SLIDE 11
The N Cycle is Driven by Redox
SLIDE 12
Ecosystem Mass Balance
IF Inputs > Outputs THEN N pools grow Losses grow
SLIDE 13
Ecosystem Mass Balance
IF Inputs > Outputs THEN N pools grow Losses grow IF Outputs > Inputs THEN N pools shrink Losses shrink
SLIDE 14
Ecosystem Mass Balance
IF Inputs > Outputs THEN N pools grow Losses grow IF Outputs > Inputs THEN N pools shrink Losses shrink IF N availability > demand THEN Available N losses high
SLIDE 15
Ecosystem Mass Balance
IF Inputs > Outputs THEN N pools grow Losses grow IF Outputs > Inputs THEN N pools shrink Losses shrink IF N availability > demand THEN Available N losses high IF N availability < demand THEN Available N losses low
SLIDE 16
Ecosystem Mass Balance
IF Inputs > Outputs THEN N pools grow Losses grow IF Outputs > Inputs THEN N pools shrink Losses shrink IF N availability > demand THEN Available N losses high IF N availability < demand THEN Available N losses low
SLIDE 17
Global patterns in the N cycle
SLIDE 18
Fixation highest in tropics
Cleveland et al., 1999
SLIDE 19
NUE lower in tropics
Vitousek 1982
SLIDE 20
Brookshire et al 2012
NO3
- losses higher in tropics
SLIDE 21
Craine et al., 2015
Soil δ15N higher in tropics
MAT (°C) MAP (mm/yr)
- 10 0 10 20 30
100 1,000 10,000
SLIDE 22
Houlton and Bai 2009
Soil δ15N higher in tropics
SLIDE 23
When, where and why does N matter in intact tropical ecosystems?
SLIDE 24
“The tropics” are not one place!!!
Townsend et al 2008
SLIDE 25
LeBauer and Tresider, 2008
Fertilization suggests N matters, but there aren’t enough data to suggest when, where or why.
SLIDE 26
Inputs: Fixation, Deposition Outputs: Gas losses, leaching Internal cycling: mineralization, nitrification, immobilization, DNRA, FEAMMOX… Controls of tropical N availability
SLIDE 27
Inputs: Fixation, Deposition Outputs: Gas losses, leaching Internal cycling: mineralization, immobilization… Controls of tropical N availability
SLIDE 28
Hedin 2009
More fixers in the tropics
SLIDE 29
Sullivan et al, 2014
But are they fixing?
SLIDE 30
Sullivan et al, 2014
But are they fixing?
Predicted from legume abundance Predicted from nodule sampling
SLIDE 31
2 4 6 8 10 11 24 40 Mature (>80 years)
Nitrogen Fixation In Bahia, Brazil (kg N/ha/yr)
But are they fixing?
Winbourne unpubl.
Forest Age (years)
SLIDE 32
y = 21.061x + 1097.2 R² = 0.9622
20000 40000 60000 80000 100000 120000 140000 1000 2000 3000 4000 5000 6000
ngN fixed Nodule Biomass in a Plot (mg)
Counting legumes doesn’t work. Counting nodules does
SLIDE 33
Sullivan et al, 2014
Our understanding of N inputs is poor
SLIDE 34
Inputs: Fixation, Deposition Outputs: Gas losses, leaching Internal cycling: mineralization, immobilization… Controls of tropical N availability
SLIDE 35
Outputs: Gas losses
Highly variable in space and time, hard to measure Highly variable in space and time, “easy”to measure Impossible to measure in the field
SLIDE 36
Zhuang et al. 2012
Tropical N gas losses: high but poorly constrained, based on N2O
SLIDE 37
N2 losses: Theory
Pilegaard 2013, from Davidson 2000
SLIDE 38
“Direct” measurement of N2 emissions
N2 N2O
Slide from M. Almaraz
SLIDE 39
N2 losses: Data From Puerto Rico
Almaraz unpubl.
SLIDE 40
N2 losses ≠ N2O losses
Almaraz unpubl.
SLIDE 41
Our understanding of N outputs is poor
Almaraz unpubl.
SLIDE 42
Inputs: Fixation, Deposition Outputs: Gas losses, leaching Internal cycling: mineralization, nitrification, immobilization… Controls of tropical N availability
SLIDE 43
“The tropics” are not one place!!!
Townsend et al 2008
SLIDE 44
N availability
Time Climate Parent material Topograph y Organisms
Heterogeneity is challenging
SLIDE 45
N availability
Time Climate Parent material Topography Organisms
Heterogeneity is challenging
SLIDE 46
How do topography, rainfall, and foliar N influence N availability?
SLIDE 47
The Osa Peninsula, Costa Rica
SLIDE 48
Hyperspectral-derived canopy N Lidar derived topography
Digital Elevation Models Foliar Nitrogen Maps
SLIDE 49
Topography Climate
SLIDE 50
Variation in topography, climate.
Drake Bay Piro North Piro South
SLIDE 51
Piro South Piro North Drake Bay
Topography
Broad, flat ridge Narrow ridge Narrow ridge
SLIDE 52
Piro South Piro North Drake Bay Broad, flat ridge Narrow ridge Narrow ridge
Topography
SLIDE 53
Piro South Piro North Drake Bay
Climate
SLIDE 54
Drake Bay
MAP ~3000 mm MAP ~6000 mm
Piro South Piro North
Climate
SLIDE 55
Sample collection & analyses
Piro South Piro North Drake Bay Top Shoulder Middle Bottom
- 3 regions x 4 catenas x 4 transects x 2 seasons
SLIDE 56
N metrics measured
Piro South Piro North Drake Bay
NO3
- -N and NH4
+-N
Net nitrification Net N mineralization δ15N Instantaneous 5 days 100s – 1000s of years
SLIDE 57
Piro South Piro North Drake Bay
Topography (δ15N o/oo)
Top Shoulder Middle Bottom 1 2 3 4 5 6 7
xcoord δ a b b b
δ15N was elevated on broad, flat ridges.
Top Shoulder Middle Bottom
xcoord δ b b b b
Osborne et al, in revision
SLIDE 58
Top Shoulder Middle Bottom
xcoord δ
Top Shoulder Middle Bottom 1 2 3 4 5 6 7
xcoord δ
Climate (δ15N o/oo)
Drake Bay
MAP ~3000 mm MAP ~6000 mm
Piro South Piro North
δ15N was elevated under drier conditions.
mean = 4.34* mean = 3.46
prob > F 0.0363*
Osborne et al, in revision
SLIDE 59
Piro South Piro North Drake Bay
Topography and climate summary
NO3
- -N and NH4
+-N
Climate effect Topography effect
✔
✗
✔
✗ ✗ ✗
δ15N NO3
- -N and NH4
+-N
Osborne et al, in revision
SLIDE 60
Organisms Climate Topography
SLIDE 61
Organisms
Low N High N
Osborne et al, in revision
SLIDE 62
Osborne et al, in revision
Organisms
SLIDE 63
scale here
Osborne et al, in revision
Organisms
SLIDE 64
High Foliar N Low Foliar N
1 2 3 4 5 6 7
NO3-N (mg kg-1)
1 2 3 4 5 6 7
NH4-N (mg kg-1)
1 2 3 4 5 6 7
Net Nitrification (mg kg-1 d-1)
Net Nitrification (mg kg-1 d-1)
1 2 3 4 5 6 7
Net Mineralization mg kg-1 d-1
Osborne et al, in revision
Organisms – link to soil N
SLIDE 65
Airborne mapping may help deal with heterogeneity at large scales
Osborne et al, in revision
SLIDE 66
The role of trees in driving the N cycling may be more important than we know.
Asner et al., 2014
SLIDE 67
“The tropics” are not one place!!!
Osborne et al, in revision
SLIDE 68
